Instruction Manual Botzee mini Screen-free Coding Robot 1 \ 6 Product Information Product List: Main ControlUSB Cable Mapnstruction Card Product Name: Botzees Mini Product Number: 83122 Product Material: ABS plastic Suitable Age: 3 years old and above Manufacturer: Pai Technology Ltd. Address: Building 10, Block 3, No.1016 Tianlin Road, Minhang District, Shanghai, CHINA Website: www.paibloks.com Service Number: 400 920 6161 Features 2 \6 LED lattice display Speaker Switch USB charging port Track Fill light Status indicator Camera Features 3 \6 1、Power On/Power Off/Charging Power On: Long press the power button for 2 seconds Power Off: Long press the power button for 2 seconds lug the cable into the Micro USB connector to charge the device. Status Indicator: Red: Charging Green: charging completed 2、Line-tracking/Command Recognition Identify the instruction card placed on the line. Identify the instruction on the map. Place the device on a black line and the device will start its line-tracking. Features 4 \6 3、How to use the Instruction Card: Notes: Do Re Mi Fa Sol La Ti Note: The device will play the corresponding note sound effect immediately after it recognizes the command during line tracking. Movement & other commands Turn right: The device will turn right at the front intersection after recognizing this command during line-tracking Turn left: The device will turn left at the front intersection after recognizing this command during line-tracking. Temporary stop: The device will stop for 2 seconds as soon as it recogniz- es this command during line-track- ing. Stop (End point): The device will stop and play a victory sound as soon as it recognizes this command during line-tracking. Start: The device will play the Start sound as soon as it recognizes this command during line-tracking. Treasure: The device will record a treasure and play corresponding sound effects after it recognizes this command during line-tracking. Features 5\ 6 4、Paired with an RF device The device is paired with other RF -supported hardware via a USB cable. The motor turns clockwise for 2 seconds The motor turns counterclockwise for 2 seconds The steering gear rotates 90° clockwise The steering gear rotates 90° counterclockwise The recording module plays sound. The light module lights up/goes out. 6\6 Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interfer- ence that may cause undesired operation. 1.The battery is not replaceable . FCC ID: 2APRA83004
