2AO2J-C53WWVBTraceable GIANT-DIGITS Radio Atomic Clock with Remote sensor

BUTTON OPERATION Standard Mode Initiate RCC receiving Press and hold 3s Enter into time and date setting Time Setting Mode Confirm setting Press and hold 3s Increase rapidly Decrease rapidly C53: 240x210mm 1089 2025 91-1089-00 120925 ABOUT THIS INSTRUCTION MANUAL These operating instructions are to be considered a component of the device. Please read the safety instructions and the operating instructions carefully before use. Keep these instructions for renewed use at a later date. When the device is sold or given to someone else, the instruction manual must be provided to the new owner/ user of the product. The device is intended only for indoor use. GENERAL WARNINGS • Risk of electric shock — This device contains electronic components. Only use the device as described in the manual; otherwise, you run the risk of an electric shock. • Choking hazard — Children should only use the device under adult supervision. Keep packaging material, like plastic bags and rubber bands, out of the reach of children, as these materials pose a choking hazard. • Risk of chemical burn — Keep batteries out of the reach of children! Make sure you insert the batteries correctly. Leaking battery acid can lead to chemical burns. Avoid contact of battery acid with skin, eyes and mucous membranes. In the event of contact, rinse the affected region immediately with a plenty of water and seek medical attention. • Risk of fire/explosion — Do not expose the device to high temperatures. Use only the recommended batteries. Do not short-circuit the device or batteries, or throw them into a fire. Excessive heat or improper handling could trigger a short-circuit, a fire or an explosion. • Do not disassemble the device. In the event of a defect, please contact your dealer. The dealer will contact the Service Centre and can send the device in to be repaired, if necessary. • Use only the recommended batteries. Always replace weak or empty batteries with a new, complete set of batteries at full capacity. Do not use batteries from different brands or with different capacities. The batteries should be removed from the unit if it has not been used for a long time. OVERVIEW MAIN UNIT: 1.– Press and hold to enter time and date setting mode. 2. - While in setting mode, press to increase one unit, press and hold to increase rapidly. 3. - While in setting mode, press to decrease one unit, press and hold to decrease rapidly. While in normal display mode, press once to initiate RCC receiving or press and hold to stop RCC receiving. 4. - Press to toggle between outdoor sensor channel 1-3. Press and hold to initiate outdoor sensor search. 5. Reset – Use a ball pen to press to reset all setting. 6. Wall Mount hole. 7. Battery compartment. 8. Table stand MAIN UNIT LCD DISPLAY 1.Weather forecast 2. Time Display 3. Weekday display and Time Zone indicator 4. Date display 5. Indoor Temperature display 6. Outdoor Temperature display Symbol Description RCC signal received Daylight Saving Time ON Low battery indicator Ice alert indicator [IN] Indoor indicator [OUT] Outdoor channel indicator [ZONE] Time zone indicator Displayed US time zone OUTDOOR SENSOR 1.Outdoor temperature display 2. / switch 3. TX (Initiate paring with main unit). 4. Channel switch. 5. Wall Mount hole GETTING STARTED INSERT BATTERIES 1.Remove the battery door from the back 2. Insert 2 pieces LR6 (AA)/ 1.5V batteries. Please make sure with correct polarity (+/-) of the batteries. 3.Reattach the battery door. NOTE: Replace batteries when displays, or when the display is dim. OUTDOOR SENSOR 1.The main unit can receive data from up to 3 outdoor sensors. 1 Sensor is included with delivery. 2. Remove the battery door from the back. 3. Insert 2x AAA (LR03)/1.5V batteries. Please ensure the polarities (+/-) of the batteries match upon installation. 4. Select a channel, then press TX. 5. Reattach the battery door. 6. Place the sensor within 30 m (98 ft) of the main unit using the table stand or wall mount. CLOCK CLOCK RECEPTION 1.When you insert or replace the batteries, RCC reception is initiated. To manually start RCC reception press the [ ] button. 2. The receiving process duration is 7 minutes. 3. During receiving process, the RCC signal symbol [ ] flashes. 4. If the RCC receiving process is successful, a completed RCC symbol [ ] will be shown in the display and the date and time will be set automatically. If it fails within 7 minutes, RCC setting will quit automatically. If that happens, press the [ ] button to re-initiate RCC receiving. 5. RCC receiving will automatically start at 1:03, 2:03, 3:03, 4:03, 5:03 every night. Auto receiving function will cease if it is successful. 6. To stop RCC reception, press and hold the [ ] button. 7. If the device is still not receiving the signal, please proceed to set the time manually. NOTE: -The RCC Clock receives WWVB signals as RCC signal. -It is necessary to manually set the time zone in order to display correct time. TIME ZONE SETTING To set a different time zone, proceed as follows: 1.Press and hold [ ] button to enter time and date setting. 2. Press [ ] button or [ ] button to select the Time zone from E, P, M, C. 3. Press [ ] button to confirm Time Zone setting 4. Continue to proceed manual clock setting as below if you want to set the clock manually or press [ ] several times to bypass the manual setting and let the clock to set automatically by receiving RCC signal. NOTE: E = EST; P = PST; M = MST; C = CST SET THE CLOCK MANUALLY 1.Press and hold [ ] button to enter into time and date setting. 2. Sequence of setting: Time Zone Year (2000 – 2099) Date format Month Date Week Day Language 12/24 Hr Hour Minute / DST on/off exit 3. During setting, the setting parameter will flash. 4. Press [ ] button to confirm setting and enter to next parameter 5. Press [ ] button once, the figure will increase 1 unit. Press and hold the [+] button, the figures will increase rapidly. 6. Press [ ] button once, the figure will decrease 1 unit. Press and…

Text truncated - open the document above for the full version.

CONTROL3, LLC Applicant as U.S. Agent Letter of Attestation Date: June 10, 2026 To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Ref: Attestation Statement – Part 2.911(d)(7) filing FCC ID: 2AO2J-C53WWVB CONTROL3, LLC (“the applicant”) as required by section 2.911(d)(7), will also serve as the agent for service of process for the above referenced FCC ID. The applicant acknowledges that they will maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. The applicant further acknowledges their responsibility to inform the FCC whenever the agent information changes. Designated U.S. Agent from Applicant Company Company Name: CONTROL3, LLC Contact Person: Bin Xu FRN: 0027216506 Address: 12554 Galveston Rd, Suite B230 Webster Texas United States 77598 Tel.: 2814821714-352 Email: [email protected] Sincerely yours, Signature Printed Name: Bin Xu Title: 2814821714-352 Email: [email protected]

Rev 1/26/2023 CONTROL3, LLC Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-05-19 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing FCC ID: 2AO2J-C53WWVB (“CONTROL3, LLC”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. (“CONTROL3, LLC”) certifies that the equipment for which authorization is sought does not include cybersecurity or anti-virus software produced or provided by Kaspersky Lab, Inc. or any of its successors and assignees, including equipment with integrated Kaspersky Lab, Inc. (or any of its successors and assignees) cybersecurity or anti-virus software pursuant to DA-24-886 and KDB 986446 D01 Covered Equipment Guidance section B(2a). Device is inherently compliant based on hardware limitations or software controls. or 口 A Software Bill of Materials (SBOM) is provided to the TCB for review, and 口 The end-user or third parties cannot install additional software on this device. Sincerely, (Applicant signature): (Applicant printed name):Bin Xu CONTROL3, LLC Rev 1/26/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-05-19 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing FCC ID: 2AO2J-C53WWVB (“CONTROL3, LLC”) certifies that, as of the date of the filing of the application, Shenzhen Moni Technology Co., LTD is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Sincerely, (Applicant signature): (Applicant printed name):Bin Xu

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 CONTROL3, LLC Date：2026-05-21 Product Model Number: C53 WWVB with remote FCC ID: 2AO2J-C53WWVB To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that QAI Laboratories Ltd. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by QAI Laboratories Ltd. on our behalf shall have the same effect as acts of our own. Signature: By: Bin Xu Contact Listed on FCC Wesbite Title:TECHNICAL MANAGER Email: [email protected] On behalf of: CONTROL3, LLC

CONTROL3,LLC Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2026-05-19 Subject; Request for Confidentiality FCC ID:2AO2J-C53WWVB To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram 口 Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); 口 External Photos 口 Test Setup Photos 口 Internal Photos □ User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Bin Xu Title:T E C H N I C A L M A N A G E R

Page 1 of 5 Report No.: LGT25H033 Appendix - External Photographs of EUT Constructional Details Photo 1 Photo 2 Page 2 of 5 Report No.: LGT25H033 Appendix - External Photographs of EUT Constructional Details Photo 3 Photo 4 Page 3 of 5 Report No.: LGT25H033 Appendix - External Photographs of EUT Constructional Details Photo 5 Photo 6 Page 4 of 5 Report No.: LGT25H033 Appendix - External Photographs of EUT Constructional Details Photo 7 Photo 8 Page 5 of 5 Report No.: LGT25H033 Appendix - External Photographs of EUT Constructional Details Photo 9

