2AOV6HP-092Bluetooth Sleep Mask

RF warning statement: (English version) Sleep Mask With Built in Bluetooth Speaker Model:HP-092 · Keep the unit away from heat sources, direct sunling, humidity,water and any other liquids · Do not use the unit if it has been dropped ordamaged in any way · Repairs telectrical equipment should only b performed bya qualified electrician. Imprope repairs may place the user at serious risk · Do not expose to excessive heat such as sunshine ,fire etc · Never immerse the unit in water or any other liquid for cleaning purposes · Keep equipment dry Product Diagram Safety Instructions Skip backward/Volume Long Press to previous track, Short press to decrease the volume MFB Button (Play/Pause/paly back/ Phone-Answer/Deny incoming call /Power ON/OFF Skip forward/Volume Long Press to next track, Short press to increase the volume    ● Bluetooth Version: 5.0V● Frequency Range: 33ft / 10m ● Frequency Response: 80HZ-20KHZ ● Battery: 180mAh ● Play T ime: 2-3hrs● Charge Time: 2-3hrs ● Charging voltage: DC5V● Function sup port: Bluetooth. Specifications Pairing Instrustion 1.Press the Power switch button for about 3 seconds you will hear a voice power on , the led indicator light will quickly flash. 2.Connect it with your bluetooth device by searching “Sylania SP062”. If a password needed,please enter”000”.When the bluetooth is paired successfully, you will here a sound. 3.The unit will be auto power off in 5 minutes during the bluetooth is disconnected or not connected.  Charing Instrustion Plug the charging cable to micro-USB port at the back of the device,make sure that your speaker is full charged for 12 hours before initial use,While charging, the red LED light constantly, Normal charging 3 hours, when charging is completed, the blue LED light on . FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. For service assistance and product information, please call: 1-800-968-9853. Curtis International Ltd. 7045 BECKETT DRIVE, UNIT 15, MISSISSAUGA, ON, L5S 2A3 www.curtisint.com (French version) Masque de sommeil avec haut-parleur Bluetooth intégré Model:HP-092 · Tenez l'appareil éloigné des sources de chaleur, de l'ensoleillement direct, de l'humidité, de l'eau et de tout autre liquide · N'utilisez pas l'appareil s'il a été échappé ou endommagé de quelque façon que ce soit. · Les réparations de l'équipement télectrique ne doivent être effectuées que par un électricien qualifié. Impropeles réparations peuvent mettre l'utilisateur en danger · Ne pas exposer à une chaleur excessive telle que le soleil, le feu, etc. · Ne plongez jamais l'appareil dans l'eau ou tout autre liquide à des fins de nettoyage · Gardez l'équipement au sec Diagramme de produit Consignes de sécurité Passer en arrière / Volume Appuyez longuement sur la piste précédente, appuyez brièvement pour diminuer le volume Bouton MFB (lecture / pause / retour en arrière / réponse téléphonique / refuser l'appel entrant / mise sous / hors tension Aller de l'avant / Volume Appuyez longuement sur la piste suivante, appuyez brièvement pour augmenter le volume    ● Version Bluetooth: 5.0V● Gamme de fréquences: 33ft / 10m ● Fréquence de réponse: 80HZ-20KHZ ● Batterie: 180mAh ● Récréation: 2-3hrs● Temps de charge: 2-3hrs ● Tension de charge: DC5V● Support de fonction:Bluetooth Caractéristiques Instruction de jumelage 1.Appuyez sur l'interrupteur d'alimentation bouton pendant environ 3 secondes, vous entendrez une voix sous tension, le voyant lumineux clignote rapidement. 2.Connectez-le à votre appareil Bluetooth en recherchant “Sylania SP062”. Si un mot de passe est nécessaire,veuillez entrer “000”.Lorsque le bluetooth est appairé avec succès, vous entendrez ici un son. 3.L'unité s'éteindra automatiquement dans 5 minutes lorsque le Bluetooth est déconnecté ou non connecté.  Instruction de charge Branchez le câble de charge sur le port micro-USB à l'arrière de l'appareil,assurez-vous que votre haut-parleur est complètement chargé pendant 12 heures avant la première utilisation,Pendant la charge, la LED rouge s'allume constamment, Charge normale 3 heures, une fois le chargement terminé, la lumière LED bleue allumée . Déclaration de FCC : Cet appareil est conforme à la partie 15 des règles de la FCC. Opération est soumise aux deux conditions suivantes: (1) Cet appareil ne peut pas causer d'interférences nuisibles, et (2) Cet appareil doit accepter toute interférence reçue, y compris les interférences susceptibles qui va provoquer une opération indésirable. Attention: Les changements ou modifications non expressément app…

Text truncated - open the document above for the full version.

