2AOKB-Y1811Wireless Charger

Anker Innovations Limited

Click to zoom

Application Details

Equipment Class: DCD - Part 15 Low Power Transmitter Below 1705 kHz
Date of Grant: Jul 31, 2022
Application Purpose: Original Equipment
Date of Application: Jul 31, 2022
Equipment Note: Wireless Charger
Frequency Range: 0.13920000 - 0.14180000
Company: Anker Innovations Limited
Country: Hong Kong

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Product Number: Y1811 51005003399 V02 For FAQs and more information, please visit: anker .com/support @Anker Deutschland @Anker Japan @Anker @AnkerOcial @Anker_JP @anker_ocial @anker_jp English 01 Deutsch 06 Español 09 Français 12 Italiano 15 Nederlands 18 Português 21 P усский 24 Türk 27 日本語 30 한국어 33 简体中文 37 繁體中文 39 ية ِ ب َ ر َ لع 42 ית ִ בר ִ ע 45 0201 EN Specifications Adapter Input100-240V~50/60HZ 1.0A Output 5.0V 3.0A / 9.0V 3.0A / 12.0V 2.5A / 15.0V 2.0A / 20.0V 1.5A Average Active Efficiency85.67% Efficiency at Low Load (10%) 84.17% No-Load Power Consumption 0.04W Wireless Charger Input12.0V 2.5A / 15.0V 2.0A / 20.0V 1.5A Output Wireless: 5W/7.5W/15W(for iPhone) 5W Max (for Apple Watch) 5W Max(for AirPods) Operating Temperature0°C - 40°C Radiated H-Field EU / UK Only: -20.70dBuA/m@10m (for iPhone) -25.60dBuA/m@10m (for Apple Watch) -14.18dBuA/m @10m (for AirPods) TX/RX Frequency Range EU / UK Only: For iPhone: 359.20-361.60kHz For Apple Watch: 324.80-327.20kHz For AirPods: 139.20-141.60KHz LED indicator StatusStatus Solid white light up for 3sConnected to power Solid whilteCharging (Airpods only) Solid orangeMetal object detected while charging. Flashing Orange Over-voltage or under-voltage protection activated. An incompatible AC adapter may be connected. Please use a Power Delivery adapter that meets the requirements. • • This wireless charger is not compatible with non-MagSafe phone cases, such as Otterbox Defender cases. • • Connect the wireless charger to a Power Delivery wall adapter. Do not connect to a 5V/1A wall charger or a USB port on a computer as it may affect the wireless charging function. • • Do not place any foreign objects between your device and the wireless charger’s surface, including metal pads on a car mount, magnetic cards, door keys, coins, NFC cards or other metal objects, as they could potentially demagnetize the wireless charger, affect the charging speed, or cause overheating. • • Wireless charging products make charging more convenient than wired chargers, but confined by current wireless technology, their charging speed is slower than that of wired chargers. • • High temperatures will reduce charging speed and restrict power. It is recommended that you charge your device in environments with temperatures below 40°C / 104°F. 0403 Important Safety Instructions Please refer to the electrical and safety information on the bottom before installing or operating the product. • • Avoid dropping. • • Do not disassemble. • • Do not expose to liquids. • • This product is suitable for moderate climates only. • • The maximum ambient temperature during use of this product must not exceed 40°C. • • Open flame sources, such as candles, must not be placed on this product. • • Only use a dry cloth or brush to clean this product. FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC RF Exposure Statement This equipment complies with FCC Radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20cm between the product and your body. Product Name: Anker 3-in-1 Cube with MagSafe Model: Y1811 The following importer is the responsible party (for FCC matters only). Company Name: Fantasia Trading LLC Address: 5350 Ontario Mills Pkwy, Suite 100, Ontario, CA 91764 Telephone: +1 800 988 7973 IC Warning Statement: This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada's licence-exempt RSS(s). Operation is subject to the following two conditions: 1. This device may not cause interference. 2. This device must accept any interference, including interference that may cause undesired operation of the device. L'émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d'Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes: 1. L'appareil ne doit pas produire de brouillage; 2. L'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement. IC RF exposure statement: This equipment complies with IC Radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated w…

Text truncated - open the document above for the full version.

