2APMK-7601218HProfessional Thermal Imager

Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2025/11/25 System Check_H2450 DUT: Dipole 2450 MHz; Type:D2450V2; SN:927 Communication System: CW; Frequency: 2450 MHz;Duty Cycle: 1:1 Medium: H2450 Medium parameters used: f = 2450 MHz;σ=1.80S/m;ε r = 39.65;ρ=1000kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2025/6/5; - Electronics: DAE4 Sn1418; Calibrated: 2025/6/5 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Pin=250mW/Area Scan (41x51x1):Interpolated grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 24.2 W/kg Pin=250mW/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 116.7 V/m; Power Drift = 0.15 dB Peak SAR (extrapolated) = 30.8 W/kg SAR(1 g) = 13.11 W/kg; SAR(10 g) = 6.14 W/kg Maximum value of SAR (measured) = 23.2 W/kg . Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2025/11/26 System Check_H5750 DUT: Dipole 5GHzV2;Type:D5GHzV2; SN:1040 Communication System: CW; Frequency: 5750 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5750 MHz;σ=5.23S/m;ε r = 35.58;ρ= 1000 kg/m 3 AmbientTemperature：22.5°C; LiquidTemperature：22.3°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2025/6/5; - Electronics: DAE4 Sn1418; Calibrated: 2025/6/5 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Pin=100mW/Area Scan (91x91x1):Interpolated grid: dx=10mm, dy=10mm Maximum value of SAR (interpolated) = 21.5 W/kg Pin=100mW/Zoom Scan (7x7x12)/Cube 0:Measurement grid: dx=4mm, dy=4mm, dz=2mm Reference Value = 62.748 V/m; Power Drift = 0.10 dB Peak SAR (extrapolated) = 36.4 W/kg SAR(1 g) = 7.97 W/kg; SAR(10 g) = 2.12 W/kg Maximum value of SAR (measured) = 21.3 W/kg

ReportNo.ENS2510300240W011Page1of2Ver.1.0 FCCID:2APMK-7601218H ReportNo.ENS2510300240W011Page2of2Ver.1.0

PhotographsofEUTSetup Fig-4.1TopofEUTwith0cmGap (BodyMode) PhotographsofEUT

Confidential Data Antenna Test Repor Project Name: UTi640Q Supplier：MyAntenna RF Technology Co., Ltd ADD:Room 410, Building A, Fenghuang Zhigu, No. 50 Tiezi Road, Gongle Community, Xixiang Street, Baoan District, Shenzhen Author:Yang Yongcheng Update: 2023-11-29 t Index: 1.Overview 2.Revision History 3.Test Item &Equipment 4.Matching Circuit 5.S Parameter Test 6.Active Test 7.Conducted Emission Test 8.Environmental Processing Confidential Data 项目概况 OverView CUSTOMER NAME优利德PROJECT NAMEUTi640Q ItemsDetails •FREQUENCY2400MHz-2500MHz；5100MHz-5800MHz •PROJECT TYPE •ANTENNA SPACE •FEED & GROUND PAD •SENSITIVE ELEMENTS •ANTENNA TYPE •PCB •OTHERS Confidential Data 日期(Date) 版本 (Revision) 负责人(Author)更改原因(Description of changes) 2023-11-29 A Yang Yongcheng 历史报告记录 Revision History Confidential Data ListTest ItemEquipment 1.S ParameterVSWR, Return LossAgilent VNA 2.Active Test TRP, TISAgilent 8960 RayZone1800 3.Passive TestGain, Efficiency, PatternAgilent E5071C Test Item & Equipment Confidential Data 2023-11-29 Matching Circuit Antenna RF Module E3E1 E2 ElementValue E1(0402)NC E2(0402)0 E3(0402)NC Confidential Data VSWR Confidential Data Passive data (efficiency) Confidential Data Passive data (gain) Confidential Data Passive data (detailed data) Freq Gain（dBi）Efficiency（%） Freq Gain（dBi）Efficiency（%） 24002.15 46.52 54002.27 55.80 24102.25 48.94 54202.04 53.21 24201.92 47.04 54402.08 51.96 24301.95 46.55 54602.42 52.63 24402.02 46.98 54802.87 53.28 24502.11 47.42 55003.14 54.74 24602.06 46.67 55202.96 52.27 24702.06 46.59 55402.82 48.76 24802.02 46.35 55603.36 50.47 24902.11 48.10 55803.82 57.27 2500 51.32.375 56003.45 55.39 51001.75 53.34 56203.58 54.11 51201.63 52.54 56403.73 55.42 51401.46 52.74 56603.71 56.70 51601.70 54.55 56803.73 57.92 51801.57 55.42 57004.12 60.54 52001.40 56.16 57203.85 57.57 52201.34 55.05 57403.85 60.36 52401.47 56.85 57603.89 62.24 52601.80 58.54 57803.81 63.50 52801.81 59.39 58003.44 61.11 53001.79 59.26 58203.08 57.01 53201.91 58.15 58402.76 53.09 53401.99 57.66 58602.80 51.74 53602.32 57.94 58802.67 50.24 53802.22 55.86 59002.33 46.95 Confidential Data 3DH面 E1 Antenna 2D/3D pattern（2450MHz） 面 E2面 Confidential Data 3DH面 E1 Antenna 2D/3D pattern（5500MHz） 面 E2面 Confidential Data dimensional drawing

