FFRC10A FIFISH Communication Station User Manual Model: FFRC10A The Communication Station FFRC10A is used for the FIFISH series robot of QINGDAO QIYUAN CXIN KEJI and Shenzhen QIYUAN technology limited company. It works as a video/image signal repeater station by achieving signal reception between robot and mobile devices. Communication Station 12. LEDbrightness:brightnessoftheLED. 13. Photo:pressfortakingphoto. 14. Chargingport:insertthe5V/3Aadaptertochargethebattery 15. MicroSDslot:caninsertamicroSDcardtodownloadthedatafrominternalcameraof robot. 16. Buttontoadjustholderwidth. 17. Holderformobilephoneorpad Note:The device is restricted to indoor use only when operating in 5150 to 5250MHz frequency range. 1. ON/OFF:Poweron/offkey. 2. Depth(ON/OFF):Depthinformationon/off 3. Lock/unlock:Lockandunlocktheimaging 4. Leftstick:chooseleftsideofvideoorimage. 5. Rightstick:chooserightsideofvideoorimage 6. Rightwheel:chooseupsideofvideoorimage 7. Leftwheel:choosedownsideofvideoorimage 8. Videorecord/stop:Videorecordkey 9. Modeselect:changevideoorimagemodes. 10. Tetherport:insertholeofthecommunicationtether. 11. Ethernetport:aEthernetoutputport. When it works, the router processor will broadcast a SSID: FIFISHRC_xxxx; in mobile device’s wifi setting, choose to connect to this SSID, then launch FIFISH APP and can see the camera image. The signal transmission path can refer to the block diagram above: Image from Camera of the Robot go through PLC modem and PHY via Ethernet to arrive the router processor, processor then forward these data to 5GHz Radio chip via PCIE, at the end,Radio chip send the image and video to mobile device using PCB antenna for wireless communication. FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction EN This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions: 1.This device may not cause interference. 2.This device must accept any interference, including interference that may cause undesired operation of the device. FR L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1.L’appareil ne doit pas produire de brouillage; 2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. RF Specification: Function Operation Frequency Max RF outputpower: Limit Wi-Fi 5.2G(802.11a/n20/n40/ ac20/ac40/ac80) 802.11a/ n20/ac20:5180MHz~5240MHz 802.11 n40/ac40:5190MHz~5230MHz 802.11ac80:5210MHz 14.48 dBm 23dBm. EU Declaration of Conformity We, QINGDAO QIYUAN CXIN KEJI CO.,LTD(No. 111 Daoli Street Tianheng Town Jimo District Qingdao, Shandong, P.R. China) hereby declares that this Communication Station is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. According to Article 10(2) of Directive 2014/53/EU, the FFRC10A can be used in Europe without restriction. Warning: RED Manufacturer's Name: QINGDAO QIYUAN CXIN KEJI CO.,LTD Product Name: Sigur MR100-Multi reader Model number: Communication Station Operating Temperature: -10°C to 40°C This product can be used across all EU member states. Hereby, QINGDAO QIYUAN CXIN KEJI CO.,LTD declares that this Communication Station product is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. A copy of the Declaration of Conformity can be found at Website: http://www.qysea.com The device complies with RF specifications when the device is used at 20cm from your body. Care for the environment! Must not be discarded with household waste! Restrictions in the 5 GHz band: According to Article 10 (10) of Directive 2014/53/EU, the packaging showsthat this radio equipment will be subject to some restrictions when placedon the market in Belgium (BE), Bulgaria (BG), the Czech Republic (CZ),Denmark (DK), Germany (DE), Estonia (EE), Ireland (IE), Greece (EL), Spain(ES), France (FR), Croatia (HR), Italy (IT), Cyprus (CY), Latvia (LV), …
Text truncated - open the document above for the full version.
Shenzhen Qi Yuan Science and Technology Co., LTD. Agent Authorization Company: Shenzhen Qi Yuan Science and Technology Co., LTD. Address: 1st Floor, Building #2 Galaxy Incubator #1 Yanan Road, Meiban Boulevard Longgang District, Shenzhen, Guangdong, China Product Name: Communication Station Model Number(s): FFRC10A Product Description: Communication Station We authorize MiCOM Labs Inc., 575 Boulder Court, Pleasanton, California 94566, USA, to act on our behalf on all matters concerning the certification of above named equipment. We declare that MiCOM Labs Inc. is allowed to forward all information related to the approval and certification of equipment to the regulatory agencies as required and to discuss any issues concerning the approval application. Any and all acts carried out by MiCOM Labs on our behalf shall have the same effect as acts of our own. Signature: Date: 2020/11/05 Name: Ping Li Title: Vice President Company: Shenzhen Qi Yuan Science and Technology Co., LTD.
Shenzhen Qi Yuan Science and Technology Co., LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: 2020/11/05 Subject; Request for Confidentiality FCC ID: 2AONKFFRC10A To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description FCC_Software_Security_Requirements_for_UNII_devices Tune-up Procedure In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuantto KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Ping Li Title: Vice President Shenzhen Qi Yuan Science and Technology Co., LTD.
FCC Software Configuration Control Declaration Rev1.1 Shenzhen Qi Yuan Science and Technology Co., LTD. FCC Software Configuration Control Declaration Date: November 5, 2020 Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Attn: OET Dept. Product/ Model Number: Communication Station / FFRC10A Regarding FCC Country Code Selection guidelines identified in KDB 594280D01v02r01. “All applications for equipment authorization for transmitters that can have radio parameters, or other technical parameters, reported to the Commission set by software must have an attestation indicating that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified.” We declare that no third party will have software, or configuration control, to program the device out of compliance of the technical rules under which it has been certified. Name: Ping Li Date: 2020/11/05 Title: Vice President Signature of applicant
Shenzhen Qi Yuan Science and Technology Co., LTD Date: Nov 05, 2020 FCC ID: 2AONKFFRC10A Model Number: FFRC10A To: Federal Communication Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21048 To Whom It May Concern, We, Shenzhen Qi Yuan Science and Technology Co., LTD. that this EUT (FCC ID: 2AONKFFRC10A) will conduct FCC compliance testing, the SDOC part recognized test lab(Shenzhen NTEK Testing Technology Co., Ltd.( ShenZhen Lab.). 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District Shenzhen, Guangdong, China) Please contact me if you have any question. Sincerely, (Signed) Name / Title: Ping Li / Vice President Company: Shenzhen Qi Yuan Science and Technology Co., LTD. Address: 1st Floor, Building #2 Galaxy Incubator #1 Yanan Road, Meiban Boulevard Longgang District, Shenzhen, Guangdong, China Phone: 0755 22662313
S20091801305 Model: FFRC10A N20191017V1 Photo 1 Photo 2 S20091801305 Model: FFRC10A N20191017V1 Photo 3 Photo 4 S20091801305 Model: FFRC10A N20191017V1 Photo 5 Photo 6 S20091801305 Model: FFRC10A N20191017V1 Photo 7 Photo 8 S20091801305 Model: FFRC10A N20191017V1 Photo 9 Photo 10
` © © 5mm I I � [ s mm 45mm F IFISH Controlle, ((!、 (CCX Xu\ l'>'YY<社 ' Mod芒IFFRC10A CMIIT ID 2018DP1077 FCC ID·2AONK FIFISH re-23<B5-FIFISH01 深圳墟范科技有限公司 Shenzhen Qi Yuan Sc,ence andTechnology Co., LTD. C E: 今 百 比 芯 需 $: , 飞 初 心 :� : ;; Op e, 引ionis s,bjecl to 1he foll ow;ng 1wo conditions :1) th,s de,ice may not cau,e hacmlul inlorlo『en«, and 2) th" do,;<e m,,t ampl any ;n叩 诬防溅水 Beware of splashing wate『 5.2GHz band is restricted to indoor use due to the Radio Law
S20091801305 Model: FFRC10A N20191017V1 Photo 1 Photo 2 S20091801305 Model: FFRC10A N20191017V1 Photo 3 Photo 4 Main ANT 0 Aux ANT 1 S20091801305 Model: FFRC10A N20191017V1 Photo 5 Photo 6 S20091801305 Model: FFRC10A N20191017V1 Photo 7 Photo 8 S20091801305 Model: FFRC10A N20191017V1 Photo 9 Photo 10 S20091801305 Model: FFRC10A N20191017V1 Photo 11 Photo 12 S20091801305 Model: FFRC10A N20191017V1 Photo 13 Photo 14
FCC ID: 2AONKFFRC10A According to §15.247(e)(i) and §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to KDB447498 D01 General RF Exposure Guidance V06 The 1-g SAR and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)]·[√f(GHZ)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f(GHZ) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Modulation Channel Freq. (GHz) Conducted power (dBm) Conducted power (mW) Tune-up power (dBm) Max tune-up power (dBm) Max tune-up power (mW) Distance (mm) Result calculation 10g SAR Exclusion threshold SAR test exclusion 802.11ac205.2010.8912.27410±11215.8495.007.228237.50YES Conclusion: For the max result : 7.22823≤ 7.5 for 10-g SAR, No SAR is required. Signature: Date: 2020-11-19 NAME AND TITLE (Please print or type): Alex Li/Manager COMPANY (Please print or type): Shenzhen NTEK Testing Technology Co., Ltd./ 1/F, Building E, Fenda Science Park, Sanwei Community, Xixiang Street Bao’an District, Shenzhen P.R. China.
Report No.: S20091801310001 Version.1.2 Page 1 of 141 FCC RADIO TEST REPORT FCC ID: 2AONKFFRC10A Product: Communication Station Trade Mark: N/A Model No.: FFRC10A Family Model: N/A Report No.: S20091801310001 Issue Date: 20 Oct. 2020 Prepared for Shenzhen Qi Yuan Science and Technology Co., LTD. 1st Floor, Building #2 Galaxy Incubator #1 Yanan Road, Meiban Boulevard Longgang District, Shenzhen, Guangdong, China Prepared by Shenzhen NTEK Testing Technology Co., Ltd. 1/F, Building E, Fenda Science Park Sanwei, Xixiang, Bao'an District Shenzhen, Guangdong, China Tel:400-800-6106 , 0755-3699-5508 Website:http://www.ntek.org.cn Report No.: S20091801310001 Version.1.2 Page 2 of 141 TEST RESULT CERTIFICATION Applicant’s name ................. : Shenzhen Qi Yuan Science and Technology Co., LTD. Address ................................. : 1st Floor, Building #2 Galaxy Incubator #1 Yanan Road, Meiban Boulevard Longgang District, Shenzhen, Guangdong, China Manufacturer's Name .......... : Shenzhen Qi Yuan Science and Technology Co., LTD. Address ................................. : 1st Floor, Building #2 Galaxy Incubator #1 Yanan Road, Meiban Boulevard Longgang District, Shenzhen, Guangdong, China Product description Product name............................ : Communication Station Model and/or type reference : FFRC10A Family Model ............................. : N/A Standards ............................. : FCC Part15.407 Test procedure ............................... : ANSI C63.10-2013 and KDB 789033 D02 General UNII Test Procedures New Rules v02r01 FCC KDB 662911 D01 Multiple Transmitter Output v02r01 This device described above has been tested by NTEK, and the test results show that the equipment under test (EUT) is in compliance with the FCC requirements/ the Industry Canada requirements.. And it is applicable only to the tested sample identified in the report. This report shall not be reproduced except in full, without the written approval of NTEK, this document may be altered or revised by NTEK, personnel only, and shall be noted in the revision of the document. Date of Test ........................................... : Date (s) of performance of tests ............. : 18 Sep. 2020 ~ 20 Oct. 2020 Date of Issue .......................................... : 20 Oct. 2020 Test Result.............................................. : Pass Testing Engineer : (Mary Hu) Technical Manager : (Jason Chen) Authorized Signatory : (Alex Li) Report No.: S20091801310001 Version.1.2 Page 3 of 141 Table of Contents Page 1 . SUMMARY OF TEST RESULTS 7 1.1 FACILITIES AND ACCREDITATIONS 8 1.2 MEASUREMENT UNCERTAINTY 8 2 . GENERAL INFORMATION 9 2.1 GENERAL DESCRIPTION OF EUT 9 2.2 DESCRIPTION OF TEST MODES 12 2.3 BLOCK DIGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 13 2.4 DESCRIPTION OF SUPPORT UNITS(CONDUCTED MODE) 14 2.5 EQUIPMENTS LIST FOR ALL TEST ITEMS 15 3 . EMC EMISSION TEST 17 3.1 CONDUCTED EMISSION MEASUREMENT 17 3.1.1 APPLICABLE STANDARD 17 3.1.2 CONFORMANCE LIMIT 17 3.1.3 TEST CONFIGURATION 17 3.1.4 TEST PROCEDURE 17 3.2 RADIATED EMISSION MEASUREMENT 20 3.2.1 APPLICABLE STANDARD 20 3.2.2 CONFORMANCE LIMIT 20 3.2.3 MEASURING INSTRUMENTS 20 3.2.4 TEST CONFIGURATION 21 3.2.5 TEST PROCEDURE 22 3.2.6 TEST RESULTS (9KHZ – 30 MHZ) 23 3.2.7 TEST RESULTS (30MHZ – 1GHZ) 24 3.2.8 TEST RESULTS (1GHZ-18GHZ) 26 4 . POWER SPECTRAL DENSITY TEST 30 4.1 APPLIED PROCEDURES / LIMIT 30 4.2 TEST PROCEDURE 31 4.3 DEVIATION FROM STANDARD 31 4.4 TEST SETUP 31 4.5 EUT OPERATION CONDITIONS 31 4.6 TEST RESULTS 32 5 . 26DB & 99% EMISSION BANDWIDTH 33 5.1 APPLIED PROCEDURES / LIMIT 33 5.2 TEST PROCEDURE 33 5.3 EUT OPERATION CONDITIONS 34 5.4 TEST RESULTS 34 6 . MINIMUM 6 DB BANDWIDTH 35 6.1 APPLIED PROCEDURES / LIMIT 35 Report No.: S20091801310001 Version.1.2 Page 4 of 141 Table of Contents Page 6.2 TEST PROCEDURE 35 6.3 DEVIATION FROM STANDARD 35 6.4 TEST SETUP 35 6.5 EUT OPERATION CONDITIONS 35 6.6 TEST RESULTS 36 7 . MAXIMUM CONDUCTED OUTPUT POWER 37 7.1 PPLIED PROCEDURES / LIMIT 37 7.2 TEST RESULTS 39 8 . OUT OF BAND EMISSIONS 40 8.1 APPLICABLE STANDARD 40 8.2 TEST PROCEDURE 40 8.3 DEVIATION FROM STANDARD 40 8.4 TEST SETUP 40 8.5 EUT OPERATION CONDITIONS 41 8.6 TEST RESULTS 42 8. FREQUENCY STABILITY MEASUREMENT 43 8.1 LIMIT 43 8.2 TEST PROCEDURES 43 8.3 TEST SETUP LAYOUT 43 8.4 EUT OPERATION DURING TEST 43 8.5 TEST RESULTS 44 9. DYNAMIC FREQUENCY SELECTION(DFS) 47 9.1 APPLICABILITY OF DFS REQUIREMENTS 47 9.2 INTERFERENCE THRESHOLD VALUES, MASTER OR CLIENT INCORPORATING IN-SERVICE MONITORING 47 9.3 DFS RESPONSE REQUIREMENT VALUES 48 9.4 SHORT PULSE RADAR TEST WAVEFORMS 48 9.5 CALIBRATION SETUP AND DFS TEST RESULTS 49 9.6 CONDUCTED CALIBRATION SETUP 49 9.7 RADAR WAVEFORM CALIBRATION RESULT 50 9.8 IN-SERVICE MONITORING: CHANNEL MOVE TIME, CHANNEL CLOSING TRANSMISSION TIME AND NON-OCCUPANCY PERIOD 51 9.9 RESULT OF CHANNEL MOVE TIME, CHANNEL CLOSING TRANSMISSION TIME AND NON-OCCUPANCY PERIOD FOR CLIENT BEACON TEST 52 10. ANTENNA REQUIREMENT 53 10.1 STANDARD REQUIREMENT 53 Report No.: S20091801310001 Version.1.2 Page 5 of 141 Table of Contents Page 10.2 EUT ANTENNA 53 11. TEST RESULTS 54 11.1 DUTY CYCLE 54 11.2 MAXIMUM CONDUCTED OUTPUT POWER 69 11.3 OCCUPIED CHANNEL BANDWIDTH 70 11.4 MAXIMUM POWER SPECTRAL DENSITY LEVEL 99 11.5 BAND EDGE 114 11.6 CONDUCTED RF SPURIOUS EMISSION 127 Report No.: S20091801310001 Version.1.2 Page 6 of 141 Revision History Report No. Version Description Issued Date S20091801310001 Rev.01 Initial issue of report 20 Oct, 2020 Report No.: S20091801310001 Version.1.2 Page 7 of 141 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: FCC Part15 (15.407) , Subpart E Standard Section Test Item Judgment Remark 15.207 AC Power Line Conducted Emissions PASS 15.209(a), 15.407 (b)(1) Spurious Radiated Emissions PASS 15.407 (a) 26 dB and 99% Emission Bandwidth PASS 15.407(e) Minimum 6 dB bandwidth N/A 15.407 (a) Maximum Conducted Output Power PASS 15.407 (b)(1) Band Edge PASS 15.407 (a) Power Sp…
