Fastenal.com 2001 Theurer Blvd Winona, MN 55987 Fastenal User’s Manual for the RN2903A Module 1 Introduction The Fastenal RN2903A module is based on the Microchip RN2903. Because Fastenal chose an antenna that exceeded the gain specified in FCC T9JRN2903 grant, it was necessary to create a new single modular certification. This user manual references the attached Microchip RN2903 datasheet for all technical information except for antenna information and regulatory approval. We, Fastenal Company, 2001 Theurer Blvd, Winona, MN 55987, declare under our sole responsibility that the product [RN2903A] complies with Part 15 Subpart B of FCC CFR47 Rules. 2 Approved Antenna Modular certification of the RN2903A module, is performed with a PCB trace antenna with a gain of 5.1 dBi. The antenna technical description and radiation pattern can be observed in the attached ANTX100P001BWPEN3 datasheet. 3 Regulatory Approval This section outlines the regulatory information for the RN2903A module for the Unites States and Canada. 3.1 United States The RN2903A module has received Federal Communications Commission (FCC) CFR47 Telecommunications, Part 15 Subpart C “Intentional Radiators” modular approval in accordance with Section 15.212 Modular Transmitter approval. Modular approval allows the end user to integrate the RN2903A subsequent and separate FCC approvals for intentional radiation, provided no changes or modifications are made to the module circuitry. Changes or modifications could void the user's authority to operate the equipment. The end user must comply with all the instructions provided by the Grantee, which indicate installation and/or operating conditions necessary for compliance. The finished product is required to comply with all applicable FCC equipment authorizations regulations, requirements and equipment functions not associated with the transmitter module portion. For example, compliance must be demonstrated to regulations for other transmitter components within the host product; to requirements for unintentional radiators (Part 15 Subpart B “Unintentional Radiators”), such as digital devices, computer peripherals, radio receivers, etc.; and to additional authorization requirements for the non-transmitter functions on the transmitter module (i.e., Verification, or Declaration of Conformity) (e.g., transmitter modules may also contain digital logic functions) as appropriate. 3.1.1 Labeling and User Information Requirements The RN2903A module has been labeled with its own FCC ID number, and if the FCC ID is not visible when the module is installed inside another device, then the outside of the finished product into which the module is installed must also display a label referring to the enclosed module. This exterior label can use wording as follows: Contains FCC ID: 2APK7RN2903A This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. A user's manual for the finished product should include the following statement: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Additional information on labeling and user information requirements for Part 15 devices can be found in KDB Publication 784748 available at the FCC Office of Engineering and Technology (OET) Laboratory Division Knowledge Database (KDB) https://apps.fcc.gov/oetcf/kdb/index.cfm. 3.1.2 RF Exposure All transmitters regulated by FCC must comply with RF exposure requirements. KDB 447498 General RF Exposure Guidance provides guidance in determining whether proposed or existing transmitting facilities, operations or devices comply with limits for human exposure to Radio Frequency (RF) fields adopted by the Federal Communications Commission (FCC). From the RN2903A FCC Grant: Output power listed is conducted. This grant is valid only when the module is used by OEM integrators and must be installed by the OEM or OEM integrators. This transmitter is restricted for use with the specific antenna(s) tested in this application for Certification and must not be co-located or operated in conjunction with any other antenna or transmitters within a host device, except in accordance with FCC multi-transmitter product procedures. 3.1.3 Approved External Antenna Types To maintain modular approval in the United States, only the antenna types that have been tested shall be used. It is permissible to use different antenna manufacturer provided the same antenna type and antenna gain (equal to or less than) is used. Testing of the RN2903A module was performed with the antenna type listed in Section 2. 3.2 Canada The RN2903A module has been certified for use in Canada under Industry Canada (IC) Radio Standards Specification (RSS) RSS-247 and RSS-Gen. Modular approval permits the installation of a module in a host device without the need to recertify the device. 3.2.1 Labeling and User Information Requirements Labeling Requirements for the Host Device (from Section 4.3, RSS-Gen, Issue 5, February 2021, Amendment 2): Any product for which Modular Approval (MA) or Limited Modular Approval (LMA) is being sought shall meet the labelling requirements in section 4.2. The Host Marketing Name (HMN) shall be displayed according to the e-labelling requ…

Text truncated - open the document above for the full version.

Engineering Test Report No. 2502504-01 Page 8 of 68 17. Photographs of EUT Engineering Test Report No. 2502504-01 Page 13 of 68 Test Setup for RF Conducted Emissions (AC Mains) Test Setup for RF Conducted Emissions (AC Mains) Engineering Test Report No. 2502504-01 Page 39 of 68 Test Setup for Spurious Radiated Emissions, 30MHz – 1GHz – Antenna Polarization Horizontal Test Setup for Spurious Radiated Emissions, 30MHz – 1GHz – Antenna Polarization Vertical Engineering Test Report No. 2502504-01 Page 40 of 68 Test Setup for Spurious Radiated Emissions, Above 1GHz – Antenna Polarization Horizontal Test Setup for Spurious Radiated Emissions, Above 1GHz – Antenna Polarization Vertical

Engineering Test Report No. 2502504-01 Page 67 of 68

Engineering Test Report No. 2502504-01 Page 68 of 68

Engineering Test Report No. 2502504-01 Page 66 of 68

Engineering Test Report No. 2502504-01 Page 65 of 68

Engineering Test Report No. 2502504-01 Page 64 of 68

Engineering Test Report No. 2502504-01 Report Date December 8, 2025 Manufacturer Name Fastenal Company Manufacturer Address 2001 Theurer Blvd Winona, MN 55987 Product Name Model No. LoRa Module RN2903A Date Received December 2, 2025 Test Dates December 2, 2025 – December 4, 2025 Specifications FCC "Code of Federal Regulations" Title 47 Part 15, Subpart C, Section 15.247 Innovation, Science, and Economic Development Canada, RSS-GEN Innovation, Science, and Economic Development Canada, RSS-247 Test Facility Elite Electronic Engineering, Inc. 1516 Centre Circle, Downers Grove, IL 60515 FCC Reg. Number: 269750 IC Reg. Number: 2987A CAB Identifier: US0107 Signature Tested by Edwin Casas Signature Approved by Raymond J. Klouda, Re gistered Professional Engineer of Illinois – 44894 PO Number 01N9961-111425-1419 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes all of the tests requested by you and the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Elite Electronic Engineering Incorporated certifies that the information contained in this report was obtained under conditions which meet or exceed those specified in the FCC "Code of Federal Regulations" Title 47 Part 15, Subpart C, Section 15.247 and Innovation, Science, and Economic Development Canada, RSS-247 test specifications. The data presented in this test report pertains to the EUT on the test dates specified. Any electrical or mechanical modifications made to the EUT subsequent to the specified test date will serve to invalidate the data and void this certification. This report must not be used to claim product certification, approval, or endorsement by A2LA, NIST, or any agency of the Federal Government. Engineering Test Report No. 2502504-01 This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Page 2 of 68 Table of Contents 1. Report Revision History ........................................................................................................................... 3 2. Introduction .............................................................................................................................................. 4 2.1. Scope of Tests ......................................................................................................................................... 4 2.2. Purpose .................................................................................................................................................... 4 2.3. Identification of the EUT ........................................................................................................................... 4 3. Power Input .............................................................................................................................................. 4 4. Grounding ................................................................................................................................................ 4 5. Support Equipment .................................................................................................................................. 4 6. Interconnect Leads .................................................................................................................................. 5 7. Modifications Made to the EUT ................................................................................................................ 5 8. Modes of Operation ................................................................................................................................. 5 9. Test Specifications ................................................................................................................................... 5 10. Test Plan .................................................................................................................................................. 5 11. Deviation, Additions to, or Exclusions from Test Specifications .............................................................. 5 12. Laboratory Conditions .............................................................................................................................. 6 13. Summary .................................................................................................................................................. 6 14. Sample Calculations ................................................................................................................................ 6 15. Statement of Conformity .......................................................................................................................... 7 16. Certification .............................................................................................................................................. 7 17. Photographs of EUT ......................................................…

Text truncated - open the document above for the full version.

DATA SHEET WIRELESS COMPONENTS PCB type antenna ANTX100P001BWPEN3 850/900/1800/1900/2100 MHZ Product S pecification – June 10, 2014 V.0 www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 2 11 Product specification PCB Type Antenna FEATURES & BENEFITS  The smallest PCB antenna in the market  Miniature design allows users to save required space  Double-side adhesive tape makes it easy to instal in device  Ranges of types of connector and cable provide a flexible design options  Halogen free and RoHS compliant APPLICATIONS  Tablet / Desktop PC  Internet TV / STB / Game console / DS  WiFi network devices (IEEE 802.11b/g/n)  Bluetooth / ZigBee devices  Car Infotainment  Smart meter  Smart home  POS terminal  Wireless Industrial Control ORDERING INFORMATION - GLOBAL PART NUMBER, PHYCOMP CTC & 12NC All part numbers are identified by the series, packing type, material, size, antenna type, working frequency and packing quantity. Y Y A A G G E E O O B B R R A A N N D D o o r r d d e e r r i i n n g g c c o o d d e e GLOBAL PART NUMBER ( PREFERRED ) ANT X100 P 001 B WPEN 3 (1) (2) (3) (4) (5) (6) (7) ( 1 ) FAMILY ANT = Antenna products ( 2 ) CONNECTOR & CABLE LENGTH (MM) X = I-PEX 100 = 100mm ( 3 ) ANTENNA TYPE P=PCB ( 4 ) SERIAL NUMBER 001 = SERIAL NUMBER 001 ( 5 ) PACKAGE TYPE B = Bulk ( 6 ) WORKING FREQUENCY WPEN = 850/900/1800/1900/2100 MHz ( 7 ) CABLE TYPE 3 = 1.13mm diameter Mini-Coaxial Cable www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 3 11 Product specification PCB Type Antenna SPECIFICATIONS DESCRIPTION VALUE Working Frequency 850/900/1800/1900/2100MHz VSWR 3.0:1 max Peak Gain 850MHz /4.2dbi(Typ) 900MHz/5.1dbi(Typ) 1800MHz /3.9dbi(Typ) 1900MHz /5.0dbi(Typ) 2110MHz /4.5dbi(Typ) Polarization Linear Radiation Pattern Omni-directional Impedance 50 Ω Nominal Operating Temperature –40 °C to 85 °C Maximum Power 1 W PCB Dimension 50mm x 20mm x 0.95mm Radio Connector I-PEX (20278-112R-13) Cable Diameter / Length / Color 1.13mm / 100mm / Black Mounting Adhesive Tape (HF-DS) Table 1 O O U U T T L L I I N N E E S S Fig. 1 Antenna outlines DIMENSIONS DIMENSION VALUE L (mm) 100 ±3.00 W (mm) 50 ± 0.30 H (mm) 20 ± 0.30 T (mm) 0.95 ± 0.15 A (mm) 2.30 Max B (mm) 1.80 ± 1.00 Table 2 Mechanical Dimension www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 4 11 Product specification PCB Type Antenna Connect to r ad io car d a c b Edge of device Antenna PC B Fig. 2 Application Instruction APPLICATION INSTRUCTION Antenna element should be placed at the edge of device, has minimum clearance from metalic object: A: 5 mm Min B: 5 mm Min C: 10 mm Min www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 5 11 Product specification PCB Type Antenna Fig. 3 Return loss & VSWR Measurement RETURN LOSS & VSWR Frequency (MHz) Frequency (MHz) Return Loss (dB) VSWR www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 