2APNFWAC000008Modern forms G3 Remote

OPERATION INSTRUCTIONS F-RCBT-WT Package Contents Pairing To pair your remote control: 1. Power cycle your fan by removing power from the circuit breaker for 10 seconds and then re-enable power. 2. Press and hold and buttons on remote control for 4-5 seconds. 3.The LED will blink green. 4.The green LED along with audible beeps will indicate that pairing is successful. 5.Test remote control using the steps in section 2. 1 button: Switch between Summer and Winter Mode. SUMMER MODE (Counter-Clockwise): A downward airow creates a cooling eect (FIG. 3). This allows you to set your air conditioner on a warmer setting without aecting your comfort. WINTER MODE (Clockwise): An upward airow moves warm air o the ceiling area and re-distributes the warm air that hovers around the ceiling to the living space. This should allow for savings on heating costs (FIG. 4). NOTE: On your fan, press the button while the fan is running Remote Control Operation Remote Control Button Functions button: Turns the light ON or OFF. Press or hold to increase the light level. Press or hold to decrease the light level. button: Turns the fan ON or OFF. Press or hold the button to increase fan speed. Press or hold the button to decrease fan speed. 2 BatteriesRemoteWall Cradle Screws CR2032 CR2032 Press and Hold NOTE: A maximum of 10 remote controls or wall controls can be used with a fan. NOTE: Pairing must be completed within three (3) minutes of turning the power ON to the fan receiever. FIG.1 FIG.2 FIG.3 FIG.4 3 Breeze Mode 1.Breeze Mode mimics the natural ebb and ow of winds in nature by varying the fan speed. NOTE: Breeze Mode always rotates your fan in the Summer (CCW) direction 2.To start Breeze Mode, press and for 4 seconds. The LED will blink green and the fan will beep. 3.To exit Breeze Mode and return to standard fan mode, press and for 4 seconds. The led will blink green and the fan will beep. Your fan will return to the direction and speed it was set to prior to entering Breeze Mode. NOTE: Your fan features 6 speeds. An audible tone will indicate when the speed is increased or decreased. When the fan has reached the minimum/maximum speed level the fan will beep twice. Fan Wi-Fi Reset NOTE: This function only resets the Wi-Fi settings. 1. Press and hold the and buttons for 10 sec. 2.The LED will blink green and the receiver will beep to indicate that Wi-Fi reset is successful. 3.After the Wi-Fi resets, the fan will broadcast its factory set network name beginning with “ModernFormsFan.” NOTE: Changes to your Wi-Fi network settings (SSID or Security Passphrase) will prevent your fan from connecting to the cloud. You can re-establish connectivity by performing a Wi-Fi Reset and using the Modern Forms app to recongure the fan to connect to the network with the new settings. 5 Using Power Switch This process can be used when it is inconvenient to use one of the other processes. NOTE: You must use a switch that cuts power to the fan receiver for this process to work. This will reset all fans connected to the switch being used. 1. Turn o power at power switch for 3 seconds. 2. Turn on power for 6 seconds. Turn o power. 3. Turn on power. In approximately 6 seconds the receiver will beep. When the receiver beeps turn o power. Repeat step 3 four additional times. On the fourth repetition the fan will beep three times indicating the fan has performed a factory reset. NOTE: This will remove remote control(s), wall control(s) and Modern Forms app connections. Using Receiver Button 1. Power down the receiver and within 3 minutes of turning the power back on, press and hold the reset button on the receiver until the receiver beeps. 2. Power cycle the circuit to complete the process. NOTE: This will remove remote control(s), wall control(s) and Modern Forms app connections. FIG.7 6 Factory Reset Using remote control Remote Control Factory Reset: 1.Press and hold the , and buttons for 10 seconds. 2.The LED will blink green and the receiver will beep CAUTION: The user is cautioned that changes or modications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures: •Reorient or relocate the receiving antenna. •Increase the separation between the equipment and receiver. •Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected. •Consult the dealer or an experienced radio/TV technician for help. FCC Supplier’s Declaration of Conformity Brand name: Modern Forms Model number: F-RCBT-WT This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. WAC LIGHTING CO. 44 Harbor Park Drive, Port Washington, NY 11050 Tel: 1-866-810-6615 Rules and Regulations Unpairing NOTE: Unpairing must be completed within 3 minutes of turning the power on to the fan receiver. 1.When you re-engage power to the fans you want to unpair, press and hold the and buttons for 4 seconds. 2.The LED will blink green, and the receiv- er will beep to indicate …

Text truncated - open the document above for the full version.

WAC Lighting Co U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: WAC Lighting Co Address: 44 Harbor Park Drive, PORT WASHINGTON PORT WASHINGTON NEW YORK 11050 USA FRN: 0036408979 Contact Name: Sean Tham Tel.: 516 515 5043 Email: [email protected] This letter is to confirm that we (“the Designated U.S. Agent) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: 2025/11/18 Signed by (Printed Name/Title): Sean Tham/VP The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: WAC Lighting Co Grantee Code: 2APNF FCC ID: 2APNFWAC000008 Contact Name: Mr Liu Xiongkang Street Address: No.390 Qingfeng RD, Qingxi TW Dongguan City, Guangdong Province China Telephone No: +86-769-87311200 Email: [email protected] FRN: 0027449396 Applicant Signature: Date: 2025/11/18 Signed by (Printed Name/Title): Xiongkang Liu /Director

(WAC Lighting Co) 2025/11/18 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for (FCC ID: 2APNFWAC000008) [WAC Lighting Co] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. We also certify that, as of the date of the filing of the application, the equipment does not utilize cyber-security or anti-virus software from Kaspersky Lab, Inc, or any of its successors and assignees, which is also on the “covered list”. Sincerely, Client’s signature: Client’s name / title : Xiongkang Liu /Director Contact information / address: No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China (WAC Lighting Co) 2025/11/18 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for (FCC ID: 2APNFWAC000008) [WAC Lighting Co] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, Client’s signature: Client’s name / title : Xiongkang Liu/Director Contact information / address: No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China

Declaration on model difference We The main model and subsequent models used in this test are only in terms of model and brand. However, all other aspects, including materials, other manufacturing processes, circuit design, and the manufacturer, are exactly the same. Finally, we selected F-RCBT-WT as the test model. FCCID: 2APNFWAC000008 Production name Trade name Model no. Modern forms G3 Remote N/A F- RCBT-WT,RC20-WT,SF-RCBT-WT Signature: Date: 2025/11/18 Name: Xiongkang Liu Title: Director Company: WAC Lighting Co

WAC Lighting Co 2025/11/18 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION Product Name: Modern forms G3 Remote FCCID: 2APNFWAC000008 Model(s): F-RCBT-WT,RC20-WT,SF-RCBT-WT To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen STS Test Services Co., Ltd. to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : Xiongkang Liu /Director Contact information / address: No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China

WAC Lighting Co 2025/11/18 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR Product Name: Modern forms G3 Remote FCCID: 2APNFWAC000008 Model(s): F-RCBT-WT,RC20-WT,SF-RCBT-WT To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : Xiongkang Liu /Director Contact information / address: No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China

External Photos

F-RC-WT FRC-63C 7DLU301089 外型尺寸 Overall dimension 黑色外框为切线，不需要印 刷。 The black frame is tangential and does not require printing. ; 5 32.7 113 REMOTE UL 标贴 UL LABEL OF REMOTE 序号 1 3 2 4 1:1 名称 柴轲 设计 审核 标准化 批准 DESIGN CHECK STANDARD APPROVE TITLE PART NO. 料号 图号 DWG NO. 材料 MATERIAL MODEL NO. 产品型号 第 1 页 PAGE 1 比例 SCALE 视角 VIEW 变更说明 更新 CHANGED BY 变更人 变更日期 REV DATE 共 1 页 TOTAL 1 PAGE 11/19/2019 消银龙 SILVER POLYESTER 46 INGESTION HAZARD: This product contains a button cell or coin 2APNFWAC000008 battery. RISQUE D'INGESTION: Ce produit contient une plie bouton ou de type 'pièce de monnaie'. INGESTION HAZARD: This product contains a button cell or coin battery. Ce produit contient une plie bouton ou de type 'pièce de monnaie'. RISQUE D'INGESTION: 2 1 2APNFWAC000008