ReportNo.ENS2510300240W01101RPage60of85Ver.1.0 11G-Ant1-2412-30~1000-PASS 11G-Ant1-2412-1000~26500-PASS ReportNo.ENS2510300240W01101RPage61of85Ver.1.0 11G-Ant1-2437-0~Reference-PASS 11G-Ant1-2437-30~1000-PASS ReportNo.ENS2510300240W01101RPage62of85Ver.1.0 11G-Ant1-2437-1000~26500-PASS 11G-Ant1-2462-0~Reference-PASS ReportNo.ENS2510300240W01101RPage63of85Ver.1.0 11G-Ant1-2462-30~1000-PASS 11G-Ant1-2462-1000~26500-PASS ReportNo.ENS2510300240W01101RPage64of85Ver.1.0 11N20SISO-Ant1-2412-0~Reference-PASS 11N20SISO-Ant1-2412-30~1000-PASS ReportNo.ENS2510300240W01101RPage65of85Ver.1.0 11N20SISO-Ant1-2412-1000~26500-PASS 11N20SISO-Ant1-2437-0~Reference-PASS ReportNo.ENS2510300240W01101RPage66of85Ver.1.0 11N20SISO-Ant1-2437-30~1000-PASS 11N20SISO-Ant1-2437-1000~26500-PASS ReportNo.ENS2510300240W01101RPage67of85Ver.1.0 11N20SISO-Ant1-2462-0~Reference-PASS 11N20SISO-Ant1-2462-30~1000-PASS ReportNo.ENS2510300240W01101RPage68of85Ver.1.0 11N20SISO-Ant1-2462-1000~26500-PASS 11N40SISO-Ant1-2422-0~Reference-PASS ReportNo.ENS2510300240W01101RPage69of85Ver.1.0 11N40SISO-Ant1-2422-30~1000-PASS 11N40SISO-Ant1-2422-1000~26500-PASS ReportNo.ENS2510300240W01101RPage70of85Ver.1.0 11N40SISO-Ant1-2437-0~Reference-PASS 11N40SISO-Ant1-2437-30~1000-PASS ReportNo.ENS2510300240W01101RPage71of85Ver.1.0 11N40SISO-Ant1-2437-1000~26500-PASS 11N40SISO-Ant1-2452-0~Reference-PASS ReportNo.ENS2510300240W01101RPage72of85Ver.1.0 11N40SISO-Ant1-2452-30~1000-PASS 11N40SISO-Ant1-2452-1000~26500-PASS ReportNo.ENS2510300240W01101RPage73of85Ver.1.0 8.6RADIATEDSPURIOUSEMISSION 8.6.1ApplicableStandard AccordingtoFCCPart15.247(d),15.205,15.209andKDB558074D0115.247MeasGuidancev05r02 AccordingtoICRSS-GenandRSS-247 8.6.2ConformanceLimit AccordingtoFCCPart15.247(d):radiatedemissionswhichfallintherestrictedbands,asdefinedin §15.205(a),mustalsocomplywiththeradiatedemissionlimitsspecifiedin§15.209(a)(see§15.205(c)). AccordingtoFCCPart15.205,Restrictedbands MHzMHzMHzGHz 0.090-0.11016.42-16.423399.9-4104.5-5.15 10.495-0.50516.69475-16.69525608-6145.35-5.46 2.1735-2.190516.80425-16.80475960-12407.25-7.75 4.125-4.12825.5-25.671300-14278.025-8.5 4.17725-4.1777537.5-38.251435-1626.59.0-9.2 4.20725-4.2077573-74.61645.5-1646.59.3-9.5 6.215-6.21874.8-75.21660-171010.6-12.7 6.26775-6.26825123-1382200-230014.47-14.5 8.291-8.294149.9-150.052310-239015.35-16.2 8.362-8.366156.52475-156.525252483.5-250017.7-21.4 8.37625-8.38675156.7-156.92690-290022.01-23.12 8.41425-8.41475162.0125-167.173260-326723.6-24.0 12.29-12.293167.72-173.23332-333931.2-31.8 12.51975-12.52025240-2853345.8-335836.43-36.5 12.57675-12.57725322-335.43600-4400(2) 13.36-13.41 AccordingtoFCCPart15.205thelevelofanytransmitterspuriousemissioninRestrictedbandsshallnot exceedtheleveloftheemissionspecifiedinthefollowingtable Restricted Frequency(MHz) FieldStrength(μV/m)FieldStrength (dBμV/m) Measurement Distance 0.009-0.4902400/F(KHz)20log(uV/m)300 0.490-1.70524000/F(KHz)20log(uV/m)30 1.705-303029.530 30-88100403 88-21615043.53 216-960200463 Above960500543 8.6.3TestConfiguration Testaccordingtoclause6.2radiofrequencytestsetup 8.6.4TestProcedure ThistestisrequiredforanyspuriousemissionthatfallsinaRestrictedBand,asdefinedinSection15.205. ItmustbeperformedwiththehighestgainofeachtypeofantennaproposedforusewiththeEUT.Use thefollowingspectrumanalyzersettings: ForAbove1GHz: TheEUTwasplacedonaturntablewhichis1.5mabovegroundplane. MaximumprocedurewasperformedonthehighestemissionstoensureEUTcompliance. Span=wideenoughtofullycapturetheemissionbeingmeasured