2AOM3-S46Smart Watch

1 Smart Watch User Manual Instrukcja obsługi smart zegarka Welcome to use our high-performance wrist-band Smart Watch which creates thoughtful and health experience for you. Zapraszamy do korzystania z naszego wysokiej klasy smart zegarka, która tworzy dla Ciebie niezapomniane doświadczenia fitness. Device maintenance 2 Konserwacja urządzenia Please remember the following tips when you maintain your Smart Watch: Podczas konserwacji smart zegarka należy pamiętać o następujących wskazówkach: •Clean the Smart Watch regularly, especially its inner side, and keep it dry. •Regularnie czyścić smart zegarek, zwłaszcza jego wewnętrzną stronę i utrzymywać go w suchości. •Adjust the Smart Watch tightness to ensure air circulation. •Wyregulować dopasowanie smart zegarka tak, aby zapewnić odpowiednią cyrkulację powietrza. •Excessive skincare product should not be used for the wrist wearing the Smart Watch. •Nie należy stosować nadmiernej ilości produktów do pielęgnacji skóry na nadgarstku, na którym noszony jest smart zegarek. •Please cease wearing the Smart Watch in case of skin allergy or any discomfort. •Proszę zaprzestać noszenia smart zegarka w przypadku wystąpienia alergii skórnej lub jakiegokolwiek dyskomfortu. Schematic diagram of main body of the Smart Watch Schemat korpusu smart zegarka Power-on Uruchomienie Long press the side button for 3 seconds or plug in the Magnetic charging cable to charge the Smart Watch. Naciśnij przycisk boczny przez 3 sekundy lub podłącz magnetyczny kabel do ładowania, aby naładować smart zegarek. 3 Downloading and binding of Smart Watch APP Pobieranie i powiązanie aplikacji dla smart zegarka 1.Download and install APP 1.Pobierz i zainstaluj aplikację 1.1 Scan QR code with mobile phone to download APP. 1.1 Zeskanuj kod QR za pomocą telefonu komórkowego, aby pobrać aplikację. 1.2 For IOS system, select APP ，storesearch Da Fit。 1.2 W przypadku systemu iOS, otwórz APP Store oraz wyszukaj aplikację Da Fit. Android system, select Google Play to download and install Da Fit.Or scan QR code to download W przypadku systemu Android, otwórz Google Play, aby pobrad i zainstalowad aplikację Da Fit lub zeskanuj kod QR, aby ją pobrad APP Store: Da Fit APP Store: Da Fit Google Play: Da Fit Google Play: Da Fit Note: your mobile phone must support Android 5.1 or IOS 8.0 or above, and Bluetooth 4.0 or above. Uwaga: Twój telefon komórkowy musi obsługiwad system Android 5.1, iOS 8.0 lub wyższy oraz Bluetooth 4.0 lub wyższy. Bind Smart Watch with APP Powiąż smart zegarek z aplikacją 4 Blueooth call connect Połączenia Blueooth Android: After the APP successfully connects to the watch's Bluetooth. Android: Po pomyślnym połączeniu aplikacji z Bluetooth zegarka. 1. The phone will automatically pop up a "pairing" request, click "Allow". 1. Telefon automatycznie wyświetli prośbę o „Sparowanie”, kliknij „Zezwól”. 2. For some brands of mobile phone models, there is no need to pop up the pairing confirmation permission. After connecting to Bluetooth, the call function is also directly connected. After the binding is successful, you can answer and make calls on the watch. 2. W przypadku niektórych modeli telefonów komórkowych nie ma potrzeby wyświetlenia pozwolenia na potwierdzenie 1.Click on "Add Device" to bind the Smart Watch. 1. Kliknij na „Dodaj urządzenie”, aby powiązać smart zegarek. 2. Click on your device in the device list scanned. 2. Kliknij nazwę swojego urządzenia na liście zeskanowanych urządzeń. 3. The IOS system will show a Bluetooth pairing request and you can click on Bluetooth "Pairing" to confirm. Connect it directly to Android system. 3. System iOS pokaże żądanie parowania Bluetooth, po czym kliknij na „Parowanie” Bluetooth, aby potwierdzić. W przypadku systemu Android wystarczy bezpośrednio podłączyć. 4. Successfully bound. 4. Parowanie zakończone sukcesem. 5 parowania. Po podłączeniu do Bluetooth, funkcja połączeo będzie od razu aktywowana. Po pomyślnym powiązaniu użytkownik będzie mógł odbierad i wykonywad połączenia bezpośrednio na zegarku. iPhone: Enter into Settings – Bluetooth, search device and connect pair (Audio_S 46). After pair successfully, you can make call/ answer incoming call. iPhone: Wejdź w Ustawienia - Bluetooth, wyszukaj urządzenie i powiąż (Audio_S 46). Po pomyślnym sparowaniu możesz wykonywać połączenia/odbierać połączenia przychodzące. Remove Bluetooth Call connection Rozłączanie połączenia Bluetooth Android：For the Android mobile phone, the device can be disconnected from your mobile phone by simply clicking on Remove device. Android：W przypadku telefonu komórkowego z systemem Android urządzenie można odłączyć od telefonu komórkowego, klikając po prostu na Usuń urządzenie. iPhone: firstly, users need dismiss pair, then enter into mobile phone Setting – Bluetooth, find Audio_S 46, click icon on the right, ignore device, watch and mobile phone are disconnection. iPhone: Po rozłączeniu telefonu należy również wejść w Ustawienia - Bluetooth, znaleźć Audio_S 46, kliknąć na symbol po prawej stronie i wybrać Ignoruj to urządzenie. Zegarek i telefon komórkowy będą rozłączone. Introduction of Smart Watch functions Wprowadzenie do funkcji smart zegarka Power-on status Stan po włączeniu zasilania Switch the menu interfaces of main screen, as the interfaces shown in the following; Użytkownik może przełączać interfejs menu ekranu głównego, na te pokazane poniżej; 6 1. Introduction of main interface functions 1. Wprowadzenie do głównych funkcji interfejsu After the smart bracelet and APP are first paired, the time and date of the mobile phone will be synchronized. Po pierwszym sparowaniu smart opaski i aplikacji, czas i data telefonu komórkowego zostaną zsynchronizowane. 2. Step counting, distance and calorie 2. Liczenie kroków, dystansu i kalorii The step-counting interface shows steps. Wear the smart bracelet on wrist, and the smart bracelet can automatically count steps, distance and calories. Interfejs liczenia kroków wyświetla ilość wykonanych kroków. Załóż …

Text truncated - open the document above for the full version.

ShenZhen YaWell intelligent Technology Co.,Ltd. Address: A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Date: 2023-02-08 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(i) Filing SUBJECT: FCC Application for FCC ID: 2AOM3-S46 To Whom It May Concern: [ShenZhen YaWell intelligent Technology Co.,Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, Signature: Date: 2023-02-08

ShenZhen YaWell intelligent Technology Co.,Ltd. Address: A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Date: 2023-02-08 Federal Communications Commission Authorization and Evaluation Division 1435 Oakland Mills Road Columbia, MD 21046 Ref: Attestation Statements Part 2.911(d)(5)(ii) Filing SUBJECT: FCC Application for FCC ID: 2AOM3-S46 To Whom It May Concern: [ShenZhen YaWell intelligent Technology Co.,Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Signature: Date: 2023-02-08

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 ShenZhen YaWell intelligent Technology Co.,Ltd. A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. Date：2023/02/02 Product Model Number: S46 FCC ID：2AOM3-S46 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: Testing Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 15118105903 On behalf of: ShenZhen YaWell intelligent Technology Co.,Ltd.

3 Shenzhen Huaxunshitong Technology Co.,Ltd. Antenna specification Customer name: Yawei Project name S46 Antenna frequency band BT Specification description □ support+shell fragment □ Single shrapnel □support+FPC+thimble ☑FPC □FM aerial □GPS aerial silk-screen：S46-1/S46-2 □coaxial-line □WIFI aerial: □FPC+wire rod： □PCB+wire rod: Customer confirmation Supplier confirmation Radio frequency confirmation Structural confirmation check contacts Wang pengchao mobile phone 13480925226 telephone 0755-23705212 facsimile 0755-23705213 mailbox [email protected] address:F3-005, Hongfenghua Internet Creative Park, No.1 Huangtiandamen Road, Hangcheng Street, Baoan District, Shenzhen 3 1.Test environment test project equipment 1. （S-parameter） 1. （Return Loss） 2. （VSWR） : Agilent E5071B HP 8753D 2. （Active ） 1. （TRP） 2. （TIS） 1. ETS 7x4x3 m (3D) Chamber ETS 5x3x3 m (3D) Chamber 2.: Agilent 8960 E5515B ×2 StarPoint SP6011 3.（Passive） 1.（Gain）2.（Efficiency） 1. ETS 7x4x3 m (3D) Chamber ETS 5x3x3 m (3D) Chamber 2. Agilent E5071B HP 8753D 2.matching circuit-BT aerial： Our company has not made any modification to the matching circuit 3 3. Antenna position map 3 4 Efficiency and gain 5.BT Measured effect of antenna 3 6.Structural drawings