Cover Letter(s)

Anker Innovations Limited Date: 05/26/2022 TO: Federal Communication Commission Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MID 21046 Regarding:FCC ID: 2AOKB-Y1811 To whom it may concern: We, the undersigned, hereby authorize Compliance Certification Services (Kunshan) Inc and Kidd Yang in Compliance Certification Services (Kunshan) Inc to act on our behalf inall manners relating to application for equipment authorization with respect to the FCC ID above,including signing of all documents relating to these matters. Any and all acts carried out by the agent on our behalf shall have the same effect as acts of our own. We, the undersigned, hereby certify that we are not subject to a denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 853(a). Where our agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for Certification, as specified by SGS North America, Inc., still resides withAnker Innovations Limited This authorization is valid until further written notice from the applicant. Sincerely, Print Name: louis QiTitle: General Manager Signature: On behalf of Company: Anker Innovations Limited Telephone: +86-13652441319 E-mail: [email protected]

Cover Letter(s)

AnkerInnovationsLimited TO: FederalCommunicationCommission EquipmentAuthorizationBranch 7435OaklandMillsRoad Columbia,MID21046 Regarding: ConfidentialityRequestregardingapplicationfor FCCID:2AOKB‐Y1811 LONGTERMCONFIDENTIALITY Pursuantto47CFRSection0.459and0.457ofthecommission’srules,theapplicantherebyrequestconfidential treatmentofthedocumentslistedbelow,associatedwiththecertificationapplicationreferencedabove. Schematic(s) BlockDiagrams OperationalDescriptions Thedocumentsabovecontainproprietaryinformationnotreleasedtothepublic.Publicdisclosureofthis informationmayproveharmfultothebusinessoftheapplicant. SHORTTERMCONFIDENTIALITY Additionally,theapplicantrequeststhefollowingdocumentsbeheldconfidentialuntilthedeviceismarketedor 180daysfromthegrantdate,whicheverisless. Ifthedeviceismarketedwithinaforementionedda ys ofthe GrantDate,theapplicantwillnotifytheTCBperFCCKDB726920D01ConfidentialityRequestProcedures. ExternalPhotos InternalPhotos TestSetupPhotos UserManuals Sincerely, PrintName:louisQiTitle:GeneralManager Signature: OnbehalfofCompany:AnkerInnovationsLimited Telephone:+86‐13652441319 E‐mail:[email protected]

Cover Letter(s)

AnkerInnovationsLimited CoverLetter‐WirelessChargerApproval Date:05/26/2022 Gentlemen: There’sawirelesschargerthatwouldliketohaveyourauthorizationasanInductivewirelesspower transferapplicationsapproval. Thespecificproductasbelow,wirelesscharger,withitsdesignedfeaturesandspecifieddescription, meetsspecialrequirementsforKDB680106D01section5.2requirements. Company: AnkerInnovationsLimited ProductName: WirelessCharger ModelNumber: Y1811 FCCID: 2AOKB‐Y1811 KDB680106D01Section5.2RequirementsProductTechnicalSpecificationReply a)Powertransferfrequencyislessthat1MHz For iPhone: 359.20‐361.60kHz For Apple Watch: 324.80‐327.20kHz For AirPods: 139.20‐141.80kHz Complied b)Outputpowerfromeachprimarycoilislessthan orequalto15watts. For iPhone: 15W max. For Apple watch: 5W For Air pods: 5W Complied c)Thetransfersystemincludesonlysingleprimary andsecondarycoils.Thisincludeschargingsystems thatmayhavemultipleprimarycoilsandclients thatareabletodetectandallowcouplingonly betweenindividualpairsofcoils Complied d)Clientdeviceisplaceddirectlyincontactwith thetransmitter. Complied e) Mobileexposureconditionsonly Complied f)TheaggregateH‐fieldstrengthsat15cm surroundingthedeviceand20cmabovethetop surfacefromallsimultaneoustransmittingcoilsare demonstratedtobelessthan50%oftheMPElimit. PleaserefertoRFexposurereportComplied Sincerely, PrintName:louisQiTitle:GeneralManager Signature: OnbehalfofCompany:AnkerInnovationsLimited Telephone:+86‐13652441319 E‐mail:[email protected]

