2APNX00TCBAC2Newline Chromebox A10

Newline Chromebox A10 Commercial Computing Device Model: TCB-AC2 User Guide Doc Version 1 Date Mar. 2020 Table of Contents Disposal Instructions .................................................. 2 Copyright ...................................................................... 5 Disclaimer ..................................................................... 5 1. Safety Instructions ...................................................... 6 ENERGY STAR Certification.......................................... 7 Risk of Overheating ...................................................... 8 2. Packing List ................................................................. 9 2-1. Standard Accessories ............................................ 9 3. Product Introduction ................................................... 10 3-1. Getting started ....................................................... 10 3-2. External View .......................................................... 12 3-3. Dimensions ............................................................. 14 3-4. Knowing your Newline Chromebox A10...................... 15 4. Contact Information..................................................... 21 5. Chrome care................................................................. 22 1 Disposal Instruction (US) For conservation purposes, please do not throw this electronic device into the municipal trash bin when discarding. To minimize pollution of our environment, please recycle this product. 廃棄上の指示 より良い地球保護のために、電子機器を廃棄処分にする時は、ゴミ箱に捨てないで下さい。汚染 を最小限に抑え、地球環境の最大限の保護のために、製品をリサイクルして下さい。 廢棄及回收處理 為了保護環境，請勿將本產品當作一般廢棄物處理。為減少環境污染，維護地 球資源，本產品報廢時，請回收本產品。 FCC caution Non-modification Statement: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. This device is restricted to indoor use 2 Instruktion til bortskaffelse (Danish) Af hensyn til vores miljø bedes De ikke bortskaffe denne elektroniske enhed i en almindelig affaldsspand. For at mindske forurening og sikre beskyttelse af miljøet bedes De genbruge produktet. Verwijderingsinstructie (Dutch) Om mogelijke schade aan het milieu of de menselijke gezondheid door ongecontroleerde afvalverwijdering te voorkomen, moet u dit elektronisch product scheiden van andere soorten afval en op een verantwoorde manier recyclen. Verwijder dit product dan ook alstublieft niet samen met ander huishoudelijk afval. Instruction de Disposition (French) Pour une meilleure protection de la terre, ne jetez pas ce dispositif électronique dans la poubelle municipale lors de la disposition. Pour éliminer la pollution et assurer la plus grande protection de l'environnement global, réutilisez s’il vous plaît le produit. Entsorgungsanleitung (German) Zum besseren Schutze unseres Planeten, schmeissen Sie elektrische Geräte bitte nicht in öffentliche Mülleimer. Zur Verringerung der Verschmutzung und zur Sicherstellung grösstmöglichen Schutzes der Umwelt recyceln Sie bitte das Produkt. 3 Istruzioni per lo smaltimento (Italian) Per una migliore salvaguardia del nostro pianeta, si prega di non gettare questo dispositivo elettronico nei normali rifiuti al momento dell'eliminazione. Per ridurre al minimo l'inquinamento ed assicurare la massima protezione dell'ambiente, si prega di riciclare il prodotto. Instruksjoner for Resirkulering og Oppsamling (Norweigian) For ĺ beskytte vĺr planet, kast ikke dette elektroniske utstyret sammen med vanlig avfall. For ĺ beskytte vĺr natur og miljř, vennligst resirkuler dette produktet. REEE - Programa de Tratamento de Resíduos de Equipamentos Eléctricos e Electrónicos (Portugese) Para melhor protecção ambiental do nosso planeta terra, não coloque o dispositivo electrónico no receptáculo de lixo municipal. Para minimizar a poluição e garantir protecção máxima do ambiente global, recicle o produto. Instrucciones para depositar los productos electrónicos (Spanish) Para proteger mejor el medio ambiente, por favor, no deposite los productos electrónicos en los contenedores de basura tradicionales. Para reducir la contaminación y proteger el medio ambiente se recomienda que los recicle. Kassering (Swedish) För att bättre värna om vår jord bör denna elektroniska utrustning ej kasseras tillsammans med vanligt avfall. För att minimera mängden föroreningar och så långt som möjligt skydda den globala miljön bör produkten återvinnas. 4 Copyright Copyright of this publication belongs to Newline. Newline reserves the right to change the content of this publication without obligation to notify any party of such changes or revisions. No part of this publication may be reproduced, transcribed, transmitted, translated into any language, and stored in a retrieval system in any form or by any means electronically, mechanically, optically without the prior written permission of Newline Disclaimer Newline makes no warranties or representations, either expressed or implied, with respect to the content herein and specifically disclaims any warranties, merchantability of fitness for any particular purpose. Newline and Newline logos used herein are registered trademarks of Newline All other brand names and trademarks are owned by their respective owners. Copyright © 2020 by Newline. All rights reserved. Chromebox is a trademark of Google LLC. Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in a…

