2AOKB-T8140ReufyCam 2 Pro

Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo are trademarks of Anker Innovations Limited, registered in the United States and other countries. All other trademarks are the property of their respective owners. 51005002588 V04 QUICK START GUIDE EUFYCAM 2 PRO WIRE-FREE HD SECURITY CAMERA SET 02 ENEN 03 GETTING STARTED For HomeBase 2 installation HomeBase 2 (T8010X) Power Adapter for HomeBase 2 Ethernet Cable Metal Pin for Resetting For eufyCam 2 Pro installation eufyCam 2 Pro (T8140R) Micro-USB Charging Cable Mounting Bracket Mounting Screws and Anchors PRODUCT OVERVIEW HomeBase 2 2 3 456 7 1 1. Status LED5. Ethernet port 2. Speaker6. SYNC/ALARM OFF button 3. Power port 7. Reset button 4. USB port eufyCam 2 Pro 3 4 5 6 2 1 1 8 7 1. Photosensitive sensor5. LED indicator 2. Camera lens6. Sync button 3. Motion sensor7. USB charging port 4. Microphone 8. Screw hole Indoor Mount Hook (for Indoor Mount) 1. Camera quantity and accessories vary by bundle package. 2. HomeBase 2 power adapter varies by region. 04 ENEN 05 CONNECTING THE HOMEBASE 2 Connect the HomeBase 2 to the Internet 1. Power on the HomeBase 2. Connect HomeBase 2 to your home router using the provided Ethernet cable. 2. The LED indicator turns blue (this may take up to 1min) when HomeBase 2 is ready for setup. SETTING UP THE SYSTEM Download the App and Set up the System Download the eufy Security app from the App Store (iOS devices) or Google Play (Android devices). Sign up for a eufy Security account, then follow the onscreen instructions to complete the setup. Note: • Make sure you place the camera near HomeBase 2 (within the distance of 1 ~ 3 feet). • Make sure you set up HomeBase 2 and eufyCam 2 Pro on the app before you mount the cameras. • Keep the camera at least 1 ft away from your internal / external hard drives. 06 ENEN 07 MOUNTING THE CAMERA Find a Good Mounting Spot To find a spot to mount eufyCam 2 Pro, you need to test wireless signal strength. ① Open the eufy Security app, go to Camera Settings > Mounting Guide. ② To test the wireless signal strength, take your camera and phone to the location where you want to mount the camera. ③ Move the camera as close to the HomeBase 2 as possible if the wireless. Select Height and Location Hang eufyCam 2 Pro 7-10 ft (2-3 m) above the ground. This height maximizes the detection range of the motion sensor of eufyCam 2 Pro. Avoid placing eufyCam 2 Pro under direct sunlight. Up to 30 ft (10 m) 7-10 ft (2 - 3 m) Camera field of view Motion Detection Zone 08 ENEN 09 Mount the camera The camera can be mounted both indoors and outdoors. 1. Turn the knob of the mounting bracket clockwise to loosen and disassemble it. 2. Drill holes with a 15/64 inch (5.95mm) drill bit, then insert the anchors into the holes; anchors are necessary for walls that are made out of hard materials such as concrete, brick, or stucco. Mount the camera 3. Firmly screw the base of the mounting bracket onto the wall. Fasten the ball knob of the bracket to the base of the bracket. 4. Tighten eufyCam 2 Pro to the mounting bracket and adjust the viewing angle by checking the live stream feed in the eufy Security a p p. Tips: 1. The HomeBase 2 pairs up to 16 cameras, you can repeat the steps mentioned above to add more eufyCam 2 Pro cameras to meet different needs of use. 2. For troubleshooting, check Help on the eufy Security App. Refer to App page for LED indicator status. 10 ENEN 11 CHARGING EUFYCAM 2 PRO Charge eufyCam 2 Pro Method 1 Method 2 5V USB Charger LED indication Charging time 12 hours Fully charged: Off Charging: Steady blue Mount the Camera Indoors Stick the camera directly to any flat surface made out of iron. Or you can use the indoor mount to mount the camera: 1. Drill a hole. Use the included anchor if it’s drywall and fasten the hook. a 2. Hang the indoor mount on the hook. b 3.Attach eufyCam 2 Pro to the indoor mount and adjust the viewing angle. c 12 ENEN 13 NOTICE FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement The device has been evaluated to meet general RF exposure requirements. The device can be used in fixed/mobile exposure condition. The min separation distance is 20cm. Notice: Shielded cablesAll connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations. The following importer is the responsible party Company Name: POWER MOBILE LIFE, LLC Address: 10900 NE 8th St, Ste 501, Bellevue WA 98004 Telephone: 1…

Text truncated - open the document above for the full version.

De claration To whomit may concern : We have declare d below feature d for FCC equipment authorization, Device FCC ID: 2AOKB-T8140R Don't operateonChannels 12and13. US2.4Gchannel 12-1 3andCountrycode selection aredisabled through pro pri etarysoftware and arenot user changeable Should you have any questions, please feel fre e to contact me. Date: 2022.12.15 Contact name: Louis Qi Tel: +86-755-86544807 Email: [email protected] Company name: Anker Innovations Limited

Anke rInno vat ions Limited Dat e:2022/12/15 To: Federal Co mmuni cat ions Co mmission, Aut ho rizat ion&Eval uat ionDivision, 7435Oakl and MillsRoad , Co lum bia, MD21046 ToWho mItMay Co nc ern: TheAnkerInnovationsLimited,the und ersigne d,he rebyaut ho rizesMrs.Wend y Zhan fromShenzhenMorl abCommunica tionsTech nologyCo.,Ltd.,toac tonthe behal foftheAnkerInnovationsLimitedsolelyinmat tersrelat ing tothe ap plicat ionforan FCC equi pment aut ho rizat ionforFCC ID:2AOKB-T 8140R inc lu ding the signi ng ofdocum ent sinconne ctionwiththi sApplicat ion. Necessar y ac tscar riedoutShenzhenMorl abCommunica tionsTech nologyCo.,Ltd.onour behal foftheAnkerInnovationsLimitedinconne ctionwiththe applicat ionshal l hav ethe sam eeffectas ac tsoftheAnkerInnovationsLimited.AnkerInnovations Limitedal sohe rebycertifythat no par tytothi sap plicat ionissub jecttoadeni al of bene fits,inc lud ing FCC bene fits,pur suant toSection5301ofthe Ant i-D rug Abus e Actof1988,21U.S.C. 862. Thank youforyour at tent iontothi smat ter. Your sSinc erely, Signat ory: Contact name: Louis Qi Tel: +86-755-86544807 Email: [email protected] Company name: Anker Innovations Limited

： AnkerInnovationsLimited Date:2022.12.15 To : Fede ralCo mmunicationsCo mmission, Authorization&EvaluationDivision, 7435OaklandMillsRoad, Co lumbia,MD21046 Re: Requ estofCo nfide ntialityforFCCID: 2AOKB-T8140R To Whomitmayconcern: Pu rsuanttosections0.457and0.459ofCo mmission’sRules(CF R47),and Section 552(b)(4) of the Freedo m of Information Act,Anker Innov ation s Limitedhereby requ ests confide ntiality and treatment of certain information accompanying this applica tion. Th e materials contain trade secrets and proprietary information not customarily released to the public. Th e public di sclosure of these matters migh t be harmful to the Applicant and provide unjustifiedbenefitstoitscompetitors. We are also hereby requ est Short-Te rm Co nfidentiality (max time 180 da ys from gr ant da te) as outlined in Pu blic Notice DA04-1705. Th is provision will gi veAnker Innovations Limited temporaryconfidentialityofcommerciallysensitiveinformationpriortoprodu ctrelease. Th erequ estedPe rmanentandShort-Te rmCo nfidentialexhibitsarelistedasfollows: PER MANEN TANDSHO RT- TE RMCONFIDENTI ALLIST ExhibitDescription PER MANEN T 1BlockDiagr am 2OperationalDescription 3Schematics 4BOM SHO RT- TE RM 5ExternalPh otos 6InternalPh otos 7Te st-SetupPh otos 8UserManual Th e Applicant unde rstands that pursuant to Rule 0.457, di sclosure of this application and all accompanying do cumentations, where applicable, will not be made public before the da te of theGrantforthisapplication. Sign atory Name: Louis Qi Company Name: Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong Tel: +86-755-86544807 Email: [email protected]

FCC ID: 2AOKB-T8140R, IC: 23451-T8140R External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

FCC ID: 2AOKB-T8140R, IC: 23451-T8140R Internal Photos 1. EUT uncover view 2. Antenna view 2.4G WIFI Antenna

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 8 REPORT No.：SZ22100354S01 RF EXPOSURE EVALUATION REPORT APPLICANT : Anker Innovations Limited PRODUCT NAME : eufyCam 2 Pro MODEL NAME :T8140R BRAND NAME : eufy SECURITY FCC ID : 2AOKB-T8140R STANDARD(S) : 47 CFR Part 2(2.1091) RECEIPT DATE : 2022-11-23 TEST DATE :2022-11-28 to 2022-12-03 ISSUE DATE :2022-12-20 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100354S01 Page 2of 8 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.3 Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2. Device Category and RF Exposure Limit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. RF Output Power ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4. RF Exposure Assessment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 7 Annex A Testing Laboratory Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 Change History Version Date Reason for change 1.0 2022-12-20 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100354S01 Page 3of 8 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Anker Innovations Limited Applicant Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Manufacturer Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong 1.2 Equipment under Test (EUT) Description Product Name: eufyCam 2 Pro Sample No.: 6# Hardware Version: T8140R-MB-V0.2 Software Version: 3.0.3.8 Modulation Technology: DSSS, OFDM Modulation Mode: 802.11b, 802.11g, 802.11n (HT20) Operating Frequency Range: 802.11b/g/n (HT20): 2412MHz–2462MHz Antenna Type: FPC antenna Antenna Gain: 2.97dBi MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100354S01 Page 4of 8 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method determination /Remark 47 CFR Part 2(2.1091) Radio Frequency Radiation Exposure Assessment: mobile devices No deviation KDB 447498 D01v06 General RF Exposure Guidance No deviation Note 1: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 2: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100354S01 Page 5of 8 2. Device Category and RF Exposure Limit Per user manual, Based on 47 CFR 2.1091, this device belongs to mobile device category with General Population/Uncontrolled exposure. Mobile Devices: 47 CFR 2.1091(b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 centimeter separation requirement. General Population/Uncontrolled Exposure: The general population/uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their employment may not be made fully aware of the potential for exposure or cannot exer…

Text truncated - open the document above for the full version.

A letter of recognition APPROVAL No.ATCSZ-5-180124-001ISSUE1 DESCRIBE: Anker Innovations Co., LTD （ T8140R) Customer NO: 400102930 PART NO: ATC1356-HY048B04RA Antenna type: 2.4G FPC ANT DATE: 2022.12.16 PROVIDER: AT&C TECHNOLOGIES(SHENZHEN) CO. LTD 1 2 TX-1 Antenna S11 3 Antenna *Efficiency FrequencyEfficiency dBi 240066%2.97 241067%2.67 242068%2.79 243067%2.83 244069%2.86 245069%2.78 246066%2.81 247064%2.71 248066%2.80 249065%2.79 250061%2.62 4 Antenna OTA TEST ChannelsTRPTIS 2.412 GHz19.61-83.46 2.437 GHz19.63-83.25 2.462 GHz19.43-83.45 5 Antenna 3D 6 Antenna Draw Size informationMeasuring sample % Tolerance Handling opinions nu mb er Dime nsion prope rty Dimen sion Lower to lerance Upper t oleranc e 123 UpperLower determi ne Supplier r eview co mments Custo mer re view c omme nts Measuring tool 1 key p oint 25.9-0.200.20 25.9125.8725.89 PASS PJ 2 key p oint 17.7 -0.200.20 17.6617.6517.69 PASS PJ 3 key p oint 1.1 -0.050.05 8.188.208.18 PASS PJ 7 8 Packaging method PE bag packaging, product emission neat, uniform quantity PART LIST The packing drawing is schematic diagram, which does not mean that the picture is the actual produc tand the actual shipment is the standard. NODESCRIPTIONQ'TYMATERIALREMARKSREV. 1 ANTENNA1/1000N/AA 2 PAD OUT 1/4 SW A골 5TN/AA 4 CARTOON BOX-SW A골 5TN/AA 5 PACKING TAPE-PPN/AA Picture: Outer box "I" seal, QC PASS seal on the left side of the outer box, sealed without exposure.

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 92 REPORT No.：SZ22100354W01 TEST REPORT APPLICANT : Anker Innovations Limited PRODUCT NAME : eufyCam 2 Pro MODEL NAME : T8140R BRAND NAME :eufy SECURITY FCC ID : 2AOKB-T8140R STANDARD(S) : 47 CFR Part 15 Subpart C RECEIPT DATE : 2022-11-23 TEST DATE :2022-11-28 to 2022-12-03 ISSUE DATE :2022-12-20 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 92 REPORT No.：SZ22100354W01 DIRECTORY 1. Summary of Test Result ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 4 1.1. Testing Applied Standards ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 5 1.2. Test Equipment List ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 6 1.3. Measurement Uncertainty ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 8 1.4. Testing Laboratory ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 8 2. General Description ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 9 2.1. Information of Applicant and Manufacturer ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 9 2.2. Information of EUT ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 9 2.3. Channel List of EUT ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 10 2.4. Test Configuration of EUT ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 11 2.5. Test Conditions ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 11 2.6. Test Setup Layout Diagram ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 12 3. Test Results ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 15 3.1. Antenna Requirement ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 15 3.2. Duty Cycle of Test Signal ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 16 3.3. Maximum Peak and Average Conducted Output Power ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 17 3.4. 6 dB Bandwidth ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 18 3.5. Conducted Spurious Emissions and Band Edge ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 19 3.6. Power Spectral Density ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 20 3.7. Conducted Emission ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 21 3.8. Restricted Frequency Bands ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 22 3.9. Radiated Emission ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 23 Annex A Test Data and Result ꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏꞏ 25 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 92 REPORT No.：SZ22100354W01 Change History Version Date Reason for change 1.0 2022-12-20 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 92 REPORT No.：SZ22100354W01 1. Summary of Test Result No. Section Description Test Date Test Engineer Result Method Determination /Remark 1 15.203 Antenna Requirement N/A N/A PASS No deviation 2 N/A Duty Cycle of Test Signal Nov. 29, 2022 He Yuyang PASS No deviation 3 15.247(b) Maximum Peak Conducted Output Power Nov. 29, 2022 He Yuyang PASS No deviation 4 15.247(b) Maximum Average Conducted Output Power Nov. 29, 2022 He Yuyang PASS No deviation 5 15.247(a) Bandwidth Nov. 29, 2022 He Yuyang PASS No deviation 6 15.247(d) Conducted Spurious Emission and Band Edge Nov. 29, 2022 He Yuyang PASS No deviation 7 15.247(e) Power Spectral Density Nov. 29, 2022 He Yuyang PASS No deviation 8 15.207 Conducted Emission Nov. 30, 2022 Fan Zehang PASS No deviation 9 15.247(d) Restricted Frequency Bands Dec. 03, 2022 Li Hanbin PASS No deviation 10 15.209, 15.247(d) Radiated Emission Nov. 30, 2022 Li Hanbin PASS No deviation Note 1: The tests were performed according to the method of measurements prescribed in ANSIC63.10-2013 and KDB558074 D01 v05r02. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 3: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology…

Text truncated - open the document above for the full version.

FCC ID: 2AOKB-T8140R, IC: 23451-T8140R Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. RF measurement setup (WIFI 2.4G)
