2AODN-T33-in-1 Wireless Charging Station

A B CD E * Only use certified 18W 9V/2A adapter * 3-in-1 wireless charging station 3-in-1 wireless charging station IMPORTANT SAFETY INSTRUCTIONS * Do not store device in high-temperature environment, including heat caused by intense sunlight or other forms of heat. Do not place device in fire or other excessively hot environments. Exposure to fire or temperature above 212°F (100°C) may cause explosion. * Do not use the wireless charger in excess of its output rating. Overloading outputs above rating may result in a risk of fire or injury to persons. * Do not expose the wireless charger to rain or snow. * Do not modify, repair or disassemble the unity, if so, please contact the manufacturer. Switch o the wireless charger when not in use. The wireless charger will automatically switch o when disconnected from its wall charger. Before Using the unit, please read the user manual carefully This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This device complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected. FCC StatementFCC Statement

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Jan. 13, 2020 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AODN-T3 T3 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Xiaoping Li Company: CYSPO Technology (Shenzhen) Co., Ltd. Address: Floor 2, Building A, Jin Chi Industry Park, Jiu Wei, Baoan District , Shenzhen, Guangdong, China Phone: +86 755-23919516 Fax: +86 755-23919516 E-Mail: [email protected]

FCC ID: 2AODN-T3 FCC ID: 2AODN-T3

FCC ID: 2AODN-T3 This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference r eceived, including interference that may caus e undesired operation.

FCC ID: 2AODN-T3 Antenna FCC ID: 2AODN-T3 FCC ID: 2AODN-T3

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200109007-1-18-2 2AODN-T3 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Jan. 08, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : CYSPO Technology (Shenzhen) Co., Ltd. Address ............................................ : Floor 2, Building A, Jin Chi Industry Park, Jiu Wei, Baoan District , Shenzhen, Guangdong, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: 3-in-1 Wireless Charging Station Trade Mark ....................................... : N/A Manufacturer .................................... : CYSPO TECHNOLOGY(SHENZHEN) CO.,LTD. Model/Type reference....................... : T3 Listed Models .................................. : N/A Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : 9V2A Result................................................ : PASS Report No.: GTS20200109007-1-18-2 Page 2 of 13 T E S T R E P O R T Test Report No. : GTS20200109007-1-18-2 Jan. 08, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : 3-in-1 Wireless Charging Station Model /Type : T3 Listed Models : N/A Applicant : CYSPO TECHNOLOGY(SHENZHEN) CO.,LTD. Address : Floor 2, Building A, Jin Chi Industry Park, Jiu Wei, Baoan District , Shenzhen, Guangdong, China Manufacturer : CYSPO TECHNOLOGY(SHENZHEN) CO.,LTD. Address : Floor 2, Building A, Jin Chi Industry Park, Jiu Wei, Baoan District , Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200109007-1-18-2 Page 3 of 13 Contents 1 ................................................................SUMMARY ............ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Description of the test mode 4 1.4 Modifications 4 2 TEST ENVIRONMENT .............................................................. 5 2.1 Address of the test laboratory 5 2.2 Test Facility 5 2.3 Environmental conditions 5 2.4 Summary of measurement results 6 2.5 Statement of the measurement uncertainty 6 2.6 Equipments Used during the Test 6 3 TEST CONDITIONS AND RESULTS ............................................. 7 3.1 Applicable Standard 7 3.2 Limit 7 3.3 Test Setup 7 3.4 Measurement Procedure 9 3.5 Test Result of E and H field Strength 9 3.6 Simultaneous E-Filed Strength and H-Filed Strength 10 3.7 Equipment Approval Considerations 12 3.8 Conclusion 12 4 TEST SETUP PHOTOS OF THE EUT ......................................... 13 Report No.: GTS20200109007-1-18-2 Page 4 of 13 1 SUMMARY 1.1 General Remarks Date of receipt of test sample : Dec. 24, 2019 Testing commenced on : Dec. 25, 2019 Testing concluded on : Jan. 07, 2020 1.2 Product Description Product Name: 3-in-1 Wireless Charging Station Model/Type reference: T3 Power supply: DC 9 from adapter Wireless Charger Antenna Type Coil Antenna Antenna Gain 0.0dBi Operation frequency 110KHz~205KHz Modulation Type ASK 1.3 Description of the test mode Equipment under test was operated during the measurement under the following conditions: Charging and communication mode Test Conditions Description TM1 AC/DC Adapter (9V/2A) + EUT + Mobile Phone (Battery Status: <1%) Pre-tested TM2 AC/DC Adapter (9V/2A) + EUT + Mobile Phone (Battery Status: <50%) Pre-tested TM3 AC/DC Adapter (9V/2A) + EUT + Mobile Phone (Battery Status: 100%) Pre-tested TM4 AC/DC Adapter (9V/2A) + EUT + iWatch(Battery Status: <1%) Pre-tested TM5 AC/DC Adapter (9V/2A) + EUT + iWatch(Battery Status: <50%) Pre-tested TM6 AC/DC Adapter (9V/2A) + EUT + iWatch(Battery Status: 100%) Pre-tested TM7 AC/DC Adapter (9V/2A) + EUT + AirPods(Battery Status: <1%) Pre-tested TM8 AC/DC Adapter (9V/2A) + EUT + AirPods(Battery Status: <50%) Pre-tested TM9 AC/DC Adapter (9V/2A) + EUT + AirPods(Battery Status: 100%) Pre-tested TM10 AC/DC Adapter (9V/2A) + EUT + Mobile Phone + iWatch(Battery Status: <1%) Pre-tested TM11 AC/DC Adapter (9V/2A) + EUT + Mobile Phone + iWatch(Battery Status: <50%) Pre-tested TM12 AC/DC Adapter (9V/2A) + EUT + Mobile Phone + iWatch(Battery Status: 100%) Pre-tested TM13 AC/DC Adapter (9V/2A) + EUT + Mobile Phone + AirPods(Battery Status: <1%) Pre-tested TM14 AC/DC Adapter (9V/2A)…
