2AOKX-TW039NTWS Earphone

Charging the Case Using a USB-C to USB cable (included), connect to the USB port of a powered on computer or USB power adaptor (not included) to charge the case. When the case is charging the Power & Battery Indicator LEDs will flash white. When fully charged all LEDs will turn solid white. Truly Wire Free Earbuds User’s Guide for Model IAEBT600 v2559-01 Power & Battery Indicator LEDs The 4 white LEDs represent the amount of battery the case charger has. 1 LED=25% 2 LEDs=50% 3 LEDs=75% 4 LEDs=100% Function Button Press and hold to power ON Press to play/pause music. Press to answer/end phone calls. Press and hold for 2 seconds to reject incoming calls. Press and hold for 5 seconds to power OFF. Press and hold for 2 seconds to activate voice assistant (LEFT). Quickly press twice to skip to next track (RIGHT). Quickly press twice to play previous tracks(LEFT). Press and hold for 2 seconds to switch modes between: Normal, Transparent, and ANC (RIGHT). Charging Contacts Charging Contacts Charging the Earbuds 1. Open the cover and place the earbuds on the charging contacts. Be sure to match the left and right earbuds with the correct docking station in the case. 2. When charging, the first and fourth Power & Battery Indicator LEDs on the case will flash white. When charging is complete, the indicator LEDs will turn off. 3. Earbud Indicator LEDs will turn red when charging. When fully charged, the LEDs will turn off. Microphone Earbud Indicator LED Red when charging. Lights off when fully charged. IAEBT600-2559-01-IB - 04Aug2020.indd 18/4/2020 10:32:47 AM Speakerphone • To accept or end a phone call, press the Function button. • You can also use the contr ols on the connected phone to handle phone functions. Charging Case & Auto-On Feature While the case power is ON: • Placing the earbuds in the charging case will • Removing the earbuds from the case will automatically power them on, link them, and connect to the last used Bluetooth device (earbuds must have been linked and connected to a Bluetooth device already). Pairing Bluetooth Note: When earbuds are powered on they automatically link and enter into pairing mode. You can power on a single earbud to use as a single unit if you wish. 1. With the earbuds linked, you can now connect to your Bluetooth device. The LED indicator on the right earbud to pair to a Bluetooth device. 2. On your Bluetooth device, access Bluetooth Settings and search for nearby devices. Select IAEBT600 when it is discover ed. When successfully connected to your Bluetooth device, the LED indicator on both of the announce the Bluetooth connection. 3. Audio played through the connected Bluetooth device will now be heard through both earbuds. Use the contr ols on the connected device to play audio and adjust volume. PLEASE NOTE: Due to the nature of truly wireless earbuds, you may experience slight interruptions with your audio in areas with multiple 2.4Ghz Customer Support Customer Service: 1-888-999-4215 | Email Support: prodinfo@ dpiinc.c om | Email Parts: [email protected] om For War ranty Inf ormation and the most up-t o-date version of this User’s Guide, go to www.iLiveElectr onics.c om To download this User’s Guide in English, Spanish, or French, or to get answers to frequently asked questions, visit the support section at: www.iLiveElectr onics.c om Par a descargar este Manual del Usuario en inglés, español y fr ancés, o para obtener respuestas a preguntas frecuentes, visite la sección de apoyo en: www.iLiveElectr onics.c om Pour télécharger ce guide de l’utilisateur en anglais, espagnol ou français, ou pour obtenir des réponses à des questions fr équemment posées, consultez la rubrique d’assistance sur: www.iLiveElectr onics.c om Copyr ight © 2020 Digital Products Inter national (DPI, Inc.) All other trademarks appearing herein are the property of their notice. FCC Warnings party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular i nstallation. If this equipment does cause harmful interfe rence to radio or television reception, which is encouraged to try to correct the interference by one or more of the following measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Additional Warnings • or moisture. • WARNING : Where the mains plug or appliance coupler is used as the disconnect device, such disconnect device shall remain readily operable. • Lithium batteries, like all rechargeable batteries, are recyclable and should be recycled or disposed of according to state and local guidelines . They should never be disposed of in normal household waste, and they should never be incinerated, as they might explode. Contact your local government for disposal or recycling practices in your area. • This product meets and complies with all Federal regulations. • To avoid hearing damage, make sure that the volume on your music player is turned down before connecting your headphones. After placing headphones in/on your ears, gradually turn up the volume until you reach a co mfortable lis tening level. WARNING : This product can expose you to chemicals including lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. This product meets and complies with required Fe…

Text truncated - open the document above for the full version.