ShenZhen YaWell intelligent Technology Co.,Ltd. A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: February 14, 2023 Subject; Request for Confidentiality FCC ID: 2AOM3-S46 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Yves Yu Title: Manager

Effective Date: April 2, 2020 QSF 7.6.4-8 – Agent Authorization Letter Template Page 1 of 1 Revision Date: Revision: 0 ShenZhen YaWell intelligent Technology Co.,Ltd. A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. Date：2023/02/02 Product Model Number: S46 FCC ID：2AOM3-S46 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: Testing Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Manager Email: [email protected] Telephone: 15118105903 On behalf of: ShenZhen YaWell intelligent Technology Co.,Ltd.

ShenZhen YaWell intelligent Technology Co.,Ltd. A402, Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road, Gaoxin District, Yuehai Street, Nanshan District, Shenzhen, China Series Models Description FCC ID: 2AOM3-S46 Date: Feb. 02, 2023 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 To whom it may concern: The device (Product Name: Smart Watch) Models Name: S46, S45, S47, S48, S48T, S49, S50, S51, S52, S53, S54, S55, S56, S57, S58, S59, S60, S61, S62, S63, S64, S65, S66, S67, S68, S69, S70, S71, S72, S73, S74, S75, S76, S77, S78, S79, S80, S81, S82, S83, S84, S85, S86, S87, S88, S89, S90, S91, S92, S93, S94, S95, S96, S97, S98, S99, S100 have same electrical, PCB and BOM, only the colour and model’s names are different for marketing requirements. Sincerely, Yves Yu / Manager

