2AO39-FMP100TempCast FMP100

TempCast Vaisala Cast ™ Sensor Features • Wireless NB-IoT communication • Self-powered with 3-year battery lifetime • Measures: • Air temperature • Relative humidity • Dew / frost point • Surface temperature (optional) • Reports observations with enhanced point forecasts • Installation to existing pole and lattice mast structures • Maintenance-free due to periodic humidity sensor self-cleaning • Easy sensor replacement from ground level • Data available through Vaisala Wx Horizon or API Vaisala TempCast is an easy and affordable way to monitor key temperature parameters from any critical location. The wireless, pole-mounted sensor has different variants to measure air temperature, relative humidity, and surface temperature. Monitor frost formation on roads Surface and dew point temperatures are important when assessing the risk for frost formation on the roads. TempCast reports high-quality observations and enhanced point forecasts so that you can be prepared for what is ahead within the next 72 hours. This information allows you to make the right treatment decisions and act at the right time. Get measurements from locations not feasible before TempCast is wireless and mounts to existing infrastructure allowing flexible installation to various locations. External powering is not required. This makes it a cost-effective solution for covering data gaps in your existing weather observation network and an ideal starting point for gaining access to local weather observations. Sensor replacement takes 5 minutes The sensor does not need any maintenance during its lifetime. It has an automatic self-cleaning function that removes contamination from the humidity sensor. At the end of its life, the sensor is replaced with a new one. There is no need for a crane or a ladder to access the sensor. The replacement takes 5 minutes by a single person from ground level by using a telescopic rod. The sensor is secured to its mounting bracket with a convenient twist-lock mechanism. This ensures that the replacement process is fast and safe. Easy access to data Measurement data from TempCast is automatically available in Vaisala Wx Horizon. Wx Horizon combines local sensor observations, radar data, and alerts in one subscription package for enhanced road weather forecasts. For integration to other systems, the Wx Horizon API can be used. Best performance with Vaisala GroundCast TempCast with remote surface temperature measurement is a convenient product for frost monitoring. When you want to monitor ice formation as well and further enhance your road weather forecast, you can co-locate TempCast with Vaisala GroundCast. NaCl Technical data Measurement performance Air temperature Measurement range−40 ... +70 °C (−40 ... +158 °F) Measurement accuracy±0.15 °C (0.27 °F) at 0 °C (32 °F) ±0 .25 °C (0.45 °F) over full range Relative humidity Measurement range0 ... 100 %RH Measurement accuracy±1.5 % at 0 °C (32 °F) / <90 %RH ±3.5 % over full range Surface temperature (optional) Measurement range−40 ... +70 °C (−40 ... +158 °F) Measurement accuracy 1) ±0.5 °C (0.9 °F) at 0 °C (32 °F) 2) ±1 °C (1.8 °F) over −20 ... +60 °C (−4 ... +140 °F) 1)Accuracy specific ation of used infrared component manufacturer in stable laboratory conditions. In real outdoor conditions, additional errors may include nighttime cold sky reflections and sunlight- based large temperature differences between sensor and road. 2)Accuracy is valid if ambient temperature is similar for road and sensor. Operating environment Operating temperature−40 ... +70 °C (−40 ... +158 °F) Storage temperature 1) Max. +30 °C (+86 °F) Operating humidity0 ... 100 %RH IP ratingIP55 1)Recommendation from the battery manufacturer. Communication and data collection Communication standardNarrowband IoT (NB-IoT) SIM card typeMicro-SIM (3ff), pr ovided by Vaisala Local connection for sensor setupNFC and Bluetooth Mobile application for sensor setupVaisala Cast Connect (for iPhone and Android phone) Data message intervalEvery 10 minutes Data storage locationVaisala cloud Data access optionsVaisala Wx Horizon UI and API Vaisala RoadDSS â UI TempCast models TempCast for air temperature, relative humidity, and surf ace temperature measurement FMP103 TempCast for air temperature and relative humidity measurement FMP102 Sensor data visualization in Vaisala Wx Horizon Mechanical specifica tions Sensor materialGlass fiber r einforced polycarbonate Installation bracket materialAISI 316 stainless steel WeightSensor 1.4 kg (3.1 lb) Bracket 0.6 kg (1.3 lb) Battery typeLithium-thionyl chloride Battery lithium metal content 7.6 g (0.017 lb) per sensor 1) Installation with standard mounting br acket For pole masts with diameter 60 ... 420 mm (2.36 ... 16.54 in) Installation with optional mounting adapter For diagonal and horizontal structures with diameter 25 ... 400 mm (1.00 ... 15.75 in) 1)Sensor includes 2 removable batteries, 3.8 g (0.008 lb) each. 300 [11.81] 133 [5.24] 100 [3.94] 60 [2.36] 316 [12.44] mm [in] Compliance EU directives and regulationsRED, RoHS Electromagnetic compatibility (EMC)EN 301 489-1, -17, -52 F CC part 15 B, Class B ICES‑3 / NMB‑3 (Class B) Radio compatibilityEN 301 908-1 EN 300 328 FCC 47 Part 22/24/27/90 ISED RSS-130, RSS-132, RSS-133, RSS-139 Radio acceptanceFCC ID: 2AO39-FMP100 IC ID: 23830-FMP100 SafetyIEC 62368-1 RF exposure: FCC 47 CFR Part 2.1091, ISED RSS-102, EN 62311, 1999/519/EC ColdIEC 60068‑2‑1 Dry heatIEC 60068‑2‑2 Vibration (sinusoidal)IEC 60068‑2‑6 Vibration (random)IEC 60068‑2‑64 Change of temperatureIEC 60068‑2‑14 ShockIEC 60068‑2‑27 Damp heat, cyclicIEC 60068‑2‑30 Damp heatIEC 60068‑2‑78 Compliance marksCE, FCC, ICES, RCM, UKCA Vaisala Cast Connect mobile application Published by Vaisala | B212524EN-E © Vaisala 2023 All rights reserved. Any logos and/or product names are trademarks of Vaisala or its individual partners. Any reproduction, transfer, distribution or storage of information contained in this document is strictly prohibited. All …