August 03, 2020 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2AOKX-TW039N Product Name: TWS Earphone Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commissions rules, we hereby request that the following documents be held confidential:  Schematics  Block diagram  Operation description These materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <Signature>： Name：Feng Yang Title： Applicant Company：Shenzhen Swetz Sound Technology Co.,Limited

August 03, 2020 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act as Agent On our behalf, I appoint Shenzhen Timeway Testing Laboratories/ Zone C, 1st Floor, Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China (Name of Agent company name and address) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. For instances where our authorized agent signs the application for certification on our behalf, I acknowledge that all responsibility for complying with the terms and conditions for certification, still resides with Shenzhen Swetz Sound Technology Co., Limited / No.18 Xiantian Road, Longgang Central, Shenzhen, China <Signature>： Name：Feng Yang Title： Applicant Company：Shenzhen Swetz Sound Technology Co.,Limited

Shenzhen Swetz Sound Technology Co.,Limited Signature: Company Name: Shenzhen Swetz Sound Technology Co.,Limited Statement We Shenzhen Swetz Sound Technology Co.,Limited Hereby Declare that The product TWS Earphone, models no. IAEBT600B, IAEBT600IND, TW039N are all identical in interior structure, electrical circuits and components, and just the mo del names are different for the mark eting requirement. The d evice have left and right earphones,they are electrically identical. Label is on the left and right earphones both Your assistance on this matter is highly appreciated. Yours sincerely,

2.22mm 22.4mm white

FCC Label Location

FCC ID: 2AOKX-TW039N RF Exposure Applicable Standard According to §1.1307(b)(5), systems operating under the provisions of this section shall be operated in a manner that ensure that the public is not exposed to radio frequency energy level in excess of the Commission’s guideline. This is a Portable device. The Section 4.3.1 and Appendix A of KDB447498 D01 V05 was used as the guidance. Calculation Result (Worse case) [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ꞏ [√f(GHz)] =0.21/5 * 1.57= 0.07, this value is less than 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR. The SAR measurement is not necessary.

Report No.: TW2007248E File reference No.: 2020-07-30 Applicant: Shenzhen Swetz Sound Technology Co.,Limited Product: TWS Earphone Model No.: IAEBT600B, IAEBT600IND, TW039N Trademark: N/A Test Standards: FCC Part 15.247 Test result: It is herewith confirmed and found to comply with the requirements set up by ANSI C63.10, FCC Part 15.247 for the evaluation of electromagnetic compatibility Approved By Jack Chung Manager Dated: July 30, 2020 Results appearing herein relate only to the sample tested The technical reports is issued errors and omissions exempt and is subject to withdrawal at SHENZHEN TIMEWAY TESTING LABORATORIES Zone C, 1st Floor, Block B, Jun Xiang Da Building, Zhongshan Park Road West, Tong Le Village, Nanshan District, Shenzhen, China Tel (755) 83448688, Fax (755) 83442996, E-Mail:[email protected] Report No.: TW2007248E Page 2 of 90 Date: 2020-07-30 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Special Statement： The testing quality ability of our laboratory meet with "Quality Law of People's Republic of China" Clause 19. The testing quality system of our laboratory meets with ISO/IEC-17025 requirements, which is approved by CNAS. This approval result is accepted by MRA of APLAC. Our test facility is recognized, certified, or accredited by the following organizations: CNAS-LAB Code: L2292 The EMC Laboratory has been assessed and in compliance with CNAS-CL01 accreditation criteria for testing Laboratories (identical to ISO/IEC 17025:2005 General Requirements) for the Competence of testing Laboratories. FCC-Registration No.: 744189 The EMC Laboratory has been registered and fully described in a report filed with the (FCC) Federal Communications commission. The acceptance letter from the FCC is maintained in our files. Registration No.: 744189. Industry Canada (IC) —Registration No.:5205A The EMC Laboratory has been registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 5205A. A2LA (Certification Number:5013.01) The EMC Laboratory has been accredited by the American Association for Laboratory Accreditation (A2LA). Certification Number:5013.01 Report No.: TW2007248E Page 3 of 90 Date: 2020-07-30 The report refers only to the sample tested and does not apply to the bulk. This report is issued in confidence to the client and it will be strictly treated as such by the SHENZHEN TIMEWAY TESTING LABORATORIES. It may not be reproduced rather in its entirety or in part and it may not be used for adverting. The client to whom the report is issued may, however, show or send it . or a certified copy there of prepared by the SHENZHEN TIMEWAY TESTING LABORATORIES. to his customer. Supplier or others persons directly concerned. SHENZHEN TIMEWAY TESTING LABORATORIES. will not, without the consent of the client enter into any discussion of correspondence with any third party concerning the contents of the report. In the event of the improper use of the report. The SHENZHEN TIMEWAY TESTING LABORATORIES. reserves the rights to withdraw it and to adopt any other remedies which may be appropriate. Test Report Conclusion Content 1.0 General Details ................................................................................................ 4 1.1 Test Lab Details................................................................................................ 4 1.2 Applicant Details.............................................................................................. 4 1.3 Description of EUT .......................................................................................... 4 1.4 Submitted Sample............................................................................................. 4 1.5 Test Duration.................................................................................................... 4 1.6 Test Uncertainty.................................................................................................5 1.7 Test By.......................................................................................................... 5 2.0 List of Measurement Equipment......................................................................... 6 3.0 Technical Details............................................................................................. 7 3.1 Summary of Test Results..................................................................................... 7 3.2 Test Standards.................................................................................................. 7 4.0 EUT Modification............................................................................................. 7 5.0 Power Line Conducted Emission Test...................................................................... 8 5.1 Schematics of the Test........................................................................................ 8 5.2 Test Method and Test Procedure............................................................................ 8 5.3 Configuration of the EUT.................................................................................... 8 5.4 EUT Operating Condi…

Text truncated - open the document above for the full version.

Conducted Emission Te s t Setup: Radiated Emission Te s t Setup:
