2AOCT-3RTHS24BZTemperature and Humidity Sensor

Third Reality, Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 29, 2022
Application Purpose: Original Equipment
Date of Application: Aug 25, 2022
Equipment Note: Temperature and Humidity Sensor
Frequency Range: 2405.00000000 - 2480.00000000
Company: Third Reality, Inc.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Temperature&HumiditySensor UserManual Index 1.ProductOverview 2.Installation 3.ResetButton 4.Specifications 5.Settingup 6.PairingwithTHIRDREALITY 7.PairingwithAmazonEcho 8.PairingwithSmartThings 9.PairingwithHubitat 10.PairingwithHomeAssistant ProductOverview FrontViewRearView Installation ResetButton 1Pressandholdtheresetbuttonontheleftsideofthesensorfor10secondsandreleasethe hold. 2SinglepresstheresetbuttontoswitchthetemperaturedisplaybetweenCelsiusand Fahrenheit. Specifications NameTemperatureandHumiditySensor Model3RTHS24BZ LEDScreen48.5mmx41.0mm Dimensions6.15cmx6.15cmx1.8cm NetWeight64g OperatingVoltageDC3V BatteryTypeAAAbatteryx2(included) WirelessConnectivityZigBee 3.0 2405~2480MHz Settingup InitializingTemp&HumiditySensor Poweron:RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully,open thebatterycoverontheback,removetheplasticinsulationsheetandthesensorispowered on,theblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. 1 Pairingmode:pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsand releasethehold,theblinkingcloudicon 切图 ontheLEDscreenindicatesthesensorisin pairingmode. 2 Followtheon-screeninstructionstosetupyourTemperature&HumiditySensor. PairingwithTHIRDREALITY Hub:ThirdRealitySmartHub App:ThirdRealityApp PairtheTemp&HumiditysensorwithThirdRealitySmartHub. Pairing 1 RegisterandsigninyourTHIRDREALITYaccount,andaddtheTHIRDREALITYhub. 2 RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully,openthe batterycoverontheback,removetheplasticinsulationsheetandthesensorispoweredon;Or pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsandreleasethehold; TheblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. 3 Tap“+”intheupperrightinTHIRDREALITYApp,scrolldowntochoosetheTemp&Humidity SensorIconandfollowtheon-screeninstructionstostartthepairingprocess. 4 Thesensorwillbediscoveredwithinoneminuteas“TemperatureandHumiditySensor1”, thetemperatureandhumiditydatawillbedisplayedinthedevicelist. ⑤ TaptheTemp&HumiditySensoricontoenterthedevicepage,youcanseeinformationlike theMACaddress,batterylevel,softwareversionandhistoryrecordsetc,youcanalsorename theTemp&HumiditySensor,andcheckforsoftwareupdates. PairingwithAmazonEcho App:AmazonAlexaApp Devices:Echodeviceswithbuilt-inZigBeehubssuchAsEchoV4,EchoPlusV1&V2,EchoStudio, EchoShow10,andEero6&6pro. ① AskAlexatocheckforupdatesbeforepairing. ② RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully,openthe batterycoverontheback,removetheplasticinsulationsheetandthesensorispoweredon;Or pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsandreleasethehold; TheblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. ③ AskAlexatodiscoverdevices,oropenAlexaApp,gotodevicepage,tap“+”ontopright, choose“AddDevice”,scrolldowntothebottomandtap“other”,tap“DISCOVERDEVICES”,the Temp&HumiditySensorwillbepairedwithyourEchodeviceinafewseconds. ④ Tapdeviceicontoenterthedevicepage,tapthesettingicontoenterthesettingspage,you caneditthenameofthesensor;Oryoucancreateroutineswiththesensortocontrolother connecteddevices. PairingwithSmartThings App:SmartThingsApp Devices:SmartThingsHub2ndGen(2015)&3rdGen.(2018),AeotecSmartHomeHub. ① Beforepairing,checkforupdatestomakesuretheSmartThingsHubfirmwareisuptodate. ② RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully,openthe batterycoverontheback,removetheplasticinsulationsheetandthesensorispoweredon;Or pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsandreleasethehold; TheblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. ③ OpentheSmartThingsApp,tap“+”ontheupperrightcornerto ” Adddevice”andthentap “Scan”to“Scanfornearbydevices”. ④ TheSmartButtonwillbepairedwiththeSmartThingshubinafewseconds. ⑤ Createroutinestocontrolconnecteddevices. PairingwithHubitat Website:http://find.hubitat.com/ PairingSteps: ① RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully,openthe batterycoverontheback,removetheplasticinsulationsheetandthesensorispoweredon;Or pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsandreleasethehold; TheblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. ② VisityourHubitatElevationhubdevicepagefromyourwebbrowser,selecttheDevicesmenu itemfromthesidebar,thenselectDiscoverDevicesintheupperright. ③ ClickStartZigBeePairingbuttonafteryouselectaZigBeedevicetype,theStart ZigBeePairingbuttonwillputthehubinZigBeepairingmodefor60seconds. ④ Afterpairingprocessiscompletedsuccessfully,youcanrenameitifneeded. ⑤ NowyoucanseetheTemp&HumiditySensorontheDevicespage. PairingwithHomeAssistant Pairingsteps ： ① RemovetheplasticstandonthebackoftheTemp&HumiditySensorcarefully, openthebatterycoverontheback,removetheplasticinsulationsheetandthe sensorispoweredon,theblinkingcloudicononthetheLEDscreenindicatesthe sensorisinpairingmode. ② MakesureHomeAssistantIntegrationsZigBeeHomeAutomationSetupisready, thengoto“Configuration”page,click“integration”. ③ Thenclickthe“Devices”ontheZigBeeitem,theclick“AddDevices”. ④ Afterthepairingiscompletedsuccessfully,itwillshowupinthepage. ⑤ Backto“Devices”page,thenyoucanfindtheTemp&HumiditySensoradded. ⑥ ClicktoenterinthecontrolinterfacetosettheTemp&HumiditySensor. ⑦ Click“+”belongstoAutomationandthenyoucanadddifferentactions. FAQ Q1HowtofactoryresettheTemp&HumiditySensor? Pressandholdtheresetbuttonontheleftsideofthesensorfor5secondsandreleasethehold, theblinkingcloudicononthetheLEDscreenindicatesthesensorisinpairingmode. Q2WhydoesthetemperaturefluctuateasIpresstheresetbutton? Theresetbuttonislocatedneartheventilationhole,sothetemperaturereadingrisesasyour fingerpresstheresetbutton,youneedtowaitfor20secondsbeforethetemperaturereading returnstonormal. Q3TheLEDscreengetsdirty,howtocleanit? YoucancleantheLEDscreenwithalcoholwipesordampsoftcloth,preventwaterfromgetting intothemonitorwhencleaningit. Limited Warranty For limited warranty, please visit www.3reality.com/devicesupport For customer support, please contact us at [email protected] or…

