2ANYT-SSPM001AAWireless condition monitoring sensor

From Geir Svoen Business area Energy Industries Phone direct +4722872858 Fax direct E-mail [email protected] Cc Reference Page 1/1 Date 2020-01-28 FCC & ISED cover letter Headquarter ABB AS Bergerveien 12, NO-1396 Billingstad PO Box 94, NO-1375 Billingstad Norway Phone +47 22 87 20 00 Telefax +47 22 87 46 38 Branch office Energy Industries Ole Deviks Vei 10, NO-0666 Oslo PO Box 6359 Etterstad, NO-0603 Oslo Norway Phone +47 22 87 20 00 Telefax +47 22 87 23 27 Organization number NO982 085 160MVA www.abb.no To whom it might concern “ABB Ability TM Smart Sensor xyzw” is a new family of wireless condition monitoring sensors from ABB. It consists externally of a rugged plastic enclosure, internally basically of a processor and communication module, a sensor module and a battery for powering the sensor over its lifetime. It is not possible to open the sensor to exchange the battery etc. Over time, various variants will be launched with different internal transducers and different batteries & sizes. The sensor will be equipped with two variants of the “Processor and communication module”: PM001 Processor module, Bluetooth PM002 Processor module, WirelessHART The modules are identical, except that PM002 is equipped with a transceiver chip that supports WirelessHART, while the Bluetooth is used for local communication and configuration only. Initiall two versions of the Smart Sensor will be released, one equipped with PM001, the other with PM002, targeting different solutions for system integration. To reduce future maintenance cost and enable that the same processor modules can be used for all future variants of the sensor, ABB hereby applies for limited modular approval. Yours sincerely, ABB AS Geir Svoen

