2APQK-SPU027Smart Plug

Smart Plug User Manual Model: SPU027 S1 S2 IP44 • The plug is waterproof to IP44, so avoid immersing or rinsing the socket in water. • Avoid exposure to high temperatures, direct sunlight, or moisture. • The maximum capacity is 1800 W. Any overload may result in a risk of fire or damage to the device. • Keep the device away from heat sources or flammable materials. • Avoid using the device in high-humidity areas like bathrooms. • Do not disassemble. The device does not contain any serviceable parts. In case of a malfunction, please contact the service. • Do not continue to use the device if there is visible damage. • Make sure to use this product together with 15A circuit breaker in the upstream. Safety Information This product is intended as a smart plug to remotely control your home appliances. This product has a power monitor to measure electric power values. This plug complies with the protection class IP44 if the appliance device plug is splash-proof (IP44) as well. Introduction Before use, please ensure the package is complete and undamaged. The package should includes: -Outdoor Smart Plug -User Manual Intended use SPU027 2APQK-SPU027 28612-SPU027 PC+ABS 120V~, 60Hz 15A 1800W -20~40°C IP44 Specifications Android 4.4 & iOS 8.0 and above IEEE 802.11 b/g/n; 2.4 GHz only Up to 300 feet (Open Space) Wi-Fi Connectivity Range Model Number FCC ID IC Material Rated Voltage Max. Load Working Temp Waterproof Rating WPA/WPA2/WPA3 WEP/TKIP/AES Support System Wi-Fi Standard Security Mechanism Encryption Type Power Button: · Press each Power Button to turn the corresponding socket ON or OFF. · Press and hold (for 5 seconds) until the LED flashes to initiate the app onboarding process or switch the indicator flashing state. · Press and hold for 5 seconds while the indicator light is flashing to toggle the flashing state. Device Overview LED Status Indicator Waterproof Cover Power Button Socket S1 S2 1. Search and download Smart Life APP in Google Play Store or APP Store. If you cannot find Smart Life APP, please scan the following QR code. 2. Open the Smart Life APP, create a Smart Life account and log in. If you already have one, please log in directly. 3. Plug the smart plug into the socket. 4. Choose one of the following three connection methods to connect. It is recommended to follow the first one (BLE Mode). Installation Notice: a. Please make sure the distance between the smart plug and the router is within 100ft. b. Before starting the connection, make sure your mobile phone has its Bluetooth turned on and is connected to the 2.4GHz WiFi network only. Step 1. Turn on the Bluetooth of your mobile phone and connect your phone to the 2.4GHz Wi-Fi network. A)BLE Mode(Recommended): Step 2. Connect the plug to the power source and long press any of the power button for more than 5s till the indicator flashes. Step 3. Launch the Smart Life app, the device will be found automatically. Step 4. Tap Add and enter the name and password of the 2.4GHz Wi-Fi network. Step 5. Wait for connection (may take up to 2 minutes). Step1. Connect your phone to the 2.4GHz Wi-Fi Network. Step2. Long press any of the power button for 5s till the indicator flashes slowly(1 time every 2 seconds); If it's flashing quickly, press and hold for 5s to switch to slow flashing mode. Step3. Launch Smart Life APP>Tap Add device >Choose "Socket (Wi-Fi)">Enter the name & password of the 2.4GHz Wi-Fi Network >Tap "Blink Slowly". B) AP Mode Step4. Connect your plug to the hotspot named SmartLife-XXXX or SL-XXXX, and back to Smart Life APP. Step5. Wait for connection (may take up to 2 minutes). Step 1. Connect your phone to the 2.4GHz Wi-Fi Network. Step 2. Long press any of the power button till the indicator flashes quickly (Flashes twice per second). Step 3. Launch the Smart Life app and tap "Add device". C)EZ Mode: Step 4. Choose "Socket (Wi-Fi)" and enter the name and password of the 2.4GHz Wi-Fi Network. Step 5. Tap "Blink Quickly". Step 6. Wait for connection (may take up to 2 minutes). Step 1. Make sure you have connected the plug to the "Smart Life" App first. Step 2. Launch the Smart Life app > Tap "Me" > Third-party service > Follow the app prompts. Third Party Control (Alexa, SmartThings and Google Assistant) 1. Remote control: Turn on/off the device remotely through the mobile phone anytime, anywhere. 2. Timer: a. Schedule: Schedule your smart plug to turn on/off automatically to simplify your daily rountine; b. Countdown: Set the countdown timer and your smart plug will automatically be toggled after the time ends (e.g., 1: turn on/off the plug after 10 mins); c. Delay off: When the device is turned on, it will be automatically turned off at the end of the set time (e.g., 2: turn off the plug after 10 mins); 3. Scene: Turn the plug on/off based on changes in weather, location, or device status, etc. 4. Group Control: The app allows you to control multiple devices at the same time and create groups for easy management. Functions: 5. Device Sharing: Share the control of the outdoor smart plug with your family members. 6. Remote & Voice Control: Tap the corresponding socket button on the app to turn on/off the plug. Alternatively, use a voice command to turn on/off the plug. 7. Power meter function Optional. The integrated power meter allows you to watch both the live and previous power measurements of the smart plug, so you can see how much electricity a product is using or has been using for each day of the last year. 1.Fail to connect to Wi-Fi ·Make sure the distance between the smart plug and the router is within 100ft; ·Check the Wi-Fi connection of the smart plug (Only Support 2.4GHz Wi-Fi); ·Make Sure the Wi-Fi name and password you entered is correct. 2.Device Offline ·Make Sure your Wi-Fi signal is good and stable; ·Check if the Wi-Fi name or password has been changed. ·Try to reset the smart plug. 3.The smart plug can be turned on/off via APP, but the connected device does not work ·Manually turn the plug on/off …

Text truncated - open the document above for the full version.

Rev1/26/2023 ShenzhenCoreImageCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:09-30-2024 Ref:AttestationStatementsPart2.911(d)(5)(i)Filing FCCID:2APQK-SPU027 (“ShenzhenCoreImageCo.,Ltd”)certifiesthattheequipmentforwhichauthorizationissoughtisnot “covered”equipmentprohibitedfromreceivinganequipmentauthorizationpursuanttosection2.903of theFCCrules. Sincerely, JimXu Rev1/26/2023 ShenzhenCoreImageCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 USA Date:10-08-2024 Ref:AttestationStatementsPart2.911(d)(5)(ii)Filing FCCID:2APQK-SPU027 (“ShenzhenCoreImageCo.,Ltd.”)certifiesthat,asofthedateofthefilingoftheapplication,the applicantisnotidentifiedontheCoveredList(asaspecificallynamedentityoranyofitssubsidiariesor affiliates)asanentityproducing“covered” equipment. Sincerely, JimXu

Rev11/20/07 ShenzhenCoreImageCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision ConfidentialityRequestregardingapplicationforcertificationofFCCID:2APQK-SPU027. PursuanttoSections0.457and0.459oftheCommission’sRules,weherebyrequestconfidential treatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName* SchematicDiagram BlockDiagram PartsList OperationalDescription Tune-upProcedure SoftwareSecurityRequirementsforUNII devices SCH.pdf OP.pdf Blockdiagram.pdf Theabovematerialscontaintradesecretsandproprietaryinformationnotcustomarilyreleasedto thepublic.Thepublicdisclosureofthesematerialsmaybeharmfultotheapplicantandprovide unjustifiedbenefitstoitscompetitors. TheapplicantunderstandsthatpursuanttoSection0.457oftheRules,disclosureofthis applicationandallaccompanyingdocumentationwillnotbemadebeforethedateoftheGrant forthisapplication. PursuanttoDA04-1705June15,2004oftheCommission’spublicnotice,wealsorequest temporaryconfidentialtreatmentofinformationaccompanyingthisapplicationasoutlinedbelow: ExhibitTypeFileName* ExternalPhotos TestSetupPhotos InternalPhotos UserManual Sincerely, JimXu

ShenzhenCoreImageCo.,Ltd. Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang, DongfangCommunity,SonggangStreet,Bao'anDistric,Shenzhen. ProductSimilarityDeclaration Date:September29,2024 FCCID:2APQK-SPU027 ModelNumber:SPU027,SPU027A,SPU027B,ET77 To: FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD ToWhomItMayConcern, We,ShenzhenCoreImageCo.,Ltd.herebydeclarethatourproduct(SmartPlug) ModelNumberSPU027,SPU027A,SPU027B,ET77board,Schematic,Hardwareversion, Softwareversion,structureandinternalphotosaresame,onlythemodelnumberis differentduetomarketingpurposes. Shouldyouhaveanyquestionsorcommentsregardingthismatter,pleasehavemybest attention. Sincerely, (Signed) Name:JimXu/Manager Company:ShenzhenCoreImageCo.,Ltd. Address:Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang,Dongfang Community,SonggangStreet,Bao'anDistric,Shenzhen.. Phone:13590446466 Fax:0755-23204136 E-Mail:[email protected]

ShenzhenCoreImageCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:September29,2024 SUBJECT:FCCApplicationfor(2APQK-SPU027) ToWhomItMayConcern: I,theundersigned,herebystatesthisequipmenthasbeentestedandfoundtocomply withthelimitsforaClassBdigitaldevice,pursuanttopart15oftheFCCRules,and willapplytheSupplier'sDeclarationofConformityproceduretotheclassB computerperipheralportionofthiscompositedevice.IunderstandthefollowingFCC requirements: 1.DevicessubjecttotheSDoCprocedurearerequiredtobetestedtoshow compliancewiththeFCCtechnicalregulationsbyarecognizedaccreditedtesting laboratory.ThetestinglaboratorymustbeaccreditedbyaCommissionapproved accreditationbodyordesignatedunderthetermsofagovernment-to-government MutualRecognitionAgreement(MRA).Alistingofthoseaccreditedtesting laboratoriesthathavebeenrecognizedbytheCommissionispublishedontheFCC Webpage:https://apps.fcc.gov/oetcf/eas/reports/TestFirmSearch.cfm(Selectthe "accredited"optiontosearchforFCCrecognizedaccreditedtestfirms.) 2.Pt2.1077containsthelistofinformationthatmustbeincludedintheSupplier's DeclarationofConformity,whichmustbesuppliedwitheachproductsold.The SDoCcomplianceinfoshallbeincludedintheUser’sManualorasaseparate sheet.Theinfomustcontainthename,address,andphonenumberofthe responsibleparty,whichmustbelocatedwithintheUnitedStates.Accordingto 2.909(b),theresponsiblepartyiseithertheManufactureroriftheproductis importedtheImporter. Regards, ShenzhenCoreImageCo.,Ltd -------------------------------

M:\MasterDocuments\TEMPLATES\POA_Letter.doc ShenzhenCoreImageCo.,Ltd. FederalCommunicationsCommission AuthorizationandEvaluationDivision 7435OaklandMillsRoad Columbia,MD21046 Date:September30,2024 SUBJECT:FCCApplicationfor(2APQK-SPU027) ToWhomItMayConcern: We,theundersigned,herebyauthorizeLionCaiatShenzhenBANTEKTestingCo.,Ltd. onourbehalf,toapplytotheFederalCommunicationsCommissiononourequipment. Anyandallactscarriedoutby__ShenzhenBANTEKTestingCo.,Ltd.onourbehalfshall havethesameeffectasactsofourown. ThisistoadvisethatweareinfullcompliancewiththeAnti-DrugAbuseAct.We,the applicant,arenotsubjecttoadenialoffederalbenefitspursuanttoSection5301ofthe Anti-DrugActof1988,21USC853a,andnopartytotheapplicationissubjecttoadenial offederalbenefitspursuanttothatsection. Regards,

ReportNo.:BTEK240913006AE Page: 1 of 4 Appendix EUTPhotos forBTEK240913006AE ReportNo.:BTEK240913006AE Page: 2 of 4 EUTConstructionalDetails(EUTPhotos) EUTView1 EUTView2 EUTView3 ReportNo.:BTEK240913006AE Page: 3 of 4 EUTView4 EUTView5 EUTView6 ReportNo.:BTEK240913006AE Page: 4 of 4 EUTView7 EUTView8 EUTView9

ReportNo.:BTEK240913006AE Page: 1 of 1 LABELANDLOCATION FCCID:2APQK-SPU027

ReportNo.:BTEK240913006AE Page: 1 of 5 Appendix EUTPhotos forBTEK240913006AE ReportNo.:BTEK240913006AE Page: 2 of 5 EUTConstructionalDetails(EUTPhotos) SPU027 EUTView10 EUTView11 EUTView12 ReportNo.:BTEK240913006AE Page: 3 of 5 EUTView13 EUTView14 EUTView15 PCBANT ReportNo.:BTEK240913006AE Page: 4 of 5 EUTView16 EUTView17 EUTView18 ReportNo.:BTEK240913006AE Page: 5 of 5 EUTView19

ReportNo.:BTEK240913006AE003 Page: 1 of 5 TESTREPORT ApplicationNo.:BTEK240913006AE Applicant:ShenzhenCoreImageCo.,Ltd. AddressofApplicant:Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang, Dongfangcommunity,SonggangStreet,Bao'anDistric,Shenzhen. Manufacturer:ShenzhenCoreImageCo.,Ltd. AddressofManufacturer:Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang, Dongfangcommunity,SonggangStreet,Bao'anDistric,Shenzhen. EquipmentUnderTest(EUT): EUTName:SmartPlug TestModel.:SPU027 AddingModel(s):SPU027A,SPU027B,ET77 TradeMark:/ FCCID:2APQK-SPU027 Standard(s): 47CFRPart2SubpartJSection2.1091 447498D01GeneralRFExposureGuidancev06 DateofReceipt: 2024-09-14 DateofTest: 2024-09-18to2024-09-24 DateofIssue: 2024-09-25 TestResult: Pass* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. LionCai/Approved&Authorized EMCLaboratoryManager ReportNo.:BTEK240913006AE003 Page: 2 of 5 RevisionRecord VersionChapterDateModifierRemark V02024-09-25Original Authorizedforissueby: ZoraHuang/ProjectEngineer JuneLi/Reviewer Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbereproduced,exceptin full,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithoutspecificstampoftestinstitute andthesignaturesofcompilerandapprover. ReportNo.:BTEK240913006AE003 Page: 3 of 5 2Contents Page 1CoverPage......................................................................................................................................................................1 2Contents..........................................................................................................................................................3 3GeneralInformation........................................................................................................................................4 3.1DetailsofE.U.T.........................................................................................................................................4 3.2DescriptionofSupportUnits......................................................................................................................4 3.3TestLocation.............................................................................................................................................4 3.4DeviationfromStandards..........................................................................................................................4 3.5AbnormalitiesfromStandardConditions...................................................................................................4 4TestRequirement............................................................................................................................................5 4.1AssessmentResult.....................................................................................................................................5 ReportNo.:BTEK240913006AE003 Page: 4 of 5 3GeneralInformation 3.1DetailsofE.U.T. Powersupply:AC120V15A1800W60Hz 2.4G-Wi-Fi SupportStandards:802.11b,802.11g,802.11n-HT20,802.11n-HT40 FrequencyRange: 2412-2462MHzfor802.11b/g/HT20 2422-2452MHzfor802.11b/g/HT40 TypeofModulation:802.11b:DSSS;802.11g/n:OFDM QuantityofChannels 11for802.11b/g/n(HT20) 9for802.11b/g/n(HT40) ChannelSeparation:5MHz TypeofAntenna:PCBAntenna SampleNo.:BTEK240913006AE-01 BLE FrequencyRange:2402MHzto2480MHz BluetoothVersion:V5.2BLE ModulationType:GFSK NumberofChannels:40 AntennaType:PCBAntenna AntennaGain:-0.14dBi SampleNo.:BTEK240913006AE-01 Remark:Theinformationinthissectionisprovidedbytheapplicantormanufacturer,BANTEKisnot liabletotheaccuracy,suitability,reliabilityor/andintegrityoftheinformation. ModelNo.:SPU027,SPU027A,SPU027B,ET77 OnlythemodelSPU027wastested.Accordingtothedeclarationfromtheapplicant,theelectricalcircuit design,layout,componentsused,internalwiringandfunctionsofothermodelsareidenticalfortheabove models,withonlydifferenceonModelNo. 3.2DescriptionofSupportUnits DescriptionManufacturerModelNo.SerialNo. //// 3.3TestLocation Alltestswereperformedat: ShenzhenBANTEKTestingCo.,Ltd., A5&A6,BuildingB1&B2,No.45GangtouRoad,BogangCommunity,ShajingStreet,Bao'anDistrict, Shenzhen,Guangdong,China518103 Tel:0755-23344200Fax:0755-23344200 FCCRegistrationNumber:264293 DesignationNumber:CN1356 Notestsweresub-contracted. 3.4DeviationfromStandards None 3.5AbnormalitiesfromStandardConditions None ReportNo.:BTEK240913006AE003 Page: 5 of 5 4TestRequirement Acco rdingto§1.1307(b)(1)andKDB447498D01GeneralRFExposureGuidancev06,systemoperating undertheprovisionsofthissectionshallbeoperatinginamannerthatthepublicisnotexposedtoradio frequencyenergylevelinexcesslimitformaximumpermissibleexposure. LimitsforMaximumPermissibleExposure(MPE) Frequencyrange (MHz) Electricfield strength (V/m) Magneticfieldstrength (A/m) Powerdensity (mW/cm 2 ) Averagingtime (minutes) (A)LimitsforOccupational/ControlledExposures 0.3–3.06141.63*(100)6 3.0–301842/f4.89/f*(900/f 2 )6 30–30061.40.1631.06 300–1500f/3006 1500–100,00056 (B)LimitsforGeneralPopulation/UncontrolledExposure 0.3–1.346141.63*(100)30 1.34–30824/f2.19/f*(180/f 2 )30 30–30027.50.0730.230 300–1500f/150030 1500–100,0001.030 f=frequencyinMHz Friistransmissionformula:Pd=(Pout*G)/(4*pi*r 2 ) Where Pd=powerdensityinmW/cm 2 ,Pout=outputpowertoantennainmW; G=gainofantennainlinearscale,Pi=3.1416; R=distancebetweenobservationpointandcenteroftheradiatorincm PdidthelimitofMPE,1mW/cm 2 .Ifweknowthemaximumgainoftheantennaandthetotalpowerinputto theantenna,throughthecalculation,wewillknowthedistancerwheretheMPElimitisreached. 4.1AssessmentResult PassedNotApplicable Frequency (MHz) Type Conducted Power (dBm) MaximumTune- up(dBm) Power Density (mW/cm 2 ) Limit(mW/cm 2) Result 24622.4G-Wi-Fi16.3816.50.01581Pass Frequency (MHz) Type Conducted Power (dBm) MaximumTune- up(dBm) Power Density (mW/cm2) Limit (mW/cm2) Result 2480BLE8.298.50.00251Pass Note:1.Theexposureevaluationsafetydistanceis20cm. 2.Onlyshowtheworstcaseinthetestreport. -EndoftheReport-