RBW=1MHz VBWRBW Sweep=auto Detectorfunction=peak Trace=maxhold ReportNo.ENS2510300240W01101RPage74of85Ver.1.0 ForBelow1GHz: TheEUTwasplacedonaturntablewhichis0.8mabovegroundplane. MaximumprocedurewasperformedonthehighestemissionstoensureEUTcompliance. Span=wideenoughtofullycapturetheemissionbeingmeasured RBW=100kHzfor VBW  RBW Sweep=auto Detectorfunction=peak Trace=maxhold ForBelow30MHz: TheEUTwasplacedonaturntablewhichis0.8mabovegroundplane. MaximumprocedurewasperformedonthehighestemissionstoensureEUTcompliance. Span=wideenoughtofullycapturetheemissionbeingmeasured RBW=9kHz VBW  RBW Sweep=auto Detectorfunction=peak Trace=maxhold ForBelow150KHz: TheEUTwasplacedonaturntablewhichis0.8mabovegroundplane. MaximumprocedurewasperformedonthehighestemissionstoensureEUTcompliance. Span=wideenoughtofullycapturetheemissionbeingmeasured RBW=200Hz VBW  RBW Sweep=auto Detectorfunction=peak Trace=maxhold FollowtheguidelinesinANSIC63.10withrespecttomaximizingtheemissionbyrotatingtheEUT, measuringtheemissionwhiletheEUTissituatedinthreeorthogonalplanes(ifappropriate),adjustingthe measurementantennaheightandpolarization,etc.Apre-ampandahighpassfilterarerequiredforthis test,inordertoprovidethemeasuringsystemwithsufficientsensitivity.Allowthetracetostabilize. Thepeakreadingoftheemission,afterbeingcorrectedbytheantennafactor,cableloss,pre-ampgain, etc.,isthepeakfieldstrength,whichmustcomplywiththelimit.Submitthisdata. NowsettheVBWto10Hz,whilemaintainingalloftheotherinstrumentsettings.Thispeaklevel,once corrected,mustcomplywiththelimit.Ifthedwelltimeperchannelofthehoppingsignalislessthan100 ms,thenthereadingobtainedwiththe10HzVBWmaybefurtheradjustedbya“dutycyclecorrection factor”,derivedfrom20log(dwelltime/100ms),inanefforttodemonstratecompliancewiththelimit. Submitthisdata. Repeataboveproceduresuntilallfrequencymeasuredwascomplete. 8.6.5TestResults Temperature: 26C RelativeHumidity: 54  ATMPressure:1011mbar SpuriousEmissionbelow30MHz(9KHzto30MHz) Freq. (MHz) Ant.Pol. Emission Level(dBuV/m) Limit3m(dBuV/m)Over(dB) H/VPKAVPKAVPKAV ---------------- Note:theamplitudeofspuriousemissionthatisattenuatedbymorethan20dBbelowthepermissible limithasnoneedtobereported. Distanceextrapolationfactor=40log(Specificdistance/testdistance)(dB); Limitline=Specificlimits(dBuV)+distanceextrapolationfactor ReportNo.ENS2510300240W01101RPage75of85Ver.1.0 SpuriousEmissionAbove1GHz(1GHzto25GHz) Alltheantenna(Antenna1)andmodes(802.11b/g/n)havebeentestedandtheworst(Antenna1, 802.11b)resultrecordedwa…

Text truncated - open the document above for the full version.

ReportNo.ENS2510300240W01101RPage37of85Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS ReportNo.ENS2510300240W01101RPage38of85Ver.1.0 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS ReportNo.ENS2510300240W01101RPage39of85Ver.1.0 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS ReportNo.ENS2510300240W01101RPage40of85Ver.1.0 8.4MAXIMUMPOWERSPECTRALDENSITY 8.4.1ApplicableStandard AccordingtoFCCPart15.247(e)andKDB558074D0115.247MeasGuidancev05r02 AccordingtoRSS-2475.2(b)andRSS-Gen6.12 8.4.2ConformanceLimit Thetransmitterpowerspectraldensityconductedfromthetransmittertotheantennashallnotbegreater than8dBminany3kHzbandduringanytimeintervalofcontinuoustransmission.Thispowerspectral densityshallbedeterminedinaccordancewiththeprovisionsofsection5.4(d),(i.e.thepowerspectral densityshallbedeterminedusingthesamemethodasisusedtodeterminetheconductedoutputpower). 8.4.3TestConfiguration Testaccordingtoclause6.1radiofrequencytestsetup 8.4.4TestProcedure Thisprocedureshallbeusedifmaximumpeakconductedoutputpowerwasusedtodemonstrate compliance Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer SetanalyzercenterfrequencytoDTSchannelcenterfrequency. Setthespanto1.5timestheDTSbandwidth. SettheRBWto:3kHz SettheVBWto:10kHz. SetDetector=peak. SetSweeptime=autocouple. SetTracemode=maxhold. Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumamplitudelevelwithintheRBW. 8.4.5TestResults Temperature: 25 ̊C RelativeHumidity: 45  ATMPressure:1011mbar Note:N/A ReportNo.ENS2510300240W01101RPage41of85Ver.1.0 TestModeAntennaFrequency[MHz]Result[dBm/3-100kHz]Limit[dBm/3kHz]Verdict 11BAnt12412-16.24≤8.00PASS 11BAnt12437-17.09≤8.00PASS 11BAnt12462-17.80≤8.00PASS 11GAnt12412-20.36≤8.00PASS 11GAnt12437-21.79≤8.00PASS 11GAnt12462-22.29≤8.00PASS 11N20SISOAnt12412-21.17≤8.00PASS 11N20SISOAnt12437-20.80≤8.00PASS 11N20SISOAnt12462-21.37≤8.00PASS 11N40SISOAnt12422-22.20≤8.00PASS 11N40SISOAnt12437-22.89≤8.00PASS 11N40SISOAnt12452-23.53≤8.00PASS ReportNo.ENS2510300240W01101RPage42of85Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2437-PASS ReportNo.ENS2510300240W01101RPage43of85Ver.1.0 11B-Ant1-2462-PASS 11G-Ant1-2412-PASS ReportNo.ENS2510300240W01101RPage44of85Ver.1.0 11G-Ant1-2437-PASS 11G-Ant1-2462-PASS ReportNo.ENS2510300240W01101RPage45of85Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1-2437-PASS ReportNo.ENS2510300240W01101RPage46of85Ver.1.0 11N20SISO-Ant1-2462-PASS 11N40SISO-Ant1-2422-PASS ReportNo.ENS2510300240W01101RPage47of85Ver.1.0 11N40SISO-Ant1-2437-PASS 11N40SISO-Ant1-2452-PASS ReportNo.ENS2510300240W01101RPage48of85Ver.1.0 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS 8.5.1ApplicableStandard AccordingtoFCCPart15.247(d)andKDB558074D0115.247MeasGuidancev05r02 AccordingtoRSS-2475.5 8.5.2ConformanceLimit AccordingtoFCCPart15.247(d): Inany100kHzbandwidthoutsidethefrequencybandinwhichthespreadspectrumordigitally modulateddeviceisoperating,theRFpowerthatisproducedshallbeatleast20dBbelowthatinthe100 kHzbandwidthwithinthebandthatcontainsthehighestlevelofthedesiredpower,basedoneitheranRF conductedoraradiatedmeasurement,providedthatthetransmitterdemonstratescompliancewiththe peakconductedpowerlimits.Ifthetransmittercomplieswiththeconductedpowerlimitsbasedontheuse ofroot-mean-squareaveragingoveratimeinterval,aspermittedundersection5.4(d),theattenuation requiredshallbe30dBinsteadof20dB.Attenuationbelowthegeneralfieldstrengthlimitsspecified inRSS-Genisnotrequired. 8.5.3TestConfiguration Testaccordingtoclause6.1radiofrequencytestsetup 8.5.4TestProcedure Thetransmitteroutput(antennaport)wasconnectedtothespectrumanalyzer Referencelevelmeasurement Establishareferencelevelbyusingthefollowingprocedure: SetinstrumentcenterfrequencytoDTSchannelcenterfrequency. Setthespanto≥1.5timestheDTSbandwidth. SettheRBW=100kHz. SettheVBW≥3xRBW. SetDetector=peak. SetSweeptime=autocouple. SetTracemode=maxhold. Allowtracetofullystabilize. UsethepeakmarkerfunctiontodeterminethemaximumPSDlevel. NotethatthechannelfoundtocontainthemaximumPSDlevelcanbeusedtoestablishthereference level. Band-edgemeasurement Usethefollowingspectrumanalyzersettings: Span=wideenoughtocapturethepeakleveloftheemissionoperatingonthechannelclosesttothe band-edge,aswellasanymodulationproductswhichfalloutsideoftheauthorizedbandofoperation SetRBW  1%ofthespan=100kHzSetVBW  3xRBW SetSweep=autoSetDetectorfunction=peakSetTrace=maxhold Allowthetracetostabilize.Setthemarkerontheemissionatthebandedge,oronthehighest modulationproductoutsideoftheband,ifthislevelisgreaterthanthatatthebandedge.Enablethe marker-deltafunction,thenusethemarker-to-peakfunctiontomovethemarkertothepeakofthein-band emission.Themarker-deltavaluenowdisplayedmustcomplywiththelimitspecifiedinthisSection. Emissionlevelmeasurement Setthecenterfrequencyandspantoencompassfrequencyrangetobemeasured. SettheRBW=100kHz. SettheVBW=300kHz. SetDetector=peak