Text truncated - open the document above for the full version.

FCC/ISED regulatory notices Modifica tion statement Vaisala Oyj has not approved any changes or modifications to this device by the user. Any changes or modifications could void the user’s authority to operate the equipment. Vaisala Oyj n’approuve aucune modification apportée à l’appareil par l’utilisateur, quelle qu’en soit la nature. Tout changement ou modification peuvent annuler le droit d’utilisation de l’appareil par l’utilisateur. Interference statement This device complies with Part 15 of the FCC Rules and Innovation, Science and Economic Development Canada (ISED) licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR Innovation, Sciences et Développement économique Canada (ISDE) applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. Wireless notice This equipment complies with FCC and ISED radiation exposure limits set forth for an uncontrolled environment. The antenna should be installed and operated with minimum distance of 20 cm between the radiator and your body. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Cet appareil est conforme aux limites d'exposition aux rayonnements de l’ISDE pour un environnement non contrôlé. L'antenne doit être installée de façon à garder une distance minimale de 20 centimètres entre la source de rayonnements et votre corps. L'émetteur ne doit pas être colocalisé ni fonctionner conjointement avec à autre antenne ou autre émetteur. FCC Class B digital device notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. CAN ICES-3 (B) / NMB-3 (B) This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne NMB-003. TempCast FMP100 certification •FCC ID: 2AO39-FMP100 M212845EN-B Regulatory Inf ormation Vaisala TempCast FMP100 PUBLISHED BY V aisala Oyj Vanha Nurmijärventie 21 FI-01670 Vantaa, Finland © Vaisala 2023 All rights reserved. Any logos and/or product names are trademarks of Vaisala or its individual partner s. Any reproduction, transfer, distribution or storage of information contained in this document is strictly prohibited. All specifications — technical included — are subject to change without notice. •IC: 23830-FMP100