ANTENNAREPORT Manufacture：TUYA ProductName：CB2S-JAntenna AntennaType：PCB TestDate：2023.8.10 Testedby：ZhangYinhua Approvedby：Licco Content 1.GeneralDescription.................................................................................1 2.TestConfigurations...................................................................................2 2.1TestEnvironment............................................................................2 2.2TestEquipment...............................................................................2 2.3TestPrinciple...................................................................................2 3.TestResults..............................................................................................3 3.1GainandEfficiency..........................................................................3 3.2RadiationPattern............................................................................4 4.AntennaDimensions................................................................................6 5.EUTPhoto................................................................................................6 6.TestSetupPhoto......................................................................................7 1 1.GeneralDescription ManufacturerHangzhouTuya InformationTechnologyCo.,Ltd Address Room 701,Building3,MoreCenter,No.87GuDunRoad, Hangzhou,Zhejiang,China Test Location Room 106, Building3, LetongSciencePark, No. 500, Qiuyi Road, BinjiangDistrict,Hangzhou ProductNameCB2S-JAntenna Productmodel CB2S-J AntennaType PCB Antenna Test Items Gain ; Efficiency; RadiationPattern Test Frequency 2400-2500MHz Test Standard ANSI/IEEEStd 149-1979 2 2.TestConfigurations 2.1TestEnvironment Temperature(°C)25 Humidity(%RH)60 AtmosphericPressure(kPa)100.5 2.2TestEquipment TestSystemTEM24Multi-probeMicrowaveChamber TestInstrumentAgilentE5071B 2.3TestPrinciple 3 3.TestResults 3.1GainandEfficiency Frequency(MHz)PeakGain(dBi)Efficiency(%) 2400-1.2438.64 2410-1.4136.98 2420-0.939.45 2430-1.1139.54 2440-0.839.54 2450-0.2641.98 2460-1.0439.99 2470-0.2641.98 2480-1.0838.37 2490-0.1443.25 2500-0.2741.78 4 3.2RadiationPattern Phi02D Phi902D Theta902D 5 2400MHz3D 2450MHz3D 2500MHz3D 6 4.AntennaDimensions Unit:mm 5.EUTPhoto 7 6.TestSetupPhoto

