2AOKB-A3390VBluetooth Speaker

Anker Innovations Limited
Bluetooth Speaker - FCC ID 2AOKB-A3390V - Anker Innovations Limited
Click to zoom

Application Details

Equipment Class
DSS - Part 15 Spread Spectrum Transmitter
Date of Grant
Jul 26, 2020
Application Purpose
Original Equipment
Date of Application
Jul 25, 2020
Equipment Note
Bluetooth Speaker
Frequency Range
2402.00000000 - 2480.00000000
Company
Anker Innovations Limited
Country
Hong Kong

Documents & Files

Select a file to view

Users Manual

↗
↗

Cover Letter(s)

↗
↗

External Photos

↗

ID Label/Location Info

↗

Internal Photos

↗

RF Exposure Info

↗

Test Report

↗

Test Setup Photos

↗

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Model: A3390 V2 Input: 15V3A Output: 5V2.1A Playtime (varies by volume level and content): 18 hours Anker Innovations Limited Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong ANKER TECHNOLOGY (UK) LTD Suite B, Fairgate House, 205 Kings Road, Tyseley, Birmingham, B11 2AA, United Kingdom X1 1 2” 2

Users Manual

© Anker Innovations Limited. All rights reserved. Soundcore and the Soundcore logo are trademarks of Anker Innovations Limited, registered in the United States and other countries.51005002366 V01 Model: A3390 EN 0102 EN Important Safety Information 1) Avoid dropping. 2) Do not disassemble. 3) Do not install near any heat sources. 4) Do not place any sources of danger on this device(e.g. liquid filled objects, lit candles). 5) Use original or certified cables. 6) Clean with a dry, soft lint-free cloth. Do not use any corrosive cleaner or oil. 7) Do not expose batteries to high heat as direct sun light, fire and Etc. 8) Please note to verify first that there is no danger of stepping or falling on the power cord. 9) In order to reduce the damage risk to the power cord, do not unplug the power adapter / charger by pulling the power cord. Please pull the charger / power adapter itself and out of the socket. 10) The adapter shall be installed near the equipment and shall be easily accessible. Notice This product complies with the radio interference requirements of the European Community. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling. Follow local rules and never dispose of the product and rechargeable batteries with normal household waste. Correct disposal of old products and rechargeable batteries helps prevent negative consequences for the environment and human health. FCC Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -Reorient or relocate the receiving antenna. EN 0304 EN -Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body. Company Name: Fantasia Trading LLC Address: 5350 Ontario Mills Pkwy, Suite 100, Ontario, CA 91764 Telephone: +1 (800) 988 7973 IC NOTICE TO CANADIAN USERS This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This device may not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. This equipment complies with IC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.” ce matériel est conforme aux limites d’exposition aux rayonnements rf de ic énoncés dans un autre environnement. ce matériel doit être installé et exploité à une distance minimale de 20 cm entre le radiateur et votre corps. Trademark The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc. and any use of such marks by Anker Innovations Limited. is under license. Other trademarks and trade names are those of their respective owners. * Additional Legal Rights for Consumers For consumers, who are covered by consumer protection laws or regulations in their country of purchase or, if different, their country of residence, the benefits conferred by Soundcore's Limited Warranty are in addition to all rights and remedies conveyed by such consumer protection laws and regulations, including but not limited to these additional rights. For FAQs and more information, please visit https://www.soundcore.com/ CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS Declaration of Conformity Hereby, Anker Innovations Limited declares that the radio equipment type A3390 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.soundcore.com Anker Innovations Deutschland GmbH Georg-Muche-Straße 3-5, 80807 München Maximum output power: 14.95dBm Frequency band: 2.4G band (2.402GHz-2.480GHz) 06 FRDE 05 Wichtige Sicherheitsinformationen 1) Nicht fallenlassen. 2) Nicht zerlegen. 3) Nicht in der Nähe von Wärmequellen installieren. 4) Keine Gefahrenquellen auf dieses G…

Text truncated - open the document above for the full version.