FromGeir Svoen Business areaEnergy Industries Phone direct+4722872858 Fax direct [email protected] Cc Reference Page1/6 Date2020-04-20 FCC "Limited Module Approval" letter Headquarter ABB AS Bergerveien 12, NO-1396 Billingstad PO Box 94, NO-1375 Billingstad Norway Phone +47 22 87 20 00 Telefax +47 22 87 46 38 Branch office Energy Industries Ole Deviks Vei 10, NO-0666 Oslo PO Box 6359 Etterstad, NO-0603 Oslo Norway Phone +47 22 87 20 00 Telefax +47 22 87 23 27 Organization number NO982 085 160MVA www.abb.no “ABB Ability TM Smart Sensor xyzw” is a new family of wireless condition monitoring sensors from ABB. It consists externally of a rugged plastic enclosure, internally basically of a processor and communication module, a sensor module and a battery for powering the sensor over its lifetime. It is not possible to open the sensor to exchange the battery etc. Over time, various variants will be launched with different internal transducers and different batteries & sizes. The sensor will be equipped with two variants of the “Processor and communication module”: PM001 Processor module, Bluetooth PM002 Processor module, WirelessHART The modules are identical, except that PM002 is equipped with a transceiver chip that supports WirelessHART, while the Bluetooth is used for local communication and configuration only. Initially two versions of the Smart Sensor will be released, one equipped with PM001, the other with PM002, targeting different solutions for system integration. The PM001 and PM002 complies with all requirements stated in FCC part 15.212 (a) except (i) concerning separate shielding of transmitter, thereby application for LMA as described under FCC part 15.212 (b). Test reports show that all applicable part 15 requirements are fulfilled: Compliance to FCC part 15.212 rules, as listed in KDB 996369 D01 clause III a): 1.The radio elements must have the radio frequency circuitry shielded: No comply, There is no shield mounted on the PM001/PM002 radio circuitry. Thorough design with multilayer PCB, and careful tracing of transmitter power and radio signals ensure that FCC requirements anyway are fulfilled. This is verified with tests and reports done by NEMKO Norway. 2.The module must have buffered modulation/data inputs: Comply, the PM001/PM002 are using standard circuits and firmware provided by Nordic Semiconductor (nRF52840) for Bluetooth and Analog for WirelessHART (LTC5800WHM for WirelessHART) which ensure that messages is transmitted according to constraints given by the protocol specification and FCC rules. 3. The module must contain power supply regulation on the module: Comply. PM001 / PM002 has integral DC/DC converter powered by an internal Lithium Thionyl chloride battery (3.6V). Date2020-04-20 Page2/6 SubjectFCC "Limited Module Approval" letter 4. The module must contain a permanently attached antenna: Comply. The antenna’s are soldered to the PM001/ PM002 PBA and is not possible change or access. 5. The module must demonstrate compliance in a stand-alone configuration: Comply. Demonstrated by tests performed by NEMKO AS, Norway. 6. The module must be labeled with its permanently affixed FCC ID label: Comply. FCC ID is laserwritten to the surface of the PM001 / PM002 PBA surface 7. The module must comply with all specific rules applicable to the transmitter: Comply: Demonstrated by tests performed by NEMKO AS, Norway. 8. The module must comply with RF exposure requirements Comply: Design with max transmit power less than 10mW and omnidirectional antennas secure that RF exposure requirements are fulfilled. This is verified by tests executed and reported by NEMKO AS Norway. Since the PM001 / PM002 does not comply with point 1 in list above, we hereby apply for Limit Module Approval for PM001 and PM002. Yours sincerely, ABB AS Geir Svoen Attachments: Compliance list INTEGRATION INSTRUCTIONS for 996369 D03 OEM the and 996369 D03 OEM by Sections 2.2 through 2.10 Date2020-04-20 Page3/6 SubjectFCC "Limited Module Approval" letter Compliance list INTEGRATION INSTRUCTIONS for 996369 D03 OEM the and 996369 D03 OEM by Sections 2.2 through 2.10. RequirementYes No Comment 2.2 List of applicable FCC rules List the FCC rules that are applicable to the modular transmitter. These are the rules that specifically establish the bands of operation, the power, spurious emissions, and operating fundamental frequencies. DO NOT list compliance to unintentional-radiator rules (Part 15 Subpart B) since that is not a condition of a module grant that is extended to a host manufacturer. See also Section 2.10 below concerning the need to notify host manufacturers that further testing is required.3 X From “PART 15—RADIO FREQUENCY DEVICES”: §15.247Operation within the bands 902–928 MHz, 2400–2483.5 MHz, and 5725–5850 MHz 2.3 Summarize the specific operational use conditions Describe use conditions that are applicable to the modular transmitter, including for example any limits on antennas, etc. For example, if point-to-point antennas are used that require reduction in power or compensation for cable loss, then this information must be in the instructions. If the use condition limitations extend to professional users, then instructions must state that this information also extends to the host manufacturer’s instruction manual. In addition, certain information may also be needed, such as peak gain per frequency band and minimum gain, specifically for master devices in 5 GHz DFS bands. X The PM001 module is restricted to be installed in ABB AbilityTM Smart Sensor enclosures as described in the installation manual. Integration shall be done so that battery cables is below the PBA except the soldering point. 2.4 Limited module procedures If a modular transmitter is approved as a “limited module,” then the module manufacturer is responsible for approving the host environment that the limited module is used with. The manufacturer of a limited module must describe, both in the filing and in the installa…

Text truncated - open the document above for the full version.

Equipment Autorisation DivisionFromGeir Svoen Federal Communications CommissionBusiness areaEnergy Industries 7435 Oakland MillsRoadPhone direct+4722872858 Columbia, MD 21046Fax direct [email protected] Cc FCC ID: 2ANYT- SSPM001AAReference Product Name: PM001 Processor Module BluetoothPage1/1 Date2020-04-20 Request for Confidentiality Headquarter ABB AS Bergerveien 12, NO-1396 Billingstad PO Box 94, NO-1375 Billingstad Norway Phone +47 22 87 20 00 Telefax +47 22 87 46 38 Branch office Energy Industries Ole Deviks Vei 10, NO-0666 Oslo PO Box 6359 Etterstad, NO-0603 Oslo Norway Phone +47 22 87 20 00 Telefax +47 22 87 23 27 Organization number NO982 085 160MVA www.abb.no Pursuant to Sections 0.457 and 0.459 of the commission’s rules, we hereby request that the following documents be held confidential: · 3BNP102777D040_PM001 and PM002 Operational description · 3BNP102777D044_PM001 and PM002 Block Diagram · 3BNP102777D045_PM001 and PM002 Installation Manual · 3BNP102828D016_en_Processor_module_PM001__PM002_circuit_diagram · 4JNO000024R001_en_PM001_Processor_Module_Bluetooth_Partlist These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. Document “3BNP102777D045_PM001 and PM002 Installation manual” would reveal ABB IP to competitors if made public. As the PM001 is for ABB internal use only, we also request confidentiality for this document. Dated this20th Day of April 20 20 By: Geir Svoen SignaturePrinted Title:Product Manager On behalf of :Antti Laakso, ABB Oy Telephone:+47 90983206

