2AOKB-T8S10B130 eufy Wi-Fi NVR

123456 QUICK START GUIDE eufy Wi-Fi NVR System AT A GLANCE ① ④⑤⑥⑦⑧ ② ③ ① Status LED ② Speaker ③ Storage Drive Bay ④ Power Port ⑤ Ethernet Port ⑥ USB Port ⑦ Reset Button ⑧ SYNC / ALARM OFF Button INSTALLING YOUR STORAGE DRIVE You need to install the included storage drive to save video recordings. ⚠ • The Wi-Fi NVR must be powered off when you install or remove a storage drive. • To avoid data loss, transfer any existing data on your storage drive to another location before adding your storage drive to the Wi-Fi NVR. 1. Unscrew and remove the storage drive bay cover. SETTING UP THE SYSTEM 1. Power on your Wi-Fi NVR and connect to your router using an Ethernet cable. Wait for up to 1 minute and the Wi-Fi NVR is now ready to be set up. 2. Connect your cameras to power using their power adapters. ① ② ③ ④⑤⑥ ⑦ ⑧ Ensure Tight Seal ① Camera Lens ② Spotlight ③ LED Indicator ④ Micro-USB Port (for maintenance only) ⑤ microSD Card Slot ⑥ SYNC Button ⑦ Mounting Bracket ⑧ Angle Adjustment Knob Model: T8S10Model: T8600 B130 eufy Wi-Fi NVRB130 eufy Wi-Fi Camera Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo are trademarks of Anker Innovations Limited, registered in the United States and other countries. All other trademarks are the property of their respective owners. 51005003653 V1 2. Take out the storage drive bracket. 3. Fix your storage drive to the bracket with the included screws. HARD DRIVE 4. Insert the bracket back into the Wi-Fi NVR, replace the cover, and secure it with the screws. Your additional storage drive must meet the following requirements: TypeStorage drive (HDD) compatible with the SATA interface Size3.5 inch CapacityUp to 8 TB RecommendedSurveillance hard drive such as WD Purple Series, Seagate SkyHawk Series, or TOSHIBA S300 Series 78910111213 MOUNTING YOUR CAMERA Select a Location and a Height Select a location that is within reach of a power outlet. If the distance is more than 16.4 ft (5 m), please contact our customer service for a separately sold extension cable. ≤16.4 ft (5 m) • Disconnect the camera from the power outlet before mounting. Make sure the camera receives a strong Wi-Fi connection in the location you want to mount it to achieve a smooth video stream. SAFETY • The suitable temperature range for B130 eufy Wi-Fi Camera and accessories is -20°C to 45°C (-4°F - 113°F). The suitable temperature range for B130 eufy Wi-Fi NVR and accessories is -10°C to 35°C (14°F - 95°F). The recommended temperature range for devices and accessories is 5°C to 25°C (41°F - 77°F). • Unless specifically indicated that it is safe to do so in the user guide or instruction manual, do not use this device in an environment that exceeds the recommended low or high temperature. • Unless specifically indicated that it is safe to do so in the user guide or instruction manual, avoid exposing your device to direct sunlight or wet environments. • The power adapter should be installed near the equipment and should be easily accessible. • Use only a power adapter supplied by or approved by the manufacturer. Using an unauthorized power adapter may cause danger and may violate the authorization of the device to receive service under warranty. • The power adapter is for indoor use only. The plug is considered as a disconnect device of the adapter. NOTICE NOTICE (United States of America) FCC Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful Mount the Camera 1. Use the position template to drill holes with correct spacing, then mount the camera using the provided screws. • Screw anchors are necessary for walls that are made out of hard materials such as concrete, brick, or stucco. 2. Route the power cable into the waterproof case and connect it to the power adaptor, then plug the adaptor into the power outlet. interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation between the equipment and receiver. (3) Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. (4) Consult the dealer or an experienced radio/TV technician for help. FCC Radio Frequency Exposure Statement The device has been evaluated to meet general RF exposure requirements. The device can be used in fixed/mobile exposure condition. The min separation distance is 20cm. Notice: Shielded cables All connections to other computing devices must be made using shielded cables to maintain compliance with FCC regulations. The following importer is the responsible party Company Name: POWER MOBILE LIFE, LLC Address: 10900 NE 8th St, Ste 501, Bellevue WA 98004 Telephone: 1-800-988-7973 NOTICE (Canada) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device…

Text truncated - open the document above for the full version.

