2APP6AG-10SELECTRIC GUITAR AMP

AG-10S英文说明书 70g书写纸黑色印刷 1.5.03.0289100 20240319 邓丽颖 文件编号设计师审核人 AROMA-RD-BZ-02 核准人 A0 版本 AG-10S英文说明书 李承龙易 华 2023 ELECTRIC GUITAR AMP AG-10S SAFETY INSTRUCTIONS PANEL FUNCTION 5" loud speaker, 10W With analog DISTROTION and CLEAN tone Bluetooth inside for convenient connection with your smart phones or other devices with bluetooth function With headphone jack Location Using the unit in the following locations can result in a malfunction. ●Locations of extreme temperature or humidity ●Excessively dusty or dirty locations ●Locations of excessive vibration ●Close to magnetic fields Power supply Be sure to turn the power OFF when the unit is not in use. Please connect the designated AC adapter to an AC outlet of the correct voltage. Do not connect it to an AC outlet of voltage other than that for which your unit is intended. Interference with other electrical devices Radios and televisions placed nearby may experience reception interference. Operate this unit at a suitable distance from radios and televisions. Handling To avoid breakage, do not apply excessive force to the switches or controls. Care If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not use liquid cleaners such as benzene or thinner, or cleaning compounds of flammable polishes. Keeping foreign matter out of your equipment Never set any container with liquid in it near this equipment. If liquid gets into the equipment, it could cause a breakdown, fire, or electrical shock. Be careful not to let metal objects get into the equipment. Keep this manual After reading this manual, please keep it for later reference. FEATURES HOW TO USE After connecting the instrument, adjust each knob to the appropriate position, the adjustable knobs are as follows. ①DISTROTION GAIN With higher gain, the overdrive will be harder. ②CLEAN/DISTROTION Change the signal between clean and distrotion. ③VOLUME Turn the knob to change the volume. ④ BASS This controls the low frequancy. ⑤ TREBLE This controls the high frequancy. PANEL CONTROL MADE IN CHINA 512*176mm 风琴4折，英文在上 BLUETOOTH FUNCTION Connect bluetooth, press and hold button” ”. The blue indicator will be on, which means the bluetooth turned on. The amp name is“AG-10S". A beep sound“Di”will be gendered when bluetooth connection succeed. * Playing music from bluetooth, the volume can only be adjusted by external device. SPECIFIATIONS 1 ------------ 6.35mm INPUT 2 ------------ DISTROTION/CLEAN 3 ------------ GAIN 4 ------------ BASS 5 ------------ TREBLE 6 ------------ VOLUME 7 ------------ LED INDICATOR 8 ------------ BLUETOOTH 9 ------------ POWER SWITCH 10 ----------- POWER JACK 11 ----------- 3.5mm HEADPHONE JACK AG-10S 1 2 3 4 5 6 7 8 THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES OPERATION IS SUBJECTTO THE FOLLOWING TWO CONDITIONS(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Contains Transmitter Module 210-207398 FCC ID: 2APP6AG-10S 12V 1.5A AG-10S 9 10 11 AG-10S THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES OPERATION IS SUBJECTTO THE FOLLOWING TWO CONDITIONS(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, (2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED,INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. Contains Transmitter Module 210-207398 FCC ID: 2APP6AG-10S 12V 1.5A AG-10S 版本 A0初版发行 A1更新FCC说明，删除UKCA标识 变更记录 Input jack: 6.35mmx1 Tone switch: CLEAN, DISTROTION Volume: CLEAN volume, DISTROTION volume Gain: DISTROTION gain EQ: BASS, TREBLE Headphone jack: 3.5mm stereo output Peak output: 10W Speaker: 5" loud speaker Bluetooth version: 5.0 Power: 12V 1.5A Dimension: 238x228x151mm Weight: 2.4kg FCC Statement Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: -- Reorient or relocate the receiving antenna. -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions (1)this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

Aroma Music Co., Ltd. Covered Equipment Certification Attestation Letter 3/22/2024 Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA A TTN.: Reviewing Engineer FCC ID: 2APP6AG-10S Aroma Music Co., Ltd.(“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. N ote: If the equipment for which the applicant seeks authorization is produced by any of the entities identified on the current Covered List, the applicant should include an explanation on why the equipment is not “covered” equipment. A roma Music Co., Ltd.(“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Signed: Printed name: hua Yi Title: Engineering Manager Company Name: Aroma Music Co., Ltd. Date: 3/22/2024

