2APU5-WPC15Magnetic Wireless Charger

WPC15 70431-0166-01 201229 Steven WPC15-SMS-JMT001 Magnetic Wireless Charger Instruction Manual Please read the following carefully before using the device to ensure safe and proper use. . Wireless Charger . USB-C to USB-C Fast Charging Cable . User Manual . Input: DC 5V,2A/ DC 9V,2A . Output: 5W/7.5W/10W/15W . Auto-magnetic alignment for Phones with magnets underneath . Charging Distance≤6mm Package Content Specif cations General information i . This charger works with all Qi-compatible devices (please make sure your device is Qi-compatible) . For normal operati on, no weaker than DC 5V, 2A adapter is required. . For fast wireless charging mode, use the QC 2.0/QC 3.0 or PD adapter and compatible smartphones. . This wireless charger can charge smartphones with non-metal protective case or silicone covers that are no thicker than 6mm. Connect the charging cable (included) to a USB-C charger, the Type -C plug to the Type-C input of the wireless charger. Placee your Qi compatible phon with inductive (wireless) charge feature onto charger (back of phone to charger), then wireless charging of the phone will The magnetic wireless charger makes wireless charging a snap, perfectly aligning the charging coil in the magnetic charger with the charging coil in the iPhone 12 series. Please note: older iPhones have the same wireless charging coil, but no magnets underneath to allow Caution: Do not drop, disassemble or modify this product. Do not expose this product to fire or excessive heat. Do not expose this product to water or excessive humidity. Do not put any bare metal on the surface area of the wireless charger when it is operating. Instructions start immediately. for magnetic connections. FCC STATEMENT : This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Warning: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limit s are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instr uctions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equi pment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving an tenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experi enced radio/TV technician for help. FCC Radiation Exposure Statement: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body.

FCCID:2APU5-WPC15

LabelLocationOnEUT Label ProductName:MagneticWirelessCharger ModelNo.:WPC15 FCCID:2APU5-WPC15 ThisdevicecomplieswithPart15oftheFCCRules.Operation issubjecttothefollowingtwoconditions: (1)Thisdevicemaynotcauseharmfulinterference,and (2)Thisdevicemustacceptanyinterferencereceived,including interferencethatmaycauseundesiredoperation.

FCCID:2APU5-WPC15

version01 JMTekIndustries(Shenzhen)Co.,Ltd DeclarationconcerningAntennaSpecification Itisherebydeclaredthattheproduct ModelNo.:WPC15,WPC15B,WPC15W FCCID:2APU5-WPC15 fulfillstherequirementinFCCtestrelatingtotheantennatype. ThedevicespecifiedaboveconfirmstotheFCCrecommendationsfor internal antennatype(s) describedbelow: ModelNo.ofantenna: N/A Typeofantenna:InductiveloopcoilAntenna Gainoftheantenna:0dBi Frequencyrange:110.1-205KHz Themountingoftheantennaisfixedtotheradiomoduleandnootherantennashouldbeused. Companyname:JMTekIndustries(Shenzhen)Co.,Ltd Address:14G,InnovationTechBuilding,QuanzhiScienceandTechnologyinnovation Park,ShaJingStreet,Bao’anDistrict,ShenZhen,China City: Shenzhen ZIP/Postalcode:N.A. Country:CHINA Place:ShenzhenDate:6/2/2021 Signature:
