2AOKB-T8453Garage-Control Cam Plus

QUICK START GUIDE Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo are trademarks of Anker Innovations Limited, registered in the United States and other countries. All other trademarks are the property of their respective owners. 51005003163 V01 Garage-Control Cam with Sensor Garage-Control Cam Plus with Sensor 21 OVERVIEW 1 Garage-Contr ol Cam Plus / Garage-Contr ol Cam Model: T8453 / T8452 ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① ② ③ Camera Lens Infrared LED Speaker Ring Light • Flashing blue: Connecting to the Internet. • Blue: Working properly. • Flashing red: Disconnected from the Internet. Microphone SYNC Button Wire Connectors: Model T8453 includes 2 pairs. Power Port MicroSD Card Slot Status LED • Flashing blue: Pairing with the camera. • OFF: Working properly / Powered off. SYNC Button Battery Cover Garage Door Sensor Model: T8450 43 SETTING UP CAMERA 2 1. Connect the camera to a power outlet. To use local storage, insert a memory card into the microSD card slot before powering the camera (Model T8453 includes one). USB-C 2. Download and install the eufy Security app, then sign up for an account. 3. Follow on-screen instructions to add the camera to your device list. 65 MOUNTING CAMERA 3 1. Mount the camera underneath the garage door opener or to the ceiling. Option 1. Garage Door Opener Magnetically attach the camera underneath the garage door opener with a metal surface or onto the metal track. For garage door openers with a non-metal surface, stick the mounting plate underneath the garage door opener with the 3M sticker provided, then magnetically attach the camera to the mounting plate. 87 Option 2. Ceiling Fix the mounting iron plate to the ceiling with the provided screw, then magnetically attach the camera to the mounting plate. For model T8453, mount the camera to the ceiling in the middle of the two garage door openers so that you can see both garage doors through the camera. 2. Manually adjust the camera angle until you get the desired view through the eufy Security app. 109 WIRING CAMERA 4 1. Press and hold the orange tabs, then insert one end of the provided motor connection wire into the connectors. Each strand can connect to any connector. 2. On the garage door opener, locate the terminals that wire to the wall control. Twist each wire strand to the motor connection wire, then connect the paired strands back to their original terminal. Make sure the paired strands are properly connected to their original terminal. If you haven't installed wall control, check your garage door opener's user manual for wall control wiring instructions to locate the right terminals. Model T8453 can wire up to 2 garage doors. Follow the steps above to wire the camera to the other garage door opener. Motor Connection WireWall Control Wire Garage Door Opener Garage Door Opener 1211 PAIRING AND MOUNTING SENSOR 5 1. Open the battery cover, then install the provided battery. Status LEDNew Battery's Status Blue for 2 secondsNormal Red for 2 secondsLow battery 2. In the eufy Security app, follow on-screen instructions to pair the sensor with the camera. 3. Select a location on your garage door to mount the sensor. Roller Door Mount the sensor at the end of the drum wheel spoke. Sectional Door Mount the sensor on the top of the door (the gray area in the figure below). + CR2450 1413 For wood doors, you can also mount the sensor with the screws provided. Make sure the SYNC button faces the same direction as the arrow on the battery cover. 5. In the eufy Security app, follow on-screen instructions to open the door for a test. Model T8453 can work with up to 2 garage doors. Buy another sensor for the other garage door, then follow the steps above to pair and mount the sensor. Tilt Door Mount the sensor on the top of the door (the gray area in the figure below). 4. Mount the seneor. Mount the sensor with the provided 3M sticker. 1615 APPENDIX. REPLACING BATTERY FOR SENOR 6 1. Pull the sensor off the battery cover. 2. Remove the battery using the provided detaching pin. Press the battery with your finger when detaching to keep the battery from popping out. To show the door status (open/closed) correctly in the eufy Security app, perform a calibration on Camera Settings > Door Settings > Calibration after you replace the battery or move the sensor. NOTICE 7 CAUTION RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE. DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS ATTENTION RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACÉE PAR UN TYPE INCORRECT. ÉLIMINER LES BATTERIES USÉES SELON LES INSTRUCTIONS Warning: – replacement of a battery with an incorrect type that can defeat a safeguard; – disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, that can result in an explosion; – leaving a battery in an extremely high temperature surrounding environment that can result in an explosion or the leakage of flammable liquid or gas; and – a battery subjected to extremely low air pressure that may result in an explosion or the leakage of flammable liquid or gas. Attention: – remplacement d’une batterie par un type incorrect pouvant supprimer une protection – mise au rebut d’une batterie dans un feu ou dans un four chaud, ou écrasement mécanique ou coupure d’une batterie, susceptible de provoquer une explosion; – maintien d’une batterie dans un environnement à très haute température pouvant provoquer une explosion ou la fuite de liquide ou de gaz inflammables; 1817 interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement The device has been evaluated to meet general RF exposure requirements. The device can be used in f…