External Photos

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 7 External Photos for FYCR2205000191AT FCC ID: 2AOKB-Y1811 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 7 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 6 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 7 of 7

ID Label/Location Info

Y1811 工艺：镭雕颜色：黑色工艺：丝印颜色：5%黑色半透亚光UV 设计：Simon 日期：20220412 版本：V5

Internal Photos

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 7 Internal Photos for FYCR2205000191AT FCC ID: 2AOKB-Y1811 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 7 EUT Constructional Details (EUT Photos) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 7 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 6 of 7 Output 1 Antenna Output 3 Antenna Output 2 Antenna Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 7 of 7

RF Exposure Info

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 1 of 9 EMC Technical Manager 1 COVER PAGE Human Exposure Report Application No.: FYCR2205000191AT Applicant: Anker Innovations Limited Address of Applicant: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Address of Manufacturer: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Factory: 1, ASAP Technology(Jiangxi) Co., Ltd 2, LUXSHARE-ICT(NGHE AN) LIMITED Address of Factory: 1, Ji'an Industrial park, Ji'an, Jiangxi 343100 China 2, No.18 Street 03, VSIP Nghe An Industrial Park, Hung Tay Commune,Hung Nguyen District,Nghe An Province, Vietnam Equipment Under Test (EUT): EUT Name: Wireless Charger Model No.: Y1811 FCC ID: 2AOKB-Y1811 Standards: 47 CFR PART 1, Subpart I, Section 1.1310 47 CFR PART 2, Subpart J, Section 2.1091 Date of Receipt: 2022-05-25 Date of Test: 2022-05-26 to 2022-07-08 Date of Issue: 2022-07-12 Test Result : Pass* * In the configuration tested, the EUT complied with the standards specified above Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 2 of 9 Revision Record Version Chapter Date Modifier Remark 01 2022-07-12 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 3 of 9 2 Contents 1 COVER PAGE ......................................................................................................................................................... 1 2 CONTENTS .............................................................................................................................................................. 3 3 GENERAL INFORMATION ................................................................................................................................... 4 3.1 DETAILS OF E.U.T. ................................................................................................................................................. 4 3.2 DESCRIPTION OF SUPPORT UNITS ........................................................................................................................... 4 3.3 TEST LOCATION ...................................................................................................................................................... 5 3.4 TEST FACILITY ....................................................................................................................................................... 5 3.5 DEVIATION FROM STANDARDS ............................................................................................................................... 5 3.6 ABNORMALITIES FROM STANDARD CONDITIONS .................................................................................................... 5 4 EQUIPMENTS USED DURING TEST .................................................................................................................. 6 5 TEST RESULTS ...................................................................................................................................................... 8 5.1 RF EXPOSURE TEST ................................................................................................................................................ 8 5.1.1 E.U.T. Operation ........................................................................................................................................ 8 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 4 of 9 3 General Information 3.1 Details of E.U.T. Power Supply: Adapter: Model: ASPD9w-P30W20 Input: 100-240V~50/60HZ 1.0A Output: 5.0V/3.0A, 9.0V/3.0A, 12.0V/2.5A, 15.0V/2.0A, 20.0V/1.5A Wireless output: Output 1: 5W/7.5W/15W (for iphone) Output 2: 5W (for iwatch) Output 3: 5W (for airpods) Cable(s): USB-C to USB-C 150cm unshielded Operation frequency: Output 1 (for iphone): 359.20-361.60KHz Output 2 (for iwatch): 324.80-327.20KHz Output 3 (for airpods): 139.20-141.80KHz Modulation type: Load modulation Antenna type: Loop Antenna 3.2 Description of Support Units Description Manufacturer Model No. Serial No. iPhone 13 Apple MLDYCH/A REF. No.SEA16Q00 iWatch Apple Apple Watch 3 N/A Airpods Apple Airpods 2 REF. No.SEA05B06D E-loading SGS N/A REF. No.SEA42A00 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 5 of 9 3.3 Test Location All tests were performed at: Compliance Certification Services（Kunshan）Inc. Shenzhen branch. Fuyong lab. Xinlong TechnoPark,Fengtang Road, Fuyong Subdistrict, Bao’an, Shenzhen, China Tel: +86 755 8866 3988 Fax: +86 755 2671 0594 No tests were sub-contracted. 3.4 Test Facility The test facility is recognized, certified, or accredited by the following organizations: • A2LA (Certificate No. 6606.01) Compliance Certification Services（Kunshan）Inc. Shenzhen branch is accredited by the American Association for Laboratory Accreditation(A2LA). Certificate No. 6606.01. • FCC –Designation Number: CN1322 Compliance Certification Services（Kunshan）Inc. Shenzhen branch has been recognized as an accredited testing laboratory. Designation Number: CN1322. Test Firm Registration Number: 718073 • Innovation, Science and Economic Development Canada Compliance Certification Services（Kunshan）Inc. Shenzhen branch has been recognized by ISED as an accredited testing laboratory. CAB identifier: CN0129. IC#: 28189. 3.5 Deviation from Standards None. 3.6 Abnormalities from Standard Conditions None. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019102 Page: 6 of 9 4 Equipments Used during Test Item Test Equipment Manufacturer Model No. Inventory No. Cal. Due date 1 3m Anechoic Chamber CRT N/A SEM001-13 2022-07-12 2 Electric and Magnetic Field Analyzer Narda EHP…