Text truncated - open the document above for the full version.

Cover Letter(s)

ThirdReality,Inc. 8/23/2022 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 AUTHORITYTOACTASAGENT-FCC Onourbehalf,IappointShanghaiATBLTechnologyCo.,Ltd./5-6/F.,Unit1,No8,FreeTrade OneLifeScienceandSci-TechIndustrialPark,No.160BashengRoad,Pudong,Shanghai, China/AdaWang,toactasouragentinthepreparationofthisapplicationforequipment certification.Icertifythatsubmitteddocumentsproperlydescribethedeviceorsystemforwhich equipmentcertificationissought.Ialsocertifythateachunitmanufactured,importedormarketed,as definedinFCCregulationswillhaveaffixedtoitalabelidenticaltothatsubmittedforapprovalwith thisapplication. Insigningthisletter,Applicantcertifiesthatneithertheapplicantnoranypartytotheapplicationis notsubjecttoadenialofFederalbenefits,thatincludeFCCbenefits,pursuanttoSection5301ofthe Anti-DrugAbuseActof1988,21U.S.C.§862becauseofaconvictionforpossessionordistribution ofacontrolledsubstance.See47CFR1.2002(b)forthedefinitionofa"party"forthesepurposes. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,I acknowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification,as specifiedbyNemkoNorthAmericaInc.,stillresideswithus. Sincerely, Printedname:ZhouTao