6 11 Product specification PCB Type Antenna Z Y X Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 849 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 849 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 849 Fig. 4 Antenna radiation patterns at 850 MHz Device Setup & Coordinates ANTENNA RADIATION PATTERNS ANTENNA GAIN & EFFICIENCY FREQUENCY (MHz) AVERAGE GAIN (dBi) EFFICIENCY (%) PEAK GAIN (dBi) 850 -2.2 60 4.2 900 -1.7 68 5.1 1800 -2.6 55 3.9 1900 -1.2 76 5.0 2100 -2.1 62 4.5 X-Y Plane X-Z Plane Y-Z Plane Table 3 Scale: 5 dBi / div Max : 5 dBi Min : -25 dBi www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 7 11 Product specification PCB Type Antenna Device Setup & Coordinates X-Y Plane X-Z Plane Y-Z Plane Z Y X Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 900 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 900 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 900 Fig. 5 Antenna radiation patterns at 900 MHz ANTENNA RADIATION PATTERNS ANTENNA GAIN & EFFICIENCY FREQUENCY (MHz) AVERAGE GAIN (dBi) EFFICIENCY (%) PEAK GAIN (dBi) 850 -2.2 60 4.2 900 -1.7 68 5.1 1800 -2.6 55 3.9 1900 -1.2 76 5.0 2100 -2.1 62 4.5 Table 4 Scale: 5 dBi / div Max : 5 dBi Min : -25 dBi www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 8 11 Product specification PCB Type Antenna Z Y X Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1805 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1805 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1805 Fig. 5 Antenna radiation patterns at 1800 MHz ANTENNA RADIATION PATTERNS ANTENNA GAIN & EFFICIENCY FREQUENCY (MHz) AVERAGE GAIN (dBi) EFFICIENCY (%) PEAK GAIN (dBi) 850 -2.2 60 4.2 900 -1.7 68 5.1 1800 -2.6 55 3.9 1900 -1.2 76 5.0 2100 -2.1 62 4.5 Table 4 Scale: 5 dBi / div Max : 5 dBi Min : -25 dBi www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 9 11 Product specification PCB Type Antenna Z Y X Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1910 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1910 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 1910 Fig. 5 Antenna radiation patterns at 1900 MHz ANTENNA RADIATION PATTERNS ANTENNA GAIN & EFFICIENCY FREQUENCY (MHz) AVERAGE GAIN (dBi) EFFICIENCY (%) PEAK GAIN (dBi) 850 -2.2 60 4.2 900 -1.7 68 5.1 1800 -2.6 55 3.9 1900 -1.2 76 5.0 2100 -2.1 62 4.5 Table 4 Scale: 5 dBi / div Max : 5 dBi Min : -25 dBi www.ya geo.co m Jun. 10, 2014 V0 Wireless Components 10 11 Product specification PCB Type Antenna Z Y X Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 2110 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 2110 Scal e: 5/di v Mi n: -25 Max : 5 0 180 30 210 60 240 90270 120 300 150 330 2110 Fig. 5 Antenna radiation patterns at 2100 MHz ANTENNA RADIATION PATTERNS ANTENNA GAIN & EFFICIENCY FREQUENCY (MHz) AVERAGE GAIN (dBi) EFFICIENCY (%) PEAK GAIN (dBi) 850 -2.…