Copyright 2020 ABB. All rights reserved. Based on Document kind General Prepared Title 2020-04-15 Geir Svoen FCC / ISED: PM001 External photos Approved Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 B en 1/4 File: 3BNP102777D042_External photos PM001.docx; Saved Date: 2020-04-15 11:26; Template: TECHNICAL DOCUMENT STANDARD, PORTRAIT.DOTX, 3AJG000402-0245, C Industrial Automation, Energy Industries FCC / ISED: PM001 External photos We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. © Copyright 2020 ABB. INTERNAL The information contained in this document has to be kept internal. Any unauthorized use, reproduction, distribution or disclosure to third parties is strictly forbidden. ABB reserves all rights regarding Intellectual Property Rights. Title Document kind FCC / ISED: PM001 External photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 B en 2/4 1. Internal photos Figure 1 PM001 Processor module Bluetooth contained in “Smart Sensor BCHC. Tranceiver for WirelessHART is not mounted. Location and text for ISED / FCC is indicated with drawing. In production the label will be laser written into the surface of the module. Figure 2 Backside of bareboard for PM001 which is without components (contact footprints is for debug ports for nRF52840 and LTC5800WH, to support firmware development) PM001 IC: 23282-SSPM001AA FCC: 2ANYT-SSPM001AA Title Document kind FCC / ISED: PM001 External photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 B en 3/4 2. Marking of product Figure 3 FCC and IC marking of product, laser written into the surface of the PCB PM001 IC: 23282-SSPM001AA FCC: 2ANYT-SSPM001AA Title Document kind FCC / ISED: PM001 External photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 B en 4/4 REVISION Rev. ind. Page (P) Chapt. C Description Date Dept./Init. A New document 2020.02.12 IAEN / GS B Changed document name to “PM001 External photos” 2020.04.15 IAEN/GS

External Photos: PM001 Host Device

Copyright 2020 ABB. All rights reserved. Based on Document kind General Prepared Title 2020-02-21 Geir Svoen FCC / ISED: PM001 Label drawing Approved Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D046 A en 1/3 File: 3BNP102777D046_PM001 Label drawing.docx; Saved Date: 2020-02-21 15:53; Template: TECHNICAL DOCUMENT STANDARD, PORTRAIT.DOTX, 3AJG000402-0245, C Industrial Automation, Energy Industries FCC / ISED: PM001 Label drawing We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. © Copyright 2020 ABB. INTERNAL The information contained in this document has to be kept internal. Any unauthorized use, reproduction, distribution or disclosure to third parties is strictly forbidden. ABB reserves all rights regarding Intellectual Property Rights. Title Document kind FCC / ISED: PM001 Label drawing General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D046 A en 2/3 1. Marking of product Figure 1 FCC and IC marking of product, laser written into the surface of the PCB PM001 IC: 23282-SSPM001AA FCC: 2ANYT-SSPM001AA Title Document kind FCC / ISED: PM001 Label drawing General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D046 A en 3/3 REVISION Rev. ind. Page (P) Chapt. C Description Date Dept./Init. A New document 2020.02.21 IAEN / GS