Label FCC ID: 2AO2J-C53WWVB

Page 1 of 2 Report No.: LGT25H033 Appendix - Internal Photographs of EUT Constructional Details Photo 1 Photo 2 ANT Page 2 of 2 Report No.: LGT25H033 Appendix - Internal Photographs of EUT Constructional Details Photo 3 Photo 4

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Page 1 of 8 RF TEST REPORT Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Model Number: C53 WWVB with remote FCC ID: 2AO2J-C53WWVB Issued For : CONTROL3, LLC 12554 Galveston Rd, Suite B230 Webster Texas United States 77598 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT25H033HA01 Sample Received Date: Aug. 11, 2025 Date of Test: Aug. 11, 2025~ Sep. 25, 2025 Date of Issue: Sep. 25, 2025 Report No.: LGT25H033HA01 Page 2 of 8 TEST REPORT CERTIFICATION Applicant: CONTROL3, LLC Address: 12554 Galveston Rd, Suite B230 Webster Texas United States 77598 Manufacturer: Ted International ( Cambodia) Industrial Co.,Ltd Address: P1-041,042 PPSEZ, National Road 4, Sangkat Beung Thom, Khan Posenchey, Phnom Penh. PPSEZ Phnom Penh, Phnom Penh 120907 Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Trademark: Traceable® Model Name: C53 WWVB with remote Series Model: N/A Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC 47 CFR §2.1093 KDB 447498 D01 General RF Exposure Guidance v06 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT25H033HA01 Page 3 of 8 TABLE OF CONTENTS 1 . GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST LABORATORY 5 2 . FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Report No.: LGT25H033HA01 Page 4 of 8 Revision History Rev. Issue Date Revisions 00 Sep. 25, 2025 Initial Issue Report No.: LGT25H033HA01 Page 5 of 8 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Model Name: C53 WWVB with remote Series Model: N/A Model Difference: N/A Frequency Bands: 433.907 MHz Rating: DC 3V By battery(AAA) Hardware Version: N/A Software Version: N/A 1.2 TEST LABORATORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: A2LA Certificate No.: 6727.01 FCC Registration No.: 746540 CAB ID: CN0136 Report No.: LGT25H033HA01 Page 6 of 8 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Report No.: LGT25H033HA01 Page 7 of 8 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Report No.: LGT25H033HA01 Page 8 of 8 2.3 TEST RESULT Turn up Result Mode Turn up Power 433.907MHz -9±1dBm The MPE result of worst mode: RF Function Frequency (MHz) Max Turn up Power (dBm) Max Turn up Power (mW) Estimated SAR Limit Ratio Result TX 433.907MHz -8 0.16 0.0209 3 0.0070 Pass Note: 1. The Maximum Power Density is less than the limit, complies with the exemption requirements. ※※※※※END OF THE REPORT※※※※※

