2ANYH-BT0C4True Wireless Earphones

CHARGING PORT TRANSMISSION DISTANCE MUSIC TIME CHARGING TIME CALL TIME FUNCTION INPUTN BATTERY STANDBY TIME 10m 4~5h 1~2h 4~5h micro USB Siri awakening, phone call, music DC3.7V lit hium battery 280mAh (charging case) DC3.7V lit hium battery 40mAh (earphones) DC5V500mA 90h 4国语言说明书80X100MM WIRELESS EARPHONES ÉCOUTEURS SANS FIL PRODUCT MANUAL 使用說明書 PLEASE READ THI S MANUAL CAR EFULLY BEFO RE USING THE PROD UCT AND KEEP IT IN A SAFE PLACE. MiniSounds系列 旋蓋TWS藍牙耳機 使用產品前請仔細閱讀本使用說明書，並請妥善保管。 MODEL: M1 4.耳 機功能 /操作介 紹 3.充 電 （1）為充電盒充電： 將充電線與相匹配的直流電源適配器連接后，將另一端插入充電盒的充電口中，即可為 充電盒充電。 （2）為耳機充電： 將耳機放入充電倉，確保耳機充電接觸點與充 電盒內部頂針接觸到位，即可為耳機充電。 充電時，耳機LED指示燈常亮紅燈，耳機充滿電 后LED指示燈熄滅。 充電時，耳機將自動關機。 功能 開機 關機 操作 把耳機從充電盒中取出，或長按MFB按鍵2秒（任意左右耳機） 將耳機放回充電倉中，或長按MFB按鍵3秒（任意左右耳機） 配對打開藍牙找到并點擊設備的名字“MINISO-M1” 手機斷開藍牙 單擊耳機多功能鍵（任意左右耳機） 雙擊耳機多功能鍵（任意左右耳機） 短按左耳機多功能鍵3下，轉到下一首歌； 短按右耳機多功能鍵3下，轉到上一首歌 藍牙斷開 切換歌曲 播放/ 暫停音樂 回撥最近 一個通話 單耳模式從充電盒中取出單個耳機，與手機配對後，即為單耳模式。 雙耳模式 從充電盒中取出兩個耳機，與手機配對后即為立體聲雙耳模式。 或在單耳模式使用時，將另一個耳機也取出，自動配對后即可 組成立體聲雙耳模式。 長按任一MFB按鍵1秒後，喚醒SIRI SIRI喚醒 當有來電時，單擊耳機多功能鍵連接來電（任意左右耳機） 接聽來電 當有來電時，長按多功能鍵1秒拒接來電（任意左右耳機）拒接來電 低電量提示 耳機電壓低於3.2V時將自動關閉 重要安全提示 產品和配件 產品參數 1.使用本產品前請詳細閱讀此說明書，請妥善保管以供日後參考。 2.請勿長時間使用，以免影響聽力。 3.請勿在駕駛時使用。 4.請勿使用過大音量播放音樂。 5.請遵守當地法律法規使用本產品。 6.請保持產品乾燥。 7.本產品內含可充電電池，請勿自行拆卸、改裝、替換，請勿暴曬，請勿靠近火源。 8、正確處置產品該標誌表示產品在歐盟地區不能和其他家用廢物一起處置。為了防止 廢物管理沒有管控而導致可能的對環境和人體健康的傷害，有責任回收產品確保物質 資源可持續再利用。為了回收使用過的器具，請使用回收系統或聯繫經銷商，以便產品 回收符合環保要求。 ①多功能按鍵（MFB） ②LED指示燈④充电指示灯 ⑤USB充電口③耳機充電接觸點 ⑥充電線 藍牙版本 靈敏度 頻響範圍 藍牙配對名 V5.120Hz~20kHz 95±3dBMINISO-M1 ① ② ⑤ ⑥ ③ ④ 2.配 对 使用指引 NCC警告 1.佩 戴耳機 充電插口 傳輸距離 音樂時間 充电時間 通話時間 功能 充電輸入 電池 待機時間 10m 4~5h 1~2h 4~5h micro USB Siri喚醒，通話功能， 支持音樂 DC3.7V鋰電池 280mAh（充電盒） DC3.7V鋰電池 40mAh（耳機） DC5V, 500mA 90h BT Discoverable DEVICES BT ON MINISO-M1 將耳機從充電倉內取出，按照內側L/R標識佩戴在耳朵上。 取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、 加大功率或變更原設計之特性及功能。低功率射頻器材之使用不得影響飛航安全及干 擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前述 合法通信，指依電信管理法規定作業之無線電通信。低功率射頻器材須忍受合法通信或 工業、科學及醫療用電波輻射性電機設備之干擾。 耳機從充電倉內取出後，耳機進入配對模式，此時耳機LED指示燈將紅藍燈交替閃爍。 開啟手機BT功能，搜索MINISO M1並點擊連接，完成配對后LED指示燈將閃爍藍燈。 低電量 充電中 充滿電 PRODUCT AND ACCESSORIES ① Multifunctional button (MFB) ② LED indicator light ④ Charging indicator light ⑤ USB charging port ③ Earphones’ charging contact point ⑥ Charging cable 1. Wearing Earphones BT Disconnect from the phone Click on MFB（of any one of the earphones） Double clic k on MFB（of any one of the earphones） Press MFB of the left earphone for 3 secs to the next, press MFB of the right earphone for 3 secs to the previous Disconnect Next/Previous song Play/Pause Redial Both ears mode Take out both earphones from the charging case. Stereo both ears mode is on after pairing with the phone. Or take the other earphone out when using single ear mode to enter stereo both ears mode after auto pairing. Press any MFB for 1 sec to awaken Siri Siri awakening When there is incoming call, clic k on MFB to receive call (at any one of the earphones) Receiving call When there is incoming call, press MFB (at any one of the earphones) for 1 secs to reject call. Rejecting call Low power prompt Earphones will automatically turn off when the voltage is lower than 3.2V. ① ② ⑤ ⑥ ③ ④ BT Discoverable DEVICES BT ON MINISO-M1 Take out the earphones from the charging compartment and wear them on your ears according to the L/R mark printed inside. 