2APN5-T5Smart Touch Wall Switch

Shenzhen Sonoff Technologies Co., Ltd.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Aug 23, 2023
Application Purpose: Original Equipment
Date of Application: Aug 23, 2023
Equipment Note: Smart Touch Wall Switch
Frequency Range: 2412.00000000 - 2462.00000000
Company: Shenzhen Sonoff Technologies Co., Ltd.
Country: China

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

Smart Touch Wall Switch ·中文 ----------1 - 9· English ----------10 - 17· Warning ----------18 -21 产品介绍设备重量＜1Kg，建议安装高度＜2米。 1 面板氛围灯开关指示灯网络指示灯接线端口触摸全屏 2 指示灯状态及说明指示灯名称状态说明配网指示灯设备处于配对状态设备未连接路由器网络指示灯指示灯状态处于“循环模式” 蓝色快闪一下设备已连接路由器，但未连接云端蓝色快闪两下操作手势说明手势主要作用短按手动开启/关闭相应通道、APP场景触发条件使设备进入配网状态长按划动多指触摸动作说明手指快速点击面板手指长按面板5秒以上 APP场景触发条件手动开启/关闭氛围灯多根手指同时触碰面板手指在面板上划动，划动距离超过面板范围50% • T5-120 横装支持左滑/右滑 • T5-120 竖装支持上滑/下滑 1. 横装 2. 竖装 3 长按短按划动多指触摸短按长按划动多指触摸功能特点 SONOFF TX Ultimate 是一款带LED灯的智能触摸墙面开关，开关时会伴随声音、灯光以及震动效果。在易微联APP配对成功后，可以在智能手机上远程控制开/关、切换氛围灯模式、设置定时或者智能场景。设备安装 1. 断电设备安装、故障维修请由专业资质电工操作。切勿在设备通电时进行接线操作或触碰到接线端子，以免发生触电危险！ 4 智能场景语音控制彩色氛围灯远程控制声光反馈振感触摸为确保电气安装的安全，必须在TX Ultimate前面安装符合国家安全标准额定电流为10A的微型断路器 (MCB) 或漏电断路器 (RCBO)。 2. 接线 5 L Out2 L Out1 100-240V AC N L In 100-240V AC L In 2C L Out1 N 1C 6 易微联APP配网 1. 下载易微联App 请前往应用商店、Google Play Store或Apple App Store 搜索"易微联"进行下载。确保线路接入无误。 L Out3 L Out2 L Out1 N 3C 100-240V AC L In 2. 上电 3 . 添加设备通电后，设备首次使用，默认进入配网模式。设备指示灯呈“循环模式”。点击“+”，选择“添加设备”，再根据 App 提示进行操作。 7 30分钟内没有进行配网，设备将退出配网模式。如需再次进入，长触摸设备面板5秒直到设备指示灯呈“循环模式”即可。家庭消息场景我的我的家家庭场景消息我的我的家添加设备扫一扫添加轻智能子设备进入 eWeLink App 设备设置页面，选择“轻智能子设备”再点击“添加”，然后触发子设备，即可添加成功。产品参数产品型号输入 Wi-Fi 工作温度工作湿度外壳材料产品规格 T5-1C-120/T5-2C-120/T5-3C-120 1C：100-240V ~ 50/60Hz Max 5A 2C：100-240V ~ 50/60Hz Max 10A 3C：100-240V ~ 50/60Hz Max 15A 输出 1C：100-240V ~ 50/60Hz Max 5A 2C：100-240V ~ 50/60Hz Max 5A/Gang 10A/Total 3C：100-240V ~ 50/60Hz Max 5A/Gang 15A/Total IEEE 802.11b/g/n 2.4GHz -10°C ~ 40°C 5% ~ 95%RH，无冷凝颜色白色 PC +CRS 120x74x39mm 8 设备设置轻智能子设备添加快捷设置位置管理分享设备创建群组小程序控制局域网控制设备设置网络指示灯轻智能子设备 0/8 LED负载 1C: 150W Max@240V,75W Max@100V 2C: 150W Max@240V/Gang,75W Max@100V/Gang 3C: 150W Max@240V/Gang,75W Max@100V/Gang 9 执行标准：GB/T 16915.2-2012 产品中有害物质的名称及含量部件名称塑料件本表格依据SJ/T 11364 的规定编制： o：表示该有害物质在该部件所有均质材料中的含量均在GB/T 26572规定的限量要求以下； x：表示该有害物质至少在该部件的某一均质材料中的含量超出GB/T 26572规定的限量要求。 oooooo xooooo oooooo oooooo 电子元器件包装盒铅 (Pb) 汞 (Hg) 镉 (Cd) 六价铭 (Cr｛VI｝多溴联苯 (PBB) 多溴二苯醚 (PBDE) 有害物质 PCB板 English 10 Product introduction The device weight is less than 1kg, and the recommended installation height is less than 2m. Switch panel Ambient light Switches LED indicator Network LED indicator Wiring ports Touch control screen English 11 LED Indicator status and instruction LED indicators Instructions Pairing LED indicator Device is in pairing mode Device is not connected to router Network LED indicator LED indicator status In the "Cycle mode" Flashes blue quickly once Device is connected to the router but not to the cloud Flashes blue quickly twice Operation instruction Operations Functions Quick click Turn on/off the switches and trigger the smart scenes Make the device enter the pairing mode Long press Swipe Multi-point click Instructions Click the switch panel quickly Long press the switch panel for 5s Trigger the smart scene Turn on/off the ambient light manually Multiple fingers click the switch panel Swipe on the switch panel and ensure the swipe distance exceeds 50% of it • T5-120 supports left/right swipe • T5-120 supports up/down swipe Quick clickLong press Quick clickLong press English 12 SwipeMulti-point click SwipeMulti-point click 1. Horizontal installation 2. Vertical installation English Installation 1. Power off Please install and maintain the device by a professional electrician. To avoid electric shock hazard, do not operate any connection or contact the terminal connector while the device is powered on! 13 Features SONOFF TX Ultimate is a smart touch wall switch with LED lights which will produce sound, light and vibration effects when it is turned on/off. After adding in the eWeLink App, you can remote control on/off, switch the ambient lighting modes, set timer and smart scene on the phone. Smart Scene Voice ControlRemote Comtrol Touch VibrationLight EffectsAmbient Lighting Mode To ensure the safety of your electrical installation, it's essential either a Miniature Circuit Breaker (MCB) or a Residual Current Operated Circuit Breaker (RCBO) with an electrical rating of 10A has been installed before the TX Ultimate. 2. Wiring instruction English 14 L Out2 L Out1 100-240V AC N L In 2C L Out1 100-240V AC N L In 1C English 15 1 . Download the eWeLink App Please download the "eWeLink" App from Google Play Store or Apple App Store. eWeLink App Pairing Make sure all wires are connected correctly. L Out3 L Out2 L Out1 100-240V AC N L In 3C English 16 2 . Power on 3 . Add device After powering on, the device will enter the Bluetooth pairing mode by default during the first use and the LED frame light will light in the "Cycle mode". Tap “+” and select “Add Device”, then operate following the prompt on the App. HomeMessageProfile My HomeMy Home HomeMessageProfile The device will exit the pairing mode when it doesn't be paired successfully within 10mins. If you want to access the pairing mode again, touch the wall switch panel for 5s until the LED frame light lights in the "Cycle mode". 17 English Add eWeLink-Remote Sub-devices Specifications Enter the Device Settings page on the eWeLink App, select "eWeLink-Remote sub-devices" and tap "Add", then trigger the sub-device to add it successfully. Model Input Wi-Fi Working temperature Working humidity Casing material Dimension T5-1C-120/T5-2C-120/T5-3C-120 1C:100-240V ~ 50/60Hz Max 5A 2C:100-240V ~ 50/60Hz Max 10A 3C:100-240V ~ 50/60Hz Max 15A Output 1C:100-240V ~ 50/60Hz Max 5A 2C:100-240V ~ 50/60Hz Max 5A/Gang 10A/Total 3C:100-240V ~ 50/60Hz Max 5A/Gang 15A/Total IEEE 802.11b/g/n 2.4GHz -10°C ~ 40°C 5% ~ 95% RH, non-condensing ColorWhite PC +CRS 120x74x39mm LED load 1C: 150W Max@240V,75W Max@100V 2C: 150W Max@240V/Gang,75W Max@100V/Gang 3C: 150W Max@240V/Gang,75W Max@100V/Gang Warning 18 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference th…

Text truncated - open the document above for the full version.

Attestation Statements

ShenzhenSonoffTechnologiesCo.,Ltd. PHOENIXTESTLABGmbHDate:2023.8.21 ProductCertificationDepartment Koenigswinkel10 32825Blomberg Germany Attestation Section2.911(d)(5)(ii),Section2.911(d)(5)(i) (KDB986446D01CoveredEquipment) ShenzhenSonoffTechnologiesCo.,Ltd.(“theapplicant”)certifiesthattheequipment forwhichauthorizationissoughtisnot“covered”equipmentprohibitedfromreceiving anequipmentauthorizationpursuanttosection2.903oftheFCCrules. ShenzhenSonoffTechnologiesCo.,Ltd.(“theapplicant”)certifiesthat,asofthedate ofthefilingoftheapplication,theapplicant[isnot]identifiedontheCoveredListas anentityproducing“covered”equipment. TypeofEquipmentsubjecttoFCCCertification: FCCID:2APN5-T5 Ifyouhaveanyquestions,pleasefeelfreetocontactme Signature: Name:FreddieDuan Company:ShenzhenSonoffTechnologiesCo.,Ltd. Address:3F&6F,BldgA,No.663,BulongRd,Shenzhen,Guangdong,China Phone:0755-29610458 Fax:0755-27955416 Email:[email protected]

Attestation Statements

ShenzhenSonoffTechnologiesCo.,Ltd. CertificationDesignatingaU.S.AgentforServiceofProcess Date:2023.8.21 Ref:Section2.911(d)(7)filing FCCID:2APN5-T5 To:FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 USA ShenzhenSonoffTechnologiesCo.,Ltd.(“theapplicant”)asrequiredbysection2.911(d)(7), willalsoserveastheagentforserviceofprocessfortheabovereferencedFCCID. Theapplicantacknowledgesthattheywillmaintainanagentfornolessthanoneyearafter thegranteehasterminatedallmarketingandimportationortheconclusionofany Commission-relatedproceedinginvolvingtheequipment.Theapplicantfurther acknowledgestheirresponsibilitytoinformtheFCCwhenevertheagentinformationchanges. FederalRegistrationNumber(FRN):0033682634 CompanyName:ITEAD,LLC CompanyAddress:651NBroadSt,Suite201Middletown,DE19709UnitedStates ContactPerson:FelixLi Email:[email protected] Sincerelyyours, Signature:Signature: Name:FreddieDuanName:FelixLi Company:ShenzhenSonoffTechnologiesCo.,Ltd.Company:ITEAD,LLC Phone:0755-29610458Phone:(925)237-1624 Fax:0755-27955416E-Mail:[email protected] E-Mail:[email protected]

Cover Letter(s)

ShenzhenSonoffTechnologiesCo.,Ltd. PHOENIXTESTLABGmbHDate:22August2023 ProductCertification Königswinkel10 D32825Blomberg RE:LETTEROFAGENCYAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize(CTCLaboratories,Inc.)toactonourbehalfinall mattersrelatingtoapplicationforequipmentauthorization,includingthesigningofall documentsrelatingtothesematters. Wecertifythatwearenotsubjecttodenialoffederalbenefits,thatincludesFCCbenefits, pursuanttoSection5301oftheAnti-DrugAbuseACTof1988,U.S.C.862.Further,noparty, asdefinedin47CFR1.2002(b),totheapplicationissubjecttodenialoffederalbenefits,that includesFCCbenefits. Thisagreementisvalidforoneyear–2023.8.21–untilfurthernotice. Ifyouhaveanyquestions,pleasefeelfreetocontactme Yourssincerely, Signature: ContactName:FreddieDuan Title:Manager ContactEmail:[email protected] ContactPhone:0755-29610458

Cover Letter(s)

