2AP9Y-XM1000SWireless Video Transmission System with intercom

XM Instruction Manual FORHOPE FORHOPE 1000S Table of Content Product Diagram-------------2 Receiver-------------------2 Transmitter----------------3 Installation Instruction--------1 Introduction----------- 6...10 Specification and Parameters--4 APP Introduction---------11...13 Warning-------------------- 14 Frequency chart---------------5 UI Camera Installation Instruction Receiver Transmitter The best reception angel Suggest installing receiver 2+ meters high from the ground Suggest installing transmitter 1.7+ meters high from the ground Ground Director F970 Battery Cameraman Monitor （transmitter and receiver face-to-face） Power Bank USB Cable FORHOPE -Grow your hope here!- FORHOPE -Grow your hope here!- 1 Foreword:Please refer to following installation diagram before using. Product Diagram 2 Receiver: 1：HDMI Output 1 2：HDMI Output 2 3：SDI Output 4：3.5mm Earphone Port 5：Power On/Off 6：USB Power Input/ Firmware Update 7：DC Power Input 1 2 3 6 7 5 4 HDMI OUT 1 HDMI OUT 2 SDI OUT OFF/O N DC IN 6-16V FORHOPE -Grow your hope here!- USB 5V\/1.5 FORHOPE TECHNOLOGY Forhope XM Series Wireless Video Transmission System Tell : 0755-27783980 Web：www.forhope.com.cn MADE IN CHINA Product Diagram 3 Transmitter: 1：HDMI Loop-out 2：HDMI Input 3：SDI Input 4：3.5mm Earphone Port 5：Power On/Off 6：USB Power Input/ Firmware Update 7：DC Power Input 1 2 3 6 7 5 4 HDMI OUT HDMI IN SDI IN OFF\O N DC IN 6-16V FORHOPE -Grow your hope here!- USB 5V\/1.5 FORHOPE TECHNOLOGY Forhope XM Series Wireless Video Transmission System Tell : 0755-27783980 Web：www.forhope.com.cn MADE IN CHINA Specifications and Parameters 4 TransmitterReceiver Interface Supply Voltage Range ＜7.5W Power Consumption ＜6.5W （L×W×H）：66*118*22mm， Don’t include antennas and battery plate Dimension Input/Output Video Format HDMI： 480P60,576P60,720P50/59.94/60, 1080I50/59.94/60, 1080P23.97/24/25/29.97/30/50/59.94/60； HDMI Type A SDI: 480P60,576P60,720P50/59.94/60, 1080I50/59.94/60, 1080P23.97/24/25/29.97/30/50/59.94/60； 1×BNC Frequency Band Transmission Power Receiving Sensitivity 20Hz～20KHz Intercom Frequency Response Range 0 ~ 40°C (working temperature); -20~60°C(storage temperature) Temperature Range 20Hz～20KHz SDI Input(BNC Female)；HDMI Input； HDMI Loop-out(output SDI or HDMI audio video)； 2 x Antenna Ports(PR-SMA Male) 3.5mm Aux Port(4 pole)；DC Input(2.0mm DC Female) Type-C Female SDI Output(BNC Female)；2 x HDMI Output； 2 x Antenna Ports(PR-SMA Male)； 3.5mm Aux Port(4 pole)； DC Input(2.0mm DC Female)； Type-C Female 5-17V (DC Input, F970 Battery, Type-C 5V,1.5A Input) （L×W×H）：66*118*22mm， Don’t include antennas and battery plate HDMI： 480P60,576P60,720P50/59.94/60, 1080I50/59.94/60, 1080P23.97/24/25/29.97/30/50/59.94/60； HDMI Type A SDI: 480P60,576P60,720P50/59.94/60, 1080I50/59.94/60, 1080P23.97/24/25/29.97/30/50/59.94/60； 1×BNC 802.11N(HT20) 5180-5250Mhz/5745~5825MHz 802.11N(HT20) 5180-5250Mhz/5745~5825MHz Maximum 17dBm / / -87dBm W:0.2kg， Don’t include antennas Net Weight W:0.2kg， Don’t include antennas Modulation Mode OFDM OFDM Latency Min0.08s Min0.08s 5-17V (DC Input, F970 Battery, Type-C 5V,1.5A Input) 0 ~ 40°C (working temperature); -20~60°C(storage temperature) 5 The startup screen is as above. When the device runs, it will display main menu. 1. Startup Screen 2. Main menu Main menu includes the following informations.Channel, Device type(TX/RX), Link status, Signal strength, Video format, intercom mode, Battery level, Temperature, Fan status. TX Link 720P60 30 C CH 03 FORHOPE 希望麦田 UI Introduction Device type Intercom mode Signal strength Battery level Link status Temperature Fan status Video format Channel 6 Press and hold the “ ”for 2s to enter into secondary menu. Press and hold the “ ”for 2s again to back to main menu. Press“ ”or “ ”to switch the options in secondary menu and press “ ”to confirm selection. 1）Channel switch: Press “ ”or“ ”to change channels. Press “ ”to confirm the channel. 2）Press and hold the “ ”on transmitter, the screen will display device name and password. Press and hold the “ ” on receiver, the screen will also display device name and password if it's connected to transmitter. 3. Secondary menu 1）Device(transmitter only): device type. Can switch between TX(transmitter) and RX(receiver) manually. Device TX RX UI Introduction 7 2）Souece(transmitter only): Switch the sources between HDMI and SDI on transmitter. SDI input is selected by default if both HDMI and SDI sources are connected.； 3）FAN Status: switch between ON and OFF to turn on or off the fan. Source SDI HDMI FAN status OFF ON UI Introduction 8 5）WPS: pairing. To pair transmitter and receiver. WPS Mode ON OFF 6）Priority: to choose high image quality prior or low latency prior； Priority Image Quality Latency 7）WIFI_SSID: showing device name and password. WIFI_SSID XWMT_5G_XXXXX PWD:12345678 UI Introduction 9 8）Version: showing the device's version number. Version V1.1.5 9）Web: manufacturer's web address Web www.forhope.com.cn 10）Telephone: after-sales Tel number. Telephone 0755-27783980 UI Introduction APP Operation Instruction 10 1. APP installation 2. Connect smart devices to transmitter Device name：XWMT_5G_xxxx Password:12345678 Search "希望麦田" at Apple APP store or "ForHope" at Google Play Store to download and install APP. After the transmitter is powered on, go to Settings-Wireless & networks on smart phone/tablet, select the transmitter's name and input the password to connect the devices. Please find transmitter's name and initial password as below. Then go to APP home page and click Video to monitor. （ No need to input password again if it was saved on smart phone/tablet） 1 1 3. APP Operation b.Click VIDEO on home page to enter into monitoring mode. Click DISPLAY at the bottom of screen. It will show SCREEN CAPTURE, RECORD(only available for Android at present), MATERIAL, CONFIGURATION. Press and hold the screen to show up the professional monitoring menu. P.S. Only monochrome, False Color and Center Mark are available at present. Other features a…