Text truncated - open the document above for the full version.

RF_160, Issue 04 Declaration of Authorization We Name: Newline Interactive Inc. Address: 101 East Park Blvd. Suite 807 City: Plano, TX 75074, Country: USA Declare that: Name Representative of agent: Delia Feng (1) Agent Company name: Cerpass Technology Corporation Address: No.10, Lane 2, Lianfu Street, Luzhu Dist., City: Taoyuan City 33848 Country Taiwan, R.O.C. is authorized to apply for Certification of the following product(s): Product description: Newline Chromebox A10 Type designation: TCB-AC2 Trademark: newline. Validity/ expiry date on our behalf. Date: Mar. 31, 2020 City: TX 75074 Name: Chelsea Wolfe (2) Function: Accounting Manager Signature: . Notes: (1): Required for FCC application (2): For FCC it must be the Grantee Code “owner” or the authorized agent.

FCC, Request for non-disclosure Date: 19-Oct-10 RF_501, Issue 7 Page 1 of 1 Company Name: Newline Interactive Inc. Address: 101 East Park Blvd. Suite 807 City: Plano, TX 75074 Country: USA To: Telefication B.V., Dept. FCC TCB Edisonstraat 12A 6902 PK ZEVENAAR The Netherlands Subject: Request for confidentiality FCC ID: 2APNX00TCBAC2 Reference number: ###### Dear FCC TCB, 1. Long-Term Confidentiality Pursuant to 47 CFR Section 0.459(a) & (b), we hereby requests non-disclosure and confidential treatment of the following materials submitted in support of FCC certification application: Bill(s) of Material Block Diagrams Operational Description Schematic Diagrams Tune-up Procedure Above materials contain secrets, proprietary and technical information, which would customarily be guarded from competitors under 47 CFR, section 0.457(d)(2). Disclosure or publication or any portion of this company confidential material to other parties could cause substantial competitive harm and provide unjustified benefits for competitors. 2. Short-Term Confidentiality (STC) Pursuant to Public Notice DA 04-1705 of the Commission’s policy, in order to comply with the marketing regulations in 47 CFR §2.803 and the importation rules in 47 CFR §2.1204, applicant hereby requests Short-Term Confidential treatment of the following materials (note 1): Internal Photos User’s Manual Test Set-up Photos External Photos Justification: Planned Release Date STC: (notes 2, 3, 4, 5). If no date is given, 45 days from grant date will be used. Date: 2020/03/31 Name and signature of applicant: Chelsea Wolfe Notes: 1) A document or type of document can only have ONE type of confidentiality! 2) Short-Term confidentiality is in principle for 45 days from date of grant; it can be extended max 3 times (total time 180 days max.)! 3) FCC must be informed when marketing begins earlier. 4) Release takes place automatically thus extension must be requested in time. Telefication does not remind you of this! 5) Request for extension or for release must be received by Telefication at least 7 days before date of actual marketing or before expiration of the STC period