ShenzhenSonoffTechnologiesCo.,Ltd. Long/Short-termConfidentialityRequest PHOENIXTESTLABGmbHDate:22August2023 ProductCertification Königswinkel10 D32825Blomberg FCCID:2APN5-T5 ToWhomItMayConcerns, Pursuanttosections0.457(d)and0.459ofCFR47andtoavoidprematurereleaseof sensitiveinformationpriortomarketingorreleaseoftheproducttothepublic,wehereby requestlong-termconfidentialtreatmentofinformationaccompanyingthisapplicationas outlinedbelow: ☒Schematics☐PartsList ☒BlockDiagram☐Tune-UpInfo ☒OperationalDescription Inadditionweherebyrequestthefollowingexhibitscontainedinthisapplicationtobe temporarily(short-termconfidentiality)withheldfromthepublicdisclosure ☐ foraninitialperiodofdays ☐ until: ☐ not applicable ☐ExternalPhotos☐TestSetupPhotos ☐InternalPhotos☐UsersManual Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarily releasedtothepublic.Thepublicdisclosureofthesemattersmightbeharmfultothe applicantandprovideunjustifiedbenefitstoitscompetitors. Theapplicantunderstandsthatpursuanttorule0.457(d),disclosureofthisapplicationand allaccompanyingdocumentationwillnotbemadebeforethedateoftheGRANTforthis application. Ifyouhaveanyquestions,pleasefeelfreetocontactme. Yourssincerely, Signature: ContactName:FreddieDuan Title:Manager ContactEmail:[email protected] ContactPhone:0755-29610458

Cover Letter(s)

ShenzhenSonoffTechnologiesCo.,Ltd. Supplier’sDeclarationOfConformity fortheFCCSDoCProcedure ThefollowingEquipmentadaptFCCSDoCProcedureaccordingtoFCCpart2.906: ProductName:____SmartTouchWallSwitch_____ BrandName:______Sonoff___________________ ModelNumber:___T5-3C-120,T5-2C-120,T5-1C-120_____ ReportNumber:_CTC20231495E01,CTC20231495E02,CTC20231495E03____ It’sherewithconfirmedtocomplywiththerequirementsofFCCPart15Rules. Operationissubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,includinginterferencethat maycauseundesiredoperation. Itisunderstoodthateachunitmarketedisidenticaltothedeviceastested,andanychangestothe devicethatcouldadverselyaffecttheemissioncharacteristicswillrequireretest. Thefollowingimporter/responsiblepartyinUnitedStates: NotAvailableatCertificationStage CompanyName:ShenzhenSonoffTechnologiesCo.,Ltd. CompanyAddress:3F&6F,BldgA,No.663,BulongRd,Shenzhen,Guangdong,China Telephone:0755-29610458 Fax:/ Personisresponsibleformarkingthisdeclaration: ___FreddieDuan_________________Manager______ Name(Fullname)Position/Title _______________________________2023.8.21__________ LegalSignatureDate

Cover Letter(s)

