2AOKB-A2596PowerWave Sense 2-in-1 Station

Product Number: A2596 51005002836 V01 For FAQs and more information, please visit: anker.com/support @Anker Deutschland @Anker Japan @Anker @AnkerOcial @Anker_JP @anker_ocial @anker_jp English01 Deutsch06 Español09 Français12 Italiano15 Português18 Pусский 21 Türk24 日本語 26 한국어 28 简体中文 31 繁體中文 33 ية ِ ب َ ر َ لع 35 ית ִ בר ִ ע 39 0201 EN LED IndicatorsStatus Solid for 3 seconds, then turns offConnected to power Solid blueCharging your devices or fully charged Flashing blue • Detected metal objects • Overvoltage or undervoltage protection • Incompatible AC adapter connected, indicating that you need to switch to a Quick Charge 2.0/3.0 or Power Delivery adapter T • You cannot charge your device wirelessly when using an ultra-thick (>4 mm) protective phone case or a case with a pop socket. • Connect the wireless charger to a Quick Charge 2.0/3.0 or Power Delivery wall adapter. Do not connect to a 5V/1A wall charger or a USB port on a computer as it may affect the wireless charging function. • Do not place any foreign objects between your device and the wireless charger’s surface, including metal pads on a car mount, magnetic cards, door keys, coins, NFC cards or other metal objects, as they could potentially demagnetize the wireless charger, affect the charging speed, or cause overheating. • Wireless chargers make charging more convenient than wired chargers, but confined by current wireless technology, their charging speed is slower than that of wired chargers. • High temperatures will reduce charging speed and restrict power. It is recommended that you charge your device in environments with temperatures below 35°C / 95°F. Important Safety Instructions Please refer to the electrical and safety information on the bottom before installing or operating the product. • Avoid dropping. • Do not disassemble. • Do not expose to liquids. • This product is suitable for moderate climates only. • The maximum ambient temperature during use of this product must not exceed 40°C. • Open flame sources, such as candles, must not be placed on this product. • Only use a dry cloth or brush to clean this product. • For the safest and fastest charge, use original or certified cables. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and 0403 receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio / TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator & your body. Product Name: PowerWave Sense 2-in-1 Station Model: A2596 The following importer is the responsible party (for FCC matters only). Company Name: Fantasia Trading LLC Address: 5350 Ontario Mills Pkwy, Suite 100, Ontario, CA 91764 Telephone: +1 800 988 7973 IC Statement This device complies with RSS-216 of Industry Canada. Operation is subject to the condition that this device does not cause harmful interference. RSS-Gen Issue 5 March 2019 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. RF exposure statement: The equipment complies with IC Radiation exposure limit set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 10cm between the radiator and your body. This device complies with Industry Canada license-ICES-003. Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. This digital apparatus complies with CAN ICES-003(B)/NMB-003(B). Declaration of Conformity Hereby, Anker Innovations Limited declares that the product type A2596 is in compliance with Directives 2014/53/EU & 2011/65/ EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.anker.com/ GB Declaration of Conformity Hereby, Anker Innovations Limited declares that the product type A2596 is in compliance with Radio Equipment Regulations 2017 and The Restriction of the Use of …