Cover Letter(s)

Anker Innovations Limited Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hongkong Long/Short-term Confidentiality Request Federal Communications Commission Date: Jul. 10, 2020 445 12 th Street SW Washington, DC 20554 FCC ID: 2AOKB-A3390V To Whom it may concerns, Pursuant to sections 0.457(d) and 0.459 of CFR 47 and to avoid premature release of sensitive information prior to marketing or release of the product to the public, we hereby requests long-term confidential treatment of information accompanying this application as outlined below: Schematics Parts List Block Diagram Tune-Up Info Operational Description In addition we hereby request the following exhibits contained in this application to be temporarily (short-term confidentilality) withheld from the public disclosure for an initial period of 180 days until: not applicable External Photos Test Setup Photos Internal Photos Users Manual The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the applicant and provide unjustified benefits to its competitors. The applicant understands that pursuant to rule 0.457(d), disclosure of this application and all accompanying documentation will not be made before the date of the GRANT for this application. If you have any questions, please feel free to contact me. Yours sincerely, Signatory Contact person: Louis Qi Title: General Manager

Cover Letter(s)

Anker Innovations Limited Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hongkong Agent Authorization Company: Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hongkong Product Name: Soundcore Rave PartyCast Model Number(s): A3390 Product Description: Bluetooth Speaker We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: Jul. 10, 2020 Name: Louis Qi Title: General Manager Company: Anker Innovations Limited 12.221dBm

External Photos

External Photos ALL VIEW OF EUT TOP VIEW OF EUT BOTTOM VIEW OF EUT FRONT VIEW OF EUT BACK VIEW OF EUT LEFT VIEW OF EUT RIGHT VIEW OF EUT VIEW OF EUT(PORT) ADAPTER

ID Label/Location Info

50mm*50mm

Internal Photos

Internal Photos OPEN VIEW OF EUT VIEW OF BATTERY(battery 1 FUJI ELECTRONICS) VIEW OF BATTERY(Battery 2 Giantsun) INTERNAL VIEW-1 OF EUT INTERNAL VIEW-2 OF EUT INTERNAL VIEW-3 OF EUT INTERNAL VIEW-4 OF EUT INTERNAL VIEW-5 OF EUT INTERNAL VIEW-6 OF EUT INTERNAL VIEW-7 OF EUT INTERNAL VIEW-8 OF EUT INTERNAL VIEW-9 OF EUT INTERNAL VIEW-10 OF EUT INTERNAL VIEW-11 OF EUT ANTENNA BT Antenna

RF Exposure Info

RF EXPOSURE EVALUATION 1. PRODUCT INFORMATION Product Description Soundcore Rave PartyCast Model Name A3390 FCC ID 2AOKB-A3390V 2. EVALUATION METHOD Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate, since exposures are assumed to occur at distances of 20 cm or more from persons. LIMITS FOR GENERAL POPULATION / UNCONTROLLED EXPOSURE Frequency Range (MHz) E-field Strength (E) (V/m) Magnetic Field Strength (H) (A/m) Power Density (S) (mW/cm 2 ) Averaging Time |E| 2 , |H| 2 or S (Minutes) 0.3 -- 1.34 614 1.63 (100)* 30 1.34 -- 30 824/f 2.19/f (180/f 2 )* 30 30 -- 300 27.5 0.073 0.2 30 300 -- 1500 -- -- f/1500 30 1500 -- 100,000 -- -- 1.0 30 *Note: 1. f= Frequency in MHz * Plane-wave Equivalent Power Density 2. The averaging time for General Population/Uncontrolled exposure to fixed transmitters is not applicable for mobile and portable transmitters. See 47 CFR §§2.1091 and 2.1093 on source-based time-averaging requirement for mobile and portable transmitters. S=PG/4πR² Where: S=power density P=power input to antenna G=power gain of the antenna in the direction of interest relative to an isotropic radiator R=distance to the center of radiation of the antenna 3. CALCULATION A minimum test separation distance ≥ 20 cm is required between the antenna and radiating structures of the device and nearby persons to apply mobile device exposure limits. The distance must be at least 20 cm and fully supported by the operating and installation configurations of the transmitter and its antenna(s), according to the source-based time-averaged maximum power requirements of § 2.1091(d)(2). In cases where cable losses or other attenuations are applied to determine compliance, the most conservative operating configurations and exposure conditions must be evaluated. BR/EDR: Antenna Gain=4.41dBi (Numeric 2.76), π=3.14 BLE: Antenna Gain=4.41dBi (Numeric 2.76), π=3.14 Note: 1. Only the worst case recorded. Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2441 12.221 16.68 0.009 1 Frequency Output Power Output Power Power Density Power Density Limit MHz dBm mW mW/cm 2 mW/cm 2 2480 6.836 4.83 0.003 1

