2APINGC481501Toy RC Monster Spinning Car

The artwork and design of this manual are protected by US copyright law and may not be reproduced, distributed, displaced, published or used for any purpose without prior written permission. Altering, removing or reproducing any of the trademark or copyright notices on this package is not permitted. © 2019 MerchSource, LLC. Irvine, CA 92618. All rights reserved. Model Number: 1012639 RC THUNDER TUMBLER®/TWIRLING TUMBLER™ OPERATING INSTRUCTIONS Locate the battery compartment on the back of each item. Swivel latches on bottom of car to release battery pack and insert batteries. Insert 4 “AA” 1.5V alkaline batteries (not included) for car and one 9V battery (not included) for remote control. iiiiii Switch both car and remote buttons to “ON” position. For best result use the car on hard surfaces such as wood or tile. iiiiii Carefully remove items from package. BATTERY WARNING: • Do not mix old and new batteries. • Do not mix alkaline, standard (carbon-zinc), or rechargeable batteries. • Insert batteries using the correct polarity. Do not short-circuit the supply terminal. • Remove batteries when not in use. Recycle or dispose of exhausted batteries according to federal, state, and local laws. Do not dispose of batteries in a fire - they may leak or explode. • Only use manufacture specified battery(ies), charger(s) and/or adapter, if applicable, specified by the manufacturer. • Always use, replace, and recharge (if applicable) batteries under adult supervision. • Keep these instructions for future reference. • Do not operate during thunderstorms or rain. • Avoid water, sand and snow when operating car. • Do not submerge car or controller in water. • Never operate your car on the street or highway. • Never operate your car in a confined or crowded area, and do not use people or animals as obstacles. • Do not run your car into furniture, objects or hard surface, as this will cause damage to both the objects and your car. • Keep fingers, hair and loose clothing away from the tires. gears and motor while the car is switched to “ON”. • Do not leave car or remote control near source of heat or under direct sunlight for long periods of time. • Do not leave car or remote control outside overnight. Dampness is harmful to interior components. • Remove all batteries when not in use to avoid accidental operation • Adult supervision is recommended when operating this car. Reverse Forward Spinning Action Action Button Hold Action Button While Spinning This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: KEEP THIS INSTRUCTION MANUAL AS IT CONTAINS IMPORTANT INFORMATION FOR FUTURE REFERENCE. Due to continuous product improvements, the pictures on this manual may dier slightly from the actual product. Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. SAFETY PRECAUTIONS 1-800-374-2744 FOR TECHNICAL SUPPORT, PLEASE CALL 6+ Battery Cover On/O Switch On/O Switch Printed in China

Page 1 of 2 EXTERNAL PHOTOS Page 2 of 2

SIZE: 35mm*20mm FCC ID: 2APINGC481501 FCC ID: 2APINGC481501

Page 1 of 2 INTERNAL PHOTOS Page 2 of 2

1 INTERTEK TESTING SERVICES Analysis Report The equipment under test (EUT) is a transmitter for a Toy RC Monster Spinning Car operating at 49.860 MHz which is controlled by a crystal. The EUT is powered by one 9.0V 6F22 battery. For more detail information pls. refer to the user manual. Antenna Type: dedicated antenna Antenna Gain: 0dBi Modulation Type: Pulse modulation The nominal conducted output power specified: -47.0dBm (+/- 3dB) The nominal radiated output power (e.r.p) specified: -49.15dBm (+/- 3dB) According to the KDB 447498: The worst-case peak radiated emission for the EUT is 47.8dBuV/m at 3m in the frequency 49.86MHz The EIRP = [(FS*D) ^2 / 30] mW= -47.43dBm The ERP = EIRP – 2.15 = -49.58dBm which is within the production variation. The maximun conducted output power specified is -44.0dBm = 0.00004mW The source- based time-averaging conducted output power = 0.00004* Duty Cycle mW < 0.00004mW (Duty Cycle<100%) Since the source-based time-averaging conducted output power is well below the SAR low threshold level of 1mW, so the EUT is considered to comply with SAR requirement without testing. Transmitter Duty Cycle Calculation The duration of one cycle = 68.406ms Effective period of the cycle = = 1.449ms x 4 + 435μs x 64 =33.636ms DC =33.636ms / 68.406ms =0.4917 or 49.17% FCC ID: 2APINGC481501

