QFX Inc. 2957 E. 46th Street, Vernon, CA 90058 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2026/07/21 U.S. Agent Designation QFX Inc. acknowledges their consent for the following contact located in the United States to act as their agent for service of process for the equipment for which authorization is sought (FCC ID: 2AOMX-KAR-990): Name and company of U.S. agent: GLOCERTS TECHNOLOGY INC Physical U.S. address of agent: 19784 SUNKISSED RIDGE DR RIVERSIDE, CA 92507 United States FRN of U.S. agent: 0036339737 Phone of U.S. agent: (626) 588-8039 Email address of U.S. agent: [email protected] GLOCERTS TECHNOLOGY INC acknowledges their obligation to accept service of process on behalf of QFX Inc. with the FRN [0027094838] accepts its obligation to maintain an agent for service of process in the United States for no less than one year after either the grantee has permanently terminated all marketing and importation of the applicable equipment within the U.S., or the conclusion of any Commission-related administrative or judicial proceeding involving the equipment, whichever is later. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(d)(7). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. An expiration date for this letter does not exist. In case the U.S. agent changes, the grantee is obligated to notify the FCC within 30 days via the granting TCB. An expiration date for this letter does not exist. Sincerely, Signature Jack Liu Manager QFX Inc. Signature Huiying Fan Director GLOCERTS TECHNOLOGY INC 48_[mo del] US_Agent_2.911(d)(7) - U, V0 5
FCC ID : 2AOMX-KAR-990 External Photos of the EUT FCC ID : 2AOMX-KAR-990 FCC ID : 2AOMX-KAR-990
Label and Location Size: L: 4.0cm*W: 3.0cm Label and Location FCC ID : 2AOMX-KAR-990
FCC ID: 2AOMX-KAR-990 Internal Photos of the EUT FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 BT ANT WIFI ANT FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 2.4G(RX ANT) FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990 FCC ID: 2AOMX-KAR-990
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn RF Exposure MPE Report Reference No. ..................... : FCC ID............................................. : CTA26060300504 2AOMX-KAR-990 Compiled by ( position+printed name+signature) . : File administrators Zoey Cao Supervised by ( position+printed name+signature) . : Project Engineer Ace Chai Approved by ( position+printed name+signature) . : RF Manager Eric Wang Date of issue .................................... : Jun. 10, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : QFX Inc. Address............................................ : 2957 E. 46th Street, Vernon, CA 90058 Standard ........................................... : 47CFR §1.1310 47CFR §2.1091 KDB447498 D01 General RF Exposure Guidance v06 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purpses as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description ..................... : Speaker Trade Mark ....................................... : N/A Manufacturer .................................... : GUANGZHOU MINFU ELECTRONIC AUDIO CO.,LTD. Model/Type reference ...................... : KAR-990 Listed Models ................................... : KAR-210, KAR-212, KAR-215, KAR-100, KAR-200, KAR-300, KAR- 400, KAR-500, KAR-600, KAR-620, KAR-660, KAR-801, KAR-802, KAR-808, KAR-880, Kar-900, KAR-910, KAR-912, KAR-928 Rating ............................................... : AC Input: 100-240V, 50/60Hz 90W DC Input: 12V90W built-in rechargeable Li-ion Battery: 11.1V/7200mAh/79.92Wh Result ............................................... : PASS Report No.: CTA26060300504 Page 2 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Speaker Model /Type : KAR-990 Listed Models : KAR-210, KAR-212, KAR-215, KAR-100, KAR-200, KAR-300, KAR- 400, KAR-500, KAR-600, KAR-620, KAR-660, KAR-801, KAR-802, KAR-808, KAR-880, Kar-900, KAR-910, KAR-912, KAR-928 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. So the tests were performed on model KAR-990 and the test results for the main test model can cover the listed models. Applicant : QFX Inc. Address : 2957 E. 46th Street, Vernon, CA 90058 Manufacturer : GUANGZHOU MINFU ELECTRONIC AUDIO CO.,LTD. Address : No. 2, Dongsheng Sanheng Road, Dalong Street, Panyu District, Guangzhou, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26060300504 Page 3 of 10 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ............................................................................................................ 4 2 SUMMARY .......................................................................................................................... 5 2.1 General Remarks .................................................................................................... 5 2.2 Product Description ................................................................................................. 5 2.3 Special Accessories ................................................................................................ 6 2.4 Modifications ........................................................................................................... 6 3 TEST ENVIRONMENT ....................................................................................................... 7 3.1 Address of the test laboratory ................................................................................. 7 3.2 Test Facility ............................................................................................................. 7 3.3 Statement of the measurement uncertainty ............................................................ 7 4 Test limit .............................................................................................................................. 8 4.1 Requirement ........................................................................................................... 8 4.2 MPE Calculation Method ........................................................................................ 8 4.3 Conducted Power Results ...................................................................................... 9 4.4 Manufacturing tolerance ....................................................................................... 10 4.5 Standalone MPE Result ..............................................................…
Text truncated - open the document above for the full version.
1. Antenna Description: Antenna type PIFA Antenna Model KAR-990 Frequency range 2400-2500MHz, 5180-5240MHz, 5745-5825MHz Manufacturer QFX Inc. Address 2957 E. 46th Street, Vernon, CA 90058 ANT Peak Gain 1.5 dBi for 2400-2500MHz 1.79 dBi for 5180-5240MHz 1.93 dBi for 5745-5825MHz 2. Antenna Photo: 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4.Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz 5180MHz 5220MHz 5240MHz 5745MHz 5785MHz 5825MHz
Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn TEST REPORT FCC PART 15 SUBPART E 15.407 Report Reference No. ..................... : FCC ID. ........................................... : CTA26060300503 2AOMX-KAR-990 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Ace Chai Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Jun. 10, 2026 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Applicant’s name ............................ : QFX Inc. Address ............................................. : 2957 E. 46th Street, Vernon, CA 90058 Test specification .......................... : Standard ........................................... : FCC Part 15 Subpart E 15.407 TRF Originator .................................. : Shenzhen CTA Testing Technology Co., Ltd. Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .................... : Speaker Trade Mark ....................................... : N/A Manufacturer..................................... : GUANGZHOU MINFU ELECTRONIC AUDIO CO.,LTD. Model/Type reference ....................... : KAR-990 Listed Models.................................... : KAR-210, KAR-212, KAR-215, KAR-100, KAR-200, KAR-300, KAR-400, KAR-500, KAR-600, KAR-620, KAR-660, KAR-801, KAR-802, KAR- 808, KAR-880, Kar-900, KAR-910, KAR-912, KAR-928 Modulation ....................................... : OFDM Frequency ......................................... : From 5180MHz-5240MHz, 5745MHz-5825MHz Ratings .............................................. : AC Input: 100-240V, 50/60Hz 90W DC Input: 12V90W built-in rechargeable Li-ion Battery: 11.1V/7200mAh/79.92Wh Result ................................................ : PASS Report No.: CTA26060300503 Page 2 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Speaker Model /Type : KAR-990 Listed Models : KAR-210, KAR-212, KAR-215, KAR-100, KAR-200, KAR-300, KAR- 400, KAR-500, KAR-600, KAR-620, KAR-660, KAR-801, KAR-802, KAR-808, KAR-880, Kar-900, KAR-910, KAR-912, KAR-928 Model difference : The PCB board, circuit, structure and internal of these models are the same, Only model number and colour is different for these model. So the tests were performed on model KAR-990 and the test results for the main test model can cover the listed models. Applicant : QFX Inc. Address : 2957 E. 46th Street, Vernon, CA 90058 Manufacturer : GUANGZHOU MINFU ELECTRONIC AUDIO CO.,LTD. Address : No. 2, Dongsheng Sanheng Road, Dalong Street, Panyu District, Guangzhou, Guangdong Province, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA26060300503 Page 3 of 38 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 TEST STANDARDS ...................................................................................................................................... 4 2 SUMMARY .................................................................................................................................................... 5 2.1 General Remarks .............................................................................................................................. 5 2.2 Product Description .......................................................................................................................... 5 2.3 Equipment Under Test ...................................................................................................................... 5 2.4 Short description of the Equipment under Test (EUT) ..................................................................... 5 2.5 EUT configuration ............................................................................................................................. 6 2.6 EUT operation mode ........................................................................................................................ 6 2.7 Block Diagram of Test Setup ............................................................................................................ 6 2.8 Related Submittal(s) / Grant (s) ........................................................................................................ 6 2.9 Modifications ..................................................................................................................................... 7 3 TEST ENVIRONMENT ..............................…
Text truncated - open the document above for the full version.
1 FCC Appendix RF Test Data for 5GWIFI FCC ID : 2AOMX-KAR-990 Company : QFX Inc. EUT : Speaker Model Number : KAR-990 Report No. : CTA26060300503 Reviewed By : Eric Wang 2 Appendix A1: Emission Bandwidth Test Result TestMode Antenna Freq(MHz) 26db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 23.64 5167.96 5191.60 --- --- 5220 24.32 5207.68 5232.00 --- --- 5240 24.28 5227.80 5252.08 --- --- 5745 24.36 5732.64 5757.00 --- --- 5785 24.44 5772.84 5797.28 --- --- 5825 23.72 5812.76 5836.48 --- --- 11N20SISO Ant1 5180 24.00 5167.88 5191.88 --- --- 5220 24.20 5208.36 5232.56 --- --- 5240 24.76 5227.04 5251.80 --- --- 5745 24.76 5732.20 5756.96 --- --- 5785 25.32 5772.32 5797.64 --- --- 5825 24.60 5812.36 5836.96 --- --- 11N40SISO Ant1 5190 44.88 5167.92 5212.80 --- --- 5230 44.24 5208.24 5252.48 --- --- 5755 46.40 5732.04 5778.44 --- --- 5795 46.00 5772.36 5818.36 --- --- 3 Test Graphs 11A_Ant1_5180 11A_Ant1_5220 11A_Ant1_5240 4 11A_Ant1_5745 11A_Ant1_5785 5 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5220 6 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 7 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 11N40SISO_Ant1_5190 8 11N40SISO_Ant1_5230 11N40SISO_Ant1_5755 9 11N40SISO_Ant1_5795 10 Appendix A2: Occupied channel bandwidth Test Result TestMode Antenna Freq(MHz) OCB [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5180 17.383 5171.4486 5188.8312 --- --- 5220 16.903 5211.6084 5228.5115 --- --- 5240 17.063 5231.5285 5248.5914 --- --- 5745 17.942 5735.9291 5753.8711 --- --- 5785 17.542 5776.2088 5793.7512 --- --- 5825 17.582 5816.0490 5833.6314 --- --- 11N20SISO Ant1 5180 18.262 5170.9291 5189.1908 --- --- 5220 18.102 5210.9291 5229.0310 --- --- 5240 18.302 5230.9690 5249.2707 --- --- 5745 18.941 5735.5295 5754.4705 --- --- 5785 18.861 5775.7692 5794.6304 --- --- 5825 18.541 5815.7692 5834.3107 --- --- 11N40SISO Ant1 5190 36.923 5171.6983 5208.6214 --- --- 5230 36.923 5211.6184 5248.5415 --- --- 5755 37.642 5736.2188 5773.8611 --- --- 5795 37.642 5776.2188 5813.8611 --- --- 11 Test Graphs 11A_Ant1_5180 11A_Ant1_5220 11A_Ant1_5240 12 11A_Ant1_5745 11A_Ant1_5785 13 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5220 14 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 15 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 11N40SISO_Ant1_5190 16 11N40SISO_Ant1_5230 11N40SISO_Ant1_5755 17 11N40SISO_Ant1_5795 18 Appendix A3: Min emission bandwidth Test Result B4 TestMode Antenna Freq(MHz) 6db EBW [MHz] FL[MHz] FH[MHz] Limit[MHz] Verdict 11A Ant1 5745 16.32 5736.84 5753.16 0.5 PASS 5785 16.32 5776.84 5793.16 0.5 PASS 5825 16.32 5816.84 5833.16 0.5 PASS 11N20SISO Ant1 5745 17.56 5736.20 5753.76 0.5 PASS 5785 17.56 5776.24 5793.80 0.5 PASS 5825 17.52 5816.24 5833.76 0.5 PASS 11N40SISO Ant1 5755 36.08 5736.84 5772.92 0.5 PASS 5795 36.32 5776.84 5813.16 0.5 PASS 19 Test Graphs B4 11A_Ant1_5745 11A_Ant1_5785 11A_Ant1_5825 20 11N20SISO_Ant1_5745 11N20SISO_Ant1_5785 21 11N20SISO_Ant1_5825 11N40SISO_Ant1_5755 11N40SISO_Ant1_5795 22 23 Appendix B: Duty Cycle Test Result TestMode Antenna Freq(MHz) Transmission Duration [ms] Transmission Period [ms] Duty Cycle [%] DC Factor [dB] Limit Verdict 11A Ant1 5180 0.15 0.20 75.00 1.25 --- --- 5220 0.15 0.20 75.00 1.25 --- --- 5240 0.15 0.20 75.00 1.25 --- --- 5745 0.14 0.19 73.68 1.33 --- --- 5785 0.15 0.19 78.95 1.03 --- --- 5825 0.15 0.19 78.95 1.03 --- --- 11N20SISO Ant1 5180 0.18 0.22 81.82 0.87 --- --- 5220 0.18 0.23 78.26 1.06 --- --- 5240 0.18 0.23 78.26 1.06 --- --- 5745 0.18 0.22 81.82 0.87 --- --- 5785 0.17 0.22 77.27 1.12 --- --- 5825 0.18 0.23 78.26 1.06 --- --- 11N40SISO Ant1 5190 0.18 0.22 81.82 0.87 --- --- 5230 0.18 0.23 78.26 1.06 --- --- 5755 0.18 0.23 78.26 1.06 --- --- 5795 0.18 0.22 81.82 0.87 --- --- 24 Test Graphs 11A_Ant1_5180 11A_Ant1_5220 11A_Ant1_5240 25 11A_Ant1_5745 11A_Ant1_5785 26 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5220 27 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 28 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 11N40SISO_Ant1_5190 29 11N40SISO_Ant1_5230 11N40SISO_Ant1_5755 30 11N40SISO_Ant1_5795 31 Appendix C: Maximum conducted output power Test Result Test Mode Antenna Freq(MH z) Channel Power [dBm] Duty Cycle [%] DC Factor [dBm] Result [dBm] Limit [dBm] Verdict 11A Ant1 5180 13.88 75.00 1.25 15.13 ≤23.98 PASS 5220 14.01 75.00 1.25 15.26 ≤23.98 PASS 5240 13.87 75.00 1.25 15.12 ≤23.98 PASS 5745 13.46 73.68 1.33 14.79 ≤30.00 PASS 5785 13.51 78.95 1.03 14.54 ≤30.00 PASS 5825 13.31 78.95 1.03 14.34 ≤30.00 PASS 11N20SI SO Ant1 5180 13.75 81.82 0.87 14.62 ≤23.98 PASS 5220 13.94 78.26 1.06 15.00 ≤23.98 PASS 5240 13.77 78.26 1.06 14.83 ≤23.98 PASS 5745 13.64 81.82 0.87 14.51 ≤30.00 PASS 5785 13.64 77.27 1.12 14.76 ≤30.00 PASS 5825 13.43 78.26 1.06 14.49 ≤30.00 PASS 11N40SI SO Ant1 5190 13.87 81.82 0.87 14.74 ≤23.98 PASS 5230 13.91 78.26 1.06 14.97 ≤23.98 PASS 5755 13.71 78.26 1.06 14.77 ≤30.00 PASS 5795 13.74 81.82 0.87 14.61 ≤30.00 PASS 32 Appendix D: Maximum power spectral density Test Result Note:1.The Result and Limit Unit is dBm/500 kHz in the band 5.725−5.85 GHz. TestMode Antenna Freq(MHz) RawData [dBm/MHz] DC Factor [dBm] Result [dBm/MHz] Limit [dBm/MHz] Verdict 11A Ant1 5180 3.46 1.25 4.71 ≤11.00 PASS 5220 3.5 1.25 4.75 ≤11.00 PASS 5240 3.25 1.25 4.50 ≤11.00 PASS 5745 -0.36 1.33 0.97 ≤30.00 PASS 5785 -0.92 1.03 0.11 ≤30.00 PASS 5825 -0.67 1.03 0.36 ≤30.00 PASS 11N20SISO Ant1 5180 2.96 0.87 3.83 ≤11.00 PASS 5220 3.04 1.06 4.10 ≤11.00 PASS 5240 3.43 1.06 4.49 ≤11.00 PASS 5745 -0.54 0.87 0.33 ≤30.00 PASS 5785 -0.5 1.12 0.62 ≤30.00 PASS 5825 -0.76 1.06 0.30 ≤30.00 PASS 11N40SISO Ant1 5190 0.31 0.87 1.18 ≤11.00 PASS 5230 0.07 1.06 1.13 ≤11.00 PASS 5755 -3.46 1.06 -2.40 ≤30.00 PASS 5795 -3.16 0.87 -2.29 ≤30.00 PASS 33 Test Graphs 11A_Ant1_5180 11A_Ant1_5220 11A_Ant1_5240 34 11A_Ant1_5745 11A_Ant1_5785 35 11A_Ant1_5825 11N20SISO_Ant1_5180 11N20SISO_Ant1_5220 36 11N20SISO_Ant1_5240 11N20SISO_Ant1_5745 37 11N20SISO_Ant1_5785 11N20SISO_Ant1_5825 11N40SISO_Ant1_5190 38 11N40SISO_Ant1_5230 11N40SISO_Ant1_5755 39 11N40SISO_Ant1_5795 40 Appendix E: Band edge…
Text truncated - open the document above for the full version.
51 11A_Ant1_5785_30~5650 11A_Ant1_5785_5925~40000 52 11A_Ant1_5825_30~5650 11A_Ant1_5825_5925~40000 11N20SISO_Ant1_5180_30~5140 53 11N20SISO_Ant1_5180_5360~40000 11N20SISO_Ant1_5220_30~5140 54 11N20SISO_Ant1_5220_5360~40000 11N20SISO_Ant1_5240_30~5140 11N20SISO_Ant1_5240_5360~40000 55 11N20SISO_Ant1_5745_30~5650 11N20SISO_Ant1_5745_5925~40000 56 11N20SISO_Ant1_5785_30~5650 11N20SISO_Ant1_5785_5925~40000 11N20SISO_Ant1_5825_30~5650 57 11N20SISO_Ant1_5825_5925~40000 11N40SISO_Ant1_5190_30~5140 58 11N40SISO_Ant1_5190_5360~40000 11N40SISO_Ant1_5230_30~5140 11N40SISO_Ant1_5230_5360~40000 59 11N40SISO_Ant1_5755_30~5650 11N40SISO_Ant1_5755_5925~40000 60 11N40SISO_Ant1_5795_30~5650 11N40SISO_Ant1_5795_5925~40000 61 Appendix G: Emissions in Restricted Bands Test Result TestMode Antenn a ChName Freq(MH z) Detector Freq [MHz] Result [dBm] Gain [dB] DC Factor [dB] EIRP [dBm] Limit [dBm] Verdict 11A Ant1 Low 5180 AV 4500.000 -56.8 2.00 1.25 -53.55 ≤-41.20 PASS AV 5144.203 -54.14 2.00 1.25 -50.89 ≤-41.20 PASS AV 5150.000 -54.15 2.00 1.25 -50.9 ≤-41.20 PASS Peak 4500.000 -47.29 2.00 0.00 -45.29 ≤-27.00 PASS Peak 5102.609 -42.65 2.00 0.00 -40.65 ≤-27.00 PASS Peak 5150.000 -42.6 2.00 0.00 -40.6 ≤-27.00 PASS High 5240 AV 5350.000 -54.55 2.00 1.25 -51.3 ≤-41.20 PASS AV 5361.565 -54.36 2.00 1.25 -51.11 ≤-41.20 PASS AV 5460.000 -55.16 2.00 1.25 -51.91 ≤-41.20 PASS Peak 5350.000 -43.72 2.00 0.00 -41.72 ≤-27.00 PASS Peak 5361.217 -41.99 2.00 0.00 -39.99 ≤-27.00 PASS Peak 5460.000 -43.81 2.00 0.00 -41.81 ≤-27.00 PASS Low 5745 Peak 5650.000 -43.89 2.00 0.00 -41.89 ≤-27.00 PASS Peak 5700.000 -43.11 2.00 0.00 -41.11 ≤10.00 PASS Peak 5720.000 -42.19 2.00 0.00 -40.19 ≤15.60 PASS Peak 5725.000 -39.59 2.00 0.00 -37.59 ≤27.00 PASS High 5825 Peak 5850.000 -40.81 2.00 0.00 -38.81 ≤27.00 PASS Peak 5855.000 -41.38 2.00 0.00 -39.38 ≤15.60 PASS Peak 5875.000 -42.1 2.00 0.00 -40.1 ≤10.00 PASS Peak 5925.000 -42.7 2.00 0.00 -40.7 ≤-27.00 PASS 11N20SI SO Ant1 Low 5180 AV 4500.000 -56.86 2.00 0.87 -53.99 ≤-41.20 PASS AV 5144.203 -54.1 2.00 0.87 -51.23 ≤-41.20 PASS AV 5150.000 -53.99 2.00 0.87 -51.12 ≤-41.20 PASS Peak 4500.000 -47.03 2.00 0.00 -45.03 ≤-27.00 PASS Peak 5128.986 -42.83 2.00 0.00 -40.83 ≤-27.00 PASS Peak 5150.000 -42.09 2.00 0.00 -40.09 ≤-27.00 PASS High 5240 AV 5350.000 -54.41 2.00 1.06 -51.35 ≤-41.20 PASS AV 5351.826 -54.23 2.00 1.06 -51.17 ≤-41.20 PASS AV 5460.000 -55.09 2.00 1.06 -52.03 ≤-41.20 PASS Peak 5350.000 -43.57 2.00 0.00 -41.57 ≤-27.00 PASS Peak 5389.391 -42.06 2.00 0.00 -40.06 ≤-27.00 PASS Peak 5460.000 -44.72 2.00 0.00 -42.72 ≤-27.00 PASS Low 5745 Peak 5650.000 -43.65 2.00 0.00 -41.65 ≤-27.00 PASS Peak 5700.000 -43.39 2.00 0.00 -41.39 ≤10.00 PASS Peak 5720.000 -42.13 2.00 0.00 -40.13 ≤15.60 PASS Peak 5725.000 -40.5 2.00 0.00 -38.5 ≤27.00 PASS 62 High 5825 Peak 5850.000 -37.65 2.00 0.00 -35.65 ≤27.00 PASS Peak 5855.000 -41.05 2.00 0.00 -39.05 ≤15.60 PASS Peak 5875.000 -41.98 2.00 0.00 -39.98 ≤10.00 PASS Peak 5925.000 -42.77 2.00 0.00 -40.77 ≤-27.00 PASS 11N40SI SO Ant1 Low 5190 AV 4500.000 -57.03 2.00 0.87 -54.16 ≤-41.20 PASS AV 5149.275 -51.11 2.00 0.87 -48.24 ≤-41.20 PASS AV 5150.000 -51.32 2.00 0.87 -48.45 ≤-41.20 PASS Peak 4500.000 -47.24 2.00 0.00 -45.24 ≤-27.00 PASS Peak 5147.246 -39.32 2.00 0.00 -37.32 ≤-27.00 PASS Peak 5150.000 -39.92 2.00 0.00 -37.92 ≤-27.00 PASS High 5230 AV 5350.000 -54.37 2.00 1.06 -51.31 ≤-41.20 PASS AV 5380.870 -54.34 2.00 1.06 -51.28 ≤-41.20 PASS AV 5460.000 -55.22 2.00 1.06 -52.16 ≤-41.20 PASS Peak 5350.000 -43.5 2.00 0.00 -41.5 ≤-27.00 PASS Peak 5368.812 -42.28 2.00 0.00 -40.28 ≤-27.00 PASS Peak 5460.000 -44.6 2.00 0.00 -42.6 ≤-27.00 PASS Low 5755 Peak 5650.000 -43.83 2.00 0.00 -41.83 ≤-27.00 PASS Peak 5700.000 -41.97 2.00 0.00 -39.97 ≤10.00 PASS Peak 5720.000 -38.48 2.00 0.00 -36.48 ≤15.60 PASS Peak 5725.000 -37.67 2.00 0.00 -35.67 ≤27.00 PASS High 5795 Peak 5850.000 -40.19 2.00 0.00 -38.19 ≤27.00 PASS Peak 5855.000 -41.24 2.00 0.00 -39.24 ≤15.60 PASS Peak 5875.000 -41.46 2.00 0.00 -39.46 ≤10.00 PASS Peak 5925.000 -43.35 2.00 0.00 -41.35 ≤-27.00 PASS Note: 1. For transmitters operating in 5150-5350 GHz band and 5470-5725 GHz band: The limit in dBm for average detector is conversion from 54dBuV/m, according to 15.209(a). The limit in dBm for peak detector is 20dB above the limit of average detector in dBm. 63 Test Graphs 11A_Ant1_Low_5180_AV 11A_Ant1_Low_5180_Peak 11A_Ant1_High_5240_AV 64 11A_Ant1_High_5240_Peak 11A_Ant1_Low_5745_Peak 65 11A_Ant1_High_5825_Peak 11N20SISO_Ant1_Low_5180_AV 11N20SISO_Ant1_Low_5180_Peak 66 11N20SISO_Ant1_High_5240_AV 11N20SISO_Ant1_High_5240_Peak 67 11N20SISO_Ant1_Low_5745_Peak 11N20SISO_Ant1_High_5825_Peak 11N40SISO_Ant1_Low_5190_AV 68 11N40SISO_Ant1_Low_5190_Peak 11N40SISO_Ant1_High_5230_AV 69 11N40SISO_Ant1_High_5230_Peak 11N40SISO_Ant1_Low_5755_Peak 11N40SISO_Ant1_High_5795_Peak 70