Sweeptime=autocouple. Tracemode=maxhold. Allowtracetofullystabilize. Usethepeakmarkerfunctiontodeterminethemaximumamplitudelevel. Ensurethattheamplitudeofallunwantedemissionsoutsideoftheauthorizedfrequencyband(excluding restrictedfrequencybands)areattenuatedbyatleasttheminimumrequirements.Reportthethree highestemissionsrelativetothelimit. ReportNo.ENS2510300240W01101RPage49of85Ver.1.0 8.5.5TestResults Temperature: 25 ̊ C RelativeHumidity: 45  ATMPressure:1011mbar Note:N/A Bandedgemeasurements TestModeAntennaChNameFrequency[MHz]RefLevel[dBm]Result[dBm]Limit[dBm]Verdict 11BAnt1Low24126.39-36.72≤-23.61PASS 11BAnt1High24624.09-47.69≤-25.91PASS 11GAnt1Low2412-0.94-40.16≤-30.94PASS 11GAnt1High2462-3.22-47.14≤-33.22PASS 11N20SISOAnt1Low2412-1.49-37.1≤-31.49PASS 11N20SISOAnt1High2462-3.45-47.02≤-33.45PASS 11N40SISOAnt1Low2422-3.54-39.46≤-33.54PASS 11N40SISOAnt1High2452-4.08-46.56≤-34.08PASS ReportNo.ENS2510300240W01101RPage50of85Ver.1.0 11B-Ant1-2412-PASS 11B-Ant1-2462-PASS ReportNo.ENS2510300240W01101RPage51of85Ver.1.0 11G-Ant1-2412-PASS 11G-Ant1-2462-PASS ReportNo.ENS2510300240W01101RPage52of85Ver.1.0 11N20SISO-Ant1-2412-PASS 11N20SISO-Ant1…

Text truncated - open the document above for the full version.

ReportNo.ENS2510300240W01101RPage1of85Ver.1.0 TESTREPORT ProductName：ProfessionalThermalImager ModelNumber：UTi760H，UTi740H+ FCCID：2APMK-7601218H Preparedfor:UNI-TRENDTECHNOLOGY(CHINA)CO.,LTD Address:No.6,IndustrialNorth1stRoad,SongshanLake Park,DongguanCity,GuangdongProvince Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Building69,MajialongIndustryZone,Nanshan District,Shenzhen,Guangdong,China TEL:(0755)26954280 FAX:(0755)26954282 ReportNumber:ENS2510300240W01101R Dateofsamplereceipt:October27,2025 Date(s)ofTests:October27,2025toNovember26,2025 Dateofissue:November26,2025 $二维码$ ReportNo.ENS2510300240W01101RPage2of85Ver.1.0 TABLEOFCONTENTS 1TESTRESULTCERTIFICATION........................................................................................................................3 2EUTTECHNICALDESCRIPTION......................................................................................................................5 3SUMMARYOFTESTRESULT.............................................................................................................................6 4TESTMETHODOLOGY........................................................................................................................................7 4.1GENERALDESCRIPTIONOFAPPLIEDSTANDARDS...............................................................................7 4.2MEASUREMENTEQUIPMENTUSED...........................................................................................................7 4.3DESCRIPTIONOFTESTMODES...................................................................................................................8 5FACILITIESANDACCREDITATIONS...............................................................................................................9 5.1FACILITIES........................................................................................................................................................9 Building69,MajialongIndustryZone,NanshanDistrict,Shenzhen,Guangdong,China.......................................9 5.2EQUIPMENT.....................................................................................................................................................9 5.3LABORATORYACCREDITATIONSANDLISTINGS...................................................................................9 6TESTSYSTEMUNCERTAINTY........................................................................................................................10 7SETUPOFEQUIPMENTUNDERTEST...........................................................................................................11 