Internal Photos Antenna

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. MPE Report Report No.:STS2512474H01 Issued for WAC Lighting Co No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Product Name: Modern forms G3 Remote Brand Name: MODERN FORMS,WAC,SCHONBEK Model Name: F-RCBT-WT Series Model(s): RC20-WT,SF-RCBT-WT FCC ID: 2APNFWAC000008 Test Standards: FCC 47CFR §2.1093 Page 2 of 8 Report No.: STS2512474H01 TEST REPORT Applicant’s Name ................. : WAC Lighting Co Address .................................. : No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Manufacturer's Name .......... : WAC Lighting Co Address .................................. : No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Product Description Product Name ........................ : Modern forms G3 Remote Brand Name ........................... : MODERN FORMS,WAC,SCHONBEK Model Name........................... : F-RCBT-WT Series Model(s) ...................... : RC20-WT,SF-RCBT-WT Test Standards ..................... : FCC 47CFR §2.1093 447498 D01 Interim General RF Exposure Guidance v06 The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the ShenZhen STS Test Services Co., Ltd. Date of Test ............................................ : Date of receipt of test item ...................... : 2025-12-15 Date (s) of performance of tests.............. : 2025-12-15 to 2025-12-24 Date of Issue ........................................... : 2025-12-24 Test Result ............................................... : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 8 Report No.: STS2512474H01 TABLE OF CONTENTS 1. GENERAL INFORMATION 5 1.1 GENERAL DESCRIPTION OF THE EUT 5 1.2 TEST FACTORY 5 2. FCC 47CFR §2.1093 REQUIREMENT 6 2.1 TEST STANDARDS 6 2.2 LIMIT 6 2.3 TEST RESULT 8 Page 4 of 8 Report No.: STS2512474H01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-24 STS2512474H01 ALL Initial Issue Page 5 of 8 Report No.: STS2512474H01 1. GENERAL INFORMATION 1.1 GENERAL DESCRIPTION OF THE EUT Product Name Modern forms G3 Remote Brand Name MODERN FORMS,WAC,SCHONBEK Model Name F-RCBT-WT Series Model(s) RC20-WT,SF-RCBT-WT Model Difference The main model and subsequent models used in this test are only in terms of model and brand. However, all other aspects, including materials, other manufacturing processes, circuit design, and the manufacturer, are exactly the same. Finally, we selected F-RCBT-WT as the test model. Product Description The EUT is Modern forms G3 Remote Operation Frequency: 2402~2480 MHz Modulation Type: GFSK Radio Technology: BLE Bluetooth Configuration: BLE(Support 1M, 2M) Number Of Channel: 40 Antenna Type: Internal antenna Antenna Gain (dBi) 2.066 Power Rating DC 3V Adapter N/A Battery N/A Hardware Version N/A Software Version N/A 1.2 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 Page 6 of 8 Report No.: STS2512474H01 2. FCC 47CFR §2.1093 REQUIREMENT 2.1 TEST STANDARDS The limit for Maximum Permissible Exposure (MPE) specified in KDB 447498 D01 General RF Exposure Guidance v06 is followed. The gain of the antennas used in the product is extracted from the Antenna data sheets provided and also the maximum total power input to the antenna is measured. Through the Friis transmission formula and the maximum gain of the antenna, we can calculate the distance, away from the product, where the limit of MPE is reached. Although the Friis Transmission formula is far field assumption, the calculated result of that is an over-prediction for near field power density. It is taken as worst case to specify the safety range. 2.2 LIMIT Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. Page 7 of 8 Report No.: STS2512474H01 The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] • [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz. Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. Page 8 of 8 Report No.: STS2512474H01 2.3 TEST RESULT Maximum measured transmitter power. Worst Case Mode frequency Maximum Output Power Tune up tolerance Max Tune up GHz dBm dBm dBm BLE 2.437 -0.25 0±1 1 Evaluation Result Mode Frequency Antenna Distance RF output power including tune up (dBm) SAR Test Exclusion Threshold SAR Test Exclusion Estimated SAR GHz mm dBm mw BLE 2.402 5 1 1.26 0.39 Yes / Multiple transmission: WIFI =0.39＜3 Note: 1. Remark: The worst case gain of the antenna is 2.066dBi. 2. Threshold at which no SAR required is 2.78192≤ 3.0 for 1-g SAR, Separation distance ≤ 5mm. ※※※※※END OF THE REPORT※※※※※

Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 1 of 15 Form No.：CR-TE-035/C OTA TEST REPORT Application name: ERD Address of application: No.390 Qingfeng RD, Qingxi TW, Dongguan, Guangdong, CHINA Product name: Antenna Trademark: WAC Model No.: F-RCBT-WT Electric rating: / Receive product date: 2025-08-26 Te sted date: 2025-08-26--2025-08-26 Revised date: / Prepared by: Reviewed by: Approved by: Note: 1. The results of this report are valid only for the samples. 2. This report shall not be reproduced except in full without written approval of the laboratory. The test results presented in this report relate only to the tested items. Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 2 of 15 Form No.：CR-TE-035/C 1.1 Summary： No Item Reference standard Result Done 1 Active OTA TRP CWG OTA Test Plan / YD/T 1484.1 / 2 Active OTA TIS CWG OTA Test Plan / YD/T 1484.1 / 3 Passive OTA IEEE Standard Test Procedures for antennas PA SS 4 5 Remark Note: WI-LA-XXXX is the LAB test Specification. Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 3 of 15 Form No.：CR-TE-035/C 1.2 EUT PHOTO and TEST PHOTO: EUT PHOTO: Global picture local picture Close-up picture EUT TEST PHOTO: Active OTA TEST Passive TEST Z Y X Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 4 of 15 Form No.：CR-TE-035/C 1.3 Critical component list: No Component Trade mark Model No. Technical parameters Remark 1 antenna WAC F-RCBT-WT 2400-2500MHz / 2 3 4 5 6 7 8 9 10 11 Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 5 of 15 Form No.：CR-TE-035/C 1.4 Test equipment list: No Equipment Manufacture Model No. Serial No. Calibration due date Used 1 Shielding room zhongkeguoji 5*5*3.7 AC3400 2026-01-13 2 SISO RF BOX zhongkeguoji Z9908A-N03 Z9908A-N03 2026-01-13 3 SISO High speed switch box zhongkeguoji Z9908A-N02 Z9908A-N02- 24 2026-01-13 4 24 antenna probe zhongkeguoji Z9810A Z9810A-24 2026-01-13 5 Comprehensive test instrument Rohde & Schwarz CMW500 CMW500 2026-01-13 6 network analyzer Rohde & Schwarz ZNL ZNL6 2026-01-13 7 Communication antenna zhongkeguoji -- -- 2026-01-13 8 6dB attenuator Shuxi tongxun MTA2-6-18-4T 21091306 2026-01-13 9 10dB attenuator Shuxi tongxun MTA2-10-18-4T 21091305 2026-01-13 Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 6 of 15 Form No.：CR-TE-035/C 1.5 Test condition: No Project Condition 1 Ambient condition Ambient temperature: (22±2 ) °C ; Relative humidity≤75 % 2 Voltage Nominal Voltage: +/- 2% 3 Frequency Nominal Frequency: +/- 2% 4 THD Total Harmonic Distortion: 5% max Remark: Unless specified otherwise in the individual Methods, the tests shall be conducted under the above environmental conditions. Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 7 of 15 Form No.：CR-TE-035/C 1.6 Test standard： No Standard No. Description Used 1 UL8750 Light Emitting Diode (LED) Equipment for Use in Lighting Products 2 YD/T 1484.1 Measurement method for radiated RF power and receiver performance of wireless device. Part 1：General requirement 3 CWG OTA Test Plan Test Plan for RF Performance Evaluation of Wi-Fi® Mobile Converged Devices 4 IEEE Standard Test Procedures for antennas IEEE Standard Test Procedures for Antennas 6 7 8 9 10 11 12 13 14 15 Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 8 of 15 Form No.：CR-TE-035/C 1.7 Test sample(s) information: Model No. Input CC CV Output CC CV Voltage Vac Vdc Frequency (Hz) Current (A) Power (W) Power Factor Voltage Vac Vdc Frequency (Hz) Current (mA) Power (W) Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Te l : + 8 6-769-87311200 Fax: +86-769-87311250 Page 9 of 15 Form No.：CR-TE-035/C 1.8 Revision Summary： Date Project Handler Section Description of Change N/A None Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, China 523653 Tel: +86-769-87311200 Fax: +86-769-87311250 Page 10 of 15 Form No.：CR-TE-035/C 2.3 Passive OTA : Reference standard: IEEE Standard Test Procedures for antennas; Method: The prototype (antenna) under test does not provide a signal source, but is fed by the network analyzer. The signal returns to the network analyzer through the antenna under test and the measuring antenna to form a test loop. Tests were performed at 22±2 °C ambient. Take down the communication antenna, connect the cable with the antenna through the adapter (a 6dB attenuator is connected in the middle), place the antenna to be tested on the turntable, and align the phase center with the laser. Requirements: Bluetooth devices typically achieve an antenna gain in the range of –10 dBi to +10 dBi. Report No.: FCC2508001 TEST LAB OF WAC LIGHTING (DONGGUAN) CO.LTD Address: No.390 Qingfeng Rd, Qingxi Town, Dongguan City, Guangdong, C…

