Used in this guide. Important safety information. Please read this and the online guide(s) at support.aeotec.com/zs10Pro carefully. Failure to follow the recommendations set forth by Aeotec Limited may be dangerous or cause a violation of the law. The manufacturer, importer, distributor, and / or reseller will not be held responsible for any loss or damage resulting from not following any instruction in this guide or in other materials. Z-Stick 10 Pro is intended for indoor use in dry locations only. Do not use in damp, moist, and / or wet locations. Features. Z-Wave 800 Series and Zigbee 3.0 Controller. Creates two separate serial ports for individual Zigbee/Z-Wave setup. Supports Windows, Linux, and MacOS. Quick start. Plug Z-Stick 10 into your PC USB port which will create two serial ports for Zigbee and Z-Wave individually. Windows - Under Ports & LPT under Device Manager. Z-Stick 10 Pro shows as two COMX device (where X can be 0-1000). Linux - under cmd prompt, enter “dmesg | grep tty” which will give you a list of all tty devices connected. Z-Stick 10 Pro shows as a /dev/ttyUSB0 and ttyUSB1 typically. OSX - Choose Apple > System Preferences, then click Network. Z-Stick 10 Pro appears as two USB Modem device (/dev/cu.usbmodem). Detailed guides. You can find more indepth setup guides and other helpful for Z-Stick 10 in Aeotec’s support articles by scanning the QR code below. The guides will include various smart home software available that are compatible and how to set them up. Get help & learn more. If you are having any issues using Z-Stick 10 Pro, visit support.aeotec.com/zs10Pro or contact our support team via aeotec.com/contact. Español. Información de seguridad importante. Lea atentamente esta guía y la(s) guía(s) en línea en support.aeotec.com/zs10Pro. No seguir las recomendaciones establecidas por Aeotec Limited puede ser peligroso o causar una violación de la ley. El fabricante, importador, distribuidor y/o revendedor no será responsable de ninguna pérdida o daño resultante de no seguir cualquier instrucción de esta guía o de otros materiales. Z-Stick 10 Pro está diseñado para su uso en interiores y sólo en lugares secos. No lo utilice en lugares húmedos o mojados. Características. Controlador Z-Wave y Zigbee 3.0 Serie 800. Crea dos puertos serie independientes para la configuración individual de Zigbee/Z-Wave. Compatible con Windows, Linux y MacOS. Inicio rápido. Conecte Z-Stick 10 en el puerto USB de su PC que creará dos puertos serie para Zigbee y Z-Wave individualmente. Windows - En Puertos y LPT en el Administrador de dispositivos. Z-Stick 10 Pro se muestra como dos dispositivos COMX (donde X puede ser 0-1000). Linux - en cmd prompt, introduzca «dmesg | grep tty» que le dará una lista de todos los dispositivos tty conectados. Z-Stick 10 Pro muestra como /dev/ttyUSB0 y ttyUSB1 típicamente. OSX - Elige Apple > Preferencias del Sistema, luego haz clic en Red. Z-Stick 10 Pro aparece como dos dispositivos USB Modem (/dev/cu.usbmodem). Configuración con Home Assistant. Schnellstart. Stecken Sie den Z-Stick 10 Pro in den USB-Port Ihres PCs, wodurch zwei serielle Ports für Zigbee und Z-Wave individuell erstellt werden. Windows - Unter Ports & LPT im Geräte-Manager. Z-Stick 10 Pro wird als zwei COMX-Geräte angezeigt (wobei X 0-1000 sein kann). Linux - Geben Sie in der Eingabeaufforderung cmd „dmesg | grep tty“ ein, um eine Liste aller angeschlossenen tty-Geräte zu erhalten. Der Z-Stick 10 Pro wird normalerweise als /dev/ttyUSB0 und ttyUSB1 angezeigt. OSX - Wählen Sie Apple > Systemeinstellungen und klicken Sie dann auf Netzwerk. Der Z-Stick 10 Pro erscheint als zwei USB-Modem-Geräte (/dev/cu.usbmodem). Setup mit Home Assistant. Ausführliche Anleitungen. Ausführliche Anleitungen zur Einrichtung und andere nützliche Informationen zum Z-Stick 10 Pro finden Sie in Aeotec's Support-Artikel, indem Sie den QR-Code scannen. Die Anleitungen beinhalten Anweisungen zum Setup von kompatiblen Smart Home Softwarelösungen. Mehr Support und Auskünfte. Wenn Sie Probleme mit dem Z-Stick 10 Pro haben, besuchen Sie support.aeotec.com/zs10Pro oder kontaktieren Sie unser Support-Team über aeotec.com/contact. Deutsch. Wichtige Sicherheitsinformationen. Bitte lesen Sie diese und die Online-Anleitung(en) unter support.aeotec.com/zs10Pro sorgfältig durch. Die Nichteinhaltung der von Aeotec Limited gegebenen Empfehlungen kann gefährlich sein oder einen Verstoß gegen das Gesetz darstellen. Der Hersteller, Importeur, Distributor und/oder Wiederverkäufer haftet nicht für Verluste oder Schäden, die sich aus der Nichtbeachtung von Anweisungen in diesem Handbuch oder in anderen Materialien ergeben. Der Z-Stick 10 Pro ist nur für die Verwendung in Innenräumen und an trockenen Orten vorgesehen. Verwenden Sie ihn nicht an feuchten, nassen und/oder nässenden Orten. Merkmale. Z-Wave 800 Serie und Zigbee 3.0 Controller. Ermöglicht zwei separate serielle Ports für individuelle Zigbee/Z-Wave-Einstellungen. Unterstützt Windows, Linux und MacOS. Z-Stick 10 Pro ZWA060 English / Deutsch / Spanish / French Setup with Home Assistant. Indicator Light Button Guías detalladas. Puede encontrar más guías de configuración detalladas y otras útiles para el Z-Stick 10 en los artículos de soporte de Aeotec escaneando el código QR que se muestra a continuación. Las guías incluirán varios software de hogar inteligente disponibles que son compatibles y cómo configurarlos. Obtén ayuda y más información. Si tienes algún problema con Z-Stick 10 Pro, visita support.aeotec.com/zs10Pro o ponte en contacto con nuestro equipo de asistencia a través de aeotec.com/contact. Démarrage rapide. Branchez le Z-Stick 10 sur le port USB de votre PC, ce qui créera deux ports série pour Zigbee et Z-Wave individuellement. Windows - Sous Ports & LPT dans le Gestionnaire de périphériques. Z-Stick 10 Pro apparaît comme deux dispositifs COMX (où X peut être compris entre 0 et 1000). Linux - à l'invite de cmd, entrez « dmesg | grep tty » qui vous donnera une li…

Text truncated - open the document above for the full version.

AEOTEC LIMITED 2024.12.16 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD21046 Ref: Attestation Statements Part 2.911(d) (5) (i) Filing SUBJECT: FCC Application for FCC ID: (2AOGIZWA060) To Whom It May Concern: AEOTEC LIMITED (“the applicant”) certifies that the equipment forwhich authorization is sought is not “covered” equipment prohibited from receiving an equipmentauthorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Print name: Scott Ding

AEOTEC LIMITED 2024.12.16 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD21046 Ref: Attestation Statements Part 2.911(d) (5) (ii) Filing SUBJECT: FCC Application for FCC ID: (2AOGIZWA060) To Whom It May Concern: AEOTEC LIMITED (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Sincerely, Signature: Print name: Scott Ding

AEOTEC LIMITED Date: December 17, 2024 FCC ID: 2AOGIZWA060 Model Number: ZWA060-A, ZWA061-A To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, AEOTEC LIMITED declare that this EUT (FCC ID: 2AOGIZWA060) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). No. 24 Xinfa East Road, Xiangshan Community, Xinqiao Street, Baoan District, Shenzhen, Guangdong, People's Republic of China) Please contact me if you have any question. Sincerely, (Signed) Name / Title: Scott Ding/ manager Company: AEOTEC LIMITED Address: OFFICE 4 10/F KWAN CHART TOWER, NO. 6 TONNOCHY ROAD, WANCHAI, HK

THREE STONES MEDIA LLC U.S. Agent Letter of Attestation To: Federal Communications Commission 7435 Oakland Mills Road, Columbia, MD 21046, USA Date: 12/17/2024 Ref: Attestation Statement – Part2.911(d)(7) filing FCC ID: 2AOGIZWA060 AEOTEC LIMITED (“the applicant”) certifies that, as of the date of the filing of the application, THREE STONES MEDIA LLC (“the agent”) is our designated U.S. agent for service of process for the abovereference FCC ID. The applicant accepts to maintain an agent for service of process in the United States forno less than one year after either the grantee has permanently terminated all marketing and importation of theapplicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicialproceeding involving the equipment, whichever is later. The applicant further acknowledges it is ourresponsibility to inform the FCC whenever the agent information changes. THREE STONES MEDIA LLC ("the agent) understand it is the agent's obligation to accept service of process in the United States for matters related to the applicable equipment, and at the physical U.S. address and email address. Designated U.S. Agent Company Name: THREE STONES MEDIA LLC FRN: 0033401761 GC: 2A99E Address: 1200 Broadway St. APT 329, Los Angeles, CA90015 Signature: Contact Person: Sijie Zhang Tel: +1 267 909 3692 Email: [email protected] Applicant Company Name: AEOTEC LIMITED Address: OFFICE 4 10/F KWAN CHART TOWER, NO. 6 TONNOCHY ROAD, WANCHAI, HK Signature: Contact Person: Scott Ding FRN: 0027036524 Tel: 00852-27935511 Email: [email protected]

AEOTEC LIMITED Family models difference declaration Product Name: Z-Stick 10 Pro/Z-Stick 10 Trade Name: AEOTEC Model Name: ZWA060-A Family Model: ZWA061-A Difference declaration: All models are the same circuit and RF module, except for the shell nameplate. We (AEOTEC LIMITED) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.), same mechanical structure and design (including product enclosure, materials, etc.), except for the shell nameplate. Regards, Signature Name: Scott DingDate: 12/24/2024

G:\ 资料同步 \Engineering Spec\Z-Stick 10 Pro\ 认证 \ 安规 \ 签字 \S24102107105001 AEOTEC LIMITED ZStick 10 Pro(SRD 915+2.4) ZWAO60 FCC ID RF\FCC POA Letter.docx ( AEOTEC LIMITED ) Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 Date: 12/17/2024 SUBJECT: FCC Application for FCC ID: 2AOGIZWA060 To Whom It May Concern: We, the undersigned, hereby authorize Alex Li at Shenzhen NTEK Testing Technology Co., Ltd. on our behalf, to apply to the Federal Communications Commission on our equipment. Any and all acts carried out by Shenzhen NTEK Testing Technology Co., Ltd. on our behalf shall have the same effect as acts of our own. This is to advise that we are in full compliance with the Anti- Drug Abuse Act. We, the applicant, are not subject to a denial of federal benefits pursuant to Section 5301 of the Anti-Drug Act of 1988, 21 USC853a, and no party to the application is subject to a denial of federal benefits pursuant to that section. Regards, (signature) (printed name): Scott Ding

< AEOTEC LIMITED > Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 12/17/2024 Subject; Request for Confidentiality FCC ID: 2AOGIZWA060 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Operational Description Tune up procedure BOM In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Scott Ding Title: manager Email: [email protected]

ATTACHMENT PHOTOGRAPHS OF EXT Photo 1 Photo 2 Photo 3 Photo 4 Photo 5 Photo 6

Z-Stick 10 AL403006102001 AL001 2024.07.23LiyaAA Z-Stick 10 Model: ZWA061-A FCC ID: 2AOGIZWA060 Frequency: 908.42MHz Assembled in China 17.8 mm 49.17 mm

ATTACHMENT PHOTOGRAPHS OF INT Photo 1 Photo 2 Photo 3 Photo 4 Zigbee ANT SRD 908-920 ANT Photo 5

FCC ID:2AOGIZWA060 Portable device According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. ZIGBEE: Operation Frequency: 2405-2480MHz Antenna Type: Built-in Antenna antenna gain: 2.36dBi; Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 2.405 4.472.804.5±15.53.55<51.100493.00YES 2.440 3.642.314±153.16<50.987933.00YES 2.480 42.514±153.16<50.995993.00YES zigbee SRD Operation Frequency: 908.4-920MHz Max Transmit power: Frequency (MHz) EIRP power (dBuV/m) EIRP power (dBm) 920 90.03 -5.23 EIRP=E-104.8+20log(D) EIRP=conducted power + antenna gain antenna gain: 1.57dBi; Modulation Channel Freq. (GHz) Conduct ed power (dBm) Conducte d power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculatio n SAR Exclusion threshold SAR test exclusion 0.920 -6.8 0.21-6.5±1-5.50.28<50.054073.00YES GFSK Conclusion: For the max result : 1.10049 ≤ 3.0 for 1g SAR, SAR is not required. For the max result : 0.05407 ≤ 3.0 for 1g SAR, SAR is not required. Signature: Date: 2024-12-10 NAME AND TITLE (Please print or type): alex li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.
