Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.
Product Number: A1770 51005003793 V01 @AnkerDeutschland @AnkerJapan @Anker @AnkerOcial @Anker_JP @anker_ocial @anker_jp For tutorial videos, FAQs, manuals, and more information, please visit: Or scan the QR code below: https://support.anker.com USER MANUAL Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Live Charged. English 01 Français 13 日本語 24 0201 What's in the Box Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Dust-proof BagAC Charging Cable Car Charging CableSolar Charging CableUser Manual 2 1 3 5 4 6 Overview Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Dust-proof BagAC Charging Cable Car Charging CableSolar Charging CableUser Manual 2 1 3 5 4 6 Output Ports:Input Ports: 1 IoT Button 4 AC Output Ports 2 Car Socket 5 XT-60 DC Input Port 3 USB PortsAC Input Port Recharging Your Power Station AC recharging (1000W Max) Recharge your Power Station by connecting to a wall outlet with the AC charging cable. Solar panel recharging (600W Max) Recharge your Power Station by connecting up to 3 Anker solar panels in parallel with a solar charging cable. Car recharging (120W Max) Recharge your Power Station by connecting to a car's output port with the car charging cable. When your portable power station only has 1% battery remaining, the Remaining Battery indicators will fl icker to remind you to recharge the product. 0403 Powering Your Devices AC charging Press the AC button and connect your devices to the AC output ports. on / o on / o USB charging Connect your devices to the USB ports. on / o on / o Car socket charging Turn on the car socket and connect your devices to start charging. on / o on / o Uninterruptible Power Supply (UPS) To use the UPS function, connect your Power Station to a wall outlet with the AC charging cable, then press the button and connect your devices via the AC output ports. on 2S SOS x1 x2 x3 o on Power Saving Mode Switching on the power saving mode prevents wasting power by automatically turning o the Power Station once all your devices are fully charged. Switching o the power saving mode will enable stable charging over an extended period, such as for time- lapse photography or for sleeping with a CPAP machine. on 2S SOS x1 x2 x3 o on The Anker App for Smart Control You can remotely control your power station using the Anker App. Please download the app and its user manual by scanning this QR code. Connect the device to a network before using the app for the fi rst time. After connecting successfully, you can connect your devices o -grid. 0605 Light Ambient light Press the button once to turn on the ambient light, and press again up to 2 times to switch between brightness levels. on 2S SOS x1 x2 x3 o on SOS mode Press and hold the button for 2 seconds to turn on SOS mode. on 2S SOS x1 x2 x3 o on LCD Screen Guide 1 2 34567891011 12 13 1415 Current Output Power Current Input Power IoT Press the IoT button for 2 seconds and connect your devices through the app when this icon appears on the screen. Remaining Battery for Expansion Battery When the expansion battery is connected successfully, this icon appears on the screen. USB-A Output Port USB-C Output Port Car Charging AC Charge and Voltage Frequency Low-Temperature Alert When this icon shows, stop using the power station until the icon disappears. 10 High-Temperature Alert When this icon shows, stop using the power station and let it cool down until the icon disappears. 11 Overload Warning This icon appears when a port is overloaded. The port will be turned o to avoid any damage. Please remove the device causing overload. 12 Estimated Time to Fully Recharge 13 Estimated Time for Battery to Deplete 14 Remaining Battery for Power Station 15 Power Saving Mode Trouble Shooting AC recharging failure When AC recharging is unavailable, check to see if the overload protection switch is switched on. If so, press it down to reset, and then recharging can resume. AC charging failure If AC charging is unavailable, it's possible that the connected devices exceed 1800W. Try unplugging one or more of the connected devices to see if this resolves the issue. Resetting your Power Station If your Power Station isn't working correctly, press the reset button (located on the front of the product) for 1 second for a factory reset. If the Power Station still doesn't work, please visit [email protected] 0807 FAQ Q1: Why does the Power Station's battery drain even when no devices are connected? When the AC and Car Socket control button is turned on, even if no devices are being charged, there will still be a certain amount of no-load power consumption. To avoid this, make sure the AC and Car Socket charging