2APVH-CAPTURE3Smartphone Stabilizer

Contents Components 1 2 3 Safety Guidelines FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. Radiation Exposure Statement This device complies with RF radiation exposure limits set forth for an uncontrolled environment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.

Shenzhen Funsnap Technology Co., Ltd Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Tel: +86 0755-86520760 Fax: +86 0755-86520760 Date: Mar. 11, 2021 Dear Sir/Madam, We, Shenzhen Funsnap Technology Co., Ltd Hereby declares the following statement for Federal Communications Commission, PCB board, circuit, structure and internal of these model(s) are the same, Only model number is different for these model: Product name: Smartphone Stabilizer Model no.: Capture π, Capture πs, Capture π PRO,Capture 3, Capture 3s Sincerely, Name: Tianrui Sun Company: Shenzhen Funsnap Technology Co., Ltd Address: Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Phone: +86 0755-86520760 Fax: +86 0755-86520760 E-Mail: [email protected]

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: Mar.11 , 2021 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2APVH-CAPTURE3 Capture π, Capture πs, Capture π PRO,Capture 3, Capture 3s For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Tianrui Sun Company: Shenzhen Funsnap Technology Co., Ltd Address: Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Phone: +86 0755-86520760 Fax: +86 0755-86520760 E-Mail: [email protected]

Shenzhen Funsnap Technology Co., Ltd Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Tel: +86 0755-86520760 Fax: +86 0755-86520760 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 3/18/2021 To whom it may concern: We, the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID:2APVH-CAPTURE3 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Tianrui Sun Company: Shenzhen Funsnap Technology Co., Ltd Address: Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Phone: +86 0755-86520760 Fax: +86 0755-86520760 E-Mail: [email protected]

FCC ID: 2APVH-CAPTURE3

FCC ID:2APVH-CAPTURE3

FCC ID: 2APVH-CAPTURE3 Antenna

RF Exposure evaluation FCC ID: 2APVH-CAPTURE3 1.1. Applicable Standard According to §1.1307(b)(1), systems operating under the provisions of this section shall be operated in a manner that ensures that the public is not exposed to radio frequency energy level in excess of the Commission’s guidelines. According to §1.1310 and §2.1093 RF exposure requirement KDB447498 v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies 1.2. Requirement According to KDB447498 D01 General RF Exposure Guidance v06 Section 4.3.1 Standalone SAR test exclusion considerations: “Unless specifically required by the published RF exposure KDB procedures, standalone 1-g head or body and 10-g extremity SAR evaluation for general population exposure conditions, by measurement or numerical simulation, is not required when the corresponding SAR Test Exclusion Threshold condition, listed below, is satisfied. These test exclusion conditions are based on source-based time-averaged maximum conducted output power of the RF channel requiring evaluation, adjusted for tune-up tolerance, and the minimum test separation distance required for the exposure conditions.22 The minimum test separation distance is determined by the smallest distance from the antenna and radiating structures or outer surface of the device, according to the host form factor, exposure conditions and platform requirements, to any part of the body or extremity of a user or bystander (see 5) of section 4.1). To qualify for SAR test exclusion, the test separation distances applied must be fully explained and justified by the operating configurations and exposure conditions of the transmitter and applicable host platform requirements, typically in the SAR measurement or SAR analysis report, according to the required published RF exposure KDB procedures. When no other RF exposure testing or reporting is required, a statement of justification and compliance must be included in the equipment approval, in lieu of the SAR report, to qualify for the SAR test exclusion. When required, the device specific conditions described in the other published RF exposure KDB procedures must be satisfied before applying these SAR test exclusion provisions; for example, handheld PTT two-way radios, handsets, laptops & tablets etc.23 “ [(max. power of channel, including tune-up tolerance, mW)/ (min. test separation distance, mm)] · [√f (GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR, where: • f (GHz) is the RF channel transmit frequency in GHz • Power and distance are rounded to the nearest mW and mm before calculation • The result is rounded to one decimal place for comparison • 3.0 and 7.5 are referred to as the numeric thresholds in the step 2 below The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm according to 5) in section 4.1 is applied to determine SAR test exclusion. 1.3. Manufacturing tolerance GFSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 2.0 2.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 π/4DQPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 5.0 4.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 8DPSK Channel Channel 00 Channel 39 Channel 78 Target (dBm) 5.0 4.0 3.0 Tolerance ±(dB) 1.0 1.0 1.0 GFSK(BLE) Channel Channel 00 Channel 19 Channel 39 Target (dBm) 3.0 2.0 2.0 Tolerance ±(dB) 1.0 1.0 1.0 2. E v a l u a t i o n R e s u l t Evaluation Results Band/Mode f (GHz) Antenna Distance (mm) RF output power (including tune-up tolerance) SAR Test Exclusion Threshold SAR Test Exclusion dBm mW BT 2.402 5 6 3.981 1.2<3.0 Yes 3. C o n c l u s i o n The measurement results comply with the FCC Limit per 47 CFR 2.1093 for the uncontrolled RF Exposure and SAR Exclusion Threshold per KDB 447498 v06, No SAR is required. .....................End.........................

