2APR2-7141-716Equinox Wireless Charging Pad

1. a. b. c. d. * MADE IN CHINA INSTRUCTIONS: Charging Mobile Devices: Ensure that your phone or tablet supports wireless charging. It will be listed in the manufacturer’s specifications. Connect the provided charging cable to a power source and to the micro USB port on the wireless charging pad (2). Once connected the LED Indicator will turn RED. Place the enabled device on the surface of the wireless charging pad(1). The LED will display RED/BLUE to indicate that the phone is charging. If the LED indicator is flashing BLUE and RED an unknown object is being detected between the wireless charging pad and the phone by FOD(Foreign Object Detection). The device will not begin to charge until object is removed. Note: To charge devices, use only the accessory cable or the cable included with your own device by the manufacturer. nstruction Manual 7141-71SL 1 x Wireless Charging Pad 1 x USB to Micro-USB Cable 1 x Instruction Manual Input power: 5V/1.5A Output power: 5W/1A 1. 2. 3. 4. • • Wireless Charging Pad Surface Micro-USB Input Port LED Indicator Non-Slip Pads What’s included: Features: Tech Specifications Do not use the device in excess of its output rating. Overload outputs above the rating may result in a risk of fire or injury. Do not use the device if damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not disassemble the device. For repairs, seek a qualified service professional. Incorrect reassembly may result in a risk of fire or injury. Do not expose the device to fire or excessive temperatures. Exposure to fire or temperatures above 104°F (40°C) may result in explosion. To ensure product safety, ensure that qualified service professionals use only identical replacement parts. Attachments on the back of your phone can impede the effectiveness of the wireless charger, and lead to overheating. Please remove attachments from the phone before charging on this device. 6. 7. 8. 9. 10. 11. 12. WARNING-When using this product, basic precautions should always be followed: Read all the instructions before use. Never store or use this product in temperatures below 32°F (0°C) or above 115°F (45°C). Do not overcharge your phone. The unit may become hot under excessive use. Remove your phone once it is fully charged. Never charge your phone for more than 7 hours at a time. To reduce the risk of injury, close supervision is required when the product is used near children. Do not expose the device to moisture. • 1. 2. 3. 4. 5. SAFETY PRECAUTIONS: Equinox Wireless Charging Pad FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. FCC ID：2APR2-7141-716 FCC RF exposure statement: The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top surface of the device must be respected.

GREAT FOREST MANUFACTURE CO, LTD. Model difference statement Product Name: Equinox Wireless Charging Pad Model N o.: 7141-71SL, 7141-71BK We (GREAT FOREST MANUFACTURE CO, LTD., Room 1709 Building A, 95 International Mansion, No.598 Jiangnan Road, High-Tech District Ningbo China.) hereby state that all the models are the same circuit and RF module, except the color and model No.. Signature: Name: YI CHUN GE Title: / Tel: +86-0574-87687017 Email: [email protected] Date: 6.21.2021

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: GREAT FOREST MANUFACTURE CO, LTD Address: Room 1709 Building A, 95 International Mansion, No.598 Jiangnan Road, High-Tech District Ningbo China Product Name: Equinox Wireless Charging Pad Model Number: 7141-71SL, 7141-71BK FCC Identifier: 2APR2-7141-716 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: YI CHUN GE Date: 6/21/2021 Title: / Signature of applicant:

C5266091_X10_Ed.1 1/1 GREAT FOREST MANUFACTURE CO, LTD. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 Date: 6/21/2021 Subject: Request for Confidentiality FCC ID: 2APR2-7141-716 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality ID Label/Location No No Attestation Statement No No External Photos No Block Diagram Schematics Test Report No No Test Setup Photos No User’s Manual Internal Photos Parts List / Tune Up RF Exposure Info Operational Description Cover Letter(s) No No SDR Software / Security Info No Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: YI CHUN GE Date: 6/21/2021 Title: /