規格承認書 Specification for Approval 客 戶： 達豐 Customer 品 名: ANTENNA GY121HT0038-004(MAIN+AUX) Part name 料 號： GY121HT0038-004 Part No. 客戶料號： DQ6121HT001 Customer Part No. Rev.(版本): 01 客戶承認印 CUSTOMER APPROVED BY APPROVAL CHIEF SUPERVISOR Approval No. Model Part No. CHIEF SALES R&D DESIGN ROX Teri JOSN James Date: 2017/02/13 Date: 2017/02/13 驊 陞 科 技 股 份 有 限 公 司 WIESON TECHNOLOGIES CO., LTD. 表格編號：324012 版本: 第四版 WIESON TECHNOLOGIES CO., LTD. SPECIFICATION LIST TYPE OF PRODUCT ANTENNA GY121HT0038-004(MAI N+AUX) ITEM INDEX PAGE 1. THE PRODUCT SPECIFICATION LIST....................................................... 1 2. BILL OF MATERIAL.................................................................................. 2 3. TEST REPORT........................................................................................ 3-15 4. WIESON CERTIFICATE............................................................................. 16 Approvals Rev Date Description Edited by Prepared : James 01 2017/02/13 NEW ISSUE James Checked : ROX Approved : ROX Issued No : 01 Sheet : 1 OF 16 No part of the information shown of this document may be used in any way without office stamp or written consent of WIESON TECHNOLOGIES CO., LTD. WIESON TECHNOLOGIES CO.,LTD BILL OF MATERIAL APPROVED BY:ROX CHECKD BY: JOSN DESIGNED BY: James Cust. 達豐 TITLE ANTENNA GY121HT0038-004(MAIN+AUX) Cust.P/N DQ6121HT001 WIESON P/N GY121HT0038-004 NO. DESCRIPTION SUPPLIER SUPPLIER PART NO. UL NO. AV L QUANTITY REMARK 1 RP-SMA PLUG ,NI-plated surface / / / 1PCS 2 Antenna rod sleeve,Size:7.8*40.5mm(Color: BLACK) / / 1PCS 3 / / 4 / / 5 / / 6 7 / / 8 9 10 11 WIESON TECHNOLOGIES CO., LTD. Page 1 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved WIESON 3D CHAMBER TEST REPORT Customer: 廣達 Project Name: 外置型天線 WIESON P/N: GY121HT0038-004 Antenna Type: 2.4GHz/5GHz Antenna WIESON TECHNOLOGIES CO., LTD. Page 2 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved INDEX. I. Summary ............................................................................................................................................ 3 II. S-Parameter Measurement ................................................................................................................ 3 III. S-Parameter Measurement Result ................................................................................................... 5 IV. The Test Information Anechoic Chamber ........................................................................................ 6 V. Antenna Measurement Photo .......................................................................................................... 