2AP5U-TB403Type Keyboard

Mousetrapper Type Designed in SwedenMousetrapper Type Fight the Pain Designed in Sweden www.mousetrapper.com www.mousetrapper.com Fight the Pain Mousetrapper TypeArt No. TB403Made in China Change button functions The button functions can easily be reprogrammed with MT Keys – which you can launch in your browser using the designated button (F1). Read more at mousetrapper.com/software Tastenfunktionen ändern Die Tastenfunktionen können mit MT Keys problemlos neu programmiert werden, was Sie über die vorgesehene Schaltfläche (F1) in Ihrem Browser ausführen können. Erfahren Sie mehr auf mousetrapper.com/software Modifier les fonctions des touches Les fonctions de bouton peuvent être facilement reprogrammées avec les MT Keys, que vous pouvez lancer dans votre navigateur à l’aide du bouton désigné (F1). Pour davantage d’informations, consultez mousetrapper.com/software Get started With a cable Connect the cable between your Type and computer. Ready! Wireless use 1. Move the switch under your TYPE to ON. 2. Press the CONNECT button under your TYPE. The LED will now start flashing blue. Open your computers Bluetooth menu and connect to the unit named MT TYPE. 3. To charge the unit, if needed, connect the cable to your computer or power source when the LED is flashing RED. Erste Schritte Mit Kabel Verbinden Sie Ihren Type und Ihren Computer mit dem Kabel. Fertig! Kabellose Nutzung 1. Stellen Sie den Schalter unter Ihrem TYPE auf EIN. 2. Drücken Sie die CONNECT-Taste unter Ihrem TYPE. Nun beginnt die LED-Leuchte blau zu blinken. Öffnen Sie das Bluetooth-Menü Ihres Computers und verbinden Sie ihn mit der Einheit mit der Bezeichnung MT TYPE. 3. Um die Einheit bei Bedarf aufzuladen, schließen Sie das Kabel an Ihren Computer oder die Stromversorgung an, wenn die LED-Anzeige ROT leuchtet. Démarrage Avec un câble Branchez le câble entre votre Type et votre ordinateur. C’est prêt! Utilisation sans fil 1. Mettez l’interrupteur sous votre TYPE sur ON. 2. Appuyez sur le bouton CONNECT sous votre TYPE. La LED se met alors à clignoter en bleu. Ouvrez le Bluetooth de votre ordinateur et connectez-vous à l’unité nommée MT TYPE. 3. Pour charger l’appareil, si nécessaire, connectez le câble à votre ordinateur ou à une source d’alimentation lorsque le voyant clignote en rouge. Customizable buttonsSolarpanelsLaunch MT Keys You can also scan the QR-code to follow the steps and learn even more about Type. Or visit mousetrapper.com/get-started-with-type Solarpanels FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications. However, there is no guarantee thatinterference will not occur in a particular installation. If this equipment does cause harmfulinterference to radio or television reception, which can be determined by turning the equipmentoff and on, the user is encouraged to try to correct the interference by one or more of thefollowing measures: • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 0cm between the radiator and your body.

Trapper Data AB Spjutvagen 6 JARFALLA Sweden Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-3-13 To whom it may concern: We, Trapper Data AB, hereby certify that the equipment for which authorization is sought (FCC ID: 2AP5U-TB403) is not “covered” equipment prohibited from receiving an equipment authorization pursuant to § 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, we are not identified on the Covered List (https://www.fcc.gov/supplychain/coveredlist) as an entity producing “covered” equipment. By signing this form, we confirm the above and that we are aware of the application requirements listed under § 2.911(b) and (d)(5) and (6). The information provided in this letter is based on the referenced rule parts of Title 47 of the CFR as well as KDB 986446 D01. Sincerely, Signature David Larsson Manager Trapper Data AB 62_[model] CoveredEqu_2.911(d)(5)(i) and (ii) - U, V03

Trapper Data AB Add: Spjutvagen 6 JARFALLA Sweden Date: 2024-3-13 FCC ID: 2AP5U-TB403 Dear Sir/Madam, We, Trapper Data AB Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Type Keyboard Model no.: TB403, TB405, TB406 Sincerely, Name/Title： David Larsson/Manager Company: Trapper Data AB Address: Spjutvagen 6 JARFALLA Sweden Phone: 0709927434 Fax: N/A E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date:<2024-3-13> Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AP5U-TB403 TB403 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name/Title： David Larsson/Manager Company: Trapper Data AB Address: Spjutvagen 6 JARFALLA Sweden Phone: 0709927434 Fax: N/A E-Mail: [email protected]

Trapper Data AB Spjutvagen 6 JARFALLA Sweden Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 2024-3-13 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AP5U-TB403 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. By signing this application form, we agree to Eurofins’ current valid General Terms and Conditions (AGB),Testing and Certification Regulations (PZO) which can be viewed on following website www.eurofins.de/ee or retrieved on request. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name/Title： David Larsson/Manager Company: Trapper Data AB Address: Spjutvagen 6 JARFALLA Sweden Phone: 0709927434 Fax: N/A E-Mail: [email protected]

FCC ID: 2AP5U-TB403 External Photos of the EUT FCC ID: 2AP5U-TB403 FCC ID: 2AP5U-TB403

Label and Location Size: L: 2.0cm*W: 1.0cm Label and Location FCC ID : 2AP5U-TB403

FCC ID: 2AP5U-TB403 Internal Photos of the EUT FCC ID: 2AP5U-TB403 BT PCB Antenna

RF Exposure evaluation FCC ID: 2AP5U-TB403 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK (Peak) Channel Channel 0 Channel 19 Channel 39 Target (dBm) 3.0 2.0 1.0 Tolerance ±(dB) 1.0 1.0 1.0 Page 2 of 2 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BLE 2.450 5 4.0 2.5119 0.7863<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06 .....................End of Report.........................