button is o or turn on the power saving mode when you're not using the Power Station Q2: What's the max power output of the AC output ports? The AC output ports can deliver a maximum of 1800W to connected devices. Q3: Can I recharge the product while charging connected devices? Yes. Q4: Can this product power a CPAP machine? Yes, but make sure to turn o the power saving mode fi rst. Q5: What kind of solar charger can charge this product? Any 11-60V solar charger with an XT-60 female connector. Specifi cations Cell Capacity 1229 Wh AC Input Voltage100-120V~ 12A Max, 50Hz/60Hz AC Input Power (Charging)1000W Max AC Input Power (Bypass Mode)1440W Max Solar Panel Input 11-32V 10A; 32V-60V12.5A (600W Max) Car Charger Output12V 10A Max AC Output120V~ 15A, 60Hz, 1800W Max USB-A Output5V 2.4A (2.4A Max Per Port) USB-C Output (100W)5V 3A/9V3A/15V3A/20V3A/20V5A (100W Max) USB-C Output (60W)5V 3A/9V3A/15V3A/20V3A (60W Max) UPS<20ms Discharging Temperature-4°F-104°F / -20°C-40°C Charging Temperature32°F-104°F / 0°C-40°C Size46.3*28.8*23.7 cm/ 18.2*11.3*9.3 inches Net Weight19.1 kg/ 42.1 lb Attention Not permitted on aircraft. IMPORTANT SAFETY INSTRUCTIONS WARNING - When using this product, basic precautions should always be followed, including the following: Read all the instructions before using …
Text truncated - open the document above for the full version.
SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 1 of 5 Appendix External Photos for SZCR2305001642AT FCC ID: 2AOKB-A1770P SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 2 of 5 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 3 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 4 of 5 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A02 Rev.A/0 Page: 5 of 5 - End of the Appendix -
Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Model: A1770 Rated Capacity: 51.2Vdc 24000mAh/1228.8Wh AC Input Voltage: 100-120V~12A Max, 50Hz/60Hz USB-C Output 1: 5V⎓3A/9V⎓3A/15V⎓3A/20V⎓3A/20V⎓5A (100W Max) USB-A Output: 5V⎓2.4A ( 2.4A Max Per Port USB-C Output 2: 5V⎓3A/9V⎓3A/15V⎓3A/20V⎓3A (60W Max) XT60 Input: 11-32V⎓10A; 32V-60V⎓12.5A (600W Max) AC Output (Bypass Mode): 100-120V~12A Max, 50Hz/60Hz, 1440W Max AC Output (Inverter Mode): 120V~15A, 60Hz, 1800W Max AC Input Power (Bypass Mode): 1440W Max AC Input Power (Charging): 1000W Max Car Charger Output:12V⎓10A Discharging Temperature: -4°F-104°F/-20°C-40°C Charging Temperature: 32°F-104°F/0°C-40°C CAN ICES-003 (B)/NMB-003(B) Contains FCC ID: 2A6CI-DB809S Contains IC : 28745-DB809S Anker Innovations Limited I Made in China The device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1)This device may not cause harmful interference, and (2) this device must accept any interferences received, including interference that may cause undesired operation. WARNING - Do not overcharge the internal battery. See Instruction Manual. Do not smoke, strike a match, or cause a spark in the vicinity of the power pack. Only charge the internal battery in a well ventilated area. CAUTION - Risk of Injury To Persons. Do not use this product if the power cord or the battery cables are damaged in any way. CAUTION - This device is not intended for use in a commercial repair facility. CAUTION: Risk of Electric Shock. Connect only to properly grounded outlets. DANGER! This device is not waterproof. Use indoors if it is raining or the ground is wet outside. AVERTISSEMENT - Ne pas surcharger la batterie interne. Consulter le manuel d’utilisation.Il ne faut pas fumer, allumer une allumette ou produire des étincelles à proximité du bloc d’alimentation. Charger la batterie uniquement dans un endroit bien aéré. MISE EN GARDE : Risque de blessure aux personnes. Ne pas utiliser ce produit si le cordond’alimentation ou les câbles de batterie sont endommagés de quelque façon. MISE EN GARDE : Le dispositif n’est pas destiné à être utilisé dans un atelier de réparation commercial. MISE EN GARDE: Risque de décharge électrique. Brancher l'uni té uniquement à des prises de courant correctement mises à la masse.DANGER ! Cet appareil n’est pas étanche. Utilisez-le à l’intérieur s’il pleut ou si le sol est humide à l’extérieur. FCC ID: 2AOKB-A1770P
SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 1 of 7 Appendix Internal Photos for SZCR2305001642AT FCC ID: 2AOKB-A1770P SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 2 of 7 EUT Constructional Details (EUT Photos) SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 3 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 4 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 5 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 6 of 7 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A03 Rev.A/0 Page: 7 of 7 - End of the Appendix - Antenna
SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164202 Page: 1 of 11 Keny Xu EMC Laboratory Manager RF EXPOSURE EVALUATION REPORT Application No.: SZCR2305001642AT Applicant: Anker Innovations Limited Address of Applicant: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Address of Manufacturer: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Equipment Under Test (EUT): EUT Name: Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Model No.: A1770 Trade Mark: Anker FCC ID: 2AOKB-A1770P Standard(s) : FCC Rules 47 CFR §2.1091 KDB 447498 D04 interim General RF Exposure Guidance v01 Date of Receipt: 2023-05-26 Date of Evaluation: 2023-05-30 to 2023-06-07 Date of Issue: 2023-06-09 Evaluation Result: Pass* * In the configuration evaluated, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164202 Page: 2 of 11 Revision Record Version Chapter Date Modifier Remark 01 2023-06-09 Original Authorized for issue by: Charlie Dai/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164202 Page: 3 of 11 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 General Description of E.U.T. ............................................................................................................ 4 3.2 Details of E.U.T. ................................................................................................................................. 4 3.3 Separation Distance ........................................................................................................................... 4 3.4 Test Location ...................................................................................................................................... 5 3.5 Test Facility ........................................................................................................................................ 5 3.6 Deviation from Standards ................................................................................................................... 5 3.7 Abnormalities from Standard Conditions ........................................................................................... 5 4 FCC Radiofrequency radiation exposure limits .................................................................................... 6 4.1 Blanket 1 mW Blanket Exemption ...................................................................................................... 6 4.2 MPE-based Exemption ...................................................................................................................... 6 4.3 SAR-based Exemption ....................................................................................................................... 7 5 Measurement and Calculation ............................................................................................................... 11 5.1 Maximum transmit power ................................................................................................................. 11 5.2 RF Exposure Calculation ................................................................................................................. 11 SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164202 Page: 4 of 11 3 General Information 3.1 General Description of E.U.T. Product Type: Portable device Mobile device Fixed device 3.2 Details of E.U.T. Power supply: AC input 100-120V 50/60Hz Max. 12A Solar/ Car input: 11-32V 10A, 32-60V 12.5A 600W Max. USB-C1 output: 5V/3A, 9V/3A, 15V/3A, 20V/3A, 20V/5A 100W Max. USB-C2 output: 5V/3A, 9V/3A, 15V/3A,20V/3A 60W Max. USB-A output: 5V/2.4A (2.4A Max. Per Port) AC output:120V 15A 60Hz 1800W Max. Car charger output: 12V/10A Max. Cable(s): AC cable 125cm unshielded Car input cable 314cm unshielded Solar input cable 257cm Operation Frequency: 2402MHz to 2480MHz Bluetooth Version: V5.0 LE Modulation Type: GFSK Data Rate: 1Mbps Number of Channels: 40 Channel Spacing: 2MHz Antenna Type: PCB Antenna Antenna Gain: 1.72dBi Remark: The information in this section is provided by the applicant or manufacturer, SGS is not liable to the accuracy, suitability, reliability or/and integrity of the information. 3.3 Separation Distance Minimum test separation distance: 20cm Remark: This minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164202 Page: 5 of 11 3.4 Test Location All tests were performed at: SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Nanshan District, Shenzhen, Guangdong, China. 518057. Tel: +86 755 2601 2053 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.5 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 3816.01) SGS-CSTC Standards Technical Services C…
Text truncated - open the document above for the full version.
