Anker PowerConf+ User Manual A3306 51005002406 V01 EN 01 At a Glance 46 89107 2315 131211 1 Multi-function button 8 Power button 2 Volume down button 9 Bluetooth button 3 Mute button 10 Bluetooth LED 4 Phone call button 11 USB port (Type-A) for charge-out 5 Volume up button 12 Audio output port 6 Status LED 13 USB port (Type-C) for charge-in 7 Power LED 02 ENEN 03 Connecting a) Connect to PC (Bluetooth USB adapter) Plug the Bluetooth USB adapter into a USB port on your PC, PowerConf+ is ready to use when powered on. A3301 A3303 • Having a problem? You might need to manually set PowerConf+ as the audio device for your PC system or conference software. iOS System System Preferences > Sound > Sound Effects / Output / Input Windows System Right-click on the sound icon > Open Sound settings > Choose your output device / Choose your input device Software (Zoom) Audio Settings... > Microphone / Speaker 04 ENEN 05 b) Connect to PC (USB-C cable) C) Connect to smartphone (Bluetooth pairing) When powered on, PowerConf+ will automatically enter the Bluetooth pairing mode. Select “Anker PowerConf+” on your smartphone’s Bluetooth list to connect. Anker PowerConf+ PressEnter pairing mode Flashes blueBluetooth pairing Steady blueBluetooth connected • Each time you power on PowerConf +, it will automatically connect with the last successfully connected device if available. • To disconnect Bluetooth, press the Bluetoth button again. Powering On/Off Press and hold the power button for 2 seconds to power on. The status LED will light on clockwise and then fade out. To power off, press and hold the power button for 2 seconds. 2” • PowerConf+ will automatically power on once connected to your PC by using the USB-C cable. • PowerConf+ will automatically power off after 30 minutes of inactivity or no source. 06 ENEN 07 Button Controls Press or press and holdVolume up/down PressAnswer/End a call Press and hold for 2 secondsReject a call Press Mute or restore the microphone PressPlay/Pause music Status LED Lights up white for 2 secondsConnected to power or PC Breathes greenComing call Partially lights up blueSound direction detected Lights up blue clockwise or counterclockwise Increase/Decrease volume Turns redMuted Lights up green Press Power button to check the battery level Charging a) Charge your PowerConf+ b) Charge an external device • When powered off or being charged, PowerConf + won’t charge out. • When the remaining battery is less than 30%, the charge out current will be 5V 1A; if less than 10%, PowerConf + won’t charge out. 08 ENEN 09 Audio Output Connect an external speaker to the AUX OUT port of PowerConf + by using an AUX cable (not provided). The audio will be played through the speaker. Soundcore App Download the Soundcore App for software updates. Soundcore Apple and the Apple logo are trademarks of Apple Inc. Google Play and the Google Play logo are trademarks of Google Inc. Specifications Specifications are subject to change without notice. Charge input5V 2A Charge out5V 2.1A Rated output power3W RMS Battery capacity 6700 mAh Charging time 4 hours Talktime24 hours Driver size1 x 1.75” (full range) Frequency response 20 Hz - 20 kHz Bluetooth version V 5.0 Bluetooth range 10 m / 33 ft 10 DEDE 11 Auf einen Blick 46 89107 2315 131211 1 Multifunktionstaste 8 Ein-/Aus-Taste 2 Lautstärketaste (leiser) 9 Bluetooth-Taste 3 Stummschalttaste 10 Bluetooth-LED 4 Anruftaste 11 USB-Anschluss (Typ A) zum Aufladen von Geräten (Ausgang) 5 Lautstärketaste (lauter) 12 Audioausgang 6 Status-LED 13 USB-Anschluss (Typ-C) zum Aufladen (Eingang) 7 Betriebs-LED Verbinden a) Verbindung mit PC (Bluetooth-USB-Adapter) Schließen Sie den Bluetooth-USB-Adapter an einen USB-Anschluss Ihres PCs an, PowerConf+ ist nach dem Einschalten betriebsbereit. A3301 A3303 • Haben Sie ein Problem? Möglicherweise müssen Sie PowerConf+ manuell als Audiogerät für Ihr PC-System oder Ihre Konferenzsoftware einstellen. iOS-System Systemeinstellungen > Ton > Toneffekte / Ausgabe / Eingabe 12 DEDE 13 Windows-System Rechtsklicken Sie auf das Sound-Symbol > Öffnen Sie Soundeinstellungen > Wählen Sie ein Ausgabegerät / Wählen Sie ein Eingabegerät Software (Zoom) Audioeinstellungen... > Mikrofon / Lautsprecher b) Verbindung mit PC (USB-C-Kabel) c) Verbindung mit Smartphone (Bluetooth-Kopplung) Beim Einschalten schaltet PowerConf+ automatisch in den Bluetooth-Kopplungsmodus. Wählen Sie „Anker PowerConf+“ aus der Bluetooth-Liste Ihres Smartphones, um eine Verbindung herzustellen. Anker PowerConf+ DrückenKopplungsmodus aktivieren Blinkt blauBluetooth-Kopplung Leuchtet blauBluetooth verbunden 14 DEDE 15 • Ihr PowerConf + wird sich nach jedem Einschalten automatisch mit dem zuletzt erfolgreich verbundenen Gerät verbinden, wenn dieses verfügbar ist. • Um die Bluetooth-Verbindung zu trennen, drücken Sie erneut die Bluetoth-Taste. Ein-/Ausschalten Zum Einschalten halten Sie die Ein-/Aus-Taste 2 Sekunden lang gedrückt. Die Status-LED leuchtet im Uhrzeigersinn auf und verlischt dann langsam. Zum Ausschalten halten Sie die Ein-/Aus-Taste 2 Sekunden lang gedrückt. 2” • PowerConf+ schaltet sich automatisch ein, sobald es über das USB-C- Kabel an Ihren PC angeschlossen ist. • PowerConf+ schaltet sich nach 30 Minuten Inaktivität oder ohne Quelle automatisch ab. Bedienelemente Drücken oder gedrückt haltenLauter/leiser DrückenAnruf annehmen/beenden 2 Sekunden lang gedrückt halten Anruf ablehnen Drücken Mikrofon stummschalten oder wiederherstellen DrückenMusik abspielen/pausieren Status-LED Leuchtet 2 Sekunden lang weiß auf An Stromversorgung oder PC angeschlossen. Schwillt grün an/verlischtEingehender Anruf Leuchtet teilweise blau aufTonrichtung erkannt Leuchtet im oder gegen den Uhrzeigersinn blau auf Lauter/Leiser Wechselt auf rotStummgeschaltet Leuchtet grün auf Drücken Sie die Ein/Aus-Taste, um den Akkustand zu prüfen 16 DEDE 17 Ladevorgang a) PowerConf+ aufladen b) Externes Gerät aufladen • Wenn PowerConf + ausgeschaltet oder aufgeladen wird, lädt es keine ander…

