2AOKB-A2561Wireless Charger

Anker Innovations Limited

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: Dec 03, 2020
Application Purpose: Original Equipment
Date of Application: Dec 03, 2020
Equipment Note: Wireless Charger
Frequency Range: 0.11010000 - 0.20500000
Company: Anker Innovations Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

External Photos

FCCID:2AOKB-A2561

ID Label/Location Info

LabelLocationOnEUT Label ProductName:WirelessCharger ModelNo.:A2561 FCCID:2AOKB-A2561 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

Internal Photos

FCCID:2AOKB-A2561 ANT ANT

Operational Description

version01 AnkerInnovationsLimited DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:A2561 FCCID:2AOKB-A2561 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsforinternalantennatype(s) describedbelow: ModelNo.ofantenna:A2561 Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname: AnkerInnovationsLimited Address:Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, HongKong City:Kowloon ZIP/Postalcode:N/A Country:HongKong Place:KowloonDate: 2020-12-02 Signature:

RF Exposure Info

ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page1of12 Code:AB-RF-05-a FCCTESTREPORT ClientName:AnkerInnovationsLimited Address: Room1318-19,HollywoodPlaza,610NathanRoad, Mongkok,Kowloon,Hongkong ProductName:WirelessCharger Date:Dec.02,2020 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page2of12 Code:AB-RF-05-a Contents 1.GeneralInformation ............................................................................................................................................... 4 1.1.ClientInformation ....................................................................................................................................... 4 1.2.DescriptionofDevice(EUT) ..................................................................................................................... 4 1.3.AuxiliaryEquipmentUsedDuringTest ................................................................................................... 5 1.4.TestEquipmentList .................................................................................................................................... 5 1.5.MeasurementUncertainty ......................................................................................................................... 5 1.6.DescriptionofTestFacility ........................................................................................................................ 6 2.MeasurementandResult ..................................................................................................................................... 7 2.1.Requirements .............................................................................................................................................. 7 2.2.TestSetup .................................................................................................................................................... 8 2.3.TestProcedure ............................................................................................................................................ 8 2.4.TestResult ................................................................................................................................................... 8 2.4.1.EquipmentApprovalConsiderationsitem5.bofKDB680106D01v03. ...................................... 8 2.4.2.EnvironmentalevaluationandexposurelimitaccordingtoFCCCFR47part1,1.1307(b), 1.1310 ................................................................................................................................................................ 10 ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page3of12 Code:AB-RF-05-a TESTREPORT Applicant: AnkerInnovationsLimited Manufacturer: AnkerInnovationsLimited ProductName: WirelessCharger ModelNo.: A2561 TradeMark:ANKER Rating(s): Input:DC5V,2.4A/DC9V,2A/DC12V,2A/DC15V,2A Mobilephoneoutput:DC5V,1A/DC9V,1.1A/DC12V,1.25AMax Powersection:5W/7.5W/10W/15W Headphoneoutput:DC5V,1A TestStandard(s): FCCPart1.1310,1.1307(b) TestMethod(s): KDB680106D01RFExposureWirelessChargingAppsv03 ThedevicedescribedaboveistestedbyShenzhenAnbotekComplianceLaboratoryLimitedto determinethemaximumemissionlevelsemanatingfromthedeviceandtheseverelevelsofthedevice canendureanditsperformancecriterion.Themeasurementresultsarecontainedinthistestreportand ShenzhenAnbotekComplianceLaboratoryLimitedisassumedfullofresponsibilityfortheaccuracy andcompletenessofthesemeasurements.Also,thisreportshowsthattheEUT(EquipmentUnder Test)istechnicallycompliantwiththeFCCPart1.1307&KDB680106D01requirements. Thisreportappliestoabovetestedsampleonlyandshallnotbereproducedinpartwithoutwritten approvalofShenzhenAnbotekComplianceLaboratoryLimited. DateofReceipt Nov.11,2020 DateofTestNov.11~Dec.01,2020 PreparedBy (Engineer/YiliaZhong) Reviewer (Supervisor/BiboZhang) Approved&AuthorizedSigner (Manager/KingkongJin) ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page4of12 Code:AB-RF-05-a 1.GeneralInformation 1.1.ClientInformation 1.2.DescriptionofDevice(EUT) ProductName : WirelessCharger ModelNo.:A2561 TradeMark:ANKER TestPowerSupply: AC120V,60Hzforadapter TestSampleNo.: 1-2-1(NormalSample),1-2-1(EngineeringSample) Product Description : OperationFrequency:110.1-205KHz ModulationType:FSK AntennaType:InductiveloopcoilAntenna AntennaGain(Peak):0dBi Remark:1)Foramoredetailedfeaturesdescription,pleaserefertothemanufacturer’sspecifications ortheUser’sManual. Applicant:AnkerInnovationsLimited Address: Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, Hongkong Manufacturer:AnkerInnovationsLimited Address : Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, Hongkong Factory:GopodGroupHoldingLimited. Address : 4-5-6/F,Building8&1F,Building3#,LianJianScienceandTechnology IndustrialPark,HuaRongRd,TongshengCommunity,DaLangStreet, LongHuaDistrict,Shenzhen ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page5of12 Code:AB-RF-05-a 1.3.AuxiliaryEquipmentUsedDuringTest N/A: 1.4.TestEquipmentList ItemEquipmentManufacturerModelNo.SerialNo.LastCal.Cal.Interval 1MagneticfieldmeterNARDAELT-400423623Dec.24,20183Year 2E-FieldProbeNardaEF0391Q15221Nov.17,20203Year 3H-FieldProbeNardaHF3061Q15835Nov.17,20203Year 1.5.MeasurementUncertainty RadiationUncertainty: Ur=3.9dB(Horizontal) Ur=3.8dB(Vertical) ConductionUncertainty: Uc=3.4dB ReportNo.:18220WC00167302FCCID:2AOKB-A2561Page6of12 Code:AB-RF-05-a 1.6.DescriptionofTestFacility Thetestfacilityisrecognized,certified,oraccreditedbythefollowingorganizations: FCC-RegistrationNo.:184111 ShenzhenAnbotekComplianceLaboratoryLimited,EMCLaboratoryhasbeenregistedandfully describedinareportfiledwiththe(FCC)FederalCommunicationsCommission.Theacceptanceletter fromtheFCCismaintainedinourfiles.RegistrationNo.184111,September30,2020. ISED-RegistrationNo.:8058A ShenzhenAnbotekComplianceLaboratoryLimited,EMCLaboratoryhasbeenregisteredandfully describedinareportfiledwiththe(ISED)Innovation,ScienceandEconomicDevelopmentCanada.The acceptanceletterfromtheISEDismaintainedinourfiles.Registration8058A,S…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:18220WC00167301FCCID:2AOKB-A2561Page1of23 Code:AB-RF-05-a FCCTESTREPORT ClientName:AnkerInnovationsLimited Address: Room1318-19,HollywoodPlaza,610NathanRoad, Mongkok,Kowloon,Hongkong ProductName:WirelessCharger Date:Dec.02,2020 ShenzhenAnbotekComplianceLaboratoryLimited ReportNo.:18220WC00167301FCCID:2AOKB-A2561Page2of23 Code:AB-RF-05-a Contents 1.GeneralInformation ............................................................................................................................................... 4 1.1.ClientInformation ....................................................................................................................................... 4 1.2.DescriptionofDevice(EUT) ..................................................................................................................... 4 1.3.AuxiliaryEquipmentUsedDuringTest ................................................................................................... 5 1.4.DescriptionofTestModes ........................................................................................................................ 5 1.5.DescriptionOfTestSetup ......................................................................................................................... 6 1.6.TestEquipmentList .................................................................................................................................... 7 1.7.MeasurementUncertainty ......................................................................................................................... 8 1.8.DescriptionofTestFacility ........................................................................................................................ 8 2.SummaryofTestResults ..................................................................................................................................... 9 3.ConductedEmissionTest ................................................................................................................................... 10 3.1.TestStandardandLimit .......................................................................................................................... 10 3.2.TestSetup .................................................................................................................................................. 10 3.3.TestProcedure .......................................................................................................................................... 10 3.4.TestData .................................................................................................................................................... 10 4.RadiationSpuriousEmissionandBandEdge ................................................................................................ 15 4.1.TestStandardandLimit .......................................................................................................................... 15 4.2.TestSetup .................................................................................................................................................. 15 4.3.TestProcedure .......................................................................................................................................... 16 4.4.TestData .................................................................................................................................................... 17 5.AntennaRequirement ......................................................................................................................................... 22 5.1.TestStandardandRequirement ............................................................................................................ 22 5.2.AntennaConnectedConstruction .......................................................................................................... 22 APPENDIXI--TESTSETUPPHOTOGRAPH ................................................................................................... 23 APPENDIXII--EXTERNALPHOTOGRAPH ..................................................................................................... 23 APPENDIXIII--INTERNALPHOTOGRAPH ..................................................................................................... 23 ReportNo.:18220WC00167301FCCID:2AOKB-A2561Page3of23 Code:AB-RF-05-a TESTREPORT Applicant: AnkerInnovationsLimited Manufacturer: AnkerInnovationsLimited ProductName: WirelessCharger ModelNo.: A2561 TradeMark:ANKER Rating(s): Input:DC5V,2.4A/DC9V,2A/DC12V,2A/DC15V,2A Mobilephoneoutput:DC5V,1A/DC9V,1.1A/DC12V,1.25AMax Powersection:5W/7.5W/10W/15W Headphoneoutput:DC5V,1A TestStandard(s): FCCPart15SubpartC2019,Paragraph15.209 TestMethod(s): ANSIC63.10:2013 ThedevicedescribedaboveistestedbyShenzhenAnbotekComplianceLaboratoryLimitedto determinethemaximumemissionlevelsemanatingfromthedeviceandtheseverelevelsofthedevice canendureanditsperformancecriterion.Themeasurementresultsarecontainedinthistestreportand ShenzhenAnbotekComplianceLaboratoryLimitedisassumedfullofresponsibilityfortheaccuracy andcompletenessofthesemeasurements.Also,thisreportshowsthattheEUT(EquipmentUnder Test)istechnicallycompliantwiththeFCCPart15SubpartCrequirements. Thisreportappliestoabovetestedsampleonlyandshallnotbereproducedinpartwithoutwritten approvalofShenzhenAnbotekComplianceLaboratoryLimited. DateofReceipt Nov.11,2020 DateofTest Nov.11~Dec.01,2020 PreparedBy (Engineer/YiliaZhong) Reviewer (Supervisor/BiboZhang) Approved&AuthorizedSigner (Manager/KingkongJin) ReportNo.:18220WC00167301FCCID:2AOKB-A2561Page4of23 Code:AB-RF-05-a 1.GeneralInformation 1.1.ClientInformation Applicant:AnkerInnovationsLimited Address: Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, Hongkong Manufacturer:AnkerInnovationsLimited Address : Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, Hongkong Factory:GopodGroupHoldingLimited. Address : 4-5-6/F,Building8&1F,Building3#,LianJianScience…

Text truncated - open the document above for the full version.

Test Setup Photos

FCCID:2AOKB-A2561 PhotoofConductedEmissionMeasurement PhotoofRadiationEmissionTest PhotoofMPEMeasurement
