Technical Specifications
| # | Rule Parts | Frequency Range | Power Output |
|---|
| 4 | 15E | 5.75 GHz - 5.83 GHz | 55.70 mW |
Modular TypeSingle Modular ApprovalConfidentialityLong Term Grant NotesSingle Modular Approval. Output power listed is average conducted
This device supports 2*2 MIMO and supports 802.11n, 802.11ac and 802.11ax with a 20 MHz, 40 MHz and 80 MHz
bandwidth mode.
RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. The antenna(s) used for this transmitter must be
installed to provide a separation distance of at least 20 cm from all persons.
The maximum antenna gain is 6.7dBi. Only those antenna(s) tested with the device or similar antenna(s) with equal or
lesser gain may be used with this transmitter.
The host integrator installing this module into their product must ensure that the final composite product complies with the
FCC requirements by a technical assessment or evaluation to the FCC rules, including the transmitter operation and should
refer to guidance in KDB 996369.