10 WIESON TECHNOLOGIES CO., LTD. Page 3 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved Revision History Revision Date Engineer Description A 2017/01/05 MARS GY121HT0038-004 x x x x x No part of the information shown of this document may be used in any way without office stamp or written consent of WIESON TECHNOLOGIES CO., LTD. I. Summary This report to account for the measurement setup and result of the Antenna. The measurement setup includes s-parameter, pattern, and gain measurement. The measured data for Antenna are presented and analysis. II. S-Parameter Measurement A. Reflection coefficient : (a) Instrument：Network Analyzer. (b) Setup： (1) Calibrate the Network Analyzer by one port calibration using O.S.L. calibration kits. (2) Connect the antenna under test to the Network Analyzer. (3) Measure the S11(reflection coefficient) shown in Fig. 1. (4) Generally, the S11 is less than –10dB to ensure the 90% power into antenna and only less than 10% power back to system. WIESON TECHNOLOGIES CO., LTD. Page 4 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved Fig.1 Antenna measured in Network Analyzer WIESON TECHNOLOGIES CO., LTD. Page 5 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved III. S-Parameter Measurement Result 1. WiFi Antenna VSWR-1 Freq(MHz) 2400 2500 5150 5850 VSWR 1.45121.59631.93951.7660 WIESON TECHNOLOGIES CO., LTD. Page 6 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved IV. The Test Information Anechoic Chamber A. Scope This statement of work defines the requirements of a far-field antenna measurement range, which includes (1) One 497.5 cm (W) x 345 cm (H) x 790 cm (L) Antenna Measurement Anechoic Chamber, detailed requirements refer section 2.0 . (2) One Far-field Antenna Measurement System with spinning linear CP measurement capabilities, detailed requirement refer section 3.0 . (3) One broad-band transmitted antenna, detailed requirements refer section 8.0 . (4) One BBHX 9120E standard gain antennas, detailed requirements refer section 9.0 . B. Antenna Measurement Anechoic Chamber Fully anechoic chamber with dimension 497.5 cm in width, 345 cm in height and 790 cm in length. The quiet zone of this Chamber shall be greater than 70 cm @ 0.9 GHz, 50 cm @1.8 GHz, 44 cm @2.4 GHz, 28 cm @5.8 GHz, 16 cm @18 GHz. Contractor should be aware of this anechoic chamber is going to be used for performing far-filed antenna measurement. C. Electrical specifications Frequency Range: 400 MHz to 18 GHz, Quiet zone size: >70 cm @ 0.9 GHz, >50 cm @1.8 GHz, >44 cm @2.4 GHz, >28 cm @5.8 GHz, >16 cm @18 GHz. Quiet zone ripple: < +/- 0.5 dB @1.5~2.4 GHz, < +/- 0.25 dB @2.4~18GHz WIESON TECHNOLOGIES CO., LTD. Page 7 of 13 WIESON TECHNOLOGIES CO., LTD. 驊陞科技 版權所有 © 2011 WIESON All Rights Reserved D. Absorbers We shall design and install proper absorbers on the inner walls of the chamber to guarantee the electrical specifications. However, the absorbers height shall be no less than 24" which enables the space in the chamber to be around 497.5 cm (W) x 345 cm (H) x 790 cm (L). All the absorber used shall meet NRL-8093 fire retardant regulations E. Far-field Antenna Measurement System We shall supply all the hardware and software which ar…