Ó Copyright 2020 ABB. All rights reserved. TitlePrepared Host Label drawing PM001 2020-06-12 Geir Svoen Approved Resp(division/department)Documentt Id.Rev.Lang.Page 3BNP102777D051A en 1/2 File: 3BNP102777D051_en_Host Label Drawing PM001.docx; 25 Saved Date: 2020-06-12 09:10; Template: TECHNICAL DOCUMENT DELIVERY, LANDSCAPE.DOTX, 3AJG000402-0249, A Ex certification label:Fonttype: ABB Voice,size 4 pt, Atex mark (` )5pt Manufacturing information:Fonttype: ABB Voice,size 4 pt For Bluetooth sensors (without W irelessHART, the W H MAC shall be omitted) Smart Sensor xCHC Article No: 4JNO000026R00x ABB AS 0666 Oslo Norway Ole Deviks vei 10 Serial number: C2xxxxxxxx BT MAC: 50:31:AD:XX:XX:XX WH MAC: 001B1E1A9AXXXXXX YYYY.MM QR Code: Version and redundancy level: 5L https://productid.abb.com/4JNO000026R00x ?sn=C2xxxxxxxx&mac=5031ADXXXXXX&whm ac=001B1E1A9AXXXXXX Size13*13mm Axis crossfor definition of the Radial, axial or tangential directions. To be left aligned with ABB Logo and top aligned with QR code. Size 9mm ABB Logo: Height 6mm (17-18pt) ABB Product name: Font type: ABB Voice, size 7pt Dividing line height 6mm (same as ABB logo) Rightmost point to touch guiding line Document is part of Ex certified product Guiding lines: Guiding lines 3mm from the edge of the flat area. Smart Sensor xxxC variants(long life housing) Product type FeaturesArticle number IC / FCC ID MAC Blueto oth MAC WirelessHART BCHCHigh performance, long life, Bluetooth host communication 4JNO000026R004 23283- SSPM001AA 2ANYT-SSPM001AA X Note: General:AlpsAlpine will do the number / mac accounting based on definitions in this document Serial number: C2“xxxxxxxx” (8 digits) is incrementally counted in hex. For prototypes and proof of concept deliveries, the number is extended with two more digits. Mac addr.BT: “XXXXXX” is incrementally counted in hex, for all versions of Smart Sensor Mac addr.WH:“XXXXXX” is incrementally counted in hex for WirelessHART versions of Smart Sensor. Omitted for other variants Product type:x is “B” for Bluetooth, H for WirelessHART variants Article no:x is 3 for WirelessHART, 4 for Bluetooth variant Label printing instruction The Axis cross, the ABB logo and the product family name on the top of the box shall be printed directly on the plastic in a separate process. The text on the sides of the sensor and the QR code on the top shall be written/ burned directly into the plastic using a laser printer made for the purpose, so that serial number and MAC addresses are incremented for each sensor. `I M1 Ex ia I Ma ` II 1 G Ex ia IIC T4 Ga ` II 1 D Ex ia IIIC T157°C Da -40°C≤T amb ≤+85°C PRESAFE 19 ATEX 14930X IECEx PRE 19.044X LR1608-1 WARNING – POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE INSTRUCTIONS AVERTISSEMENT - RISQUE DE CHARGE ÉLECTROSTATIQUE -VOIR LES INSTRUCTIONS Cl I, Zn 0, AEx ia I Ma Cl I, Zn 0, AEx ia IIC T4 Ga Zn 20 , AEx ia IIIC T157°C Da Cl I, Div 1, Gr A, B, C and D T4 Cl II, Div 1, Gr E, F and G T4 Cl III, Div 1 Radio and market access labels: Font type: ABB Voice, size 4 pt C0470 Contained FCC ID:2ANYT-SSPM001AA IC:23283-SSPM001AA