Cover Letter(s)

ThirdReality,Inc. 8/22/2022 NemkoNorthAmerica,Inc. 303RiverRoad Ottawa,Ontario,Canada K1V1H2 REQUESTFORCONFIDENTIALITY-FCC FCCID:2AOCT--3RTHS24BZ PursuanttoSections0.457(d)(1)(ii)and0.459oftheCommission’sRulesandFCCGuidance document726920,weherebyrequestconfidentialtreatmentofinformationaccompanyingthis applicationasoutlinedbelow: PERMANENTLONG-TERMCONFIDENTIALITY: Schematics BillofMaterials/PartsList BlockDiagrams TheoryofOperation Whenthedeviceismarketedbeforetherequestednumberofdayslistedabove,thegranteewill informtheTCBtoreleasetheShort-TermConfidentialityinformationwithheldontheFCCequipment authorizationwebsite. Theaboveinformationcontainstradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthisinformationmightbeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors.TheApplicantunderstandsthatpursuanttoRule 0.457(d)(1)(ii),disclosureofthisApplicationandallaccompanyingmaterialswillnotbemadebefore thedateoftheGrantforthisApplication. Sincerely, Signed: Printedname:ZhouTao Title:Manager

External Photos

Page 1 of 3 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 3 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. Photo3 Photo4 Page 3 of 3 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. Photo5 Photo6

ID Label/Location Info

Lablelocation

Internal Photos

Page 1 of 4 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. PHOTOGRAPHSOFTHEEUTCONSTRUCTIONALDETAILS Photo1 Photo2 Page 2 of 4 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. Photo3 Photo4 Page 3 of 4 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. Photo5 Photo6 Zigbee Page 4 of 4 ReportNo.:SHATBL2207023 ShanghaiATBLTechnologyCo.,Ltd. Photo7