The test report is effective only with both signature and specialized stamp. This report shall not be reproduced except in full without the written approval of the Laboratory. The results in this report only apply to the tested sample. Shenzhen LGT Test Service Co., Ltd. Tel: 0755-89668180 E-mail:[email protected] Web: www.lgt-cert.com Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China RF TEST REPORT Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Model Number: C53 WWVB with remote FCC ID: 2AO2J-C53WWVB Issued For : CONTROL3, LLC 12554 Galveston Rd, Suite B230 Webster Texas United States 77598 Issued By : Shenzhen LGT Test Service Co., Ltd. Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Report Number: LGT25H033RF01 Received Date: Aug. 11, 2025 Date of Test: Aug. 11, 2025~ Sep. 25, 2025 Date of Issue: Sep. 25, 2025 Report No.: LGT25H033RF01 Page 2 of 33 TEST REPORT CERTIFICATION Applicant: CONTROL3, LLC Address: 12554 Galveston Rd, Suite B230 Webster Texas United States 77598 Manufacturer: Ted International ( Cambodia) Industrial Co.,Ltd Address: P1-041,042 PPSEZ, National Road 4, Sangkat Beung Thom, Khan Posenchey, Phnom Penh. PPSEZ Phnom Penh, Phnom Penh 120907 Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Trademark: Traceable® Model Number: C53 WWVB with remote Sample Status: Normal APPLICABLE STANDARDS STANDARD TEST RESULTS FCC Part 15.231, Subpart C ANSI C63.10-2020 PASS Prepared by: Approved by: Zane Shan Vita Li Engineer Technical Director Report No.: LGT25H033RF01 Page 3 of 33 TABLE OF CONTENTS Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 9 2.4 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.5 EQUIPMENTS LIST 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 RADIATED EMISSION LIMITS 14 4.2 TEST PROCEDURE 16 4.3 DEVIATION FROM TEST STANDARD 16 4.4 TEST SETUP 17 4.5 EUT OPERATING CONDITIONS 18 4.6 TEST RESULTS 18 4.7 FIELD STRENGTH CALCULATION 19 5. BANDWIDTH TEST 24 5.1 LIMIT 24 5.2 TEST REQUIREMENTS 24 5.3 TEST PROCEDURE 24 5.4 TEST SETUP 24 5.5 EUT OPERATION CONDITIONS 24 5.6 TEST RESULTS 25 6. DUTY CYCLE 26 6.1 TEST PROCEDURE 26 6.2 TEST SETUP 26 6.3 EUT OPERATION CONDITIONS 26 6.4 TEST RESULTS 27 Report No.: LGT25H033RF01 Page 4 of 33 TABLE OF CONTENTS Page 6. TRANSMITTER TIMEOUT 30 6.1 LIMIT 30 6.2 TEST PROCEDURE 30 6.3 TEST SETUP 30 8. ANTENNA REQUIREMENT 32 8.1 STANDARD REQUIREMENT 32 8.2 EUT ANTENNA 32 APPENDIX I-PHOTOS OF TEST SETUP 33 Report No.: LGT25H033RF01 Page 5 of 33 Revision History Rev. Issue Date Revisions 00 Sep. 25, 2025 Initial Issue Report No.: LGT25H033RF01 Page 6 of 33 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part 15.231, Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A -- 15.205(a)/15.209/ 15.231.(e) Radiated Spurious Emission PASS -- 15.231 Transmission requirement PASS -- 15.231(C) 20 dB Bandwidth PASS -- 15.203 Antenna Requirement PASS -- NOTE: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. Report No.: LGT25H033RF01 Page 7 of 33 1.1 TEST FACTORY Company Name: Shenzhen LGT Test Service Co., Ltd. Address: Room 205, Building 13, Zone B, Zhenxiong Industrial Park, No.177, Renmin West Road, Jinsha, Kengzi Street, Pingshan District, Shenzhen, Guangdong, China Accreditation Certificate: FCC Registration No.: 746540 CAB ID: CN0136 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. Parameter Uncertainty RF Output Power, Conducted ±0.71dB Unwanted Emission, Conducted ±0.63dB Conducted emission ±2.80dB All Emissions, Radiated (0.009-30MHz) ±2.16dB All Emissions, Radiated (30MHz-1GHz) ±4.61dB All Emissions, Radiated (1GHz-18GHz) ±5.49dB Note: The measurement uncertainty is not included in the test result. Report No.: LGT25H033RF01 Page 8 of 33 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name: Traceable GIANT-DIGITS Radio Atomic Clock with Remote sensor Test Model Number: C53 WWVB with remote Series Number: N/A Model Difference: N/A Frequency band: 433.907 MHz Power Rating: DC 3V By battery(AAA) Modulation Type: ASK Antenna Type: Spring Antenna Antenna Gain: 0dBi Hardware version: N/A Software version: N/A Connecting I/O Port(s): N/A Note: 1. For a more detailed features description, please refer to the manufacturer’s specifications orthe User Manual. 2. The antenna information refers to the manufacturer provide report, applicable only to the tested sample identified in the report. Due to the incorrect antenna information, a series of problems such as the accuracy of the test results will be borne by the customer. Report No.: LGT25H033RF01 Page 9 of 33 2.2 DESCRIPTION OF THE TEST MODES To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-scanning tested base on the consideration of following EUT operation mode or test configuration mode which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test configuration mode(s) mentioned above was evaluated respectively. Pretest Mode Description Mode 1 TX Mode For Radiated Emission Final Test Mode Description Mode 1 TX Mode 2.3 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED During test, Keep EUT is in continuous transmiss…

Text truncated - open the document above for the full version.

Antenna Spec Antenna dexcribe: Antenna Type： Spring Antenna Model name： C53 WWVB with remote Antenna gain： 0dBi(Max.) Frequency range(MHz)： 400-450 Connector type： direct Manufacture： Ted International (Cambodia) Industrial Co.,Ltd Manufacture Address： P1-041,042 PPSEZ, National Road 4, Sangkat Beung Thom, Khan Posenchey, Phnom Penh. PPSEZ Phnom Penh, Phnom Penh 120907 Lenth=18mm 18mm Antenna Radiation Patter

Page 1 of 1 Report No.: LGT25H033 Appendix - Test Setup photos Set-up for Radiated Spurious Emission, Below 1GHz Set-up for Radiated Spurious Emission, Above 1GHz