Text truncated - open the document above for the full version.

CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 1 of 22 Photographs of EUT CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 2 of 22 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 19 of 22 Adapter: CHICONY \ A11-065N1A CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 20 of 22 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 21 of 22 Adapter: CHICONY \ A16-090P1A CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 22 of 22

Label & Location

CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 3 of 20 RF Chip CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 4 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 5 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 6 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 7 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 8 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 9 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 10 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 11 of 20 M/B: DA00WJMBAA0 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 12 of 20 CPU CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 13 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 14 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 15 of 20 CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 16 of 20 Memory CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 17 of 20 SSD CERPASS TECHNOLOGY CORP. Report No.: 2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 Page No. : 18 of 20 Wireless: Intel \ 7265NGW

CERPASS TECHNOLOGY CORP. Report No.: TEFE2002144 CERPASS TECHNOLOGY CORP. Issued date : Mar. 20, 2020 T-FD-511-0 V1.0 Page No. : 177 of 179 FCC ID : 2APNX00TCBAC2 13. Radio Frequency Exposure 13.1. Applicable Standards The measurements shown in this test report were made in accordance with the procedures given in FCC Part 2 (Section 2.1091) KDB 447498 IEEE C95.1:2005 13.2. EUT Specification Frequency band (Operating) WLAN: 2412MHz ~ 2462MHz WLAN: 5150MHz ~ 5250MHz WLAN: 5250MHz ~ 5350MHz WLAN: 5470MHz ~ 5725MHz WLAN: 5725MHz ~ 5850MHz Bluetooth: 2402MHz ~ 2480MHz Device category Portable (<20cm separation) Mobile (>20cm separation) Exposure classification Occupational/Controlled exposure General Population/Uncontrolled exposure Antenna diversity Single antenna Multiple antennas Tx diversity Rx diversity Tx/Rx diversity Evaluation applied MPE Evaluation* SAR Evaluation N/A Remark: 1. The maximum conducted output power is 16.93dBm (49.354mW) at 5755MHz (with 1.59 dBi antenna gain.) 2. DTS device is not subject to routine RF evaluation; MPE estimate is used to justify the compliance. 3. For mobile or fixed location transmitters, no SAR consideration applied. The maximum power density is 1.0 mW/cm 2 even if the calculation indicates that the power density would be larger. 13.3. Test Results No non-compliance noted. CERPASS TECHNOLOGY CORP. Report No.: TEFE2002144 CERPASS TECHNOLOGY CORP. Issued date : Mar. 20, 2020 T-FD-511-0 V1.0 Page No. : 178 of 179 FCC ID : 2APNX00TCBAC2 13.4. Calculation Given d GP E   30 & 3770 2 E S Where E = Field strength in Volts / meter P = Power in Watts G = Numeric antenna gain d = Distance in meters S = Power density in milliwatts / square centimeter Combining equations and re-arranging the terms to express the distance as a function of the remaining variables yields: 2 3770 30 d GP S   Changing to units of mW and cm, using: P (mW) = P (W) / 1000 and d (cm) = d(m) / 100 Yields   2 2 0796.0 100/3770 1000/30 d GP d GP S      Equation 1 Where d = Distance in cm P = Power in mW G = Numeric antenna gain S = Power density in mW / cm 2 CERPASS TECHNOLOGY CORP. Report No.: TEFE2002144 CERPASS TECHNOLOGY CORP. Issued date : Mar. 20, 2020 T-FD-511-0 V1.0 Page No. : 179 of 179 FCC ID : 2APNX00TCBAC2 13.5. Maximum Permissible Exposure Channel Frequency (MHz) Max. Conducted output power (dBm) Antenna gain (dBi) Distance (cm) Power density (mW/cm 2 ) Limit (mW/cm 2 ) 5180-5240 15.65 2.52 20 0.013 1 5260-5320 15.95 2.52 20 0.014 1 5500-5700 16.45 2.02 20 0.014 1 5745-5825 16.93 1.59 20 0.014 1 Maximum Permissible Exposure (Co-location) BT+Wifi 2.4G Modulation Type Channel Frequency (MHz) Max. Conducted output power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) MPE Ratio 11n HT20 2412-2462 23.64 3.53 20 0.104 1.000 0.104 GFSK 2402-2480 4.94 3.53 20 0.001 1.000 0.001 Co-location Total 0.105 ∑MPE ratios Limit 1 BT+Wifi 5G Modulation Type Channel Frequency (MHz) Max. Conducted output power (dBm) Antenna Gain (dBi) Distance (cm) Power Density (mW/cm 2 ) Limit (mW/cm 2 ) MPE Ratio 11ac VHT40 5745-5825 16.93 1.59 20 0.014 1.000 0.014 GFSK 2402-2480 4.94 3.53 20 0.001 1.000 0.001 Co-location Total 0.015 ∑MPE ratios Limit 1