Text truncated - open the document above for the full version.

FCCID:2AOKB-T8453

Door1Door2Door1

FCCID:2AOKB-T8453 ANT

version01 AnkerInnovationsLimited DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:T8453 FCCID:2AOKB-T8453 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: BLE&WiFi2.4G: ModelNo.ofantenna:N/A Typeofantenna:Shrapnelantenna Gainoftheantenna:1.9dBi Frequencyrange:WIFI2.4G:2412-2462MHzMHz BLE:2402-2480MHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:AnkerInnovationsLimited Address:Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon, HongKong City:Hongkong ZIP/Postalcode:/ Country:HongKong Place:KowloonDate:1/20/2022 Signature:

RFEXPOSUREEVALUATION AccordingtoFCC1.1310:Thecriterialistedinthefollowingtableshallbeusedto evaluatetheenvironmentimpactofhumanexposuretoradiofrequency(RF)Radiation asspecifiedin§1.1307(b) FCCID:2AOKB-T8453 EUTSpecification EUT Garage-ControlCamPlus Frequencyband(Operating)WLAN:2.412GHz~2.462GHz WLAN:5.18GHz~5.32GHz/5.50GHz~5.70GHz WLAN:5.745GHz~5825GHz Others:BLE:2402-2480MHz DevicecategoryPortable(<20cmseparation) Mobile(>20cmseparation) Others___ ExposureclassificationOccupational/Controlledexposure(S=5mW/cm2) GeneralPopulation/Uncontrolledexposure(S=1mW/cm2) AntennadiversitySingleantenna Multipleantennas Txdiversity Rxdiversity Tx/Rxdiversity Max.outputpowerBLE:2.09dBm(0.0016W) WIFI2.4G:22.34dBm(0.1714W) Antennagain(Max)1.9dBi EvaluationappliedMPEEvaluation SAREvaluation LimitsforMaximumPermissibleExposure(MPE) Frequency Range(MHz) ElectricField Strength(V/m) MagneticField Strength(A/m) Power Density(mW/cm 2 ) Average Time (A)LimitsforOccupational/ControlExposures 300-1500----F/3006 1500-100000----56 (B)LimitsforGeneralPopulation/UncontrolExposures 300-1500----F/15006 1500-100000----130 Friistransmissionformula:Pd=(Pout*G)\(4*pi*R2) Where Pd=PowerdensityinmW/cm 2 Pout=outputpowertoantennainMw G=gainofantennainlinearscale Pi=3.1416 R=distancebetweenobservationpointandcenteroftheradiatorincm PdthelimitofMPE,1mW/cm2.Ifweknowthemaximumgainoftheantennaand totalpowerinputtotheantenna,throughthecalculation,wewillknowthedistance wheretheMPElimitisreached. MeasurementResult Operating Mode Channel Frequency (MHz) Maximum output power (dBm) Tuneup tolerance (dBm) Max.Tuneup Power (dBm) Antenna Gain (dBi) Power densityat 20cm (mW/cm2) Power density Limits (mW/cm2) 802.11b 241222.3422.34±123.341.9 0.0665 1 243721.9221.92 ±1 22.921.90.06041 246222.3222.32±123.321.90.06621 802.11g 241220.6020.60±121.61.90.04451 243720.3020.30 ±1 21.31.90.04161 246220.4720.47±121.471.90.04321 802.11n (HT20) 241219.6819.68±120.681.90.03601 243719.5519.55 ±1 20.551.90.03501 246219.5919.59±120.591.90.03531 BLE 2402 2.042.04±13.041.90.00061 2440 0.510.51 ±1 1.511.90.00041 2480 2.092.09±13.091.90.00061

Page1of22 AppendixTestData ReportNo.:18220WC10276002TestSampleNo.:1-2-2 StartTestDate:2021.12.14FinishTestDate:2022.1.12 TestEngineer:Auditor: Temperature:24.5 °C RelativeHumidity:54% Pressure:1012hPa AppendixA:DTSBandwidth TestResult TestModeAntennaChannel DTSBW [MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24020.7082401.6362402.344≥0.5PASS 24400.6762439.6562440.332≥0.5PASS 24800.7042479.6322480.336≥0.5PASS Page2of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page3of22 Page4of22 AppendixB:OccupiedChannelBandwidth TestResult TestModeAntennaChannel OCB[MHz] FL[MHz]FH[MHz]Limit[MHz]Verdict BLE_1MAnt1 24021.03092401.4892402.520---PASS 24401.02762439.4912440.518---PASS 24801.02332479.4922480.515---PASS Page5of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page6of22 Page7of22 AppendixC:Maximumconductedoutputpower TestResult TestModeAntennaChannelResult[dBm]Limit[dBm]Verdict BLE_1MAnt1 24022.04≤30PASS 24400.51≤30PASS 24802.09≤30PASS Page8of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page9of22 Page10of22 AppendixD:Maximumpowerspectraldensity TestResult TestModeAntennaChannelResult[dBm/3kHz]Limit[dBm/3kHz]Verdict BLE_1MAnt1 2402-12.45≤8PASS 2440-14.82≤8PASS 2480-12.94≤8PASS Page11of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page12of22 Page13of22 AppendixE:Bandedgemeasurements TestResult TestModeAntennaChNameChannelRefLevel[dBm]Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 Low24021.25-57.62≤-18.75PASS High24800.57-58.58≤-19.43PASS Page14of22 TestGraphs BLE_1M_Ant1_Low_2402 BLE_1M_Ant1_High_2480 Page15of22 AppendixF:ConductedSpuriousEmission TestResult TestModeAntennaChannel FreqRange [MHz] RefLevel [dBm] Result[dBm]Limit[dBm]Verdict BLE_1MAnt1 2402 Reference0.950.95---PASS 30~10000.95-65.08≤-19.06PASS 1000~265 00 0.95-47.02≤-19.06PASS 2440 Reference-0.70-0.70---PASS 30~1000-0.70-67.34≤-20.7PASS 1000~265 00 -0.70-47.87≤-20.7PASS 2480 Reference1.281.28---PASS 30~10001.28-66.92≤-18.72PASS 1000~265 00 1.28-49.5≤-18.72PASS Page16of22 TestGraphs BLE_1M_Ant1_2402_0~Reference BLE_1M_Ant1_2402_30~1000 BLE_1M_Ant1_2402_1000~26500 Page17of22 BLE_1M_Ant1_2440_0~Reference BLE_1M_Ant1_2440_30~1000 Page18of22 BLE_1M_Ant1_2440_1000~26500 BLE_1M_Ant1_2480_0~Reference BLE_1M_Ant1_2480_30~1000 Page19of22 BLE_1M_Ant1_2480_1000~26500 Page20of22 AppendixG:DutyCycle TestResult TestModeAntennaChannel ONTime [ms] Period [ms] XDC [%] xFactor LimitVerdict BLE_1MAnt1 24020.380.63 0.603 2 60.322.20---PASS 24400.380.63 0.603 2 60.322.20---PASS 24800.380.63 0.603 2 60.322.20---PASS Page21of22 TestGraphs BLE_1M_Ant1_2402 BLE_1M_Ant1_2440 BLE_1M_Ant1_2480 Page22of22 ---End---