Ó Copyright 2020 ABB. All rights reserved. TitlePrepared Smart sensor xxxC Label drawing 2020-05-05 Geir Svoen Approved Resp(division/department)Documentt Id.Rev.Lang.Page 4JNO000026D007Ed2 en 1/2 File: 4JNO000026D007_en Smart sensor xxxC Label drawing_rev Ed2.docx; 25 Saved Date: 2020-05-07 14:35; Template: TECHNICAL DOCUMENT DELIVERY, LANDSCAPE.DOTX, 3AJG000402-0249, A Manufacturing information:Fonttype: ABB Voice,size 4 pt Smart Sensor xCHC Article No: 4JNO000026R00x ABB AS 0666 Oslo Norway Ole Deviks vei 10 MAC addr WirelessHART: 001B1E1A9AXXXXXX MAC addr Bluetooth: 50:31:AD:XX:XX:XX Serial number:C2xxxxxxxx YYYY.MM QR Code: Redundancy level: Medium https://productid.abb.com/4JNO000026R00x ?sn=C2xxxxxxxx&mac=5031ADXXXXXX&whm ac=001B1E1A9AXXXXXX Size14*14mm Axis crossfor definition of the Radial, axial or tangential directions. To be left aligned with ABB Logo and top aligned with QR code. Size 9mm ABB Logo: Height 6mm (17-18pt) ABB Product name: Font type: ABB Voice, size 7pt Dividing line height 6mm (same as ABB logo) Rightmost point to touch guiding line Document is part of Ex certified product Guiding lines: Guiding lines 3mm from the edge of the flat area. Smart Sensor xxxC variants(long life housing) Product type FeaturesArticle number IC / FCC ID MAC Bluetooth MAC WirelessHART BCHCHigh performance, long life, Bluetooth host communication 4JNO000026R004 23283- SSPM001AA 2ANYT- SSPM001AA X HCHCHigh performance, long life, WirelessHART host comm. 4JNO000026R003 23283- SSPM002AA 2ANYT- SSPM002AA XX Note: General:AlpsAlpine will do the number / mac accounting based on definitions in this document Serial number: C2“xxxxxxxx” (8 digits) is incrementally counted in hex. For prototypes and proof of concept deliveries, the number is extended with two more digits. Mac addr.BT: “XXXXXX” is incrementally counted in hex, for all versions of Smart Sensor Mac addr.WH:“XXXXXX” is incrementally counted in hex for WirelessHART versions of Smart Sensor. Omitted for other variants Product type:x is “B” for Bluetooth, H for WirelessHART variants Article no:x is 3 for WirelessHART, 4 for Bluetooth variant Label printing instruction The Axis cross, the ABB logo and the product family name on the top of the box shall be printed directly on the plastic in a separate process. The text on the sides of the sensor and the QR code on the top shall be written/ burned directly into the plastic using a laser printer made for the purpose, so that serial number and MAC addresses are incremented for each sensor. Ex certification label:Fonttype: ABB Voice,size 4 pt ` `I M1 Ex ia I Ma-40°C≤T amb ≤+85°C ` II 1 G Ex ia IIC T4 Ga -40°C≤T amb ≤+85°C ` II 1 D Ex ia IIIC T157°C Da -40°C≤T amb ≤+85°C PRESAFE 19 ATEX 14930X IECEx PRE 19.044X WARNING – POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE INSTRUCTIONS AVERTISSEMENT - RISQUE DE CHARGE ÉLECTROSTATIQUE - VOIR LES INSTRUCTIONS Class 1 Zone 0, AEx ia I Ma, -40°C ≤ Tamb ≤ +85°CClass 1 Division 1, Group A B C and D T4 Class 1 Zone 0, AEx ia IIC T4 Ga , -40°C ≤ Tamb ≤ +85°C Class II, Division 1 Group E F and G T4 Zone 20 , AEx ia IIIC T157°C Da, , -40°C ≤ Tamb ≤ +85°C Class III, Division 1 Radio and market access labels: Font type: ABB Voice, size 4 pt C0470 Contained FCC ID:2ANYT-SSPM001AA IC no:23283-SSPM001AA TitleResp(division/department)Document id.Rev.Lang.Page Smart sensor xxxC Label drawing 4JNO000026D007Ed2 en2/2 REVISION Rev.ind. Page (P) Chapt. (C) DescriptionDate Dept./Name. Ad1New document2019.09.19 IAEN/Geir Svoen Ad2P1 QR code definition updated to reflect new ABB standard. Drawing reference to article number and type made generic (replace specific number or type with “x”) 2019.11.18 IAEN/Geir Svoen Ad3P1QPS certification removed for first release. “Contains FCC/IC” numbers added, also column under variants. Serial number changed to 9 digits plus manufacturer code (C kept for Alps) 2019.12.09 IAEN/Geir Svoen A Changed to status approved 2019.12.10 IAEN/Geir Svoen BP1Update of Ex part according to 4JNO000026D006 rev C. QR code updated. Note with description of accounting of serial number and MAC addresses 2019.12.25 IAEN/Geir Svoen Cd1P1Removed type name from QR code.2020.01.30 IAEN/Geir Svoen CP1Adjusted QR code so that all characters are visible, and made dynamic characters red.. Added temperature range for mining in Ex part of label 2020.02.05 IAEN/Geir Svoen DP1FCC and IC registration numbers removed as registration is non completed before first production batch. Size of QR code increased to 14*14mm 2020.03.12 IAEN/Geir Svoen Ed1P1FCC and IC codes for US&Canada added QPS code for Ex certification for USA and Canada added Redundancy level M (15%) specified for QR code 2020.04.30 IAEN/Geir Svoen Ed2P1Swapped radio certification marks with Ex to give more space for Ex Added detailed certification marks for USA Canada according to instructions from Presafe 2020.05.05 IAEN/Geir Svoen