Declaration To whom it may concern: We have declared below featured for FCC equipment authorization, Device FCC ID: 2AOKB-T8S10 Don't operate on Channels 12 and 13. US 2.4G channel 12-13 and Country code selection are disabled through proprietary software and are not user changeable Should you have any questions, please feel free to contact me. Date: 2022/12/1 Signature : Title: Certification Direct Company name: Anker Innovations Limited

AnkerInnovationsLimited Date:2022/11/24 To:FederalCommunicationsCommission, Authorization& EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD21046 To
Whom
It
May
Concern: The
Anker
Innovations
Limited,
the
undersigned,
hereby
authorizes
Mrs.
Wendy
Zhan
from
Shenzhen
Morlab
Communications
Technology
Co.,
Ltd. ,
to
act
on
the
behalf
of
the
Anker
Innovations
Limited
solely
in
matters
relating
to
the
application
for
an
FCC
equipment
authorization
for
FCC
ID:
2AOKB-T8S10
including
the
signing
of
documents
in
connection
with
this
Application.
Necessary
acts
carried
out
Shenzhen
Morlab
Communications
Technology
Co.,
Ltd.
on
our
behalf
of
the
Anker Innovations
Limited
in
connection
with
the
application
shall
have
the
same
effect
as
acts
of
the
Anker
Innovations
Limited.
Anker
Innovations
Limited
also
hereby
certify
that
no
party
to
this
application
is
subject
to
a
denial
of
benefits,
including
FCC
benefits,
pursuant
to
Section
5301
of
the
Anti-Drug
Abuse
Act
of
1988,
21
U.S.C.
862. Thank
you
for
your
attention
to
this
matter. YoursSincerely, Signatory: Contactname:LouisQi Tel:+86-13652441319 Email:[email protected] Companyname:AnkerInnovationsLimited

： AnkerInnovationsLimited Date:20 22/11/24 To:FederalCommunicationsCommission, Authorization& EvaluationDivision, 7435OaklandMillsRoad, Columbia,MD 21046 Re:
Request
of
Confidentiality
for
FCC
ID:
2AOKB-T8S10 To
Whom
it
may
concern: Pursuant
to
sections
0.457
and
0.459
of
Commission’s
Rules(CFR
47),
and
Section 552(b)(4)
of
the
Freedom
of
Information
Act,
Anker
Innovations
Limited
hereby
requests
confidentiality
and
treatment
of
certain
information
accompanying
this
application.
The
materials
contain
trade
secrets
and
proprietary
information
not
customarily
released
to
the
public.
The
public
disclosure
of
these
matters
might
be
harmful
to
the
Applicant
and
provide
unjustified
benefits
to
its
competitors. We
are
also
hereby
request
Short-Term
Confidentiality
(max
time
180
days
from
grant
date)
as
outlined
in
Public
Notice
DA04-1705.
This
provision
will
give
Anker
Innovations
Limited
temporary
confidentiality
of
commercially
sensitive
information
prior
to
product
release. The
requested
Permanent
and
Short-Term
Confidential
exhibits
are
listed
as
follows: PERMANENTANDSHORT-TERMCONFIDENTIALLIST ExhibitDescription PERMANENT 1BlockDiagram 2OperationalDescription 3Schematics 4BOM SHORT-TERM 5ExternalPhotos 6InternalPhotos 7Test-SetupPhotos 8UserManual TheApplicantunderstandsthatpursuantto Rule0.457,disclosureof thisapplicationandall accompanyingdocumentations,whereapplicable,willnot be madepublicbeforethe dateof the Grantfor thisapplication. Signatory Name: LouisQi CompanyName : AnkerInnovationsLimited Address: Room1318-19,HollywoodPlaza,610NathanRoad,Mongkok,Kowloon,HongKong Tel:+86-13652441319 Email: [email protected]

FCC ID: 2AOKB-T8S10, Model Name: T8S10 External Photos 1. EUT front view 2. EUT rear view 3. EUT left side view 4. EUT right side view 5. EUT top view 6. EUT bottom view 7. Accessories

1. Label 2. Label location

3-3 Environment treatment

FCC ID: 2AOKB-T8S10, Model Name: T8S10 Internal Photos 1. EUT uncover view 2. Antenna view 2.4G WIFI Antenna