TIANHENG CONSULTING INC. 130 Terence Matthews Cres, Suite C2, Kanata, ON K2M 0J1, Canada Phone: +1-613-220-8490 Email: [email protected] Page 1 of 3 FCC US Agent Service Agreement This Services Agreement (the “Agreement”) is entered into as of the date of the last signature below (the “Effective Date”) by and between TianHeng Consulting Inc. (“TianHeng”), with principle place of business at 130 Terence Matthews Cres, Suite C2, Kanata, ON K2M 0J1, Canada, and ShenZhen YaWell intelligent Technology Co.,Ltd. (“the Client”), with office at A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. 1. Introduction Working together with our partner company in Wilmington, MA, United States, TianHeng Consulting Inc. is pleased to provide FCC U.S. Agent services to clients outside of United States requiring an U.S. Agent to fulfill the FCC Part 2.911(d)(7)requirements for the FCC ID application procedure. Note: this service agreement is for one FCC ID only and covering the following product(s). Product Name: Smart Watch FCC ID: 2AOM3-S46 Model Number(s): S46, S45, S47, S48, S48T, S49, S50, S51, S52, S53, S54, S55, S56, S57, S58, S59, S60, S61, S62, S63, S64, S65, S66, S67, S68, S69, S70, S71, S72, S73, S74, S75, S76, S77, S78, S79, S80, S81, S82, S83, S84, S85, S86, S87, S88, S89, S90, S91, S92, S93, S94, S95, S96, S97, S98, S99, S100 2. Responsibilities of TianHeng Consulting Inc. 1) TianHeng Consulting Inc. (TianHeng) hereby agrees with ShenZhen YaWell intelligent Technology Co.,Ltd. that TianHeng will provide FCC U.S. Agent Service to the Client, for the term as set forth in this agreement, starting from the signatory date of this agreement. 2) The details of the U.S. Agent are: Company Name: TianHeng Consulting, LLC Address: 392 Andover Street, Wilmington, MA 01887, United States Phone: +1 (617) 997-4010 Email:[email protected] 3) TianHeng Consulting Inc. ensures that TianHeng Consulting, LLC will fulfill the FCC Part 2.911(d)(7)requirements and take the obligation of the designated U.S. agent for service of process for the above referenced FCC ID.. Note: TianHeng Consulting, LLC. is not actually responsible for the initial and ongoing compliance of the Client products to FCC Certification requirements. It is the TIANHENG CONSULTING INC. 130 Terence Matthews Cres, Suite C2, Kanata, ON K2M 0J1, Canada Phone: +1-613-220-8490 Email: [email protected] Page 2 of 3 Client’s responsibility to ensure the product meets and maintain continuous compliance for FCC regulations. 4) TianHeng agrees to keep the Client advised on any phone calls, emails, letters or any other FCC notifications regarding the Client products mentioned above. 3. Responsibilities of the Client 1) The Client agrees to provide TianHeng with up-to-date contact info of their company. 2) The Client shall provide all the applicable test reports for the products. 3) The Client shall take necessary steps to assure that the production units of all their products will continue to comply with the FCC Commission’s requirements. 4) If The Client makes any modifications to their products after the FCC Certification, or makes other relevant changes, it is the Client’s responsibility to ensure that the modified products continue to comply with all FCC requirements. 4. Service Term Service Term FCC ID ☐ 5 years starting from the signatory date of this agreement. One FCC ID ☐ 1 year starting from the signatory date of this agreement. Unlimited ☐ 3 years starting from the signatory date of this agreement. Unlimited 5. Termination TianHeng has the right to terminate this agreement if the Client fails to pay the fee within the above set time frame or fails to fulfill the Client responsibilities as set forth in this agreement. Client has the right to terminate this agreement with at least 2 weeks of written notice. 6. Renewal After this agreement expires, extension and fee of the U.S. Agent would be agreed by mutual consent. 7. Non-disclosure 1) A party receiving information (“Receiving Party”) shall not disclose, publish, or disseminate the Confidential Information (as defined below in clause 7(2)) of the party providing that information (“Disclosing Party”)) to anyone other than those of such Receiving Party’s employees and consultants with a need to know, and who are bound by a written agreement, enforceable by Disclosing Party, to protect the confidentiality of such Confidential Information, or to any individual as may be required by legal process. Each party agrees to take reasonable precautions, but in no event less than due care, to prevent any unauthorized use, disclosure, publication, or dissemination of the other party’s Confidential Information. Each party agrees to TIANHENG CONSULTING INC. 130 Terence Matthews Cres, Suite C2, Kanata, ON K2M 0J1, Canada Phone: +1-613-220-8490 Email: [email protected] Page 3 of 3 accept the other party’s Confidential Information for the sole purpose of carrying out such Receiving Party’s authorized activities under this Agreement. Each party agrees not to use the Confidential Information of the other party for its own or any third party’s benefit without the prior written approval of an authorized representative of the Disclosing Party in each instance. In the event a Receiving Party is required to disclose Disclosing Party’s Confidential Information by an order of a court or governmental agency or pursuant to an applicable law, the Receiving Party shall first give written notice to the Disclosing Party to allow the Disclosing Party to make a reasonable effort to obtain a protective order or other treatment of the Confidential Information most appropriate to the protection of its confidential nature. 2) “Confidential Information” means confidential and proprietary information of either party that is disclosed to the other party which, in the case of written information, is marked “confide…

Text truncated - open the document above for the full version.

FCC ID: 2AOM3-S46 Page 1 of 4 Report No.: CTL2211303012-WF External Photos of EUT FCC ID: 2AOM3-S46 Page 2 of 4 Report No.: CTL2211303012-WF FCC ID: 2AOM3-S46 Page 3 of 4 Report No.: CTL2211303012-WF FCC ID: 2AOM3-S46 Page 4 of 4 Report No.: CTL2211303012-WF

FCC ID: 2AOM3-S46 Page 1 of 1 Report No.: CTL2211303012-WF FCC ID Label Information Label location: Smart Watch Model: S46 FCC ID: 2AOM3-S46

FCC ID: 2AOM3-S46 Page 1 of 3 Report No.: CTL2211303012-WF Internal Photos of EUT Antenna 1 Antenna 2 FCC ID: 2AOM3-S46 Page 2 of 3 Report No.: CTL2211303012-WF FCC ID: 2AOM3-S46 Page 3 of 3 Report No.: CTL2211303012-WF Note: Antenna 2 is not used during actual use.

FCC ID: 2AOM3-S46 Page 1 of 1 Report No.: CTL2211303012-WF RF Exposure evaluation According to 447498 D01 General RF Exposure Guidance v06 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] ·[√f(GHz)] ≤3.0 for 1-g SAR and ≤7.5 for 10-g extremity SAR, where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison For Bluetooth low Energy pt=-4.21dBm=0.3793mW at 2440MHz So (0.3793mW/5mm)x √2.440GHz = 0.1185<3 Then SAR evaluation is not required/

Shenzhen CTL Testing Technology Co., Ltd. Tel: +86-755-89486194 E-mail: [email protected] TEST REPORT FCC PART 15.247 Report Reference No. ................ : CTL2211303012-WF Compiled by: ( position+printed name+signature) Happy Guo (File administrators) Tested by: ( position+printed name+signature) Gary Gao (Test Engineer) Approved by: ( position+printed name+signature) Ivan Xie (Manager) Product Name ............................ : Smart Watch Model/Type reference ................ : S46 List Model(s) ............................... : See next page Trade Mark .................................. : N/A FCC ID ......................................... : 2AOM3-S46 Applicant’s name ....................... : ShenZhen YaWell intelligent Technology Co.,Ltd. Address of applicant ................. : A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. Test Firm ..................................... : Shenzhen CTL Testing Technology Co., Ltd. Address of Test Firm ................. : Floor 1-A, Baisha Technology Park, No.3011, Shahexi Road, Nanshan District, Shenzhen, China 518055 Test specification ....................... : Standard ...................................... : FCC Part 15.247: Operation within the bands 902-928 MHz, 2400-2483.5 MHz and 5725-5850 MHz. TRF Originator ............................. : Shenzhen CTL Testing Technology Co., Ltd. Master TRF .................................. : Dated 2011-01 Date of receipt of test item ........ : Dec.07 2022 Date of Test Date ........................ : Dec.07 2022- Jan.09 2023 Date of Issue .............................. : Jan.10 2023 Result .......................................... : Pass Shenzhen CTL Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTL Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTL Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. V1.0 Page 2 of 35 Report No.: CTL2211303012-WF TEST REPORT Test Report No. : CTL2211303012-WF Jan.10 2023 Date of issue Equipment under Test : Smart Watch Sample No : CTL221130301-1-S001 Model /Type : S46 Listed Models : S45, S47, S48, S48T, S49, S50, S51, S52, S53, S54, S55, S56, S57, S58, S59, S60, S61, S62, S63, S64, S65, S66, S67, S68, S69, S70, S71, S72, S73, S74, S75, S76, S77, S78, S79, S80, S81, S82, S83, S84, S85, S86, S87, S88, S89, S90, S91, S92, S93, S94, S95, S96, S97, S98, S99, S100 Applicant : ShenZhen YaWell intelligent Technology Co.,Ltd. Address : A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. Manufacturer : ShenZhen YaWell intelligent Technology Co.,Ltd. Address : A402 Wuhan University, Shenzhen Research Institute, No. 6 Yuexing 2nd Road Gaoxin District YueHai Street, Nanshan District, Shenzhen, China. Test result Pass * * In the configuration tested, the EUT complied with the standards specified page 5. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the issuing testing laboratory. The device (Product Name: Smart Watch) Models Name: S46, S45, S47, S48, S48T, S49, S50, S51, S52, S53, S54, S55, S56, S57, S58, S59, S60, S61, S62, S63, S64, S65, S66, S67, S68, S69, S70, S71, S72, S73, S74, S75, S76, S77, S78, S79, S80, S81, S82, S83, S84, S85, S86, S87, S88, S89, S90, S91, S92, S93, S94, S95, S96, S97, S98, S99, S100 have same electrical, PCB and BOM, only the model’s name and colour are different for marketing requirements. V1.0 Page 3 of 35 Report No.: CTL2211303012-WF ** Modified History ** Revisions Description Issued Data Report No. Remark Version 1.0 Initial Test Report Release 2023-01-10 CTL2211303012-WF Tracy Qi V1.0 Page 4 of 35 Report No.: CTL2211303012-WF Table of Contents Page 1. SUMMARY ............................................................................................................................................................... 5 1.1. TEST STANDARDS ..................................................................................................................................................... 5 1.2. TEST DESCRIPTION ........................................................................................................................................................ 5 1.3. TEST FACILITY .............................................................................................................................................................. 6 1.4. STATEMENT OF THE MEASUREMENT UNCERTAINTY ............................................................................................................... 6 2. GENERAL INFORMATION .......................................................................................................................................... 8 2.1. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 8 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 8 2.3. DESCRIPTION OF TEST MODES AND TEST FREQUENCY .......................................................................................................... 9 2.4. EQUIPMENTS USED DURING THE TEST ............................................................................................................................ 10 2.5. RELATED SUBMITTAL(S) / GRANT (S) ........................................................................................................…

Text truncated - open the document above for the full version.

V1.0 Page 1 of 26 Report No.: CTL2211303012-WF 1. Bandwidth 1.1 OBW 1.1.1 Test Result Mode TX Type Frequency (MHz) ANT 99% Occupied Bandwidth (MHz) Verdict Result 1M SISO 2402 1 1.025 Pass 2440 1 1.025 Pass 2480 1 1.022 Pass 2M SISO 2402 1 2.053 Pass 2440 1 2.051 Pass 2480 1 2.052 Pass V1.0 Page 2 of 26 Report No.: CTL2211303012-WF 1.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV V1.0 Page 3 of 26 Report No.: CTL2211303012-WF 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV V1.0 Page 4 of 26 Report No.: CTL2211303012-WF 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV V1.0 Page 5 of 26 Report No.: CTL2211303012-WF 1.2 6dB BW 1.2.1 Test Result Mode TX Type Frequency (MHz) ANT 6dB Bandwidth (MHz) Verdict Result Limit 1M SISO 2402 1 0.665 >=0.5 Pass 2440 1 0.668 >=0.5 Pass 2480 1 0.664 >=0.5 Pass 2M SISO 2402 1 1.185 >=0.5 Pass 2440 1 1.181 >=0.5 Pass 2480 1 1.188 >=0.5 Pass V1.0 Page 6 of 26 Report No.: CTL2211303012-WF 1.2.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV V1.0 Page 7 of 26 Report No.: CTL2211303012-WF 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV V1.0 Page 8 of 26 Report No.: CTL2211303012-WF 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV V1.0 Page 9 of 26 Report No.: CTL2211303012-WF 2. Maximum Conducted Output Power 2.1 Power 2.1.1 Test Result Mode TX Type Frequency (MHz) Maximum Peak Conducted Output Power (dBm) Verdict ANT1 Limit 1M SISO 2402 -4.40 <=30 Pass 2440 -4.25 <=30 Pass 2480 -5.03 <=30 Pass 2M SISO 2402 -4.39 <=30 Pass 2440 -4.21 <=30 Pass 2480 -4.98 <=30 Pass Note1: Antenna Gain: Ant1: 2.13dBi; V1.0 Page 10 of 26 Report No.: CTL2211303012-WF 2.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV V1.0 Page 11 of 26 Report No.: CTL2211303012-WF 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV V1.0 Page 12 of 26 Report No.: CTL2211303012-WF 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV V1.0 Page 13 of 26 Report No.: CTL2211303012-WF 3. Maximum Power Spectral Density 3.1 PSD 3.1.1 Test Result Mode TX Type Frequency (MHz) Maximum PSD (dBm/3kHz) Verdict ANT1 Limit 1M SISO 2402 -19.16 <=8 Pass 2440 -19.04 <=8 Pass 2480 -19.88 <=8 Pass 2M SISO 2402 -21.12 <=8 Pass 2440 -20.94 <=8 Pass 2480 -21.69 <=8 Pass Note1: Antenna Gain: Ant1: 0.00dBi; V1.0 Page 14 of 26 Report No.: CTL2211303012-WF 3.1.2 Test Graph 1M_LCH_2402MHz_Ant1_NTNV 1M_MCH_2440MHz_Ant1_NTNV V1.0 Page 15 of 26 Report No.: CTL2211303012-WF 1M_HCH_2480MHz_Ant1_NTNV 2M_LCH_2402MHz_Ant1_NTNV V1.0 Page 16 of 26 Report No.: CTL2211303012-WF 2M_MCH_2440MHz_Ant1_NTNV 2M_HCH_2480MHz_Ant1_NTNV V1.0 Page 17 of 26 Report No.: CTL2211303012-WF 4. Unwanted Emissions In Non-restricted Frequency Bands 4.1 Ref 4.1.1 Test Result Mode TX Type Fre…