Copyright 2020 ABB. All rights reserved. Based on Document kind General Prepared Title 2020-02-12 Geir Svoen FCC / ISED: PM001 Internal photos Approved Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 A en 1/4 File: 3BNP102777D042_Internal photos PM001.docx; Saved Date: 2020-02-12 14:39; Template: TECHNICAL DOCUMENT STANDARD, PORTRAIT.DOTX, 3AJG000402-0245, C Industrial Automation, Energy Industries FCC / ISED: PM001 Internal photos We reserve all rights in this document and in the information contained therein. Reproduction, use or disclosure to third parties without express authority is strictly forbidden. © Copyright 2020 ABB. INTERNAL The information contained in this document has to be kept internal. Any unauthorized use, reproduction, distribution or disclosure to third parties is strictly forbidden. ABB reserves all rights regarding Intellectual Property Rights. Title Document kind FCC / ISED: PM001 Internal photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 A en 2/4 1. Internal photos Figure 1 PM001 Processor module Bluetooth contained in “Smart Sensor BCHC. Tranceiver for WirelessHART is not mounted. Location and text for ISED / FCC is indicated with drawing. In production the label will be laser written into the surface of the module. Figure 2 Backside of bareboard for PM001 which is without components (contact footprints is for debug ports for nRF52840 and LTC5800WH, to support firmware development) PM001 IC: 23282-SSPM001AA FCC: 2ANYT-SSPM001AA Title Document kind FCC / ISED: PM001 Internal photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 A en 3/4 2. Marking of product Figure 3 FCC and IC marking of product, laser written into the surface of the PCB PM001 IC: 23282-SSPM001AA FCC: 2ANYT-SSPM001AA Title Document kind FCC / ISED: PM001 Internal photos General Resp. (division/department) Document id. Rev. Lang. Page Energy Industries 3BNP102777D042 A en 4/4 REVISION Rev. ind. Page (P) Chapt. C Description Date Dept./Init. A New document 2020.02.12 IAEN / GS

FCC ID: 2ANYT-SSPM001AA MPE Calculation for FCC Uncontrolled Environment Formula from page 18 of OET Bulletin 65, Edition 97-01 where:S = power density P = power input to the antenna G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna Source Based Time Averaged Duty Cycle is 100% in calculation below Maximum peak output power at antenna input terminal:3.70(dBm) Maximum peak output power at antenna input terminal:0.002(W) Maximum antenna gain:3.00(dBi) Maximum antenna gain:1.995(numeric) Prediction distance:20(cm) Prediction frequency:2440(MHz) Time Averaged Duty Cycle100% MPE limit for uncontrolled exposure at prediction frequency:10.00(W/m^2) Power density at prediction frequency:0.0009(mW/cm^2) Power density at prediction frequency:0.009(W/m^2) Maximum allowable antenna gain:33.31(dBi) Margin of Compliance:30.31(dB) 2 4R PG S p =