RF Exposure Info

Any reproduction of this document must be done in full. No single part of this document may be reproduced without permission from STS, all test data presented in this report is only applicable to presented test sample. Shenzhen STS Test Services Co., Ltd. A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China TEL: +86-755 3688 6288 FAX: +86-755 3688 6277 E-mail:[email protected] RADIO TEST REPORT Report No: STS2208021H01 Issued for Third Reality, Inc. NO.9 Nanxu Road,RunZhou District,Zhenjiang,Jiangsu,China Product Name: Temperature and Humidity Sensor Brand Name: N/A Model Name: 3RTHS24BZ Series Model: N/A FCC ID: 2AOCT-3RTHS24BZ Test Standard: FCC 47CFR §2.1091 S T L A B S Page 2 of 9 Report No.: STS2208021H01 Test Report Certification Applicant’s Name ................. : Third Reality, Inc. Address ................................. : NO.9 Nanxu Road,RunZhou District,Zhenjiang,Jiangsu,China Manufacturer's Name .......... : Third Reality, Inc. Address ................................. : NO.9 Nanxu Road,RunZhou District,Zhenjiang,Jiangsu,China Product Description Product Name ........................ : Temperature and Humidity Sensor Brand Name ......................... : N/A Model Name .......................... : ... : 3RTHS24BZ Series Model .......................... : N/A Standards ............................. : FCC 47CFR §2.1091 447498 D04 Interim General RF Exposure Guidance v01 This report shall not be reproduced except in full, without the written approval of STS, this document only be altered or revised by STS, personal only, and shall be noted in the revision of the document. Date of Test ........................................... : Date of receipt of test item ..................... : 03 Aug. 2022 Date (s) of performance of tests ............. : 03 Aug. 2022 ~08 Aug. 2022 Date of Issue .......................................... : 08 Aug. 2022 Test Result.............................................. : Pass Testing Engineer : (Chris Chen) Technical Manager : (Sean she) Authorized Signatory : (Bovey Yang) Page 3 of 9 Report No.: STS2208021H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1091 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 9 Page 4 of 9 Report No.: STS2208021H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 08 Aug. 2022 STS2208021H01 ALL Initial Issue Page 5 of 9 Report No.: STS2208021H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Temperature and Humidity Sensor Brand Name N/A Model Name 3RTHS24BZ Series Model N/A Model Difference N/A Product Description The EUT is Temperature and Humidity Sensor. Operation Frequency: ZigBee: 2405~2480 MHz Modulation Type: OQPSK Antenna gain: 2dBi Antenna Designation: PCB Antenna Rating Input : 3V Battery Rated Voltage:1.5V Capacity: 1200mAh Hardware Version REV0.4 Software Version V14. 1.00.14 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : A 1/F, Building B, Zhuoke Science Park, No.190 Chongqing Road, HepingShequ, Fuyong Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 9 Report No.: STS2208021H01 2. FCC 47CFR §2.1091 REQUIREMENT 2.1 TEST STANDARDS Follow the maximum permissible exposure (MPE) limits specified in 447498 D04 Interim General Radio Frequency Exposure Guidelines v01. The gain of the antenna used in the product was extracted from the supplied antenna data sheet and the maximum total power input to the antenna was also measured. Calculate the distance from the product to the MPE limit by the formula. 2.2 LIMIT For single RF sources (i.e., any single fixed RF source, mobile device, or portable device, as defined in paragraph (b)(2) of this section): A single RF source is exempt if: (A) The available maximum time-averaged power is no more than 1 mW, regardless of separation distance. This exemption may not be used in conjunction with other exemption criteria other than those in paragraph (b)(3)(ii)(A) of Part 1.1307. Medical implant devices may only use this exemption and that in paragraph (b)(3)(ii)(A); (B) Or the available maximum time-averaged power or effective radiated power (ERP), whichever is greater, is less than or equal to the threshold Pth (mW) described in the following formula. This method shall only be used at separation distances (cm) from 0.5 centimeters to 40 centimeters and at frequencies from 0.3 GHz to 6 GHz (inclusive). Pth is given by: Page 7 of 9 Report No.: STS2208021H01 (C) Or using below table and the minimum separation distance (R in meters) from the body of a nearby person for the frequency (f in MHz) at which the source operates, the ERP (watts) is no more than the calculated value prescribed for that frequency. For the exemption in Table 1 to apply, R must be at least λ/2π, where λ is the free-space operating wavelength in meters. If the ERP of a single RF source is not easily obtained, then the available maximum time-averaged power may be used in lieu of ERP if the physical dimensions of the radiating structure(s) do not exceed the electrical length of λ/4 or if the antenna gain is less than that of a half-wave dipole (1.64 linear value). RF Source frequency (MHz) Threshold ERP(watts) 0.3-1.34 1,920 R 2 . 1.34-30 3,450 R 2 /f 2 . 30-300 3.83 R 2 . 300-1,500 0.0128 R 2 f. 1,500-100,000 19.2R 2 . Page 8 of 9 Report No.: STS2208021H01 For multiple RF sources: Multiple RF sources are exempt if: (A) The available maximum time-averaged power of each source is no more than 1 mW and there is a separation distance of two centimeters between any portion of a radiating structure operating and the nearest portion of any other radiating structure in the same device, except if the sum of multiple sources is less than 1 mW during the time-averagi…

Text truncated - open the document above for the full version.

Test Report

"ShanghaiATBLTechnologyCo.,Ltd."herebycertifiesthataccordingtoactualtestingconditions.Thetestresultsor observationsareprovidedinaccordancewithmeasuredvalue,withouttakingriskscausedbyuncertaintyintoaccount. Withoutexplicitstipulationinspecialagreements,standardsorregulations,ATBLshallnotassumeanyresponsibility.Thetest resultsorobservationsareapplicableonlytotestedsample.Clientshallberesponsibleforrepresentativenessofthesample andauthenticityofthematerial.Thisreportwillbevoidwithoutauthorizedsignatureorspecialsealfortestingreport.Donot copiedwithoutauthorization. Tel:+86(0)21-51298625Web:www.atbl-lab.comEmail:[email protected] RADIOTESTREPORT ReportNo.:SHATBL2207023W02 Applicant: ThirdReality,Inc. Address: NO.9NanxuRoad,RunZhouDistrict,ZhenjiangCity,Jiangsu,China ProductName:TemperatureandHumiditySensor BrandName:N/A ModelName:3RTHS24BZ SeriesModel:N/A TestStandard:FCCPart15.247 FCCID: 2AOCT-3RTHS24BZ IC: 28296-3RTHS24BZ Page2of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 GENERALDESCRIPTION Applicant’sName .................... : ThirdReality,Inc. Address ...................................... : NO.9NanxuRoad,RunZhouDistrict,ZhenjiangCity,Jiangsu,China Manufacture'sName..............: ThirdReality,Inc. Address......................................: NO.9NanxuRoad,RunZhouDistrict,ZhenjiangCity,Jiangsu,China ProductDescription ProductName...........................: TemperatureandHumiditySensor BrandName.............................:N/A ModelName..............................: 3RTHS24BZ SeriesModel..............................: N/A TestStandards ........................ : FCCPart15.247 TestProcedure..........................: ANSIC63.10-2013 ThisdevicedescribedabovehasbeentestedbyATBL,thetestresultsshowthattheequipmentunder test(EUT)isincompliancewiththeFCCrequirements.Anditisapplicableonlytothetestedsample identifiedinthereport. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofATBL,thisdocument maybealteredorrevisedbyATBL,personalonly,andshallbenotedintherevisionofthedocument. Dateofreceiptoftestitem........................: 22July.2022 Date(s)ofperformanceoftests...............: 23July.2022~25July.2022 DateofIssue .............................................. : 26July.2022 TestResult .................................................. :Pass ReportPreparedby: ReportApprovedby (Roean Wei) : AuthorizedSignatory (GhostLi) : (Terry Yang) Page3of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 TableofContents 1.SUMMARYOFTESTRESULTS6 2.GENERALINFORMATION7 2.1GENERALDESCRIPTIONOFTHEEUT7 2.2DESCRIPTIONOFTHETESTMODES9 2.3TESTSOFTWAREANDPOWERLEVEL9 2.4BLOCKDIGRAMSHOWINGTHECONFIGURATIONOFSYSTEMTESTED10 2.5DESCRIPTIONOFNECESSARYACCESSORIESANDSUPPORTUNITS11 2.6LABORATORYINFORMATION11 2.7MEASUREMENTUNCERTAINTY12 2.8EQUIPMENTSLIST13 3.EMCEMISSIONTEST14 3.1CONDUCTEDEMISSIONMEASUREMENT14 3.2TESTPROCEDURE15 3.3TESTSETUP15 3.4EUTOPERATINGCONDITIONS15 3.5TESTRESULTS15 4.RADIATEDEMISSIONMEASUREMENT16 4.1RADIATEDEMISSIONLIMITS16 4.2TESTPROCEDURE18 4.3TESTSETUP19 4.4EUTOPERATINGCONDITIONS19 