Text truncated - open the document above for the full version.

FCC ID: 2AOKB-A3303

Label Location On EUT Label FCC ID: 2AOKB-A3303

FCC ID: 2AOKB-A3303 ANT

AnkerInnovationsLimited DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:A3303 FCCID:2AOKB-A3303 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: BT&BLE ModelNo.ofantenna:CW503 Typeofantenna:CeramicAntenna Gainoftheantenna:1.9dBi Frequencyrange:2402MHz~2480MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:AnkerInnovationsLimited Address:Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, HongKong City:Kowloon ZIP/Postalcode:N/A Country:HongKong Place:KowloonDate: 2020-08-06 Signature: version01

RF EXPOSURE EVALUATION FCC ID: 2AOKB-A3303 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters withoutput power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (dBm) Distance (mm) Calculation results Limit Operating Mode 24026.210 6.210±1 7.21051.6303 BDR&EDR 24416.284 6.284±1 7.28451.6723 24804.171 4.171±1 5.17151.0363 24024.690 4.690±1 5.69051.1493 24415.241 5.241±1 6.24151.3153 24804.954 4.954±1 5.95451.2413 24025.749 5.749±1 6.74951.4663 BLE24405.998 5.998±1 6.99851.5653 24805.540 5.540±1 6.54051.4203 Test Results:PASS.