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong FCC PART 15 SUBPART C TEST REPORT FCC PART 15.247 Report Reference No......................: FCC ID............................................ : GTS20210310012-1-2 2APVH-CAPTURE3 Compiled by ( position+printed name+signature)..:File administrators Jimmy Wang Supervised by ( position+printed name+signature)..:Test Engineer Aaron Tan Approved by ( position+printed name+signature)..: Manager Jason Hu Date of issue.....................................:Mar. 01, 2021 Representative Laboratory Name.:Shenzhen Global Test Service Co., Ltd. Address............................................: No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name............................: Shenzhen Funsnap Technology Co., Ltd Address............................................: Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Test specification...........................: Standard...........................................: FCC Part 15.247 TRF Originator..................................:Shenzhen Global Test Service Co.,Ltd. Master TRF.......................................:Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description.....................: Smartphone Stabilizer Trade Mark.......................................: FUNSNAP Manufacturer....................................: Guangdong Silver Basis Technology Co., LTD Model/Type reference.......................: Capture π Listed Models ..................................: Capture πs, Capture π PRO,Capture 3, Capture 3s Modulation Type...............................: GFSK Operation Frequency........................: From 2402MHz to 2480MHz Rating...............................................: DC3.7V from battery Result...............................................: PASS Report No.: GTS20210310012-1-2 Page 2 of 29 T E S T R E P O R T Test Report No. :GTS20210310012-1-2 Mar. 01, 2021 ____________________________________________________________________________________ Date of issue Equipment under Test: Smartphone Stabilizer Model /Type : Capture π Listed Models: Capture πs, Capture π PRO,Capture 3, Capture 3s Applicant:Shenzhen Funsnap Technology Co., Ltd Address: Room C901, 9/F, South Block, Yuanxing Science and Technology Building, 1 Songpingshan Road, Songpingshan Community, Xili street, Nanshan District, Shenzhen, China Manufacturer:Guangdong Silver Basis Technology Co., LTD Address: First Phase of Mold Industry Park,Hengli Town, Dongguan, 523000, P.R.China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20210310012-1-2 Page 3 of 29 Contents 1TEST STANDARDS..................................................................4 2SUMMARY.............................................................................5 2.1General Remarks5 2.2Product Description5 2.3Test Sample5 2.4Equipment Under Test5 2.5Short description of the Equipment under Test (EUT)6 2.6EUT operation mode6 2.7Block Diagram of Test Setup6 2.8Special Accessories6 2.9Relatelated Submittal(s) / Grant (s)6 2.10Modifications6 3TEST ENVIRONMENT ...............................................................7 3.1Address of the test laboratory7 3.2Test Facility7 3.3Environmental conditions7 3.4Summary of measurement results8 3.5Statement of the measurement uncertainty8 3.6Equipments Used during the Test9 4TEST CONDITIONS AND RESULTS............................................10 4.1AC Power Conducted Emission10 4.2Radiated Emissions and Band Edge13 4.3Maximum Peak Output Power19 4.4Power Spectral Density20 4.56dB Bandwidth22 4.6Out-of-band Emissions24 4.7Antenna Requirement27 5TEST SETUP PHOTOS OF THE EUT..........................................28 6PHOTOS OF THE EUT............................................................29 Report No.: GTS20210310012-1-2 Page 4 of 29 1TEST STANDARDS The tests were performed according to following standards: FCC Rules Part 15.247: Frequency Hopping, Direct Spread Spectrum and Hybrid Systems that are in operation within the bands of 902-928 MHz, 2400-2483.5 MHz, and 5725-5850 MHz. ANSI C63.10-2013: American National Standard for Testing Unlicensed Wireless Devices KDB558074 D01 V03r05: Guidance for Performing Compliance Measurements on Digital Transmission Systems (DTS) Operating Under §15.247 Report No.: GTS20210310012-1-2 Page 5 of 29 2SUMMARY 2.1General Remarks Date of receipt of test sample:Feb. 20, 2021 Testing commenced on:Feb. 21, 2021 Testing concluded on:Feb. 29, 2021 2.2Product Description Product Name:Smartphone Stabilizer Model/Type reference:Capture π Power supply:DC 3.7V from battery Hardware version:FUNSNAP-C03-POWER-V02-20210125 Software version:V1.0 Sample ID:GTS20210310012-1-1#/ GTS20210310012-1-2# Bluetooth LE Supported type:Bluetooth low Energy Modulation: GFSK Operation frequency: 2402MHz to 2480MHz Channel number:40 Channel separation: 2 MHz Antenna type: PCB antenna Antenna gain: 0 dBi 2.3Test Sample The application provides 2 samples to meet requirement. Sample NumberDescription GTS20210310012-1-1#…

Text truncated - open the document above for the full version.

FCC ID: 2APVH-CAPTURE3