Aroma Music Co., Ltd. U.S. Agent Designation for Service of Process (Applicant and U.S. Agent are Separate Parties) TO: Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 ATTENTION: FCC Certification – Section 2.911(d)(7) Information Designated U.S. Agent Company Name: Baihetian Innovative Solutions FRN: 0033401605 Contact Name: Kenneth Young Street Address: 6837 Chase Rd City/Province/Zip: Dearborn, MI 48126 Telephone No: 313-395-3113 Email: [email protected] This letter is to confirm that we (“Baihetian Innovative Solutions) have accepted the responsibility to act as the Designated U.S. Agent for Service of Process as required by section 47 CFR 2.911(d)(7) on behalf of the Applicant noted below. U.S. Agent Signature: Date: Mar 26, 2024 Signed by (Printed Name/Title): Kenneth Young/Manager The Applicant acknowledges that they must maintain an agent for no less than one year after terminating all marketing and importation OR the conclusion of any Commission-related proceeding involving the equipment. The applicant further acknowledges their responsibility to inform the FCC whenever the Designated U.S. Agent information above changes. Applicant Company name: Aroma Music Co., Ltd. Grantee Code: 2APP6 FRN: 0027496876 Contact Name: hua Yi Street Address: 203, No. 93 Qianjin 2nd Road, Area 81, Hexi Neighbourhood, Xixiang Town, Baoan District City/Province/Zip: Shenzhen City, Guangdong, 518000 China Telephone No: +86-0755-27331944 Email: [email protected] Applicant Signature: Date:2024-03-22 Signed by (Printed Name/Title): hua Yi/ Engineering Manager FCC ID：2APP6AG-10S Mar 2024

Aroma Music Co., Ltd. 2024-03-22 Federal Communications Commission Authorization & Evaluation Division 7345 Oakland Mills Road Columbia, Maryland 21046 Authority to Act asAgent On our behalf, I appoint SHENZHEN TONGCE TESTING LAB / 2101 & 2201, Zhenchang Factory Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China (Name of Agent company name andaddress) to act as our agent in the preparation of this application for equipment certification. I certify that submitted documents properly describe the device or system for which equipment certification is sought. I also certify that each unit manufactured, imported or marketed, as defined in the Federal Communications Commission’s regulations will have affixed to it a label identical to that submitted for approval with this application. Forinstanceswhereourauthorizedagentsignstheapplicationforcertificationonourbehalf,Iack nowledgethatallresponsibilityforcomplyingwiththetermsandconditionsforcertification,stillres ideswith Aroma Music Co., Ltd. / 203, No. 93 Qianjin 2nd Road, Area 81, Hexi Neighbourhood, Xixiang Town, Baoan District, Shenzhen City, Guangdong, 518000 China (Applicant Nameandaddress) < Signature> Na me: hua Yi Title: Engineering Manager Applicant Company: Aroma Music Co., Ltd.

Aroma Music Co., Ltd. 2024-03-22 Equipment Autorisation Division Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 FCC ID: 2APP6AG-10S Product Name: ELECTRIC GUITAR AMP Request for Confidentiality Pursuant to Sections 0.457 and 0.459 of the commiss ions rules, we hereby request that the following documents be held confidential: •Sc hematics •Block diagram •Operation description Thes e materials contain trade secrets and proprietary information and are not customarily released to the public. The public disclosure of this information might be harmful to the company and provide unjustified benefits to our competitors. <S ignature> Nam e: hua Yi Title: Engineering Manager Company: Aroma Music Co., Ltd.

Aroma Music Co., Ltd. 203, No. 93 Qianjin 2nd Road, Area 81, Hexi Neighbourhood, Xixiang Town, Baoan District, Shenzhen City, Guangdong, 518000 China Statement Product: ELECTRIC GUITAR AMP Model: AG-10S Additional Model: Fazley Kubo BT 10, FAM-10, SG-10, EG-10, JG-10S, HG-10S, GA-10S, GG-10S, ZG-10S, MG-10S, NJ-10S, DG-10S, LG-10S, WG-10S Trademark : N/A We hereby state that AG-10S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of AG-10S can represent the remaining models. Your assistance on this matter is highly appreciated. Y ours sincerely, S ignature: Date: 2024/04/03 N ame: hua Yi Company Name: Aroma Music Co., Ltd. Address: 203, No. 93 Qianjin 2nd Road, Area 81, Hexi Neighbourhood, Xixiang Town, Baoan District, Shenzhen City, Guangdong, 518000 China Tel / Fax: +86-0755-27331944/+86-0755-29770452 E- Mail: [email protected]

Page 1 of 4 Appendix C: Photographs of EUT Product: ELECTRIC GUITAR AMP Model: AG-10S External Photos Page 2 of 4 Page 3 of 4 Page 4 of 4

LabelArtworkandLocation Model:AG-10S Label: Size:L*W=199*54.5mm Location

Page 1 of 3 Appendix C: Photographs of EUT Product: ELECTRIC GUITAR AMP Model: AG-10S Internal Photos Antenna Page 2 of 3 Page 3 of 3

Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com TEST REPORT FCC ID. ............................ : 2APP6AG-10S Test Report No. ............... : TCT240311E040 Date of issue ................... : Mar. 19, 2024 Testing laboratory .......... : SHENZHEN TONGCE TESTING LAB Testing location/ address: 2101 & 2201, Zhenchang Factory, Renshan Industrial Zone, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, 518103, People's Republic of China Applicant's name ............ : Aroma Music Co., Ltd. Address ........................... : 203, No. 93 Qianjin 2nd Road, Area 81, Hexi Neighbourhood, Xixiang Town, Baoan District, Shenzhen City, Guangdong, 518000 China Manufacturer's name ... : Aroma Technology Co., Limited Address ........................... : Building A, Aroma Park, Guwu Village, Danshui Town, Huiyang District, Huizhou, Guangdong 516200 China Standard(s) ..................... : FCC CFR Title 47 Part 1.1307 Test item description ..... : ELECTRIC GUITAR AMP Trade Mark ...................... : N/A Model/Type reference..... : AG-10S, Fazley Kubo BT 10, FAM-10, SG-10, EG-10, JG-10S, HG-10S, GA-10S, GG-10S, ZG-10S, MG-10S, NJ-10S, DG-10S, LG-10S, WG-10S Rating(s).......................... : Refer to EUT description of page 3 Date of receipt of test item ......................................... : Mar. 11, 2024 Date (s) of performance of test ................................... : Mar. 11, 2024 ~ Mar. 19, 2024 Tested by (+signature) ... : Ronaldo LUO Check by (+signature) .... : Beryl ZHAO Approved by (+signature): Tomsin General disclaimer: This report shall not be reproduced except in full, without the written approval of SHENZHEN TONGCE TESTING LAB. This document may be altered or revised by SHENZHEN TONGCE TESTING LAB personnel only, and shall be noted in the revision section of the document. The test results in the report only apply to the tested sample. Report No.: TCT240311E040 Page 2 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com Table of Contents 1. General Product Information .................................................................. 3 1.1. EUT description ..................................................................................................... 3 1.2. Model(s) list ............................................................................................................ 3 2. General Information ................................................................................. 4 2.1. Test environment and mode ................................................................................. 4 2.2. Description of Support Units ................................................................................ 4 3. Facilities and Accreditations .................................................................. 5 3.1. Facilities ................................................................................................................. 5 3.2. Location ................................................................................................................. 5 4. Test Results and Measurement Data ..................................................... 6 Report No.: TCT240311E040 Page 3 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 1. General Product Information 1.1. EUT description Test item description ........... : ELECTRIC GUITAR AMP Model/Type reference........... : AG-10S Sample Number....................: TCT240311E039-0101 Operation Frequency ........... : 2402MHz~2480MHz Modulation Type ................... : GFSK, π/4-DQPSK, 8DPSK Antenna Type ........................ : PCB Antenna Antenna Gain ........................ : -0.58dBi Rating(s)................................ : Adapter Information: MODEL: GM53-120150-F INPUT: AC 100-240V, 50/60Hz, 2.0A OUTPUT: DC 12.0V, 1.5A, 18.0W Note: The antenna gain listed in this report is provided by applicant, and the test laboratory is not responsible for this parameter. 1.2. Model(s) list No. Model No. Tested with 1 AG-10S Other models Fazley Kubo BT 10, FAM-10, SG-10, EG-10, JG-10S, HG-10S, GA-10S, GG-10S, ZG-10S, MG-10S, NJ-10S, DG-10S, LG-10S, WG-10S Note: AG-10S is tested model, other models are derivative models. The models are identical in circuit and PCB layout, only different on the model names. So the test data of AG-10S can represent the remaining models. Report No.: TCT240311E040 Page 4 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 2. General Information 2.1. Test environment and mode Item Normal condition Temperature +25ºC Voltage AC 120V/60Hz Humidity 56% Atmospheric Pressure: 1008 mbar Test Mode: Engineering mode: Keep the EUT in continuous transmitting by select channel 2.2. Description of Support Units The EUT has been tested as an independent unit together with other necessary accessories or support units. The following support units or accessories were used to form a representative test configuration during the tests. Equipment Model No. Serial No. FCC ID Trade Name / / / / / Note: 1. All the equipment/cables were placed in the worst-case configuration to maximize the emission during the test. 2. Grounding was established in accordance with the manufacturer’s requirements and conditions for the intended use. 3. For conducted measurements (Output Power, 20dB Occupied Bandwidth, Carrier Frequencies Separation, Hopping Channel Number, Dwell Time, Spurious Emissions), the antenna of EUT is connected to the test equipment via temporary antenna connector, the antenna connector is soldered on the antenna port of EUT, and the temporary antenna connector is listed in the Test Instruments. Report No.: TCT240311E040 Page 5 of 6 Hotline: 400-6611-140 Tel: 86-755-27673339 Fax: 86-755-27673332 http://www.tct-lab.com 3. Facilities and Accreditations 3.1. Facilities The test facility is recognized, certified, or accredited by the followin…