7.1RADIOFREQUENCYTESTSETUP1...........................................................................................................11 7.2RADIOFREQUENCYTESTSETUP2...........................................................................................................11 7.3CONDUCTEDEMISSIONTESTSETUP......................................................................................................14 7.4BLOCKDIAGRAMCONFIGURATIONOFTESTSYSTEM......................................................................15 7.5SUPPORTEQUIPMENT.................................................................................................................................15 8TESTREQUIREMENTS......................................................................................................................................16 8.1DTS6DBBANDWIDTH.................................................................................................................................16 8.2DTS99%BANDWIDTH.................................................................................................................................24 8.3MAXIMUMPEAKCONDUCTEDOUTPUTPOWER.................................................................................32 8.4MAXIMUMPOWERSPECTRALDENSITY................................................................................................40 8.5UNWANTEDEMISSIONSINNON-RESTRICTEDFREQUENCYBANDS..............................................48 8.6RADIATEDSPURIOUSEMISSION..............................................................................................................73 8.7CONDUCTEDEMISSIONTEST....................................................................................................................81 8.8ANTENNAAPPLICATION.............................................................................................................................84 ReportNo.ENS2510300240W01101RPage3of85Ver.1.0 1TESTRESULTCERTIFICATION Applicant:UNI-TRENDTECHNOLOGY(CHINA)CO.,LTD Address: No.6,IndustrialNorth1stRoad,SongshanLakePark,DongguanCity, GuangdongProvince Manufacturer:UNI-TRENDTECHNOLOGY(CHINA)CO.,LTD Address: No.6,IndustrialNorth1stRoad,SongshanLakePark,DongguanCity, GuangdongProvince Factory:UNI-TRENDTECHNOLOGY(CHINA)CO.,LTD Address: No.6,IndustrialNorth1stRoad,SongshanLakePark,DongguanCity, GuangdongProvince EUT:ProfessionalThermalImager ModelName:UTi760H，UTi740H+ Trademark:UNI-T MeasurementProcedureUsed: APPLICABLESTANDARDS STANDARDTESTRESULT FCC47CFRPart2,SubpartJ FCC47CFRPart15,SubpartC PASS ICRSS-GEN,Issue5(04-2018)+A1(03-2019)+A2(02-2021) ICRSS-247Issue4(07-2025) PASS TheaboveequipmentwastestedbyEMTEK(SHENZHEN)CO.,LTD.Thetestdata,dataevaluation,test procedures,andequipmentconfigurationsshowninthisreportweremadeinaccordancewiththe proceduresgiveninANSIC63.10(2020)andtheenergyemittedbythesampleEUTtestedasdescribed inthisreportisincompliancewiththerequirementsofFCCRulesPart2,Part15.247,ICRSS-247Issue 2andICRSS-GEN,Issue5. DateofTest:October27,2025toNovember26,2025 Preparedby: UnaYu/Editor Reviewer: JoeXia/Supervisor Approve&AuthorizedSigner:LisaWang/Manager ReportNo.ENS2510300240W01101RPage4of85Ver.1.0 ModifiedHistory VersionReportNo.RevisionDateSummary V1.0ENS2510300240W01101R/OriginalReport ReportNo.ENS2510300240W01101RPage5of85Ver.1.0 2EUTTECHNICALDESCRIPTION Note:formoredetails,pleaserefertotheU…

Text truncated - open the document above for the full version.