CERPASS TECHNOLOGY CORP. Report No.: TEFU2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 T-FD-503-0 Ver 1.0 Page No. : 1 of 27 FCC ID. : 2APNX00TCBAC2 FCC RADIO TEST REPORT Applicant : Newline Interactive Inc. Address : 101 East Park Blvd. Suite 807 Plano, TX 75074, USA Equipment : Newline Chromebox A10 Model No. : TCB-AC2 Trade Name : FCC ID. : 2APNX00TCBAC2 I HEREBY CERTIFY THAT : The sample was received on Apr. 15, 2019 and the testing was carried out on Jun. 08, 2019 at Cerpass Technology Corp. The test result refers exclusively to the test presented test model / sample. Without written approval of Cerpass Technology Corp., the test report shall not be reproduced except in full. Approved by: Mark Liao / Supervisor Laboratory Accreditation: Cerpass Technology Corporation Test Laboratory CERPASS TECHNOLOGY CORP. Report No.: TEFU2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 T-FD-503-0 Ver 1.0 Page No. : 2 of 27 FCC ID. : 2APNX00TCBAC2 Contents 1. Summary of Test Procedure and Test Results ................................................................................. 4 1.1 Applicable Standards ................................................................................................................. 4 2. Test Configuration of Equipment under Test ................................................................................... 5 2.1 Feature of Equipment under Test ............................................................................................... 5 2.2 Test Mode and Test Software ..................................................................................................... 6 2.3 Description of Test System ......................................................................................................... 6 2.4 General Information of Test ........................................................................................................ 7 2.5 Measurement Uncertainty .......................................................................................................... 8 3. Test Equipment and Ancillaries Used for Tests ............................................................................... 9 4. Test of AC Power Line Conducted Emission ................................................................................. 10 4.1 Test Result and Data ................................................................................................................ 10 4.2Test Photographs ........................................................................................................................... 14 5. Test of Spurious Emission (Radiated) ............................................................................................ 15 5.1 Test Limit .................................................................................................................................. 15 5.2 Test Procedures ....................................................................................................................... 15 5.3 Typical Test Setup .................................................................................................................... 16 5.4 Test Result and Data (9kHz ~ 30MHz) ..................................................................................... 17 5.5 Test Result and Data (30MHz ~ 1GHz) .................................................................................... 17 5.6 Test Result and Data (1GHz ~ 40GHz) .................................................................................... 21 5.7 Restricted Bands of Operation ................................................................................................. 25 5.8 Test Photographs (30MHz ~ 1GHz) ......................................................................................... 26 5.9 Test Photographs (1GHz ~ 40GHz) ......................................................................................... 27 CERPASS TECHNOLOGY CORP. Report No.: TEFU2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 T-FD-503-0 Ver 1.0 Page No. : 3 of 27 FCC ID. : 2APNX00TCBAC2 History of this test report Report No. Issue Date Description TEFU2002144 Mar. 20, 2020 Original Report Type Description □ Original report NA ■ Derivative Report This sample provided has been confirmed to be identical to the original report sample. The only difference are as listed below. As it doesn’t affect the test result, the original report number: TEFU1903256 and content will be used. 1.Applicant information change. 2.Model No. change. 3.Trade Name change. CERPASS TECHNOLOGY CORP. Report No.: TEFU2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 T-FD-503-0 Ver 1.0 Page No. : 4 of 27 FCC ID. : 2APNX00TCBAC2 1. Summary of Test Procedure and Test Results 1.1 Applicable Standards ANSI C63.4:2014 ANSI C63.10:2013 FCC Rule . Description of Test Result 15.203 . CO-LOCATION PASS *The principle of judgment is made according to the laboratory’s reporting control and measurement uncertainty standard procedures. *This EUT has been also tested and compiled with the requirement of FCC Part 15, Subpart B, recorded in a separate test report(TEFD1901352). CERPASS TECHNOLOGY CORP. Report No.: TEFU2002144 Cerpass Technology Corp. Issued Date : Mar. 20, 2020 T-FD-503-0 Ver 1.0 Page No. : 5 of 27 FCC ID. : 2APNX00TCBAC2 2. Test Configuration of Equipment under Test 2.1 Feature of Equipment under Test WLAN Module Intel / Dual Band Wireless-AC 7265(Stone Peak) Frequency Range BT / BLE: 2400-2483.5MHz 802.11b/g/n: 2400-2483.5MHz 802.11a/n/ac: 5150-5250MHz, 5250-5350MHz, 5470-5725MHz, 5725-5850MHz Modulation Type BT: GFSK, π/4-DQPSK, 8DPSK BLE: GFSK 802.11b: CCK, DQPSK, DBPSK 802.11g/n/a: BPSK, QPSK, 16QAM, 64QAM 802.11ac: BPSK, QPSK, 16QAM, 64QAM, 256QAM Data Rate BT: GFSK: 1Mbps, π/4-DQPSK: 2Mbps, 8DPSK: 3Mbps BLE: GFSK: 1Mbps WLAN: 802.11b: 1, 2, 5.5, 11Mbps 802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps 802.11n: MCS0 – MCS15, HT20/40 802.11a…