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 8 REPORT No.：SZ22100126S01 RF EXPOSURE EVALUATION REPORT APPLICANT : Anker Innovations Limited PRODUCT NAME : B130 eufy Wi-Fi NVR MODEL NAME :T8S10 BRAND NAME : eufy SECURITY BUSINESS FCC ID :2AOKB-T8S10 STANDARD(S) : 47 CFR Part 2(2.1091) RECEIPT DATE : 2022-10-14 TEST DATE :2022-10-26 to 2022-11-16 ISSUE DATE :2022-12-02 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100126S01 Page2of 8 DIRECTORY 1. Technical Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.1 Applicant and Manufacturer Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.2 Equipment under Test (EUT) Description ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 3 1.3 Applied Reference Documents ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 4 2. Device Category and RF Exposure Limit ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 5 3. RF Output Power ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 6 4. RF Exposure Assessment ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 7 Annex A Testing Laboratory Information ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 8 Change History Version Date Reason for change 1.0 2022-12-02 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100126S01 Page3of 8 1. Technical Information Note: Provide by applicant. 1.1 Applicant and Manufacturer Information Applicant: Anker Innovations Limited Applicant Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Manufacturer Address: Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong Kong 1.2 Equipment under Test (EUT) Description Product Name: B130 eufy Wi-Fi NVR Sample No.: 1# Hardware Version: T8S10-MAINBOARD-V0.2 Software Version: 1.1.0.0 Modulation Technology: DSSS, OFDM Operating Frequency Range: 802.11b/g/n (HT20): 2412MHz–2462MHz Antenna Type: PCB Antenna Antenna Gain: ANT 1: 2.73dBi; ANT 2: 2.95dBi Note 1: The EUT can be used with two kinds of antenna and it operates in single antenna. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100126S01 Page4of 8 1.3 Applied Reference Documents Leading reference documents for testing: Identity Document Title Method determination /Remark 47 CFR Part 2(2.1091) Radio Frequency Radiation Exposure Assessment: mobile devices No deviation KDB 447498 D01v06 General RF Exposure Guidance No deviation Note 1: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 2: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] REPORT No.：SZ22100126S01 Page5of 8 2. Device Category and RF Exposure Limit Per user manual, based on 47 CFR 2.1091, this device belongs to mobile device category with General Population/Uncontrolled exposure. Mobile Devices: 47 CFR 2.1091(b) For purposes of this section, a mobile device is defined as a transmitting device designed to be used in other than fixed locations and to generally be used in such a way that a separation distance of at least 20 centimeters is normally maintained between the transmitter's radiating structure(s) and the body of the user or nearby persons. In this context, the term “fixed location” means that the device is physically secured at one location and is not able to be easily moved to another location. Transmitting devices designed to be used by consumers or workers that can be easily re-located, such as wireless devices associated with a personal computer, are considered to be mobile devices if they meet the 20 centimeter separation requirement. General Population/Uncontrolled Exposure: The general population/uncontrolled exposure limits are applicable to situations in which the general public may be exposed or in which persons who are exposed as a consequence of their e…

Text truncated - open the document above for the full version.

