2AOKB-A2598BAnker 335 Wireless Charger (3-in-1 Station)

01020304 EN LED Indicators Status Two LED lights stay blue for 3 seconds, then turn off Connected to power The left LED light stays blue for 6 seconds, then turns off Charging your phone The right LED light stays blue for 6 seconds, then turns off Charging your earbuds Flashing blue • • Metal objects detected • • Overvoltage or undervoltage protection • • Incompatible AC adapter connected, indicating that you need to switch to a Quick Charge 2.0/3.0 or Power Delivery adapter T • • You cannot charge your device wirelessly in these scenarios: using a case with a magnetic/iron plate; using a case with a pop socket; using an ultra-thick (> 5 mm) protective phone case. • • Connect the wireless charger to a Quick Charge 2.0/3.0 or Power Delivery wall adapter. Do not connect to a 5V/1A wall charger or a USB port on a computer as it may affect the wireless charging function. • • Do not place any foreign objects between your device and the wireless charger’s surface, including metal pads on a car mount, magnetic cards, door keys, coins, NFC cards or other metal objects, as they could potentially demagnetize the wireless charger, affect the charging speed, or cause overheating. • • Wireless charging products make charging more convenient than wired chargers, but confined by current wireless technology, their charging speed is slower than that of wired chargers. • • High temperatures will reduce charging speed and restrict power. It is recommended that you charge your device in environments with temperatures below 40°C / 104°F. Important Safety Instructions Please refer to the electrical and safety information on the bottom before installing or operating the product. • • Avoid dropping. • • Do not disassemble. • • Do not expose to liquids. • • This product is suitable for moderate climates only. • • The maximum ambient temperature during use of this product must not exceed 40°C. • • Open flame sources, such as candles, must not be placed on this product. • • Only use a dry cloth or brush to clean this product. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio / TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 cm between the radiator & your body. Product Name: Anker 335 Wireless Charger (3-in-1 Station) Model: A2598 The following importer is the responsible party (for FCC matters only). Company Name: Fantasia Trading LLC Address: 5350 Ontario Mills Pkwy, Suite 100, Ontario, CA 91764 Telephone: +1 800 988 7973 IC Caution Radio Standards Specification RSS-Gen, issue 5 This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. RF exposure statement: The equipment complies with IC Radiation exposure limit set forth for uncontrolled environment. This equipment should be installed and operated with minimum distance 10cm between the radiator and your body. Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation, Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas causer d'interférences. (2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement indésirable de l'appareil. Déclaration d'exposition RF: L'équipement est conforme à la limite d'exposition aux radiations de la IC établie pour un environnement non contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 10 cm entre le radiateur et votre corps. This product complies with the radio interference requirements of the European Community. Declaration of Conformity Hereby, Anker Innovations Limited declares that this product is in compliance with Directives 2014/53/EU & 2011/65/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.anker.com/ GB Declaration of Conformity Hereby, Anker Innovations Limited declares that the product type A2598 is in compliance with Radio Equipment Regulations 2017 and The Restriction of the Use of Certain Hazardous Substances in Electrical and Elect…

Text truncated - open the document above for the full version.

AnkerInnovationsLimited * the applicant must designate a contact located in the United States for purposes of acting as the applicant’s agent for service of process, regardless of whether the applicant is a domestic or foreign entity. An applicant located in the United States may designate itself as the agent for service of process. U.S. Agent Designation for Service of Process - Certification Attestation Letter 2/20/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AOKB-A2598B Per section 2.911(d)(7) of the FCC rules, Anker Innovations Limited (“theapplicant”) certifies that the equipment for which authorization is sought is designated to thefollowing U.S. agent* for service of process: Company Name: Fantasia Trading LLC FCC Registration Number (FRN): 0033423005 Physical U.S. Company Address: 5350 Ontario Mills Pkwy, STE 100, Ontario,CA 91764, United States Contact Person: Louis Qi Agent Email Address: [email protected] The above contact person accepts the obligation for service of process. The applicant accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any Commission-related proceeding involving the equipment. Applicant Signed:Agent Signed (if different from Applicant): Signed:Signed: Printed name: louis QiPrinted name: louis Qi Title: General ManagerTitle: Compliance Manager Company Name: Anker Innovations LimitedCompany Name: Fantasia Trading LLC Date: 2/20/2023Date: 2/20/2023

Anker Innovations Limited Covered Equipment Certification Attestation Letter 2/13/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AOKB-A2598B Anker Innovations Limited (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: louis Qi Title: General Manager Company Name: Anker Innovations Limited Date: 2/13/2023

Anker Innovations Limited Covered Equipment Certification Attestation Letter 2/11/2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA ATTN.: Reviewing Engineer FCC ID: 2AOKB-A2598B Anker Innovations Limited (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Note: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List , the applicant should include an explanation on why the equipment is not “covered” equipment. Signed: Printed name: louis Qi Title: General Manager Company Name: Anker Innovations Limited Date: 2/13/2023

DATE : 2/24/2023 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint EST Technology Co., Ltd. Address:Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong <Signature> Name： louis Qi Title：General Manager Applicant Company：Anker Innovations Limited

DATE : 2/24/2023 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AOKB-A2598B Product Name: Anker 335 Wireless Charger (3-in-1 Station) Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature> Name：louis Qi Title：General Manager Company：Anker Innovations Limited

DATE : 2/24/2023 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AOKB-A2598B Product Name: Anker 335 Wireless Charger (3-in-1 Station) Request for Short-Term Confidentiality Pursuant to Sections 0.457 and 0.459 of the commission rules, and in accordance with the FCC Public notice dated June 15, 2004 (DA 04-1705), we hereby request short-term confidentiality for the following items prior to marketing the device.:  Test Setup Photos  External Photos  Internal Photos  User Manual The applicant requests the exhibits selected above as short term confidential be withheld from public view for a period of 180 days from the date of the Grant of Equipment Authorization and prior to marketing. This is to avoid premature release of sensitive information prior to marketing or release of the product to the public. <Signature> Name：louis Qi Title：General Manager Company：Anker Innovations Limited

External Photos M/N: A2598 External Photos M/N: A2598 External Photos M/N: A2598 External Photos M/N: A2598 External Photos M/N: A2598

0.3M1M

Internal Photos M/N: A2598 Internal Photos M/N: A2598 Internal Photos M/N: A2598 Internal Photos M/N: A2598 5W Coil Antenna 10W Coil Antenna

FCC ID: 2AOKB-A2598B EST Technology Co., Ltd Report No. ESTE-R2302083 Page 1 of 9 RF EXPOSURE REPORT FOR CERTIFICATION On Behalf of Anker Innovations Limited Anker 335 Wireless Charger (3-in-1 Station) Model Number: A2598 FCC ID: 2AOKB-A2598B Applicant: Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong, Kong Prepared By: EST Technology Co., Ltd. Chilingxiang, Qishantou, Santun, Houjie, Dongguan, Guangdong, China Tel: 86-769-83081888-808 Report Number: ESTE-R2302083 Date of Test: Jan. 09~Feb. 08, 2023 Date of Report: Feb. 09, 2023 FCC ID: 2AOKB-A2598B EST Technology Co., Ltd Report No. ESTE-R2302083 Page 2 of 9 TABLE OF CONTENTS Description Page TEST REPORT VERIFICATION......................................................................................................................... 3 1.