ReportNo.:BTEK240913006AE001 Page: 1 of 26 TESTREPORT ApplicationNo.:BTEK240913006AE Applicant:ShenzhenCoreImageCo.,Ltd. AddressofApplicant:Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang, Dongfangcommunity,SonggangStreet,Bao'anDistric,Shenzhen. Manufacturer:ShenzhenCoreImageCo.,Ltd. AddressofManufacturer:Building2ndFloor,No.1HuafengHi-techPark,YangwuKonggang, Dongfangcommunity,SonggangStreet,Bao'anDistric,Shenzhen. EquipmentUnderTest(EUT): EUTName:SmartPlug TestModel.:SPU027 AddingModel(s):SPU027A,SPU027B,ET77 TradeMark:/ FCCID:2APQK-SPU027 Standard(s): 47CFRPart15,SubpartC15.247 KDB558074D0115.247MeasGuidancev05r02 ANSIC63.10:2013 DateofReceipt: 2024-09-14 DateofTest: 2024-09-18to2024-09-24 DateofIssue: 2024-09-25 TestResult: Pass* *Intheconfigurationtested,theEUTcompliedwiththestandardsspecifiedabove. LionCai/Approved&Authorized EMCLaboratoryManager ReportNo.:BTEK240913006AE001 Page: 2 of 26 RevisionRecord VersionChapterDateModifierRemark V02024-09-25Original Authorizedforissueby: ZoraHuang/ProjectEngineer JuneLi/Reviewer Remarks: Theresultsshowninthistestreportreferonlytothesample(s)tested,thistestreportcannotbereproduced,exceptin full,withoutpriorwrittenpermissionofthecompany.Thereportwouldbeinvalidwithoutspecificstampoftestinstitute andthesignaturesofcompilerandapprover. ReportNo.:BTEK240913006AE001 Page: 3 of 26 2TestSummary RadioSpectrumTechnicalRequirement StandardItemMethodRequirementResult Antenna Requirement 47CFRPart15,SubpartC 15.247 N/A 47CFRPart15,Subpart C15.203&15.247(b)(4) Pass RadioSpectrumMatterPart ItemStandardMethodRequirementResult 47CFRPart15, SubpartC15.247 ConductedEmissionsatAC PowerLine(150kHz-30MHz) ANSIC63.10(2013) Section6.2 47CFRPart15,Subpart C15.207 Pass ConductedPeakOutputPower ANSIC63.10(2013) Section11.9.1.3 47CFRPart15,Subpart C15.247(b)(3) Pass Minimum6dBBandwidth ANSIC63.10(2013) Section11.8.1 47CFRPart15,Subpart C15.247a(2) Pass PowerSpectrumDensity ANSIC63.10(2013) Section11.10.2 47CFRPart15,Subpart C15.247(e) Pass ConductedBandEdges Measurement ANSIC63.10(2013) Section11.13.3.2 47CFRPart15,Subpart C15.247(d) Pass ConductedSpuriousEmissions ANSIC63.10(2013) Section11.11 47CFRPart15,Subpart C15.247(d) Pass RadiatedEmissionswhichfallin therestrictedbands ANSIC63.10(2013) Section6.10.5 47CFRPart15,Subpart C15.205&15.209 Pass RadiatedSpuriousEmissions ANSIC63.10(2013) Section6.4,6.5,6.6 47CFRPart15,Subpart C15.205&15.209 Pass Note: E.U.T./EUTmeansEquipmentUnderTest. Passmeansthetestresultpassedtheteststandardrequirement,pleasefindthedetaileddecisionrule inthereportrelativesection. ReportNo.:BTEK240913006AE001 Page: 4 of 26 3Contents Page 1CoverPage......................................................................................................................................................................1 2TestSummary.................................................................................................................................................3 3Contents..........................................................................................................................................................4 4GeneralInformation........................................................................................................................................5 4.1DetailsofE.U.T.......................................................................................................................................................5 4.2EUTTestModeandTestCondition.....................................................................................................................5 4.3MeasurementUncertainty......................................................................................................................................6 4.4TestLocation...........................................................................................................................................................6 4.5DeviationfromStandards......................................................................................................................................6 4.6AbnormalitiesfromStandardConditions.............................................................................................................6 5EquipmentList................................................................................................................................................7 6RadioSpectrumTechnicalRequirement.....................................................................................................9 6.1AntennaRequirement.............................................................................................................................................9 6.1.1TestRequirement:..........................................................................................................................................9 6.1.2Conclusion.......................................................................................................................................................9 7RadioSpectrumMatterTestResults..........................................................................................................10 7.1ConductedEmissionsatACPowerLine(150kHz-30MHz)...........................................................................10 7.1.1TestSetupDiagram......................................................................................................................................10 7.1.2MeasurementProcedureandData...........................................................................................................10 7.2ConductedPeakOutputPower..........................................................................................................................13 7.2.1TestSetupDiagram......................................................................................................................................13 7.2.2MeasurementProcedureandData...................................................…