Text truncated - open the document above for the full version.

Engineering Test Report No. 2502504-02 Report Date December 5, 2025 Manufacturer Name Fastenal Company Manufacturer Address 2001 Theurer Blvd Winona, MN 55987 Product Name Brand/Model No. LoRa Module RN2903A Date Received December 2, 2025 Assessment Date December 5, 2025 Specifications FCC 47 CFR Part 2.1093 KDB, 447498 D01 OET Bulletin 65:1997 RSS-102 Issue 6 Test Facility Elite Electronic Engineering, Inc. 1516 Centre Circle, Downers Grove, IL 60515 Signature Tested by Edwin Casas Signature Approved by Raymond J. Klouda, Re gistered Professional Engineer of Illinois – 44894 PO Number 01N9961-111425-1419 This report is for your exclusive use. Any copying or replication of this report to or for any other person or entity, or use of our name or trademark, is permitted only with our prior written permission. This report sets forth our findings solely with respect to the test samples identified herein. The results set forth in this report are not indicative or representative of the quality or characteristics of the lot from which a test sample was taken or any similar or identical product unless specifically and expressly noted. Our report includes the results thereof based upon the information that you provided to us. You have 60 days from date of issuance of this report to notify us of any material error or omission caused by our negligence, provided, however, that such notice shall be in writing and shall specifically address the issue you wish to raise. A failure to raise such issue within the prescribed time shall constitute your unqualified acceptance of the completeness of this report, the tests conducted and the correctness of the report contents. This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Engineering Test Report No. 2502504-02 This report shall not be reproduced, except in full, without the written approval of Elite Electronic Engineering Inc. Page 2 of 22 Table of Contents 1. Report Revision History ........................................................................................................................... 3 2. Introduction .............................................................................................................................................. 4 3. Subject of Investigation ............................................................................................................................ 4 4. Standards and Requirements .................................................................................................................. 4 5. Sample Calculations ................................................................................................................................ 4 6. Photographs of EUT ................................................................................................................................ 6 7. Limits and Requirements ......................................................................................................................... 7 7.1. Requirements mandated by the FCC ...................................................................................................... 7 7.2. Requirements mandated by Innovation, Science and Economic Development Canada ........................ 9 8. Assessment Results .............................................................................................................................. 10 8.1. RF Exposure Evaluation Relevant to the Requirements of the FCC ..................................................... 10 8.2. RF Exposure Evaluation Relevant to the Requirements of the ISED .................................................... 11 9. Statement of Compliance ....................................................................................................................... 11 10. Certification ............................................................................................................................................ 11 11. Scope of Accreditation ........................................................................................................................... 12 Engineering Test Report No. 2502504-02 Page 3 of 22 1. Report Revision History Revision Date Description – 9 DEC 2025 Initial Release of Engineering Test Report No. ETR 2502504-02 Engineering Test Report No. 2502504-02 Page 4 of 22 2. Introduction The FCC and Innovation, Science and Economic Development Canada publish standards regarding the evaluation of the RF Exposure hazard of radio communications devices. An evaluation has been performed on the Fastenal Company LoRa Module, Model No. RN2903A pursuant to the relevant requirements. 3. Subject of Investigation This document presents the demonstration of RF Exposure compliance on a LoRa Module, (hereinafter referred to as the Equipment under Test (EUT)). The EUT was identified as follows: EUT Identification Description LoRa Module Model/Part No. RN2903A S/N N/A Radio Access Technology LoRa Bands of Operation 902MHz – 928MHz EIRP 20.5dBm Conducted Output Power 18.95dBm 4. Standards and Requirements The tests were performed to selected portions of, and in accordance with the following specifications. - 47 CFR Parts 1.1310, 2.1091 and 2.1093 Code of Federal Regulations, Title 47, Telecommunications - KDB 447498 D01 – “RF Exposure Procedures and Equipment Authorization Polices for Mobile and Portable Devices, General RF Exposure Guidance v06” - OET Bulletin 65 Edition 97-01:1997 – “Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields” - ANSI/IEEE C95.1:1992 – "Safety Levels with Respect to Human Exposure to Radio Frequency Electromagnetic Fields, 3 kHz to 300 GHz," - RSS-102, Issue 6 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) 5. Sample Calculations The far field power density can be calculated using the following formula: 푆= 푃퐺 4 휋푅 ଶ (1) w…

Text truncated - open the document above for the full version.

3-12-2026 Sylvia M. Buxbaum Authorized Representative

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 ATTENTION: Federal Communication Commission Equipment Authorization To whom it may concern, We would like to submit for Single Modular Certification to the FCC: 2APK7RN2903A. Please find in the following application all related documentation to support this Single Modular Certification. We would appreciate your prompt attention to the submittal. Applicant Company name: Fastenal Company Contact Name: John Burrell Address: 2001 Theurer Blvd, Winona, MN 55987 Telephone No: 513-644-6429 Email: [email protected] FCC ID Number: 2APK7-RN2903A Signature: Date: 01/23/2026 Signed by (printed name): John Burrell

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 01/09/2026 Elite Electronic Engineering, Inc. 1516 Centre Circle Downers Grove, IL 60515 To Whom It May Concern: Elite Electronic Engineering, Inc. is authorized to act on our behalf, until otherwise notified, for applications to Elite Electronic Engineering, Inc. We certify that we are not subject to denial of federal benefits, that includes FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, U.S.C. 862. Further, no party, as defined in 47 CFR 1.2002 (b) to the application is subject to denial of federal benefits, that includes FCC benefits. Thank you. Regards, Signature: Date: 01/23/2026 Signed by (printed name): John Burrell

Date: 1/9/2026 Subject: Confidentiality Request for: 2APK7RN2903A Pursuant to FCC 47 CRF 0.457(d) and 0.459 and IC RSP-100, Section 10, the applicant requests that a part of the subject FCC application be held confidential. Type of Confidentiality Requested Exhibit Short Term Permanent Block Diagrams Short Term External Photos Short Term Permanent Internal Photos Short Term Permanent Operation Description/Theory of Operation Short Term Permanent Parts List & Placement/BOM Short Term Permanent Tune-Up Procedure Short Term Permanent Schematics Short Term Test Setup Photos Short Term Permanent* User’s Manual The Fastenal Company has spent substantial effort in developing this product and it is one of the first of its kind in industry. Having the subject information easily available to "competition" would negate the advantage they have achieved by developing this product. Not protecting the details of the design will result in financial hardship. Permanent Confidentiality: The applicant requests the exhibits listed above as permanently confidential be permanently withheld from public review due to materials that contain trade secrets and proprietary information not customarily released to the public. NOTE for Industry Canada Applications: The applicant understands that until such time that IC distinguishes between Short Term and Permanent Confidentiality, either type of marked exhibit above will simply be marked Confidential when submitted to IC. Sincerely, By: __________________________ John Burrell____________ (Signature/Title) (Print name)

Date: 01/26/2026 Federal Communications Commission Equipment Authorization Division 7435 Oakland Mills Road Columbia, MD 21046 Subject: Modular Approval Checklist for FCC ID: 2APK7RN2903A Dear FCC Examiner, In accordance with FCC Public Notice DA 00-1407, we confirm that the transmitter module (FCC ID: 2APK7RN2903A) meets the following eight modular approval requirements: ☑ RF shielding is provided. ☑ Data/modulation inputs are buffered. ☑ The module has its own regulated power supply. ☑ Antenna requirements are met (permanent attachment or unique connector, compliant with §15.203/§15.204). ☑ Module was tested stand-alone, independent of host devices. ☑ FCC ID labeling is provided, or host device labeling will be used if necessary. ☑ User manual includes required Part 15 compliance statements. ☑ Module has been evaluated in typical host configurations to ensure compliance. We respectfully request modular approval for FCC ID: 2APK7RN2903A. Please contact us if additional information is required. Sincerely, John Burrell Product Design Engineer Fastenal Company 2001 Theurer Blvd, Winona, MN 55987 Telephone No: 513-644-6429 Email: jcondobu

TO: Federal Communication Commission Equipment Authorization Division Application Processing Branch 7435 Oakland Mills Rd Columbia, MD 21046 02/06/2026 Pursuant to FCC 22-84 Report and Order and KDB 986446 D01 Covered Equipment v01, the Commission adopted new FCC requirements to protect the nation’s networks and supply chains from equipment that poses an unacceptable risk to national security or the safety of U.S. persons. Specifically, the Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List. Certifications FCC ID: 2APK7RN2903A concerning “covered” equipment. Section 2.911…