ReportNo.ENS2510300240W00601RPage 1 of 38 Ver.1.0 TESTREPORT ProductName：ProfessionalThermalImager ModelNumber：UTi760H，UTi740H+ FCCID：2APMK-7601218H Preparedfor:UNI-TRENDTECHNOLOGY(CHINA)CO.,LTD Address:No.6,IndustrialNorth1stRoad,SongshanLakePark, DongguanCity,GuangdongProvince Preparedby:EMTEK(SHENZHEN)CO.,LTD. Address:Bldg69,MajialongIndustryZone,NanshanDistrict, Shenzhen,Guangdong,China Tel:(0755)26954280 Fax:(0755)26954282 ReportNumber:ENS2510300240W00601R Date(s)ofTests:November25,2025toNovember26,2025 DateofIssue:November27,2025 ReportNo.ENS2510300240W00601RPage 2 of 38 Ver.1.0 TABLEOFCONTENTS 1.TESTRESULTCERTIFICATION................................................................................................................................................4 2.DescriptionofEquipmentUnderTest......................................................................................................................................6 3.SARMeasurementSystem.......................................................................................................................................................7 3.1DefinitionofSpecificAbsorptionRate(SAR)......................................................................................................................7 3.2SPEAGDASYSystem........................................................................................................................................................7 3.2.1Robot...................................................................................................................................................................8 3.2.2Probes..................................................................................................................................................................9 3.2.3DataAcquisitionElectronics(DAE)......................................................................................................................9 3.2.4Phantoms...........................................................................................................................................................10 3.2.5DeviceHolder.....................................................................................................................................................11 3.2.6SystemValidationDipoles..................................................................................................................................11 3.2.7TissueSimulatingLiquids..................................................................................................................................12 3.3SARSystemVerification...................................................................................................................................................14 3.4SARMeasurementProcedure..........................................................................................................................................15 3.4.1Area&ZoomScanProcedure...........................................................................................................................15 3.4.2VolumeScanProcedure....................................................................................................................................15 3.4.3PowerDriftMonitoring.......................................................................................................................................16 3.4.4SpatialPeakSAREvaluation............................................................................................................................16 3.4.5SARAveragedMethods.....................................................................................................................................16 4.SARMeasurementEvaluation................................................................................................................................................17 