Text truncated - open the document above for the full version.

Test Report

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019101 Page: 1 of 31 EMC Technical Manager TEST REPORT Application No.: FYCR2205000191AT Applicant: Anker Innovations Limited Address of Applicant: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Manufacturer: Anker Innovations Limited Address of Manufacturer: Room 1318-19, Hollywood Plaza 610 Nathan Road, Mongkok, Kowloon, Hong Kong Factory: 1, ASAP Technology(Jiangxi) Co., Ltd 2, LUXSHARE-ICT(NGHE AN) LIMITED Address of Factory: 1, Ji'an Industrial park, Ji'an, Jiangxi 343100 China 2, No.18 Street 03, VSIP Nghe An Industrial Park, Hung Tay Commune,Hung Nguyen District,Nghe An Province, Vietnam Equipment Under Test (EUT): EUT Name: Wireless Charger Model No.: Y1811 FCC ID: 2AOKB-Y1811 Standard(s) : 47 CFR Part 15, Subpart C Date of Receipt: 2022-05-25 Date of Test: 2022-05-26 to 2022-07-08 Date of Issue: 2022-07-12 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019101 Page: 2 of 31 Revision Record Version Chapter Date Modifier Remark 01 2022-07-12 Original Authorized for issue by: Tree Zhan/Project Engineer Winkey Wang/Reviewer Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019101 Page: 3 of 31 2 Test Summary Radio Spectrum Technical Requirement Item Standard Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C N/A 47 CFR Part 15, Subpart C 15.203 Pass Radio Spectrum Matter Part Item Standard Method Requirement Result Conducted Emissions at AC Mains Power Port (150kHz-30MHz) 47 CFR Part 15, Subpart C ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 Pass Radiated Emissions (30MHz-1GHz) ANSI C63.10 (2013) Section 6.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Emissions (9kHz-30MHz) ANSI C63.10 (2013) Section 6.4 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass 20dB Bandwidth ANSI C63.10 (2013) Section 6.9.2 47 CFR Part 15, Subpart C 15.215 Pass Restricted Bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 Pass Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Report No.: FYCR220500019101 Page: 4 of 31 3 Contents Page 1 COVER PAGE ............................................................................................................................................ 1 2 TEST SUMMARY ....................................................................................................................................... 3 3 CONTENTS ................................................................................................................................................ 4 4 GENERAL INFORMATION ........................................................................................................................ 6 4.1 DETAILS OF E.U.T. ............................................................................................................................... 6 4.2 DESCRIPTION OF SUPPORT UNITS ......................................................................................................... 6 4.3 MEASUREMENT UNCERTAINTY .............................................................................................................. 6 4.4 TEST LOCATION .................................................................................................................................... 7 4.5 TEST FACILITY ...................................................................................................................................... 7 4.6 DEVIATION FROM STANDARDS ............................................................................................................... 7 4.7 ABNORMALITIES FROM STANDARD CONDITIONS ..................................................................................... 