Report No. 376453-04-R00 Template version: C Nemko Norway Nemko AS, Instituttveien 6, P.O. Box 96 Kjeller, 2027 Kjeller, Norway TEL +47 22 96 03 30 FAX +47 22 96 05 50 EMAIL [email protected] ENTERPRISE NUMBER NO974404532 nemko.com/no Test Report Product Wireless Sensor with Bluetooth Low Energy Processor Module Name and address of the applicant ABB AS Ole Deviks vei 10 NO-0666 Oslo, NORWAY Name and address of the manufacturer ABB AS Ole Deviks vei 10 NO-0666 Oslo, NORWAY Model PM001 Rating 3.7V DC (Primary Battery, Lithium) Trademark ABB Ability Smart Sensor Serial number 4JN0 23R3 G424 Additional information Bluetooth LE 5.0 Tested according to FCC Part 15.247 Digital Transmission Systems Industry Canada RSS-247, Issue 2 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Devices Order number 376453 Tested in period 2019-11-22 to 2019-11-26 Issue date 2020-01-16 Name and address of the testing laboratory Instituttveien 6 Kjeller, Norway www.nemko.com CAB Number: FCC: NO0001 ISED: NO0470 TEL: +47 22 96 03 30 FAX: +47 22 96 05 50 An accredited technical test executed under the Norwegian accreditation scheme Prepared by [Frode Sveinsen] Approved by [G.Suhanthakumar] This report shall not be reproduced except in full without the written approval of Nemko. Opinions and interpretations expressed within this report are not part of the current accreditation. This report was originally distributed electronically with digital signatures. For more information contact Nemko. TEST REPORT FCC Part 15.247 Report no.: 376453-04-R00 FCC ID: 2ANYT-SSPM001AA Nemko Norway, Instituttveien 6, Kjeller, Norway Page 2 (67) CONTENTS 1 INFORMATION ......................................................................................................................... 3 1.1 Test Item .................................................................................................................................... 3 1.2 Normal test condition ................................................................................................................. 4 1.3 Test Engineer(s) ........................................................................................................................ 4 1.4 Description of modification for Modification Filing ...................................................................... 4 1.5 Family List Rational ................................................................................................................... 4 1.6 Antenna Requirement ................................................................................................................ 4 1.7 Worst-Case Configuration and Mode ......................................................................................... 4 1.8 Comments ................................................................................................................................. 4 2 TEST REPORT SUMMARY ...................................................................................................... 5 2.1 General ...................................................................................................................................... 5 2.2 Test Summary ........................................................................................................................... 6 3 TEST RESULTS ........................................................................................................................ 7 3.1 Occupied Bandwidth (99% BW)................................................................................................. 7 3.2 DTS Bandwidth (6dB BW) ....................................................................................................... 11 3.3 Peak Power Output .................................................................................................................. 15 3.4 Conducted Emissions at Antenna Connector .......................................................................... 22 3.5 Restricted Bands of operation.................................................................................................. 32 3.6 Radiated Emissions, Band Edge ............................................................................................. 33 3.7 Radiated Emission, 30 – 1000 MHz. ........................................................................................ 36 3.8 Radiated Emissions, 1-26 GHz ................................................................................................ 39 3.9 Power Spectral Density (PSD) ................................................................................................. 61 4 Measurement Uncertainty ..................................................................................................... 65 5 LIST OF TEST EQUIPMENT................................................................................................... 66 6 BLOCK DIAGRAM .................................................................................................................. 67 6.1 Power Line Conducted Emission ............................................................................................. 67 6.2 Test Site Radiated Emission .................................................................................................... 67 TEST REPORT FCC Part 15.247 Report no.: 376453-04-R00 FCC ID: 2ANYT-SSPM001AA Nemko Norway, Instituttveien 6, Kjeller, Norway Page 3 (67) 1 INFORMATION 1.1 Test Item Name ABB Ability Smart Sensor FCC ID 2ANYT-SSPM001AA ISED ID 23238-SSPM001AA Model/version PM001 Serial number 4JN0 23R3 G424 Hardware identity and/or version A Software identity and/or version 5.0-4 (Version used …

Text truncated - open the document above for the full version.