4.1ApplicableStandards........................................................................................................................................................17 4.2EUTConfigurationandSetting.........................................................................................................................................17 4.3EUTTestingPosition.........................................................................................................................................................19 4.2.1Hand-heldusageofthedevice,notattheheadortorso...................................................................................19 4.3.1SARTestExclusionEvaluations........................................................................................................................21 4.4TissueVerification.............................................................................................................................................................22 4.5SystemValidation.............................................................................................................................................................22 4.6SystemVerification...........................................................................................................................................................23 4.7MaximumOutputPower...................................................................................................................................................24 4.7.1MaximumConductedPower..............................................................................................................................24 4.7.2MeasuredConductedPowerResult..................................................................................................................25 4.8SARTestingResults.........................................................................................................................................................27 4.8.1SARTestReductionConsiderations...............................…

Text truncated - open the document above for the full version.

Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2025/11/25 2.4GWIFI DUT: UTi640H, UTi384H+ Communication System: 802.11b; Frequency: 2437 MHz;Duty Cycle: 1:1 Medium: HSL2450 Medium parameters used : f = 2437 MHz;σ=1.83S/m;ε r = 39.62;ρ= 1000 kg/m 3 AmbientTemperature：22.1°C; LiquidTemperature：21.9°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2025/6/5; - Electronics: DAE4 Sn1418; Calibrated: 2025/6/5 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.10 (4); SEMCAD X Version 14.6.14 (7501) Top/Area Scan (9x11x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.0591 W/kg Top/Zoom Scan (7x7x7)/Cube 0:Measurement grid: dx=5mm, dy=5mm, dz=5mm Reference Value = 2.954 V/m; Power Drift = -0.10 dB Peak SAR (extrapolated) = 0.0820 W/kg SAR(1 g) = 0.240 W/kg; SAR(10 g) = 0.123 W/kg Smallest distance from peaks to all points 3 dB below = 11.7 mm Ratio of SAR at M2 to SAR at M1 = 48.1% Maximum value of SAR (measured) = 0.0573 W/kg Test Laboratory: Shenzhen EMTEK Co.,Ltd.Date: 2025/11/26 5.8GWIFI DUT: UTi640H, UTi384H+ Communication System: 802.11a; Frequency: 5785 MHz;Duty Cycle: 1:1 Medium: H5G Medium parameters used: f = 5785 MHz;σ=5.28S/m;ε r = 35.60;ρ= 1000 kg/m 3 AmbientTemperature：22.5°C; LiquidTemperature：22.3°C DASY5 Configuration: - Probe: EX3DV4 - SN3970; Calibrated: 2025/6/5; - Electronics: DAE4 Sn1418; Calibrated: 2025/6/5 - Phantom: ELI v5.0; Type: QDOVA002AA; Serial: TP:1231 - Measurement SW: DASY52, Version 52.8 (7); SEMCAD X Version 14.6.10 (7164) Top/Area Scan (9x11x1):Measurement grid: dx=15mm, dy=15mm Maximum value of SAR (measured) = 0.145 W/kg Top/Zoom Scan (9x9x16)/Cube 0:Measurement …

Text truncated - open the document above for the full version.