M212844EN-A Setup Guide Vaisala TempCast FMP102, FMP103 Vaisala TempCast Vaisala TempCast is a wireless and self-powered sensor, with dierent variants to measure air temperature, relative humidity, and surface temperature. Check that the installation location is within the NB-IoT network coverage area of the network operator. Mount the device on a pole mast with diameter 60 ... 425 mm (2.36 ... 16.73 in). FMP103 1 Temperature and relative humidity sensor 2 Surface temperature sensor FMP102 1 Temperature and relative humidity sensor Installation site requirements 2 1 1 Max Ø 425 mm (16.73 in) Min Ø 60 mm (2.36 in) Setting up device Included in the product • Vaisala TempCast sensor FMP102 or FMP103 • Mounting bracket with steel bands • Locking key • Alignment tool Other needed equipment • Android phone with NFC reader and Bluetooth • Vaisala Cast Connect mobile application • 7-mm socket wrench or flat head screwdriver • Tin snips (for cutting steel band) • Aerial work platform • Prot ec tive clothing (PPE) • Road safety equipment To set up the device: 1. Activate the device at the installation location using the Vaisala Cast™ Connect mobile application. 2. Install the device at the installation location. 3. Align the surface temperature sensor (only for FMP103). 1. Activating device Activate the device at the installation location. 1.1 Download the Vaisala Cast Connect mobile application from Google Play. 1.2 Open the mobile application and select Connect to device. Hold the phone close to the NFC symbol and wait until the device and phone are paired with Bluetooth. 1.3 Select the Measurements tab to view the device measurements. 1.5 Select Start activation. Follow the onscreen instructions. 1.4 Check the signal strength from the Connection tab and wait until the cloud connection is established. Establishing the cloud connection may take several minutes. 1.6 Complete the activation. The device is sending measurements to the cloud. i To relocate device or change activation information Connect to the device with Vaisala Cast Connect, and deactivate and activate the device again. 9,3 °C 7,5 °C 52 % 2. Installing device 2.1 Select the installation height. The recommended installation height is 2 ... 5 meters (6 ... 16 ft). Low installation height is more representative of the temperature and relative humidity near the road surface. For the surface temperature measurement, select the installation height so that you can aim the sensor at the desired measurement point (max. tilt angle 60°). Note! A large tilt angle may extend the surface temperature measurement area outside the desired measurement point. 2.2 Fasten the mounting bracket. Cut o excess steel band or place it neatly into the bracket. 2.3 Use the locking key to lift and secure the device to the bracket. Remove the locking key. SNAP! Tilt angle 60° Tilt angle 10° 2 ... 5 m (6 ... 16 ft) Desired measurement point 3.1 Loosen the finger screws to adjust the sensor angles. The sensor rotates 180° and tilts 60°. 3.2 Attach the alignment tool on the sensor. The tool can be positioned on either side of the device. 3.3 Look through the alignment tool to aim the sensor at the measurement point. Tighten the finger screws and remove the tool. Note! The oset from the tool to the sensor is 10 cm (3.94 in). 3. Aligning surface temperature sensor (FMP103 only) Replacing and recycling device Included in the product • Vaisala TempCast sensor FMP102 or FMP103 • Locking key • Telescopic rod Other needed equipment • Android phone with NFC reader and Bluetooth • Vaisala Cast Connect mobile application • Prot ec tive clothing • Road safety equipment • 3-mm Allen key At the end of its 3-year lifetime the device needs to be replaced. Use the telescopic rod to install the new device to the existing bracket. Activate the new device using the Vaisala Cast Connect mobile application. 1. Replacing device 1.1 Attach the locking key to the telescopic rod. 1.4 Open Vaisala Cast Connect and select Connect to device. Hold the phone close to the NFC symbol and wait until the device and phone are paired with Bluetooth. Select Start activation. 1.5 Follow the onscreen instructions to activate the device. The new device is sending measurements to the cloud. 1.6 Lift the new device to the bracket. FMP103 only: 1.3 Copy the surface temperature sensor angles to the new device. 1.2 Turn the locking key to release the device and lift the device from the bracket. 0 10 20 30 40 50 60 90 80 70 60 50 40 30 20 10 0 180 170 160 150 140 130 120 110 100 0 10 20 30 40 50 60 90 80 70 60 50 40 30 20 10 0 180 170 160 150 140 130 120 110 100 New device New device Old device WARNING! The sensor contains batteries, which poses a fire, explosion, and severe burn hazard. Do not crush, disassemble, heat above 100 °C (212 °F), or incinerate. WARNING! The batteries must be removed from the sensor during the recycling. The recycling of batteries must only be conducted by fully trained personnel of licensed recyclers. WARNING! Do not leave the battery in an environment surrounded by extremely high temperatures. Extremely high temperature can result in an explosion or the leakage of flammable liquid or gas. WARNING! Make sure that the battery is not subjected to an extremely low air pressure. Extremely low air pressure can result in an explosion or the leakage of flammable liquid or gas. WARNING! Only use batteries delivered with the sensor by Vaisala. 2.1 Loosen 3 screws and remove the cover. 2.2 Detach the power cable. Detach the battery wires. 2.3 Remove the batteries. 2. Removing batteries 3. Recycling These recycling instructions guide you on the end-of-life treatment of this Vaisala product. As waste regulations and infrastructure vary in each country, these instructions only indicate the dierent components to be separated and common ways to handle them. Always follow local requirements when disposing of the product. Vaisala encourages to use the best available recycling practices to minimi…