SPECIFICATION SPECIFICATION SHEETFORAPPROVAL （Revision：R：A1） CUSTOMER(客户名称) Anker CSP/N(客户机种) T8S10 T810 PARTNAME(品名) ANT0ASSY FREQUENCY( 频率 ) 2400~2500MHz ZTXNO.( 物料编号 ) 2.00005593 A04-32002000098 DATE( 日期 ) 2022-12-01 Remark(备注)： Sign(客户确认签字盖章)： Add:NO.34ShilongRoad,Bao'anDistrict,Shenzhen,GuangdongProvince,China Code:518000Tel:0755-27588320Fax:0755-27588045 http://www.chinaztx.com CUSTOMER QA CHECKED ME CHECKED RF CHECKED MANAGER CHECKED MANAGER CHECKED MANAGER CHECKED ME CHECKED RF CHECKED LISTER LIPING.LIUYIQING.LIN ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page1of8 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY Revisionhistory RevDateDescription A12022-12-01 FIRSTISSUE ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page2of8 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY Index Revisionhistory 1 lndex 2 1MechanicalSpecification 3 1-1 MechanicalSpecification （ T8S10ANT0ASSY ） 3 2Testequipment 4 3TestResultsSurmmary 5 3-1 ActiveTest 5 3-2PassiveTest 5 3-2-1VSWR 6 3-2-2EfficiencyandGain 6 3-2-32D/3DRadiationPatternResults 7 3-2-4Environmenttreatment 7 4TestReport 8~9 5Thepackingway 10 ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page3of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 1.MechanicalSpecification 1-1MechanicalConfiguration（T8S10ANT0ASSY） ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page4of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 2.Testequipment ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page5of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 3.TestResultsSurmmary 3-1ActiveTest 3-2PassiveTest 3-2-1VSWR ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page6of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 3-2-2lsolation 3-2-3EfficiencyandGain ANTENNA SPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev: R:A1 Page 7 of 10 CUS P/N :T8S10 ANT0 ASSY ZTX P/N :T8S10 ANT0 ASSY 3-2-4 2D/3D Radiation Pattern Results 3-3 Environment treatment Please refer to ANT Report-Photo for details. ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page8of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 4.TestReport ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page9of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page10of10 CUSP/N:T8S10ANT0ASSY ZTXP/N:T8S10ANT0ASSY 5.Thepackingway

SPECIFICATION SPECIFICATION SHEETFORAPPROVAL （Revision：R：A1） CUSTOMER(客户名称) Anker CSP/N(客户机种) T8S10 T810 PARTNAME(品名) ANT1ASSY FREQUENCY( 频率 ) 2400~2500MHz ZTXNO.( 物料编号 ) 2.00005594 A04-32002000099 DATE( 日期 ) 2022-12-01 Remark(备注)： Sign(客户确认签字盖章)： Add:NO.34ShilongRoad,Bao'anDistrict,Shenzhen,GuangdongProvince,China Code:518000Tel:0755-27588320Fax:0755-27588045 http:// www.chinaztx.com CUSTOMER QA CHECKED ME CHECKED RF CHECKED MANAGER CHECKED MANAGER CHECKED MANAGER CHECKED ME CHECKED RF CHECKED LISTER LIPING.LIUYIQING.LIN ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page1of8 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY Revisionhistory RevDateDescription A12022-12-01 FIRSTISSUE ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page2of8 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY Index Revisionhistory 1 lndex 2 1MechanicalSpecification 3 1-1 MechanicalSpecification （ T8S10ANT1ASSY ） 3 2Testequipment 4 3TestResultsSurmmary 5 3-1 ActiveTest 5 3-2PassiveTest 5 3-2-1VSWR 6 3-2-2 EfficiencyandGain 6 3-2-32D/3DRadiationPatternResults 7 3-2-4Environmenttreatment 7 4TestReport 8~9 5Thepackingway 10 ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page3of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY 1.MechanicalSpecification 1-1MechanicalConfiguration（T8S10ANT1ASSY） ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page4of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY 2.Testequipment ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page5of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY 3.TestResultsSurmmary 3-1ActiveTest 3-2PassiveTest 3-2-1VSWR ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page6of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY 3-2-2lsolation 3-2-3EfficiencyandGain ANTENNA SPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev: R:A1 Page 7 of 10 CUS P/N :T8S10 ANT1ASSY ZTX P/N :T8S10 ANT1ASSY 3-2-4 2D/3D Radiation Pattern Results 3-3 Environment treatment 4.TestReport Please refer to ANT Report-Photo for details. ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page8of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page9of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY 5.Thepackingway ANTENNASPECIFICATION ApplicationDate:Dec,01,2022 Editor: Rev:R:A1 Page10of10 CUSP/N:T8S10ANT1ASSY ZTXP/N:T8S10ANT1ASSY