ShenzhenSonoffTechnologiesCo.,Ltd. ADD:3F&6F,BldgA,No.663,BulongRd,Shenzhen,Guangdong,China TEL:+86-0755-27955416FAX:+86-0755-27955416 Mail:[email protected] /2 1 DECLARATIONOFSIMILARITY Date ： 2023-7-14 ToWhomItMayConcern DearSirorMadam: We,ShenzhenSonoffTechnologiesCo.,Ltd.,herebydeclarethatproduct:SmartTouchWall Switch,ThemodelT5-3C-120,T5-2C-120,T5-1C-120whichweretestedbyCTC Laboratories,Inc.withthesameelectromagneticemissionsandelectromagneticcompatibility characteristics. Thefollowingisadescriptionofthedifferencesanddeclarationsimilaritiesbetween severalconfigurations. ModelRelayGang(s) PCBBoard PowersupplyboardRF&ControlBoard T5-1C-12011 Theproductcontainsone relayandthreeterminal blocksonpowersupply board,buttherestarethe same same T5-2C-12022 Theproductcontainstwo relaysandfourterminal blocksonpowersupply board,buttherestarethe same T5-3C-12033 Theproductcontainsthree relaysandfiveterminal blocksonpowersupply board,buttherestarethe same ShenzhenSonoffTechnologiesCo.,Ltd. ADD:3F&6F,BldgA,No.663,BulongRd,Shenzhen,Guangdong,China TEL:+86-0755-27955416FAX:+86-0755-27955416 Mail:[email protected] /2 2 ModelRelay PCBBoard PowersupplyboardRF&ControlBoard T5-3C-120,T5-2C- 120,T5-1C-120 Relay Manufacturer：ZhejiangFanhar ElectronicsCo.,Ltd Model：W18-1AST-DC5V Control：DC5V Load:5A250VAC/30VDC same T5-3C-120,T5-2C- 120,T5-1C-120Alt Manufacturer：SUZHOUGEEKOELECTRIC APPLIANCESCO.,LTD Model：GK101-1AS-DC5V Control：DC5V Load:5A250VAC/30VDC Exceptthedifferencesabove,wedeclaretheproductsareelectricallyidentical.Weguaranteeall theinformationprovidedaboveistrue,andnoticethatwe’llbearalltheconsequencescausedby anyfalseinformationorconcealing. Pleasecontactmeshouldtherebeneedforanyadditionalclarificationorinformation. BestRegards, Signature Name:FreddieDuan Manager

External Photos

CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel: +86-755-27521059 Fax: +86-755-27521011 http://www.sz-ctc.org.cn FCC ID: 2APN5-T5 IC: 29127-T5 Page 1 of 3 External Photos Page 2 of 3 Page 3 of 3

External Photos

Internal Photos

RF Exposure Info

CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel: +86-755-27521059 Fax: +86-755-27521011 http://www.sz-ctc.org.cn CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Maximum Permissible Exposure Evaluation FCC ID: 2APN5-T5 According to FCC 1.1310: The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) Radiation as specified in §1.1307(b). EUT Specification Applicant Shenzhen Sonoff Technologies Co.,Ltd. Address 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China Product Name: Smart Touch Wall Switch Trade Mark: Sonoff Model/Type Reference: T5-3C-120 Listed Model(s): T5-2C-120, T5-1C-120 Model Differences: All these models are identical in the same PCB, layout, electrical circuit. The difference is the number of output terminal blocks and the number of relays. Model: T5-1C-120, the product contains one relay and three terminal blocks on power supply board, but the rest are the same. Model: T5-2C-120, the product contains two relays and four terminal blocks on power supply board, but the rest are the same. Model: T5-3C-120, the product contains three relays and five terminal blocks on power supply board, but the rest are the same. Frequency Band (Operating) BLE: 2402~2480MHz WiFi: 2412-2462MHz Device Category Portable (<5mm separation) Mobile (>20cm separation) Fixed (>20cm separation) Others ___ Exposure Classification Occupational/Controlled exposure (S=5mW/cm 2 ) General Population/Uncontrolled exposure (S=1mW/cm 2 ) Antenna Diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Antenna Gain (Max) 2.82dBi Evaluation Applied MPE Evaluation SAR Evaluation Page 2 of 2 Report No.: CTC20231495E03 CTC Laboratories, Inc. 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : yz.cnca.cn Limits for Maximum Permissible Exposure (MPE) Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm 2 ) Averaging Time (minutes) (A) Limits for Occupational/Controlled Exposure 300-1500 -- -- F/300 <6 1500-100000 -- -- 5 <6 (B) Limits for General Population/Uncontrolled Exposure 300-1500 -- -- F/1500 <30 1500-100000 -- -- 1 <30 Calculation Method Friis transmission formula: Pd=(P out *G)/(4*Pi*R 2 ) Where: Pd= Power density in mW/cm 2 P out = output power to antenna in mW G= gain of antenna in linear scale Pi= 3.1416 R= distance between observation point and center of the radiator in cm Pd limit of MPE is 1mW/cm 2 . If we know the maximum gain of the antenna and total power input to the antenna, through the calculation, we will know the distance where the MPE limit is reached. Measurement Result Mode Frequency (MHz) Antenna Gain (dBi) Maximum Power (dBm) Tune Up Tolerance (dB) Max. Tune Up Power (dBm) Power Density at 20cm (mW/cm 2 ) Limit (mW/cm 2 ) BLE 2402 2.82 3.061 ±1 4.00 0.0010 1 802.11b 2412 2.82 18.73 ±1 19.50 0.0339 1 The BLE and WiFi can transmit simultaneously. Mode Frequency (MHz) Antenna Gain (dBi) Power Density at 20cm (mW/cm 2 ) Total Power density at 20cm (mW/cm2 ) Limit (mW/cm 2 ) BLE 2402 2.82 0.0010 0.0349 1 802.11b 2412 2.82 0.0339 0 Note: 1. Calculate in the worst-case mode. 2. Max. Tune Up Power is declared by manufacturer, and used to calculate. 3. For a more detailed features description, please refer to the RF Test Report. **********************THE END**********************