1. Antenna Description: Antenna type PCB antenna Model TB403 Frequency range 2400-2500MHz Manufacturer SHENZHEN ASTARGO TECHNOLOGY CO., LTD ANT Peak Gain 0.90 dBi 2. Antenna Photo: Length: 9.53mm Width: 6.28mm 3. Test Equipment & Conditions 3.1 Test instrument VSWR is tested using Agilent E5071B connected to a hand mechanism, and the status is free space. 3.2 Test environment and methods 4．Antenna Radiation Pattern 2400MHz 2450MHz 2500MHz

Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No. ..................... : FCC ID. ............................................ : CTA24022100901 2AP5U-TB403 Compiled by ( position+printed name+signature) .. : File administrators Zoey Cao Supervised by ( position+printed name+signature) .. : Project Engineer Amy Wen Approved by ( position+printed name+signature) .. : RF Manager Eric Wang Date of issue ..................................... : Feb. 28, 2024 Testing Laboratory Name .............. : Shenzhen CTA Testing Technology Co., Ltd. Address ............................................ : Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao‘an District, Shenzhen, China Applicant’s name ............................ : Trapper Data AB Address ............................................ : Spjutvagen 6 P.O. Box 17561, JARFALLA, 17561 Sweden Test specification ...........................: Standard ........................................... : FCC Part 15.247 Shenzhen CTA Testing Technology Co., Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen CTA Testing Technology Co., Ltd. is acknowledged as copyright owner and source of the material. Shenzhen CTA Testing Technology Co., Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Equipment description...................: Type Keyboard Trade Mark ....................................... : Mousetrapper Manufacturer .................................... : SHENZHEN ASTARGO TECHNOLOGY CO., LTD Model/Type reference....................... : TB403 Listed Models .................................. : TB405, TB406 Modulation ....................................... : GFSK Frequency .......................................... From 2402MHz to 2480MHz Ratings ............................................. : DC 5.0V From external circuit Result................................................ : PASS Report No.: CTA24022100901 Page 2 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn T E S T R E P O R T Equipment under Test : Type Keyboard Model /Type : TB403 Listed Models : TB405, TB406 Applicant : Trapper Data AB Address : Spjutvagen 6 P.O. Box 17561, JARFALLA, 17561 Sweden Manufacturer : SHENZHEN ASTARGO TECHNOLOGY CO., LTD Address : Room 522, Tianhui Building, No.26, Huaxing Road, Huanggekeng Community, Longcheng Street, Longgang District, Shenzhen, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: CTA24022100901 Page 3 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn Contents 1 T E S T S T A N D A R D S ................................................................. 4 2 S U M MA R Y ............................................................................ 5 2.1 General Remarks 5 2.2 Product Description* 5 2.3 Equipment Under Test 5 2.4 Short description of the Equipment under Test (EUT) 5 2.5 EUT operation mode 6 2.6 Block Diagram of Test Setup 6 2.7 Related Submittal(s) / Grant (s) 6 2.8 Modifications 6 3 T E S T E N V I R O N M E N T .............................................................. 7 3.1 Address of the test laboratory 7 3.2 Test Facility 7 3.3 Environmental conditions 7 3.4 Summary of measurement results 8 3.5 Statement of the measurement uncertainty 8 3.6 Equipments Used during the Test 9 4 T E S T C O N D I T I O N S A N D RE S U L T S ........................................... 11 4.1 AC Power Conducted Emission 11 4.2 Radiated Emissions and Band Edge 14 4.3 Maximum Peak Output Power 21 4.4 Power Spectral Density 22 4.5 6dB Bandwidth 24 4.6 Out-of-band Emissions 26 4.7 Antenna Requirement 30 5 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 31 6 P H O T O S O F T H E E U T ........................................................... 32 Report No.: CTA24022100901 Page 4 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 1 T E S T S T A N D A R D S The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V05r02: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: CTA24022100901 Page 5 of 35 Shenzhen CTA Testing Technology Co., Ltd. Room 106, Building 1, Yibaolai Industrial Park, Qiaotou Community, Fuhai Street, Bao’an District, Shenzhen, China Tel:+86-755 2322 5875 E-mail:[email protected] Web:http://www.cta-test.cn 2 S U M M A R Y 2.1 General Remarks Date of receipt of test sample : Feb. 21, 2024 Testing commenced on : Feb. 21, 2024 Testing c…

Text truncated - open the document above for the full version.

FCC ID: 2AP5U-TB403 Test Setup Photos of the EUT