Text truncated - open the document above for the full version.

1 (1) The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-08-07 To whom it may concern: We, Vaisala Oyj, hereby certify that the equipment for which authorization is sought (FCC ID: 2AO39-FMP100) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). Sincerely, Signature Sami Lehtonen Product Compliance Manager Vaisala Oyj 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V02

1 (1) Restricted Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-06-05 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID:2AO39-FMP100 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Signature Sami Lehtonen Product Compliance Manager Vaisala Oyj

1 (2) Restricted Federal Communications Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2023-09-14 Request for Confidentiality Company name: Vaisala Oyj FCC ID: 2AO39-FMP100 In accordance with CFR 47 §0.457(d) and CFR 47 §0.459 of the Commission’s Rules, Vaisala Oyj hereby requests confidentiality of following exhibits: Exhibit Type: Type of Confidentiality Requested Detailed block diagrams* x Long-term confidentiality Schematic diagrams* x Long-term confidentiality Detailed operational descriptions* x Long-term confidentiality Parts lists/ tune up information* x Long-term confidentiality External photos X Short-term confidentiality** Internal photos X Short-term confidentiality** Test setup photos Short-term confidentiality** User’s manual Short-term confidentiality** Short-term maximum confidentiality period: 180 days OR: Short-term confidentiality release date (product launch): 12/31/2023 * Exhibits not routinely made available to the public. ** Only if applicable: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. When the device is marketed the grantee must inform the TCB to release the Short-Term Confidentiality information withheld on the FCC equipment authorization website. 2 (2) Restricted 2/2 Long-term confidentiality: The documents indicated as long-term confidential contain detailed system and equipment description and related information about the product which Vaisala Oyj considers to be proprietary, confidential and a custom design and the information is not publicly available. Since the design is a basis from which future technological products will evolve, Vaisala Oyj considers that this information would be of benefit to its competitors and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Short-term confidentiality (if applicable): Vaisala Oyj requests the exhibits selected above as short-term confidential to be withheld from public view for the period as indicated above. When the device is marketed, Vaisala Oyj will inform the TCB to release the short-term confidentiality information withheld on the FCC equipment authorization website. Sincerely, Signature Sami Lehtonen Product Compliance Manager Vaisala Oyj Vanha Nurmijärventie 21 01670 Vantaa Finland



VAISALA CAST SENSOR TEMPCAST FMP100 MODEL: FMP102 Manufactured Month, YYYY IMEI XXXXXXXXXXXXXXX FCC ID 2AO39-FMP100 IC 23830-FMP100 Made in Finland, Vaisala Oyj, Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland UK address: Vaisala Ltd, 6230 Bishops Court, Birmingham B37 7YB Contains Li-SOCl2 batteries Serial No. 12345678 CFG01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES3(B)/NMB3(B) VAISALA CAST SENSOR TEMPCAST FMP100 MODEL: FMP103 Manufactured Month, YYYY IMEI XXXXXXXXXXXXXXX FCC ID 2AO39-FMP100 IC 23830-FMP100 Made in Finland, Vaisala Oyj, Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland UK address: Vaisala Ltd, 6230 Bishops Court, Birmingham B37 7YB Contains Li-SOCl2 batteries Serial No. 12345678 CFG01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES3(B)/NMB3(B) FMP102FMP103 TEMPCAST FMP100 LABELING EXAMPLES 19.09.2023

VAISALA CAST SENSOR TEMPCAST FMP100 MODEL: FMP102 Manufactured Month, YYYY IMEI XXXXXXXXXXXXXXX FCC ID 2AO39-FMP100 IC 23830-FMP100 Made in Finland, Vaisala Oyj, Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland UK address: Vaisala Ltd, 6230 Bishops Court, Birmingham B37 7YB Contains Li-SOCl2 batteries Serial No. 12345678 CFG01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES3(B)/NMB3(B) VAISALA CAST SENSOR TEMPCAST FMP100 MODEL: FMP103 Manufactured Month, YYYY IMEI XXXXXXXXXXXXXXX FCC ID 2AO39-FMP100 IC 23830-FMP100 Made in Finland, Vaisala Oyj, Vanha Nurmijärventie 21, FI-01670 Vantaa, Finland UK address: Vaisala Ltd, 6230 Bishops Court, Birmingham B37 7YB Contains Li-SOCl2 batteries Serial No. 12345678 CFG01 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAN ICES3(B)/NMB3(B) FMP102FMP103 TEMPCAST FMP100 LABELING EXAMPLES 19.09.2023

Restricted TEMPCAST FMP102 INTERNAL PHOTOGRAPHS Rev. G Rönkkä Antti © Vaisala 2023 TempCast FMP102 photographs 1 (13) 2023-08-07 Restricted Table of Contents 1 Internal Photographs .................................................................................................................... 2 TempCast FMP102 photographs 2 (13) 2023-08-07 Restricted Tempcast FMP102 Internal photographs 1 Internal Photographs Photo 6. FMP102 opened, top view TempCast FMP102 photographs 3 (13) 2023-08-07 Restricted Photo 7. FMP102 opened, plastic shield removed TempCast FMP102 photographs 4 (13) 2023-08-07 Restricted Photo 8. FMP102 Electronics TempCast FMP102 photographs 5 (13) 2023-08-07 Restricted Photo 9. IOTMAINCB and Antennas, Front View TempCast FMP102 photographs 6 (13) 2023-08-07 Restricted Photo 10. IOTMAINCB and Antennas, Back View TempCast FMP102 photographs 7 (13) 2023-08-07 Restricted Photo 11. IOTMAIN CB, front view TempCast FMP102 photographs 8 (13) 2023-08-07 Restricted Photo 12. IOTMAINCB, back view TempCast FMP102 photographs 9 (13) 2023-08-07 Restricted Photo 13. IOTHMPIF and IOTHMP -sensor TempCast FMP102 photographs 10 (13) 2023-08-07 Restricted Photo 14. IOTHMPIF, front view TempCast FMP102 photographs 11 (13) 2023-08-07 Restricted Photo 15. IOTHMPIF, back view TempCast FMP102 photographs 12 (13) 2023-08-07 Restricted Photo 16. IOTPWR and batteries, front view TempCast FMP102 photographs 13 (13) 2023-08-07 Restricted Photo 17. IOTPWR and batteries, back view

Restricted TEMPCAST FMP103 INTERNAL PHOTOGRAPHS Rev. G Rönkkä Antti © Vaisala 2023 TempCast FMP103 photographs 1 (16) 2023-08-07 Restricted Table of Contents 1 Internal Photographs .................................................................................................................... 2 TempCast FMP103 photographs 2 (16) 2023-08-07 Restricted Tempcast FMP103 photographs 1 Internal Photographs Photo 6. FMP103 opened, top view TempCast FMP103 photographs 3 (16) 2023-08-07 Restricted Photo 7. Plastic shield removed TempCast FMP103 photographs 4 (16) 2023-08-07 Restricted Photo 8. FMP103 Electornics TempCast FMP103 photographs 5 (16) 2023-08-07 Restricted Photo 9. IOTMAINCB and Antennas, Front View TempCast FMP103 photographs 6 (16) 2023-08-07 Restricted Photo 10. IOTMAINCB and Antennas, Back View TempCast FMP103 photographs 7 (16) 2023-08-07 Restricted Photo 11. IOTMAIN CB, top view TempCast FMP103 photographs 8 (16) 2023-08-07 Restricted Photo 12. IOTMAINCB, back view TempCast FMP103 photographs 9 (16) 2023-08-07 Restricted Photo 13. IOTHMPIF and IOTHMP -sensor TempCast FMP103 photographs 10 (16) 2023-08-07 Restricted Photo 14. IOTHMPIF, front view TempCast FMP103 photographs 11 (16) 2023-08-07 Restricted Photo 15. IOTHMPIF, back view TempCast FMP103 photographs 12 (16) 2023-08-07 Restricted Photo 16. MT11IF and MT11 sensor TempCast FMP103 photographs 13 (16) 2023-08-07 Restricted Photo 17. MT11IF, front view TempCast FMP103 photographs 14 (16) 2023-08-07 Restricted Photo 18. MT11IF, back view TempCast FMP103 photographs 15 (16) 2023-08-07 Restricted Photo 19. IOTPWR and batteries, front view TempCast FMP103 photographs 16 (16) 2023-08-07 Restricted Photo 20. IOTPWR and batteries, back view

