2AOKB-T8741Doorbell Chime USB Dongle for HomeBase2

Anker Innovations Limited. All rights reserved. eufy and the eufy logo are trademarks of Anker Innovations Limited, registered in the United States and other countries. All other trademarks are the property of their respective owners. 51005002240 V01 USER MANUAL Video Doorbell Chime Table of Contents What’s in the Box 02 What’s Required for Installation? 02 Installation 03 Replacing the Power Connector 03 Notice 05 Customer Service 07 01 EnglishEnglish 02 INSTALLATION Step 1. Fix the Power Connector to the Doorbell Chime. A . Place the Power Connector over the Chime in the direction the arrows indicate. B . Align the raised slots of the Power Connector with the notch on the base of the Doorbell Chime. C . Rotate clockwise to lock the Power Connector in place. Step 2. Plug the Doorbell Chime into an AC power supply at your desired location. Step 3. Plug the USB dongle into the USB port on the back of the HomeBase 2. Step 4. In the eufySecurity App, go to Doorbell Settings - Indoor Chime. Follow the onscreen instruction to add the Chime to your existing Video Doorbell. WHAT’S IN THE BOX Doorbell Chime Model: T8740 Power Connector (Pin type may vary in different regions) Doorbell Chime USB Dongle for HomeBase 2 Model: T8741 WHAT’S REQUIRED FOR INSTALLATION? This Doorbell Chime is an accessory exclusive to the eufy Security Video Doorbell 2K (Battery-Powered). The USB dongle enables eufy HomeBase 2 to connect to doorbell chimes. One USB dongle can control up to 4 doorbell chimes. The USB dongle can only work with HomeBase 2 when a eufy video doorbell is connected to this HomeBase 2 and the doorbell is pressed. 03 EnglishEnglish 04 NOTICE T his product complies with the radio interference requirements of the European Community. Declaration of Conformity Hereby, Anker Innovations Limited declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU.For the declaration of conformity, visit the Web site https://www.eufylife.com/. Do not use the Device in the environment at too high or too low temperature, never expose the Device under strong sunshine or too wet environment. The suitable temperature for the product and accessories is 0°C - 45°C. RF exposure information: The Maximum Permissible Exposure (MPE) level has been calculated based on a distance of d=20 cm between the device and the human body. To maintain compliance with RF exposure requirement, use product that maintain a 20cm distance between the device and human body. 433MHz Frequency Range:433.92MHZ;433MHz Max Output Power:7.303dBm The following importer is the responsible party (contact for EU matters only) Importer: Anker Technology (UK) Ltd Importer Address: Suite B, Fairgate House, 205 Kings Road, Tyseley, Birmingham, B11 2AA, United Kingdom This product is designed and manufactured with high quality materials and components, which can be recycled and reused. This symbol means the product must not be discarded as household waste, and should be delivered to an appropriate collection facility for recycling. Proper disposal and recycling helps protect natural resources, human health and the environment. For more information on disposal and recycling of this product, contact your local municipality, disposal service, or the shop where you bought this product. FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Step 5. You may select the ringtone and adjust the volume level by using the Music and Volume buttons located on the side of the Doorbell Chime. There are 8 ringtones and 3 volume levels selectable. Each Chime can play a different ringtone according to your setting. REPLACING THE POWER CONNECTOR 1 . Press the Lock button and twist the Power Connector counterclockwise at the same time to remove it from the Doorbell Chime base. 2 . Install the new Power Connector onto the Doorbell Chime following the same procedure mentioned at the start of the guide. 05 EnglishEnglish 06 Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement The device has been evaluated to meet general RF exposure requirements. The device can be used in fixed / mobile exposure condition. The min separation distance is 20cm. The following importer is the responsible party Company Name: POWER MOBILE LIFE, LLC Address: 400 108th Ave NE Ste 400, Bellevue, WA 98004-5541 Telephone: 1-800-988-7973 This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device." Le présent appareil est conforme …

Text truncated - open the document above for the full version.

FCC ID: 2AOKB-T8741

Label Location On EUT Label

FCC ID: 2AOKB-T8741 ANT

version01 Anker Innovations Limited Declaration concerning Antenna Specification It is hereby declared that the product Model No.: T8741 FCC ID : 2AOKB-T8741 fulfills the requirement in FCC test relating to the antenna type. The device specified above confirms to the FCC recommendations for internal antenna type(s) described below: Model No. of antenna: T8741 Type of antenna:Spring Antenna Gain of the antenna: 0 dBi Frequency range:433.92MHz The mounting of the antenna is fixed to the radio module and no other antenna should be used. Company name: Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong City:Kowloon ZIP / Postal code: N/A Country:Hong Kong Place:KowloonDate:2020-05-15 Signature:

FCC ID: 2AOKB-T8741 RF EXPOSURE EVALUATION EUT Specification EUT Doorbell Chime USB Dongle for HomeBase2 Model Name T8741 Frequency band (Operating) WLAN: 2.412GHz ~ 2.462GHz WLAN: 5.18GHz ~ 5.32GHz / 5.50GHz ~ 5.70GHz WLAN: 5.745GHz ~ 5825GHz Others(433.92MHz) Device category Portable (<20cm separation) Mobile (>20cm separation) Others ___ Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Max. output power 80.42 dBuV/m (-14.837dBm)(0.033mW) Antenna gain 0 dBi Evaluation applied MPE Evaluation SAR Evaluation Standard Requirement Portable Device According to §15.247(i) and §1.1307b(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy levels in excess of the Commission’s guidelines. See KDB 447498 D01 General RF Exposure Guidance V6, section 4.3.1. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, 16 where ·f(GHz) is the RF channel transmit frequency in GHz ·Power and distance are rounded to the nearest mW and mm before calculation17 ·The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. FCC ID: 2AOKB-T8741 Measurement Result Channel Frequency (MHz) Max Output power (dBm) Max Output power (mW) Calculation Value (Note 1) Threshold Value 433.92 -14.837 0.033 0.0044 3.0 EIRP=E-104.8+20logD= 73.59 -104.8+20log3= -14.837dbm Note 1: Calculation Value =[(max. power of channel, mW)/(min. test separation distance, mm)] ·[√f(GHz)]. Fox example: 0.033/5*√0.43392= 0.0044 ≤3.0 According to KDB447498 D01 V6, threshold at which no SAR required is ≤3.0 for 1-g SAR, separation distance is 5mm, and no simultaneous SAR measurement is required. Standard Applicable According to 2.1093 this is a portable device. According to KDB 447498 D01 V6, Appendix A SAR test exclusion thresholds for below table, the power level 22mW at 5mm. Measurement Result: This is a portable device and the Max. peak output power is -14.837dBm(0.033mW) lower than low threshold 22mW at 5mm in general population category; The SAR measurement is not necessary.

Report No.: 18220WC00037401FCC ID: 2AOKB-T8741Page 1 of 25 Code:AB-RF-05-a FCC Test Report Client Name: Anker Innovations Limited Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong Product Name: Doorbell Chime USB Dongle for HomeBase2 Date: May 15, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00037401FCC ID: 2AOKB-T8741Page 2 of 25 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 4 1.1. Client Information ....................................................................................................................................... 4 1.2. Description of Device (EUT) ..................................................................................................................... 4 1.3. Auxiliary Equipment Used During Test ................................................................................................... 4 1.4. Description of Test Modes ........................................................................................................................ 5 1.5. List of channels ........................................................................................................................................... 5 1.6. Description Of Test Setup ......................................................................................................................... 6 1.7. Test Equipment List .................................................................................................................................... 7 1.8. Measurement Uncertainty ......................................................................................................................... 8 1.9. Description of Test Facility ........................................................................................................................ 8 2. Summary of Test Results ..................................................................................................................................... 9 3. Conducted Emission Test ................................................................................................................................... 10 3.1. Test Standard and Limit .......................................................................................................................... 10 3.2. Test Setup .................................................................................................................................................. 10 3.3. Test Procedure .......................................................................................................................................... 10 3.4. Test Data .................................................................................................................................................... 10 4. Radiation Spurious Emission and Band Edge ................................................................................................ 13 4.1. Test Standard and Limit .......................................................................................................................... 13 4.2. Test Setup .................................................................................................................................................. 14 4.3. Test Procedure .......................................................................................................................................... 15 4.4. Test Data .................................................................................................................................................... 15 5. 20DB Occupy Bandwidth Test ........................................................................................................................... 21 5.1. Test Standard and Limit .......................................................................................................................... 21 5.2. Test Setup .................................................................................................................................................. 21 5.3. Test Procedure .......................................................................................................................................... 21 5.4. Test Data .................................................................................................................................................... 21 6. Dwell Time Test .................................................................................................................................................... 23 6.1. Test Standard and Limit .......................................................................................................................... 23 6.2. Test Setup .................................................................................................................................................. 23 6.3. Test Procedure .......................................................................................................................................... 23 6.4. Test Data .................................................................................................................................................... 23 7. Antenna Requirement ......................................................................................................................................... 25 7.1. Test Standard and Requirement ............................................................................................................ 25 7.2. Antenna Connected Construction .......................................................................................................... 25 Report No.: 18220WC00037401FCC ID: 2AOKB-T8741Page 3 of 25 Code:AB-RF-05-a TEST REPORT Applicant: Anker Innovations Limited Manufacturer: Anker Innovations…

Text truncated - open the document above for the full version.

FCC ID: 2AOKB-T8741 Photo of Conducted Emission Measurement Photo of Radiated Emission Measurement