Shantou Heshenglong Plastic Co., Ltd TEST REPORT SCOPE OF WORK RF TESTING–1012639 REPORT NUMBER GZHH00417354-001 ISSUE DATE JANUARY 6, 2022 PAGES 166 DOCUMENT CONTROL NUMBER FCC ID_b-235 © 2017 INTERTEK Intertek Report No.: GZHH00417354-001 • The test results reported in this test report shall refer only to the sample actually tested and shall not refer or be deemed to refer to bulk from which such a sample may be said to have been obtained. • This report is for the exclusive use of Intertek's Client and is provided pursuant to the agreement between Intertek and its Client. Intertek's responsibility and liability are limited to the terms and conditions of the agreement. Intertek assumes no liability to any party, other than to the Client in accordance with the agreement, for any loss, expense or damage occasioned by the use of this report. Only the Client is authorized to copy or distribute this report. Any use of the Intertek name or one of its marks for the sale or advertisement of the tested material, product or service must first be approved in writing by Intertek. The observations and test results referenced from this report are relevant only to the sample tested. This report by itself does not imply that the material, product, or service is or has ever been under an Intertek certification program. • For Terms And Conditions of the services, it can be provided upon request. • The evaluation data of the report will be kept for 3 years from the date of issuance. Intertek Testing Services Shenzhen Ltd. Longhua Branch 101, 201, Building B, No. 308 Wuhe Avenue, Zhangkengjing Community GuanHu Subdistrict, LongHua District, Shenzhen, People’s Republic of China Tel: (86 755) 8601 6288 Fax: (86 755) 8601 6751 Version: 01 November 2017 Page: 1 of 16 FCC ID_b-235 Test Report Shantou Heshenglong Plastic Co., Ltd Application For Certification FCC ID: 2APINGC481501 Product Name: Toy RC Monster Spinning Car Model: 1012639 Additional Model: HSL2021 Transmitter Report No.: GZHH00417354-001 We hereby certify that the sample of the above item is considered to comply with the requirements of FCC Part 15, Subpart C for Intentional Radiator, mention 47 CFR [10-1-20] Prepared and Checked by: Approved by: Sign on file Maura Wang Engineer Peter Kang Technical Supervisor Date: January 6, 2022 Intertek Report No.: GZHH00417354-001 Version: 01 November 2017 Page: 2 of 16 FCC ID_b-235 Test Report GENERAL INFORMATION Shantou Heshenglong Plastic Co., Ltd MODEL: 1012639 FCC ID: 2APINGC481501 Grantee: Shantou Heshenglong Plastic Co., Ltd Grantee Address: North Side Of Wenguan Rd.,South Side Of Dezheng Rd.,Chenghua Subdistrict, Chenghai District,Shantou, Guangdong, China Contact Person: Susan Chen Tel: (86)13417150011 Manufacturer: Shantou Heshenglong Plastic Co., Ltd Manufacturer Address: North Side Of Wenguan Rd.,South Side Of Dezheng Rd.,Chenghua Subdistrict, Chenghai District,Shantou, Guangdong, China Model: 1012639 Type of EUT: Transmitter Description of EUT: Toy RC Monster Spinning Car Serial Number: N/A FCC ID : 2APINGC481501 Date of Sample Submitted: July 22, 2021 Date of Test: August 25, 2021 Report No.: GZHH00417354-001 Report Date: January 6, 2022 Environmental Conidtions: Temperature: +10 to 40°C Humidity: 10 to 90% Intertek Report No.: GZHH00417354-001 Version: 01 November 2017 Page: 3 of 16 FCC ID_b-235 Test Report SUMMARY OF TEST RESULT Shantou Heshenglong Plastic Co., Ltd MODEL: 1012639 FCC ID: 2APINGC481501 TEST SPECIFICATION REFERENCE RESULTS Maximum Peak Output Power 15.247(b), (c) / RSS-210 A8.4 N/A Hopping Channel Carrier Frequencies Separation (for 2.4GHz Digital) 15.247(e) / RSS-210 A8.1 N/A 20dB Bandwidth of the Hopping Channel 15.247(a) / RSS-210 A8.1 N/A Number of Hopping Frequencies 15.247(e) / RSS-210 A8.1 N/A Average Time of Occupancy of Hopping Frequency 15.247(e) / RSS-210 A8.1 N/A Anteann Conducted Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A Radiated Spurious Emissions 15.247(d) / RSS-210 A8.5 N/A RF Exposure Compliance 15.247(i) / RSS-Gen 5.5 N/A Transmitter Power Line Conducted Emissions 15.207 / RSS-Gen 7.2.2 N/A Transmitter Field Strength (for 27MHz) 15.227 / RSS-310 3.8 N/A Transmitter Field Strength (for 40MHz) 15.229 / RSS-210 A2.7 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for Remote Control) 15.231(a) / RSS-210 A1.1.1 N/A Transmitter Field Strength, Bandwidth and Timing Requirement (for 433MHz) 15.231(e) / RSS-210 A1.1.5 N/A Transmitter Field Strength and Bandwidth Requirement(for 88-108MHz) 15.239 / RSS-210 A2.8 N/A Transmitter Field Strength and Bandwidth Requirement(for 902- 928MHz or 2.4GHz) 15.249 / RSS-210 A2.9 N/A Transmitter Field Strength and Bandwidth Requirement (for 49MHz) 15.235 / RSS-310 3.9 Pass Receiver / Digital Device Radiated Eissions 15.109 / ICES-003 N/A Digital Device Conducted Emissions 15.107 / ICES-003 N/A Note: 1. The EUT uses an dedicated antenna, in accordance to section 15.203, is considered sufficient to comply with the provisions of this section. 2. Pursuant to FCC part 15 Section 15.215(c), the 20 dB bandwidth of the emission was contained within the frequency band designated (mentioned as above) which the EUT operated. The effects, if any, from frequency sweeping, frequency hopping, other modulation techniques and frequency stability over excepted variations in temperature and supply voltage were considered. Intertek Report No.: GZHH00417354-001 Version: 01 November 2017 Page: 4 of 16 FCC ID_b-235 Test Report Table of Contents 1.0 General Description ..................................................................................................................................... 5 1.1 Product Description .................................................................................................................................... 5 1.2 Related Submittal(s) Grants ...................................................................................................................... 5 1.3 Test Methodology ......…

Text truncated - open the document above for the full version.

Page 1 of 1 RADIATED PHOTOS Up to 1GHz (EUT was placed in the centre of the turntable)