7 5 EQUIPMENT LIST ...................................................................................................................................... 8 6 RADIO SPECTRUM TECHNICAL REQUIREMENT ............................................................................... 10 6.1 ANTENNA REQUIREMENT .................................................................................................................... 10 6.1.1 Test Requirement: ....................................................................................................................... 10 6.1.2 Conclusion ................................................................................................................................... 10 7 RADIO SPECTRUM MATTER TEST RESULTS ..................................................................................... 11 7.1 CONDUCTED EMISSIONS AT AC MAINS POWER PORT (150KHZ-30MHZ) .............................................. 11 7.1.1 E.U.T. Operation .......................................................................................................................... 11 7.1.2 Test Mode Description ................................................................................................................. 11 7.1.3 Test Setup Diagram ..................................................................................................................... 12 7.1.4 Measurement Procedure and Data............................................................................................. 12 7.2 RADIATED EMISSIONS (30MHZ-1GHZ) ................................................................................................ 15 7.2.1 E.U.T. Operation .......................................................................................................................... 15 7.2.2 Test Mode Description ................................................................................................................. 15 7.2.3 Test Setup Diagram ..........................................................…

Text truncated - open the document above for the full version.

Test Setup Photos

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 5 RF Exposure Setup Photos for FYCR2205000191AT FCC ID: 2AOKB-Y1811 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 5 Photographs Side 1 Side 2 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 5 Side 3 Side 4 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 4 of 5 Top Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 5 of 5

Test Setup Photos

Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 1 of 3 Appendix Photographs of Test Setup for FYCR2205000191AT FCC ID: 2AOKB-Y1811 Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 2 of 3 Test Setup Photos Conducted Emissions at AC Mains Power Port (150kHz-30MHz) Radiated Emissions (30MHz-1GHz) Compliance Certification Services (Kunshan) Inc. Shenzhen Branch Page: 3 of 3 Radiated Emissions (9kHz-30MHz)

Contact Information

Applicant

Louis Qi

[email protected]+86-755-86544807Fax: N/A

Technical Contact

Compliance Certification Services (Kunshan) IncKidd Yang

[email protected]+8675525326619

Fuyong Lab Xinlong Techno Park Fengtang Road · Shenzhen · China

Non-Technical Contact

Compliance Certification Services (Kunshan) IncKidd Yang

[email protected]+8675525326619

Test Firm

Compliance Certification Services (Kunshan) IncLina Ye

[email protected]8613798526121

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
3	15C	0.1392 MHz - 0.1418 MHz	-

Confidentiality

Long Term

Grant Notes

The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons. Co-location of this module with other transmitters that operate simultaneously are required to be evaluated using the FCC multi-transmitter procedures. End-Users must be provided with transmitter operation conditions for satisfying RF exposure compliance.