2. Pairing After being taken out of the charging compartment, the earphones will be paired while the LED indicator will flash red and blue alt ernatively. Init iat e BT function on your mobile phone and search Miniso M1 to connect it, after which the LED indicator will flash blue. 4. Functions/Operation of Earphones 3. Charging （1）Charging charging compartment: After connecting the charging cable with the compatible DC adapter, plug the other end of the charging cable into the charging port to charge. （2）Charging earphones: Put the earphones into the charging compartment, making sure that the ear- phones’ charging contact point are in touch with the thimble inside the charging case to charge the earphones. LED indicator light will stay on red when charging and turn off after charging. Earphones will automatically power off when charging. Function Turn on Turn off Operation Take out the earphones from the charging case or long press MFB for 2 secs (at any one of the earphones) Put the earphones back to the charging compartment or press MFB for 3 secs (at any one of the earphones) Pairing Turn on BT and click “MINISO-M1” to connect Single ear mode Take out an earphone from the charging case. Single ear mode is on after pairing with the phone. Low battery Charging Fully charged IMPORTANT SAFETY NOTES 1. Before using this product, read this manual carefully and keep it properly for future reference. 2. Do not use this product for a prolonged time to avoid affecting hearing. 3. Do not use this product when driving. 4. Do not play music at an extra large voice. 5. Please use this product according to the local laws and regulations. 6. Please keep it dry. 7. Containing rechargeable battery, this product cannot be dismantled, alt ered or replaced by yourself. Do not expose it to sunlight or fire sources. 8.This mark indicates the product should not be disposed of in the same way as other household wastes in EU regions. The product should be recycled to ensure sustainable reuse of resources and to prevent potential harm for the environment and human health caused by non-control of waste management. To rec ycle the used appliance, apply the recycling system or contact the franchiser to recycle the product according to the environmental protection requirements. SPECIFICATIONS USAGE INSTRUCTIONS FCC Warning: This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority…

Text truncated - open the document above for the full version.

Shenzhen Muke Technology Co.,Ltd Model Confirmation Letter We, (Shenzhen Muke Technology Co.,Ltd) certify the product: Model No.: BT-0C4, MINISO-M1 Their electrical circuit design, layout, components used and internal wiring are identical, Only the model number and market is different. Signiture: Grantee Contact: Liyong Xiao Company Name: Shenzhen Muke Technology Co.,Ltd Date:2020-12-21