nRF9160 Internal Pictures Nordic Semiconductor Version 1.0 Modulepictures; Open-top view © NORDIC SEMICONDUCTORSTRICTLY CONFIDENTIAL SiP module; Open-top view © NORDIC SEMICONDUCTORSTRICTLY CONFIDENTIAL SiP module; Bottom view

Test Report No.: G0M-2304-2019-TFC091MP-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 1 of 27 RF-EXPOSURE REPORT FCC 47 CFR Part 2.1091 ISED RSS-102 Maximum permissible exposure Report Reference No G0M-2304-2019-TFC091MP-V02 Testing Laboratory Eurofins Product Service GmbH Address Storkower Str. 38c 15526 Reichenwalde Germany Accreditation A2LA Accredited Testing Laboratory, Certificate No.: 1983.01 FCC Test Firm Designation Number: DE0008 ISED Testing Laboratory site: 3470A Applicant Vaisala Oyj Address Vanha Nurmijärventie 21 01670 Vantaa Finland Test Specification According to FCC/ISED rules Standard FCC 47 CFR 2.1091 ISED RSS-102 Non-Standard Test Method None Equipment under Test (EUT): Product Description TempCast FMP100 Model(s) FMP103 Additional Model(s) None Brand Name(s) Vaisala Hardware Version(s) F Software Version(s) 1.0.9 FCC ID 2AO39-FMP100 IC 23830-FMP100 Test Result PASSED Test Report No.: G0M-2304-2019-TFC091MP-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 3 of 27 VERSION HISTORY Version History Version Issue Date Remarks Revised By 01 2023-07-14 Initial Release Florian Voigt 02 2023-09-22 Replaced document: G0M-2304-2019-TFC91MP-V01 Replaced by: G0M-2304-2019-TFC91MP-V02 Reason: 1. Page 6: Replaced “Contains FCC ID” and “Contains IC” fields with FCC ID, IC, PMN, HVIN and FVIN from EUT. 2. Page 7: Removed reference to unused radio report 59675RRF.002. 3. Page 7: Added reference to BTLE radio report 3772RER005A1. 4. Page 8: Changed maximum duty cycle of 20% to 100% for NB-IoT modem. 5. Page 8: Added Bluetooth LE as a second transmitter. 6. Recalculated MPE with Bluetooth LE which has major effect on all following pages from page 8. - Test Report No.: G0M-2304-2019-TFC091MP-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 4 of 27 ABBREVIATIONS AND ACRONYMS Acronyms Acronym Description EIRP Equivalent Isotropic Radiated Power EUT Equipment Under Test MPE Maximum Permissible Exposure Test Report No.: G0M-2304-2019-TFC091MP-V02 Eurofins Product Service GmbH Storkower Str. 38c, D-15526 Reichenwalde, Germany Page 5 of 27 REPORT INDEX 1 Equipment (Test Item) Under Test................................................................................................... 6 1.1 Reference Documents ................................................................................................................................... 7 1.2 Power density radiation sources.................................................................................................................... 8 1.3 Field strength radiation sources .................................................................................................................... 8 1.4 Concurrent Sources ...................................................................................................................................... 8 2 Result Summary ................................................................................................................................. 9 3 RF-Exposure classification ............................................................................................................ 11 4 RF-Exposure limits .......................................................................................................................... 12 5 RF-Exposure Evaluation ................................................................................................................. 13 6 Single Source Evaluation Results - FCC ..............................................................................…

Text truncated - open the document above for the full version.