Test Report

ANTENNA SPECIFICATION Product description: 2.4G FPC Antenna Uni Link’s part number: GDT-SL-081-30 Issue Date: 2023-05-22 Note: 2400-2500MHz Manufacturer: Shenzhen Guandetong Electronic Co., Ltd Address: 3rd floor, Building D, South Maoyuan Industrial Park, Guanhu Street, Longhua District, Shenzhen 1、（PRODUCT TECHNICAL SPECIFICATION） Electrical Specifications Frequency Range (MHz) 2400-2500 Input Impendence (Ω) 50 V.S.W.R ≤2 Gain (dBi) 2.82 Polarization Type Vertical Power Capacity (w) 2 Mechanical Specifications Antenna Length (mm) 47mm Radiator Cuprum Connect Type IPEX-3 Working Temp( °C) -10~40 Storage Temperature(°C) -40~85 antenna size 43.49*4.14mm Weight (g) 3 2、PRODUCT PICTURE 3、PRODUCT SPECIFICATION CHART 4、Image of antenna field shape test

Test Report

CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel: +86-755-27521059 Fax: +86-755-27521011 http://www.sz-ctc.org.cn TEST REPORT Report No. .................................... : CTC20231495E01 FCC ID ........................................... : 2APN5-T5 IC ................................................... : 29127-T5 Applicant ...................................... : Shenzhen Sonoff Technologies Co.,Ltd. Address .......................................... : 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China Manufacturer..................................: Shenzhen Sonoff Technologies Co.,Ltd. Address..........................................: 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China Product Name .............................. : Smart Touch Wall Switch Trade Mark .................................... : Sonoff Model/Type reference .................... : T5-3C-120 Listed Model(s) .............................. : T5-2C-120, T5-1C-120 Standard ....................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 RSS-247 Issue 2 Date of receipt of test sample........: Jul. 27, 2023 Date of testing..............................: Jul. 27, 2023 to Aug. 20, 2023 Date of issue................................: Aug. 21, 2023 Result............................................: PASS Compiled by: (Printed name+signature) Jim Jiang Supervised by: (Printed name+signature) Eric Zhang Approved by: (Printed name+signature) Totti Zhao $英文检测章$ $Totti$ This test report may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CTC. The Test Result in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CTC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. The test report merely corresponds to the test sample. Page 2 of 39 Report No.: CTC20231495E01 CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : http://yz.cnca.cn Table of Contents Page 1. TEST SUMMARY ....................................................................................................................................................... 3 1.1. TEST STANDARDS .......................................................................................................................................................... 3 1.2. REPORT VERSION ......................................................................................................................................................... 3 1.3. TEST DESCRIPTION ........................................................................................................................................................ 3 1.4. TEST FACILITY .............................................................................................................................................................. 4 1.5. MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 1.6. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 5 2. GENERAL INFORMATION .......................................................................................................................................... 6 2.1. CLIENT INFORMATION ................................................................................................................................................... 6 2.2. GENERAL DESCRIPTION OF EUT ...................................................................................................................................... 6 2.3. ACCESSORY EQUIPMENT INFORMATION ............................................................................................................................ 7 2.4. OPERATION STATE ........................................................................................................................................................ 8 2.5. MEASUREMENT INSTRUMENTS LIST ................................................................................................................................. 9 3. TEST ITEM AND RESULTS ........................................................................................................................................ 10 3.1. CONDUCTED EMISSION................................................................................................................................................ 10 3.2. RADIATED EMISSION ................................................................................................................................................... 13 3.3. BAND EDGE EMISSIONS (RADIATED) .............................................................................................................................. 21 3.4. BAND EDGE AND SPURIOUS EMISSIONS (CONDUCTED) ...................................................................................................... 26 3.5. DTS BANDWIDTH ....................................................................................................................................................... 29 3.6. PEAK OUTPUT POWER .............................................…