Text truncated - open the document above for the full version.

ReportNo.:BTEK240913006AE001 Page:1of17 Appendix TestData forBTEK240913006AE Startdate2024/9/20Finishdate2024/9/20 Temperature 22.5°C Humidity57% RFspecificationsBLETestEngineerZora ReportNo.:BTEK240913006AE001 Page:2of17 TableofContents 1.-6dBBandwidth............................................................................................................................................................3 2.99%OccupiedBandwidth............................................................................................................................................5 3.DutyCycle.....................................................................................................................................................................7 4.PeakOutputPower.......................................................................................................................................................9 5.PowerSpectralDensity...............................................................................................................................................11 6.Bandedge....................................................................................................................................................................13 7.SpuriousEmission.......................................................................................................................................................15 ReportNo.:BTEK240913006AE001 Page:3of17 1.-6dBBandwidth ConditionAntennaRateFrequency(MHz)-6dBBW(kHz)limit(kHz)Result NVNTANT11Mbps2402.00678.21500Pass NVNTANT11Mbps2440.00677.98500Pass NVNTANT11Mbps2480.00679.32500Pass -6dB_Bandwidth_NVNT_ANT1_1Mbps_2402 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240913006AE001 Page:4of17 -6dB_Bandwidth_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240913006AE001 Page:5of17 2.99%OccupiedBandwidth ConditionAntennaRateFrequency(MHz)99%%BW(MHz) NVNTANT11Mbps2402.001.027 NVNTANT11Mbps2440.001.027 NVNTANT11Mbps2480.001.027 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2402 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240913006AE001 Page:6of17 99%_Occupied_Bandwidth_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240913006AE001 Page:7of17 3.DutyCycle ConditionAntennaRateFrequency(MHz)Dutycycle(%)Duty_factor NVNTANT11Mbps2402.0070.971.49 NVNTANT11Mbps2440.0068.751.63 NVNTANT11Mbps2480.0068.751.63 Duty_Cycle_NVNT_ANT1_1Mbps_2402 Duty_Cycle_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240913006AE001 Page:8of17 Duty_Cycle_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240913006AE001 Page:9of17 4.PeakOutputPower ConditionAntennaRate Frequency (MHz) Max.Conducted Power(dBm) Max.Conducted Power(mW) Limit(mW)Result NVNTANT11Mbps2402.007.405.491000Pass NVNTANT11Mbps2440.007.675.851000Pass NVNTANT11Mbps2480.008.296.741000Pass Peak_Output_Power_NVNT_ANT1_1Mbps_2402 Peak_Output_Power_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240913006AE001 Page:10of17 Peak_Output_Power_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240913006AE001 Page:11of17 5.PowerSpectralDensity ConditionAntennaRateFrequency(MHz)PowerSpectralDensity(dBm)Limit(dBm/3kHz)Result NVNTANT11Mbps2402.00-6.898Pass NVNTANT11Mbps2440.00-7.018Pass NVNTANT11Mbps2480.00-6.388Pass Power_Spectral_Density_NVNT_ANT1_1Mbps_2402 Power_Spectral_Density_NVNT_ANT1_1Mbps_2440 ReportNo.:BTEK240913006AE001 Page:12of17 Power_Spectral_Density_NVNT_ANT1_1Mbps_2480 ReportNo.:BTEK240913006AE001 Page:13of17 6.Bandedge ConditionAntennaRate TX_Frequency (MHz) Max.MarkFrequency (MHz) Spurious level(dBm) limit(dBm)Result NVNTANT11Mbps2402.002399.680-42.113-12.737Pass NVNTANT11Mbps2480.002484.200-46.304-11.755Pass 1_Reference_Level_NVNT_ANT1_…

Text truncated - open the document above for the full version.