Text truncated - open the document above for the full version.

The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Radio Test Report Report No.:STS2512474W01 Issued for WAC Lighting Co No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Product Name: Modern forms G3 Remote Brand Name: MODERN FORMS,WAC,SCHONBEK Model Name: F-RCBT-WT Series Model(s): RC20-WT,SF-RCBT-WT FCC ID: 2APNFWAC000008 Test Standards: FCC Part15.247 Page 2 of 58 Report No.: STS2512474W01 TEST REPORT Applicant’s Name ................. : WAC Lighting Co Address ................................. : No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Manufacturer's Name .......... : WAC Lighting Co Address ................................. : No.390 Qingfeng RD, Qingxi TW, Dongguan City, Guangdong Province ,China Product Description Product Name ....................... : Modern forms G3 Remote Brand Name .......................... : MODERN FORMS,WAC,SCHONBEK Model Name .......................... : ... : F-RCBT-WT Series Model(s) .................... : RC20-WT,SF-RCBT-WT Test Standards ..................... : FCC Part15.247 Test Procedure ...................... : ANSI C63.10-2020 This device described above has been tested by STS, the test results show that the equipment under test (EUT) is in compliance with the IC requirements. And it is applicable only to the tested sample identified in the report. The test results presented in this report relate only to the object tested. This report shall not be reproduced, except in full, without the written approval of the Shenzhen STS Test Services Co., Ltd. Date of Test ........................................... : Date of receipt of test item ..................... : 2025-12-15 Date (s) of performance of tests ............. : 2025-12-15 to 2025-12-24 Date of Issue .......................................... : 2025-12-24 Test Result.............................................. : Pass Testing Engineer : (Aaron Bu) Technical Manager : (Skylar Li) Authorized Signatory : (Bovey Yang) Page 3 of 58 Report No.: STS2512474W01 Table of Contents Page 1. SUMMARY OF TEST RESULTS 6 1.1 TEST FACTORY 7 1.2 MEASUREMENT UNCERTAINTY 7 2. GENERAL INFORMATION 8 2.1 GENERAL DESCRIPTION OF THE EUT 8 2.2 DESCRIPTION OF THE TEST MODES 9 2.3 TEST SOFTWARE AND POWER LEVEL 10 2.4 BLOCK DIAGRAM SHOWING THE CONFIGURATION OF SYSTEM TESTED 10 2.5 DESCRIPTION OF NECESSARY ACCESSORIES AND SUPPORT UNITS 10 2.6 EQUIPMENTS LIST 11 RF RADIATION TEST EQUIPMENT 11 3. EMC EMISSION TEST 12 3.1 CONDUCTED EMISSION MEASUREMENT 12 3.2 TEST PROCEDURE 13 3.3 TEST SETUP 13 3.4 EUT OPERATING CONDITIONS 13 3.5 TEST RESULTS 13 4. RADIATED EMISSION MEASUREMENT 14 4.1 RADIATED EMISSION LIMITS 14 4.2 TEST PROCEDURE 16 4.3 TEST SETUP 17 4.4 EUT OPERATING CONDITIONS 17 4.5 FIELD STRENGTH CALCULATION 18 4.6 TEST RESULTS 19 5. CONDUCTED SPURIOUS & BAND EDGE EMISSION 26 5.1 LIMIT 26 5.2 TEST PROCEDURE 26 5.3 TEST SETUP 26 5.4 EUT OPERATION CONDITIONS 26 5.5 TEST RESULTS 26 6. POWER SPECTRAL DENSITY TEST 27 6.1 LIMIT 27 6.2 TEST PROCEDURE 27 Page 4 of 58 Report No.: STS2512474W01 Table of Contents Page 6.3 TEST SETUP 27 6.4 EUT OPERATION CONDITIONS 27 6.5 TEST RESULTS 27 7. BANDWIDTH TEST 28 7.1 LIMIT 28 7.2 TEST PROCEDURE 28 7.3 TEST SETUP 28 7.4 EUT OPERATION CONDITIONS 28 7.5 TEST RESULTS 28 8. PEAK OUTPUT POWER TEST 29 8.1 LIMIT 29 8.2 TEST PROCEDURE 29 8.3 TEST SETUP 29 8.4 EUT OPERATION CONDITIONS 29 8.5 TEST RESULTS 29 9. ANTENNA REQUIREMENT 30 9.1 STANDARD REQUIREMENT 30 9.2 EUT ANTENNA 30 APPENDIX 1-TEST DATA 31 APPENDIX 2- EUT TEST PHOTO 58 Page 5 of 58 Report No.: STS2512474W01 Revision History Rev. Issue Date Report No. Effect Page Contents 00 2025-12-24 STS2512474W01 ALL Initial Issue Page 6 of 58 Report No.: STS2512474W01 1. SUMMARY OF TEST RESULTS Test procedures according to the technical standards: KDB 558074 D01 15.247 Meas Guidance v05r02. FCC Part 15.247,Subpart C Standard Section Test Item Judgment Remark 15.207 Conducted Emission N/A 3 -- 15.247 (a)(2) 6dB Bandwidth PASS -- 15.247 (b)(3) Output Power PASS -- 15.209 Radiated Spurious Emission PASS -- 15.247 (d) Conducted Spurious & Band Edge Emission PASS -- 15.247 (e) Power Spectral Density PASS -- 15.205 Restricted bands of operation PASS -- Part 15.247(d)/ Part 15.209(a) Band Edge Emission PASS -- 15.203 Antenna Requirement PASS -- Note: (1) ‘N/A’ denotes test is not applicable in this Test Report. (2) All tests are according to ANSI C63.10-2020. (3) The EUT is powered by the DC only, the test item is not applicable. Page 7 of 58 Report No.: STS2512474W01 1.1 TEST FACTORY SHENZHEN STS TEST SERVICES CO., LTD Add. : 101, Building B, Zhuoke Science Park, No.190 Chongqing Road, ZhanChengShequ, Fuhai Sub-District, Bao’an District, Shenzhen, Guang Dong, China FCC test Firm Registration Number: 625569 IC test Firm Registration Number: 12108A A2LA Certificate No.: 4338.01 1.2 MEASUREMENT UNCERTAINTY The reported uncertainty of measurement y ± U, where expended uncertainty U is based on a standard uncertainty multiplied by a coverage factor of k=2, providing a level of confidence of approximately 95 %. No. Item Uncertainty 1 RF output power, conducted ±0.751dB 2 Unwanted Emissions, conducted ±2.888dB 3 All emissions, radiated 9K-30MHz ±2.48dB 4 All emissions, radiated 30M-1GHz ±2.52dB 5 All emissions, radiated 1G-18GHz ±3.48dB 6 All emissions, radiated>18GHz ±4.18dB 7 Conducted Emission (9KHz-150KHz) ±2.48dB 8 Conducted Emission (150KHz-30MHz) ±2.52dB 9 Occupied Channel Bandwidth ±3.6% 10 Power Spectral Density, conducted ±1.214dB 11 Duty Cycle ±3.2% Page 8 of 58 Report No.: STS2512474W01 2. GENERAL INFORMATION 2.1 GENERAL DESCRIPTION OF THE EUT Product Name Modern forms G3 Remote Brand Name MODERN FORMS,WAC,SCHONBEK Model Name F-RCBT-WT Series Model(s) RC20-WT,SF-RCBT-WT Model Difference The main…

Text truncated - open the document above for the full version.