4.5FIELDSTRENGTHCALCULATION20 4.6TESTRESULTS21 5.CONDUCTEDSPURIOUS&BANDEDGEEMISSION32 5.1LIMIT32 5.2TESTPROCEDURE32 5.3TESTSETUP32 5.4EUTOPERATIONCONDITIONS32 5.5TESTRESULTS33 6.POWERSPECTRALDENSITYTEST36 6.1LIMIT36 6.2TESTPROCEDURE36 Page4of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 TableofContents 6.3TESTSETUP36 6.4EUTOPERATIONCONDITIONS36 6.5TESTRESULTS37 7.BANDWIDTHTEST39 7.1LIMIT39 7.2TESTPROCEDURE39 7.3TESTSETUP39 7.4EUTOPERATIONCONDITIONS39 7.5TESTRESULTS40 8.PEAKOUTPUTPOWERTEST42 8.1LIMIT42 8.2TESTPROCEDURE42 8.3TESTSETUP42 8.4EUTOPERATIONCONDITIONS42 8.5TESTRESULTS42 9.ANTENNAREQUIREMENT45 9.1STANDARDREQUIREMENT45 9.2EUTANTENNA45 APPENDIX-PHOTOSOFTESTSETUP46 Page5of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 RevisionHistory Rev.IssueDateReportNO.EffectPageContents 0026July.2022SHATBL2207023W02ALLInitialIssue Page6of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 1.SUMMARYOFTESTRESULTS Testproceduresaccordingtothetechnicalstandards: KDB558074D0115.247MeasGuidancev05r02. FCCPart15.247,SubpartC Standard Section TestItemJudgmentRemark 15.207ConductedEmissionPASS-- 15.247(a)(2)6dB&99%BandwidthPASS-- 15.247(b)(3)OutputPowerPASS-- 15.247(d)&15.209& 15.205 RadiatedSpuriousEmissionPASS-- 15.247(d)&15.205 ConductedSpurious&BandEdge Emission PASS-- 15.247(e)PowerSpectralDensityPASS-- 15.205RestrictedbandsofoperationPASS-- 15.203AntennaRequirementPASS-- NOTE: (1)‘N/A’denotestestisnotapplicableinthisTestReport. (2)AlltestsareaccordingtoANSIC63.10-2013. Page7of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 2.GENERALINFORMATION 2.1GENERALDESCRIPTIONOFTHEEUT ProductNameTemperatureandHumiditySensor TradeName N/A ModelName3RTHS24BZ SeriesModel N/A ModelDifferenceN/A ProductDescription TheEUTisaTemperature&HumiditySensor Operation Frequency: 2405~2480MHz ModulationType: OQPSK RadioTechnology:ZigBee NumberOf Channel: 16 Antenna Designation: PleaserefertotheNote3. AntennaGain(dBi)2dBi ChannelList PleaserefertotheNote2. PowerRating 2XAAA1.5V Battery RatedVoltage:1.5V Capacity:1200mAh Hardwareversionnumber REV0.4 Softwareversionnumber V14.1.00.14 ConnectingI/OPort(s) PleaserefertotheNote1. Note: 1. Foramoredetailedfeaturesdescription,pleaserefertothemanufacturer’sspecificationsor theUserManual. Page8of48 ReportNo.:SHATBL2207023W02 ShanghaiATBLTechnologyCo.,Ltd.Number:SHATBL-W-05Releasedate:2022-03-01VersionNo.A/1 2. Channellist ChannelFrequency(MHz)Channel Frequency (MHz) CH112405CH192445 CH122410CH202450 CH132415CH212455 CH142420CH222460 CH152425CH232465 CH162430CH242470 CH172435CH252475 CH182440CH262480 3. TableforFile…

Text truncated - open the document above for the full version.

Test Setup Photos

Contact Information

Applicant

Zhou Tao

[email protected]+86-021-8019768Fax: +86-021-8019768

Test Firm

Shanghai ATBL Technology Co., Ltd.Haofei Huang

[email protected]13818033377

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.40 GHz - 2.48 GHz	6.10 mW

Confidentiality

Long Term

Grant Notes

Output power is conducted. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance.
