2AOM3-S30Smart bracelet

9SGXZ(XGIKRKZ ;YKX3GT[GR Federal Communications Commission (FCC) Statement Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Note: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user’s authority to operate the equipment. FCC ID: 2AOM3-S30 =KRIUSKZU[YKU[XNOMNVKXLUXSGTIK]XOYZ HGTJYSGXZHXGIKRKZ]NOINIXKGZKYZNU[MNZL[R GTJNKGRZNK^VKXOKTIKLUX_U[ 9INKSGZOIJOGMXGSULSGOTHUJ_ULZNKYSGXZ HXGIKRKZ *K\OIKSGOTZKTGTIK 6RKGYKXKSKSHKXZNKLURRU]OTMZOVY]NKT_U[SGOTZGOT_U[X YSGXZHXGIKRKZ ș)RKGTZNKYSGXZHXGIKRKZXKM[RGXR_KYVKIOGRR_OZYOTTKXYOJK GTJQKKVOZJX_ ș'JP[YZZNKYSGXZHXGIKRKZZOMNZTKYYZUKTY[XKGOXIOXI[RGZOUT ș+^IKYYO\KYQOTIGXKVXUJ[IZYNU[RJTUZHK[YKJLUXZNK]XOYZ ]KGXOTMZNKYSGXZHXGIKRKZ ș6RKGYKIKGYK]KGXOTMZNKYSGXZHXGIKRKZOTIGYKULYQOT GRRKXM_UXGT_JOYIUSLUXZ  *U]TRUGJOTMGTJHOTJOTMULYSGXZHXGIKRKZ'66 *U]TRUGJGTJOTYZGRR'66 6U]KXUT 2UTMVXKYYZNKYOJKH[ZZUTLUXYKIUTJYUXVR[MOTZNK 3GMTKZOIROTKZUINGXMKZNKYSGXZHXGIKRKZ 9IGT78IUJK]OZNSUHORKVNUTKZUJU]TRUGJ'66 ,UX/59Y_YZKSYKRKIZ'VV9ZUXK!GTJLUX'TJXUOJY_YZKS YKRKIZ-UUMRK6RG_9ZUXKZUJU]TRUGJGTJOTYZGRR0?U[6XU 4UZK _U[XSUHORKVNUTKS[YZY[VVUXZ'TJXUOJUX/59 UXGHU\KGTJ(R[KZUUZNUXGHU\K 0?U[6XU  (OTJYSGXZHXGIKRKZ]OZN'66 )ROIQUT9IGTLUXJK\OIKZUHOTJZNKYSGXZHXGIKRKZ )ROIQUT_U[XJK\OIKOTZNKJK\OIKROYZYIGTTKJ ʒʓ  :NK/59Y_YZKS]ORRYNU]G(R[KZUUZNVGOXOTMXKW[KYZGTJ _U[IGTIROIQUT(R[KZUUZN6GOXOTMZUIUTLOXS)UTTKIZOZ JOXKIZR_ZU'TJXUOJY_YZKS ʔʕ :NKHOTJOTMOYY[IIKYYL[R  /TZXUJ[IZOUTULYSGXZHXGIKRKZL[TIZOUTY 6U]KXUTYZGZ[Y Y]OZINZNKSKT[OTZKXLGIKYULSGOTYIXKKTGYZNKOTZKXLGIKY YNU]TOTZNKLURRU]OTM!  8KSU\KJK\OIK ,UXZNK'TJXUOJSUHORKVNUTKZNKJK\OIKIGTHK JOYIUTTKIZKJLXUS_U[XSUHORKVNUTKH_YOSVR_IROIQOTMUT 8KSU\KJK\OIK ,UX'VVRKSUHORKVNUTKGLZKXHOTJOTMXKSU\GR_U[TKKJZU IROIQUTZNKY_SHURUTZNKXOMNZOT9KZZOTM(R[KZUUZNGTJ INUUYKZUOMTUXKZNKJK\OIK'YYNU]THKRU] ʒʓ  ,XKW[KTZR_'YQKJ7[KYZOUTY,'7Y =N_JUKYZNKYSGXZHXGIKRKZG[ZUSGZOIGRR_ JOYIUTTKIZ(R[KZUUZN]NKTZNK'TJXUOJYIXKKT MUKYU[Z% $2UIQHGIQMXU[TJ'66=NKTZNK0?U[6XUVXUIKYYOY IRKGXKJZNKYSGXZHXGIKRKZ]ORRHKJOYIUTTKIZKJLXUSZNK SUHORKVNUTK $9KZ'66YKRLYZGXZ[V ʔʕ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

Shenzhen Yawell Intelligent Technology Co., Ltd A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Tel: 15118105903 Series Models Description Date: Jan. 11, 2021 To whom it may concern: The device (Product Name:Smart bracelet) Models Name: S30, S28, S30, S31, S32, S33, S40, S50, P8Pro, P30, P40 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. Sincerely, Yves Yu /Manager

C5266091_X8_Ed.1 1/1 Letter of Authorization Shenzhen Yawell Intelligent Technology Co., Ltd Company: Shenzhen Yawell Intelligent Technology Co., Ltd Address: A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Product Name: Smart bracelet Model Number: S30,S28, S30, S31, S32, S33, S40, S50, P8Pro, P30, P40 FCC Identifier: 2AOM3-S30 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Yves Yu Date: 2021-01-11 Title: Manager Signature of applicant:

C5266091_X10_Ed.1 1/1 <Shenzhen Yawell Intelligent Technology Co., Ltd> Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 2021-01-11 Subject: Request for Confidentiality FCC ID: 2AOM3-S30 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. ExhibitsLong-Term Confidentiality Short-Term Confidentiality ID Label/LocationNoNo Attestation StatementNoNo External PhotosNo Block Diagram Schematics Test ReportNoNo Test Setup PhotosNo User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s)NoNo SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. Itisourunderstandingthatallmeasurementtestreports,FCCIDlabelformatand correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yves Yu

FCCID: 2AOM3-S30

FCC ID Label Location FCC ID:2AOM3-S30

FCCID: 2AOM3-S30 Antenna

FCCID:2AOM3-S30 RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances≤50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHz)]≤3.0 for 1-g SAR and≤7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison For Bluetooth Low Energy pt=-1.68dBm=0.68mW at 2402MHz So (0.68mW/5mm)x√2.402GHz = 0.21<3 Then SAR evaluation is not required

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No. ................. : CTL2010294051-WF Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Nice Nong (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name .............................. : Smart bracelet Model/Type reference ................. : S30 List Model(s) ................................ : S28, S30, S31, S32, S33, S40, S50, P8Pro, P30, P40 Trade Mark ................................... : N/A FCC ID .......................................... : 2AOM3-S30 Applicant’s name ........................ : ShenZhen YaWell intelligent Technology Co.,Ltd. Address of applicant .................. : A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Test Firm ...................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm .................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ........................ : Standard ........................................ : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator .............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF ................................... : Dated 2011-01 Date of receipt of test item ......... : Nov. 05, 2020 Date of sampling ......................... : Nov. 05, 2020 Date of Test Date ......................... : Nov. 05, 2020–Dec. 14, 2020 Date of Issue ................................ : Dec. 15, 2020 Result ........................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 28 Report No.: CTL2010294051-WF TEST REPORT Test Report No. : CTL2010294051-WF Dec. 15, 2020 Date of issue Equipment under Test : Smart bracelet Sample No : CTL201029405-1-S001 Model /Type : S30 Listed Models : S28, S30, S31, S32, S33, S40, S50, P8Pro, P30, P40 Applicant : Shenzhen Yawell Intelligent Technology Co.,Ltd Address : A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Manufacturer : Shenzhen Yawell Intelligent Technology Co.,Ltd Address : A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Test result Pass * * In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. V1.0 Page 3 of 28 Report No.: CTL2010294051-WF ** Modified History ** Revisions Description Issued DataReport No. Remark Version 1.0 Initial Test Report Release2020-12-15 CTL2010294051-WF Tracy Qi V1.0 Page 4 of 28 Report No.: CTL2010294051-WF Table of Contents Page 1. SUMMARY ................................................................................................................................................................ 5 1.1. TEST STANDARDS ........................................................................................................................................................... 5 1.2. TEST DESCRIPTION .............................................................................................................................................................. 5 1.3. TEST FACILITY ..................................................................................................................................................................... 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ..................................................................................................................... 6 2. GENERAL INFORMATION ........................................................................................................................................... 7 2.1. ENVIRONMENTAL CONDITIONS .............................................................................................................................................. 7 2.2. GENERAL DESCRIPTION OF EUT ............................................................................................................................................ 7 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY ................................................................................................................ 8 2.4. EQUIPMENTS USED DURING THE TEST ..................................................................................................................................... 9 2.5. RELATED SUBMITTAL(S) / GRANT (S) ...................................................................................................................................... 9 2.6. MODIFICATIONS ................................................................................................................................................................. 9 3. TEST CONDITIONS AND RESULTS...............................................................................................................................10 3.1. CONDUCTED EMISSIONS TEST ....................................................................................…

Text truncated - open the document above for the full version.

Appendix for 15.247 1. Bandwidth 1.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. 6dB Bandwidth Verdict Test Result (MHz)Limits (MHz) 1M 2402 SISO 1 0.691 ≥0.5 PASS 2440 SISO 1 0.681 ≥0.5 PASS 2480 SISO 1 0.678 ≥0.5 PASS Test Mode Frequency (MHz) TX Type ANT No. 99% Occupied Bandwidth Test Result (MHz) 1M 2402 SISO 1 1.047 Only for Report Use 2440 SISO 1 1.036 Only for Report Use 2480 SISO 1 1.042 Only for Report Use 1.2 Test Graph - 6dB Bandwidth 1.3 Test Graph - 99% Occupied Bandwidth 2. Maximum Conducted Output Power 2.1 Test Result Test Mode Frequency (MHz) Tx Type Measured Peak Output Power (dBm) Limits (dBm) Verdict Ant 1 1M 2402 SISO -1.68 30 PASS 2440 SISO -1.95 30 PASS 2480 SISO -1.94 30 PASS 2.2 Test Graph 3. Maximum Power Spectral Density (PSD) 3.1 Test Result Test Mode Frequency (MHz) Tx Type Maximum Power Spectral Density (dBm/3KHz) Limits (dBm/3kHz) Verdict Ant 1 1M 2402 SISO -16.62 ≤8 PASS 2440 SISO -17.00 ≤8 PASS 2480 SISO -17.00 ≤8 PASS 3.2 Test Graph 4. Unwanted Emissions in Non-restricted Frequency Bands 4.1 Test Result Test Mode Frequency (MHz) TX Type ANT No. Spurious Conducted Emission (dBm) Limits (dBm) Verdict 1M 2402 SISO 1 Refer to test graph -21.87 PASS 2440 SISO 1 Refer to test graph -21.87 PASS 2480 SISO 1 Refer to test graph -21.87 PASS 4.2 Test Graph

FCCID: 2AOM3-S30