FCC ID: 2AOV6HP-092

FCC ID: 2AOV6HP-092 ANT

RF EXPOSURE EVALUATION FCC ID: 2AOV6HP-092 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency(RF) Radiation as specified in §1.1307(b): Routine SAR evaluation refers to that specifically required by §2.1093, using measurements or computer simulation. When routine SAR evaluation is not required, portable transmitters withoutput power greater than the applicable low threshold require SAR evaluation to qualify for TCB approval. Channel (MHz) Maximum output power (dBm) Tune up tolerance (dBm) Max Tune Up Power (dBm) Distance (mm) Calculation results Limit Operating Mode 24022.103 2.103±1 3.10350.6333 BDR+EDR 24410.316 0.316±1 1.31650.4233 24800.914 0.914±1 1.91450.4893 24023.177 3.177±1 4.17750.8113 24411.449 1.449±1 2.44950.5493 24802.062 2.062±1 3.06250.6373 Test Results:PASS.

Report No.: 18220WC00073001FCC ID: 2AOV6HP-092Page 1 of 59 Code:AB-RF-05-a FCC TEST REPORT Client Name: Shenzhen Minsuo Industrial Co.,Ltd. Address: 12th floor, Block B, Tengyao Building, No. 268 Gushu 2nd road,Xixiang Town, Bao'an, Shenzhen, Guangdong, China Product Name: Bluetooth Sleep Mask Date: Jun. 22, 2020 Shenzhen Anbotek Compliance Laboratory Limited Report No.: 18220WC00073001FCC ID: 2AOV6HP-092Page 2 of 59 Code:AB-RF-05-a Contents 1. General Information ............................................................................................................................................... 5 1.1. Client Information ....................................................................................................................................... 5 1.2. Description of Device (EUT) ..................................................................................................................... 5 1.3. Auxiliary Equipment Used During Test ................................................................................................... 6 1.4. Description of Test Modes ........................................................................................................................ 6 1.5. List of channels ........................................................................................................................................... 7 1.6. Description Of Test Setup ......................................................................................................................... 8 1.7. Test Equipment List .................................................................................................................................... 9 1.8. Measurement Uncertainty ....................................................................................................................... 10 1.9. Description of Test Facility ...................................................................................................................... 10 2. Summary of Test Results ................................................................................................................................... 11 3. Conducted Emission Test ................................................................................................................................... 12 3.1. Test Standard and Limit .......................................................................................................................... 12 3.2. Test Setup .................................................................................................................................................. 12 3.3. Test Procedure .......................................................................................................................................... 12 3.4. Test Data .................................................................................................................................................... 12 4. Radiation Spurious Emission and Band Edge ................................................................................................ 17 4.1. Test Standard and Limit .......................................................................................................................... 17 4.2. Test Setup .................................................................................................................................................. 17 4.3. Test Procedure .......................................................................................................................................... 18 4.4. Test Data .................................................................................................................................................... 19 5. Maximum Peak Output Power Test .................................................................................................................. 27 5.1. Test Standard and Limit .......................................................................................................................... 27 5.2. Test Setup .................................................................................................................................................. 27 5.3. Test Procedure .......................................................................................................................................... 27 5.4. Test Data .................................................................................................................................................... 27 6. 20DB Occupy Bandwidth Test ........................................................................................................................... 31 6.1. Test Standard ............................................................................................................................................ 31 6.2. Test Setup .................................................................................................................................................. 31 6.3. Test Procedure .......................................................................................................................................... 31 6.4. Test Data .................................................................................................................................................... 31 7. Carrier Frequency Separation Test ................................................................................................................... 35 7.1. Test Standard and Limit .......................................................................................................................... 35 7.2. Test Setup .................................................................................................................................................. 35 7.3. Test Procedure ......................................................................................................…

Text truncated - open the document above for the full version.

FCC ID: 2AOV6HP-092 Photo of Conducted Emission Measurement Photo of Radiation Emission Test