NOTE: This document is issued by Shenzhen Morlab Communications Technology Co., Ltd., the test report shall not be reproduced except in full without prior written permission of the company. The test results apply only to the particular sample(s) tested and to the specific tests carried out which is available on request for validation and information confirmed at our website. MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 1 of 83 REPORT No.：SZ22100126W01 TEST REPORT APPLICANT : Anker Innovations Limited PRODUCT NAME : B130 eufy Wi-Fi NVR MODEL NAME : T8S10 BRAND NAME :eufy SECURITY BUSINESS FCC ID :2AOKB-T8S10 STANDARD(S) :47 CFR Part 15 Subpart C RECEIPT DATE : 2022-10-14 TEST DATE :2022-10-26 to 2022-11-16 ISSUE DATE :2022-12-02 Edited by: Peng Mi (Rapporteur) Approved by: Shen Junsheng (Supervisor) MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 2 of 83 REPORT No.：SZ22100126W01 DIRECTORY 1. Summary of Test Result ················································································ 4 1.1. Testing Applied Standards ·········································································· 5 1.2. Test Equipment List ··················································································· 6 1.3. Measurement Uncertainty ··········································································· 8 1.4. Testing Laboratory ····················································································· 8 2. General Description ····················································································· 9 2.1. Information of Applicant and Manufacturer ··················································· 9 2.2. Information of EUT ····················································································· 9 2.3. Channel List of EUT ·················································································· 10 2.4. Test Configuration of EUT ·········································································· 11 2.5. Test Conditions ························································································ 11 2.6. Test Setup Layout Diagram ········································································ 12 3. Test Results ······························································································· 15 3.1. Antenna Requirement ··············································································· 15 3.2. Duty Cycle of Test Signal ··········································································· 16 3.3. Maximum Peak and Average Conducted Output Power ·································· 17 3.4. 6 dB Bandwidth ························································································ 18 3.5. Conducted Spurious Emissions and Band Edge ··········································· 19 3.6. Power Spectral Density ············································································· 20 3.7. Conducted Emission ················································································· 21 3.8. Restricted Frequency Bands ······································································ 22 3.9. Radiated Emission ···················································································· 23 Annex A Test Data and Result ·········································································· 25 MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 3 of 83 REPORT No.：SZ22100126W01 Change History Version Date Reason for change 1.0 2022-12-02 First edition MORLAB Shenzhen Morlab Communications Technology Co., Ltd. FL1-3, Building A, FeiYang Science Park, No.8 LongChang Road, Block67, BaoAn District, ShenZhen , GuangDong Province, P. R. China Tel: 86-755-36698555 Fax: 86-755-36698525 Http://www.morlab.cn E-mail: [email protected] Page 4 of 83 REPORT No.：SZ22100126W01 1. Summary of Test Result No. Section Description Test Date Test Engineer Result Method Determination /Remark 1 15.203 Antenna Requirement N/A N/A PASS No deviation 2 N/A Duty Cycle of Test Signal Oct. 26, 2022 Su Xiaoxian PASS No deviation 3 15.247(b) Maximum Peak Conducted Output Power Nov. 04, 2022 Su Xiaoxian PASS No deviation 4 15.247(b) Maximum Average Conducted Output Power Nov. 04, 2022 Su Xiaoxian PASS No deviation 5 15.247(a) Bandwidth Nov. 01, 2022 Su Xiaoxian PASS No deviation 6 15.247(d) Conducted Spurious Emission and Band Edge Nov. 01, 2022 Su Xiaoxian PASS No deviation 7 15.247(e) Power Spectral Density Nov. 01, 2022 Su Xiaoxian PASS No deviation 8 15.207 Conducted Emission Nov. 03, 2022 Fan Zehang PASS No deviation 9 15.247(d) Restricted Frequency Bands Nov. 16, 2022 Gao Jianrou PASS No deviation 10 15.209, 15.247(d) Radiated Emission Nov. 16, 2022 Gao Jianrou PASS No deviation Note 1: The tests were performed according to the method of measurements prescribed in ANSIC63.10-2013 and KDB558074 D01 v05r02. Note 2: Additions to, deviation, or exclusions from the method shall be judged in the "method determination" column of add, deviate or exclude from the specific method shall be explained in the "Remark" of the above table. Note 3: When the test result is a critical value, we will use the measurement uncertainty give the judgment result based on the 95% confidence intervals. MORLAB Shenzhen Morla…

Text truncated - open the document above for the full version.

FCC ID: 2AOKB-T8S10, Model Name: T8S10 Test Setup Photos 1. Conducted emission main’s port front view 2. Conducted emission main’s port side view 3. Radiated emission (9KHz-30MHz) 4. Radiated emission (30MHz-1GHz) 5. Radiated emission (above 1GHz) 6. RF measurement setup (WIFI 2.4G)
