8BitDo P30 2.4G Wireless Gamepad Instruction Manual PC Engine Mini，PC Engine CoreGrafx Mini & TurboGrafx 16 Mini 1. Plug the receiver to your chosen device, blue LED blinks once per cycle. 2. Press HOME button on the controller to pair. 3. Blue LEDs on both the controller and receiver become solid when connection is successful. Switch 1. Plug the receiver to your Switch, blue LED blinks 4 times per cycle. 2. Press HOME button on the controller to pair. 3. Blue LEDs on both the controller and receiver become solid when connection is successful. * Switch system needs to be 3.0.0 or above. Go to System Setting > Controller and Sensors > turn on Pro Controller Wired Communication Battery Status LED Indicator Low battery mode Red LED blinks Battery charging Red LED stays solid Battery charged LED turns off ·Built-in 180 mAh Li-on with 18 hours of play time. ·Rechargeable via USB cable with 1 – 2 hour charging time. ·Controller turns off in 1 minute with no connection and 15 minutes with connection but no use Retrieve a lost connection or connect to a new receiver 1. Turn on the controller then press and hold SELECT button for 3 seconds. Blue LED starts to rapidly blink. 2. Move the controller close to the receiver. Blue LED becomes solid when connection is successful. Support Please visit support.8bitdo.com for further information and additional support. FCC Statement 15.19 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 15.21 Note: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance. Such modifications could void the user’s authority to operate the equipment. 15.105(b) NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help

SHENZHEN 8BITDO TECH CO., LTD. Date: Feb 28, 2020 To: Federal Comm un ications Commission, Authorization & Evaluation Division, 7435 Oakland Mills Road, Columbia, MD 21046 To Whom It May Concern: The SHENZHEN 8BITDO TECH CO., LTD., the undersigned, hereby authorizes Mr. Wu Xuewen from Shenzhen BALUN Technology Co., Ltd., to act on the behalf of the SHENZHEN 8BITDO TECH CO., LTD. solely in matters relating to the application for an FCC equipment authorization for FCC ID:2AOWF-24GPCEi ncluding the signing of documents in connection with this Application. Necessary acts carried out by Shenzhen BALUN Technology Co., Ltd. in connection with the Application sh all have the same effect as acts of theSHENZHEN 8BITDO TECH CO., LTD. The SHENZHEN 8BITDO TECH CO., LTD. also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. Section 862. Yours Sincerely, Print name: Huijiang Tan Title: Mangaer SHENZHEN 8BITDO TECH CO., LTD.

SHENZHEN 8BITDO TECH CO., LTD. Date:Feb 28, 2020 To: Federal Communications Commission, Authorization & Evalua tion Division, 7435 Oakland Mills Road, Columbia, MD 21046 RE: SHENZHEN 8BITDO TECH CO., LTD. FCC ID:2AOWF-24GPCE FCC Certification Confidentiality Request Gentlemen: This letter isto comply with 47 CFR 0.457 and 0.459 pertaining to confidentiality material. SHENZHEN 8BITDO TECH CO., LTD. requests that the following documents regarding this submission for FCC ID:2AOWF-24GPCEb e kept Long-Term confidential: Exhibit TypeFile Name Block DiagramBlock Diagram.pdf SchematicsSchematics.pdf Operational DescriptionOperational Description.pdf Those documents contain detailed system and equipment description and related information about the product which SHENZHEN 8BITDO TECH CO., LTD. considers to be confidential proprietary, a custom design and, otherwise, not releasable to the general public. Since this design is a basis form which future technological products will evolve, SHENZHEN 8BITDO TECH CO., LTD. considers this information would be of benefit to its competitors, and that the disclosure of the information in these documents would give competitors an unfair advantage in the market. Thank you for your attention to this matter. Yours Sincerely, Print name: Huijiang Tan Title: Mangaer SHENZHEN 8BITDO TECH CO., LTD.

Annex No.: BL-SZ2020087-AW 1 / 4 EUT EXTERNAL PHOTOS FRONT VIEW OF EUT REAR VIEW OF EUT Annex No.: BL-SZ2020087-AW 2 / 4 LEFT SIDE VIEW OF EUT RIGHT SIDE OF EUT Annex No.: BL-SZ2020087-AW 3 / 4 TOP VIEW OF EUT BOTTOM VIEW OF EUT Annex No.: BL-SZ2020087-AW 4 / 4 Accessory- USB Cable Accessory-Dongle

Label: Label location:

Annex No.: BL-SZ2020087-AI 1 / 2 EUT INTERNAL PHOTOS EUT UNCOVER VIEW MAIN BOARD TOP VIEW PCB Antenna Annex No.: BL-SZ2020087-AI 2 / 2 MAIN BOARD REAR VIEW Battery Photo

RF Exposure Evaluation for FCC ID: 2AOWF‐24GPCE Refer user manual this device is a 8BitDo PCE 2.4g wireless gamepad, and this device was designed used in portable devices that the minimum distance between human’s body is 5mm. Based on the 47CFR 2.1093, this device belongs to portable device. The definition of the category as following: Portable Derives: CFR Title 47 §2.1093(b) (b) For purposes of this section, a portable device is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. FCC KDB 447498 D01 General RF Exposure Guidance v06 Limit Unless specifically required by the published RF exposure KDB procedures, standalone 1‐g head or body and 10‐g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source‐ based time‐averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune‐up tolerance, and the minimum test separation distance required for the exposure conditions. The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander. The 1‐g and 10‐g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune‐up tolerance, mW) / (min. test separation distance, mm)] · [√f(GHz) ] ≤ 3.0 for 1‐g SAR and ≤ 7.5 for 10‐g extremity SAR Where • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Test data 2.4G ISM Band (GFSK modulation) Mode Low Channel Middle Channel High Channel Peak Power (dBm) -6.72 -4.50 -6.44 Note: This report listed the worst case peak power value, please refer to RF test report for more details. Turn-up power Mode Range (dBm) 2.4G ISM Band (GFSK modulation) (-7.00) - (-4.00) FCC exclusion condition= [0.40 mW/5 mm] · [√2.441 GHz] = 0.12 ＜ 3.0 RF Exposure Evaluation Result: Pass Note: More power data, Please refer to the RF report.