Text truncated - open the document above for the full version.

Test Report

CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel: +86-755-27521059 Fax: +86-755-27521011 http://www.sz-ctc.org.cn TEST REPORT Report No. .................................... : CTC20231495E02 FCC ID ........................................... : 2APN5-T5 IC ................................................... : 29127-T5 Applicant ...................................... : Shenzhen Sonoff Technologies Co.,Ltd. Address .......................................... : 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China Manufacturer..................................: Shenzhen Sonoff Technologies Co.,Ltd. Address..........................................: 3F & 6F, Bldg A, No. 663, Bulong Rd, Shenzhen, Guangdong, China Product Name .............................. : Smart Touch Wall Switch Trade Mark .................................... : Sonoff Model/Type reference .................... : T5-3C-120 Listed Model(s) .............................. : T5-2C-120, T5-1C-120 Standard ....................................... : FCC CFR Title 47 Part 15 Subpart C Section 15.247 RSS-247 Issue 2 Date of receipt of test sample........: Jul. 27, 2023 Date of testing..............................: Jul. 27, 2023 to Aug. 20, 2023 Date of issue................................: Aug. 21, 2023 Result............................................: PASS Compiled by: (Printed name+signature) Jim Jiang Supervised by: (Printed name+signature) Eric Zhang Approved by: (Printed name+signature) Totti Zhao $英文检测章$ $Totti$ This test report may be duplicated completely for legal use with the approval of the applicant. It should not be reproduced except in full, without the written approval of our laboratory. The client should not use it to claim product endorsement by CTC. The Test Result in the report only apply to the tested sample. The test report shall be invalid without all the signatures of testing engineers, reviewer and approver. Any objections must be raised to CTC within 15 days since the date when the report is received. It will not be taken into consideration beyond this limit. The test report merely corresponds to the test sample. Page 2 of 93 Report No.: CTC20231495E02 CTC Laboratories, Inc. 2/F., Building 1 and 1-2/F., Building 2, Jiaquan Building, Guanlan High-Tech Park, Longhua District, Shenzhen, Guangdong, China Tel.: (86)755-27521059 Fax: (86)755-27521011 Http://www.sz-ctc.org.cn For anti-fake verification, please visit the official website of Certification and Accreditation Administration of the People’s Republic of China : http://yz.cnca.cn Table of Contents Page 1. TEST SUMMARY ....................................................................................................................................................... 3 1.1. TEST STANDARDS .......................................................................................................................................................... 3 1.2. REPORT VERSION ......................................................................................................................................................... 3 1.3. TEST DESCRIPTION ........................................................................................................................................................ 3 1.4. TEST FACILITY .............................................................................................................................................................. 4 1.5. MEASUREMENT UNCERTAINTY ........................................................................................................................................ 5 1.6. ENVIRONMENTAL CONDITIONS ........................................................................................................................................ 5 2. GENERAL INFORMATION .......................................................................................................................................... 6 2.1. CLIENT INFORMATION ................................................................................................................................................... 6 2.2. GENERAL DESCRIPTION OF EUT ...............................................................…

Text truncated - open the document above for the full version.

Contact Information

Applicant

Stan Li(Manager)

[email protected]0755-29610458Fax: 0755-27955416

Test Firm

CTC Laboratories, Inc.Totti Zhao

[email protected]+8675527521059

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
2	15C	2.41 GHz - 2.46 GHz	74.64 mW

Confidentiality

Long Term

Grant Notes

Output power is maximum peak conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co- located or operating in conjunction with any other antenna or transmitter. End users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.