Test Report

Page 1 of 64 FCC Test Report Report No.: AGC01110200529FE03 FCC ID : 2AOKB-A3390V APPLICATION PURPOSE : Original Equipment PRODUCT DESIGNATION : Soundcore Rave PartyCast BRAND NAME : Soundcore MODEL NAME : A3390 APPLICANT : Anker Innovations Limited DATE OF ISSUE : July 03, 2020 STANDARD(S) : FCC Part 15.247 REPORT VERSION : V1.0 Attestation of Global Compliance(Shenzhen) Co., Ltd CAUTION: This report shall not be reproduced except in full without the written permission of the test laboratory and shall not be quoted out of context. Report No.:AGC01110200529FE03 Page 2 of 64 REPORT REVISE RECORD Report Version Revise Time Issued Date Valid Version Notes V1.0 / July 03, 2020 Valid Initial Release Report No.:AGC01110200529FE03 Page 3 of 64 TABLE OF CONTENTS 1. VERIFICATION OF CONFORMITY .................................................................................................................. 5 2. GENERAL INFORMATION .............................................................................................................................. 6 2.1. PRODUCT DESCRIPTION ................................................................................................................... 6 2.2. TABLE OF CARRIER FREQUENCYS .................................................................................................. 6 2.3. RECEIVER INPUT BANDWIDTH .......................................................................................................... 7 2.4. EXAMPLE OF A HOPPING SEQUENCY IN DATA MODE ................................................................... 7 2.5. EQUALLY AVERAGE USE OF FREQUENCIES AND BEHAVIOUR .................................................... 7 2.6. RELATED SUBMITTAL(S) / GRANT (S) ............................................................................................... 8 2.7. TEST METHODOLOGY ........................................................................................................................ 8 2.8. SPECIAL ACCESSORIES ..................................................................................................................... 8 2.9. EQUIPMENT MODIFICATIONS ............................................................................................................ 8 3. MEASUREMENT UNCERTAINTY ................................................................................................................... 9 4. DESCRIPTION OF TEST MODES ................................................................................................................. 10 5. SYSTEM TEST CONFIGURATION ................................................................................................................. 11 5.1. CONFIGURATION OF EUT SYSTEM .................................................................................................. 11 5.2. EQUIPMENT USED IN TESTED SYSTEM ......................................................................................... 11 5.3. SUMMARY OF TEST RESULTS ......................................................................................................... 12 6. TEST FACILITY .............................................................................................................................................. 13 7. PEAK OUTPUT POWER ................................................................................................................................ 14 7.1. MEASUREMENT PROCEDURE ......................................................................................................... 14 7.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 14 7.3. LIMITS AND MEASUREMENT RESULT ............................................................................................. 15 8. 20DB BANDWIDTH ........................................................................................................................................ 21 8.1. MEASUREMENT PROCEDURE ......................................................................................................... 21 8.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 21 8.3. LIMITS AND MEASUREMENT RESULTS .......................................................................................... 22 9. CONDUCTED SPURIOUS EMISSION........................................................................................................... 28 9.1. MEASUREMENT PROCEDURE ......................................................................................................... 28 9.2. TEST SET-UP (BLOCK DIAGRAM OF CONFIGURATION) ............................................................... 28 9.3. MEASUREMENT EQUIPMENT USED ............................................................................................... 28 9.4. LIMITS AND MEASUREMENT RESULT ............................................................................................. 28 10. RADIATED EMISSION ................................................................................................................................. 41 10.1. MEASUREMENT PROCEDURE ....................................................................................................... 41 10.2. TEST SETUP ..................................................................................................................................... 43 10.3. LIMITS AND MEASUREMENT RESULT ........................................................................................... 44 Report No.:AGC01110200529FE03 Page 4 of 64 10.4. TEST RESULT ................................................................................................................................... 44 11. NUMBER OF HOPPING FREQUENCY ....................................................................................................... 54 11.1. MEASUREMENT PROCEDURE ..................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Test Setup Photos RADIATED EMISSION TEST SETUP BELOW 1GHZ RADIATED EMISSION TEST SETUP ABOVE 1GHZ CONDUCTED EMISSION TEST SETUP CONDUCTED TEST SETUP

Contact Information

Applicant

Louis Qi
[email protected]+86-755-86544807Fax: N/A

Technical Contact

Anker Innovations Limited
[email protected]

Hong Kong

Test Firm

Attestation of Global Compliance (Shenzhen) Co., LDoris Li
[email protected]+86-755-25234088

Technical Specifications

#Rule PartsFrequency RangePower Output
115C2.40 GHz - 2.48 GHz16.60 mW
Confidentiality
Long Term
Grant Notes
Output power listed is conducted power.The antenna used with this transmitter must be installed to provide a minimum separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi- transmitter product procedures. End-users must be provided with operating procedures for satisfying RF exposure compliance.