DB809S BLE-Module PCB Antenna Specification 1. Antenna Description: Antenna plate Omni-directional Make name / Model name BOBLINKER / DB809S Antenna peak gain 1.72dBi Frequency range 2.402MHz ~2.480MHz Connect type Direct Connect Impedance 50 Ohm Antenna length 31.9mm Manufacture SHENZHEN DADOUTEK ELECTRONICS CO.,LTD 2. Picture of antenna 3. Passive Test For 2.4G Passive Test For 2.4G Fre(MHz) Effi(%) Gain(dBi) 2400 47.40 1.37 2450 49.60 1.29 2500 50.10 1.64 4. Antenna Radiation Pattern
SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164201 Page: 1 of 61 Keny Xu EMC Laboratory Manager TEST REPORT Application No.: SZCR2305001642AT Applicant: Anker Innovations Limited Address of Applicant: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Address of Manufacturer: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Equipment Under Test (EUT): EUT Name: Anker SOLIX F1200 Portable Power Station (PowerHouse 757) Model No.: A1770 Trade Mark: Anker FCC ID: 2AOKB-A1770P Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2023-05-26 Date of Test: 2023-05-30 to 2023-06-07 Date of Issue: 2023-06-09 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164201 Page: 2 of 61 Revision Record Version Chapter Date Modifier Remark 01 2023-06-09 Original Authorized for issue by: Charlie Dai/Project Engineer Eric Fu/Reviewer SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164201 Page: 3 of 61 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Power Line (150kHz-30MHz) 47 CFR Part 15, Subpart C 15.247 ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Below 1GHz ANSI C63.10 (2013) Section 6.4,6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions Above 1GHz ANSI C63.10 (2013) Section 6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-01 Rev. A/0 Aug01,2022 Report No.: SZCR230500164201 Page: 4 of 61 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ........................................................................................................................................... 3 3 Contents .................................................................................................................................................... 4 4 General Information .................................................................................................................................. 6 4.1 Details of E.U.T. ................................................................................................................................. 6 4.2 Description of Support Units .............................................................................................................. 6 4.3 Measurement Uncertainty .................................................................................................................. 7 4.4 Test Location ...................................................................................................................................... 8 4.5 Test Facility ........................................................................................................................................ 8 4.6 Deviation from Standards ................................................................................................................... 8 4.7 Abnormalities from Standard Conditions ........................................................................................... 8 5 Equipment List .......................................................................................................................................... 9 6 Radio Spectrum Technical Requirement ............................................................................................. 12 6.1 Antenna Requirement ...................................................................................................................... 12 6.1.1 Test Requirement: ....................................................................................................................... 12 6.1.2 Conclusion ................................................................................................................................... 12 7 Radio Spectrum Matter Test Results .................................................................................................... 13 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) ............................................................. 13 7.1.1 E.U.T. Operation .......................................................................................................................... 13 7.1.2 Test Mode Description ................................................................................................................. 13 7.1.3 Test Setup Diagram ..................................................................................................................... 14 7.1.4 Measurement Procedure and Data..................................................................…
Text truncated - open the document above for the full version.
SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 1 of 3 Appendix Test Setup Photos for SZCR2305001642AT FCC ID: 2AOKB-A1770P SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 2 of 3 Test Setup Photo Conducted Emissions at AC Power Line (150kHz-30MHz) Radiated Spurious Emissions Below 1GHz SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch SZEMC-TRF-A04 Rev.A/0 Page: 3 of 3 Radiated Spurious Emissions Above 1GHz - End of the Appendix -
No.1 Workshop, M-10, Middle Section Science & Tech · Shenzhen · China
| # | Rule Parts | Frequency Range | Power Output |
|---|---|---|---|
| 1 | 15C | 2.40 GHz - 2.48 GHz | 1.30 mW |
