Page1of50ReportNo.:UNIA20121711FR-01 FCCRADIOTESTREPORT FCCID:2AQ4R-HP-H011 IC:26771-HPH011 Product ： TurntablePlayer TradeName ： mbeatorotherbrand ModelName/HVIN(s)： HP-H011-MA SeriesModel： HP-H011XXX,MB-PT-38XXX,GLD-BHT38XXX, (“XXX”canbereplacedbyletterfrom“A”to“Z”, numberfrom“0”to“9”orblank) ReportNo.： UNIA20121711FR-01 Preparedfor HaipingIndustryCo.,Ltd. 3F,BuildingC,NO.68,HongshiRoad,Buxin,FenggangTown,Dongguan, GuangdongChina. Preparedby ShenzhenUnitedTestingTechnologyCo.,Ltd. 2F,AnnexBldg,JiahuangyuanTechPark,#365Baotian1Rd,Tiegang Community,XixiangStr,Bao'anDistrict,Shenzhen,China Page2of50ReportNo.:UNIA20121711FR-01 TESTRESULTCERTIFICATION Applicant’sname....................:HaipingIndustryCo.,Ltd. Address ...................................... : 3F,BuildingC,NO.68,HongshiRoad,Buxin,FenggangTown, Dongguan,GuangdongChina. Manufacture'sName .............. :HaipingIndustryCo.,Ltd. Address......................................: 3F,BuildingC,NO.68,HongshiRoad,Buxin,FenggangTown, Dongguan,GuangdongChina. Productdescription Productname...............................:TurntablePlayer TradeMark.................................:mbeatorotherbrand Modeland/ortypereference . : HP-H011-MA,HP-H011XXX,MB-PT-38XXX,GLD-BHT38XXX, (“XXX”canbereplacedbyletterfrom“A”to“Z”,numberfrom“0” to“9”orblank) Standards .................................. : FCCRulesandRegulationsPart15SubpartCSection15.247, RSS-247Issue2:February2017,RSS-GenIssue5April2018 ANSIC63.10:2013 ThisdevicedescribedabovehasbeentestedbyShenzhenUnitedTestingTechnology Co.,Ltd.,andthetestresultsshowthattheequipmentundertest(EUT)isincompliance withtheFCCrequirements.Anditisapplicableonlytothetestedsampleidentifiedinthe report. Thisreportshallnotbereproducedexceptinfull,withoutthewrittenapprovalofUNI,this documentmaybealteredorrevisedbyShenzhenUnitedTestingTechnologyCo.,Ltd., personnelonly,andshallbenotedintherevisionofthedocument. DateofTest...............................................: Date(s)ofperformanceoftests...............:Dec.01~18,2020 DateofIssue..............................................:Dec.21,2020 TestResult .................................................. :Pass Testedby: Bobliao/Editor Reviewer: Kahnyang/Supervisor Approved&AuthorizedSigner: Liuze/Manager Page3of50ReportNo.:UNIA20121711FR-01 TableofContentsPage 1.TESTSUMMARY...................................................................................................................5 1.1TESTPROCEDURESANDRESULTS....................................................................................5 1.2TESTFACILITY............................................................................................................................5 1.3MEASUREMENTUNCERTAINTY............................................................................................5 2.GENERALINFORMATION ................................................................................................... 6 2.1GENERALDESCRIPTIONOFEUT.........................................................................................6 2.2CarrierFrequencyofChannels.................................................................................................7 2.3OperationofEUTduringtesting................................................................................................7 2.4DESCRIPTIONOFTESTSETUP.............................................................................................7 2.5MEASUREMENTINSTRUMENTSLIST..................................................................................8 3.CONDUCTEDEMISSIONSTEST.......................................................................................9 3.1ConductedPowerLineEmissionLimit ..................................................................................... 9 3.2TestSetup ..................................................................................................................................... 9 3.3TestProcedure ............................................................................................................................. 9 3.4TestResult .................................................................................................................................... 9 4.RADIATEDEMISSIONTEST.............................................................................................12 4.1RadiationLimit...........................................................................................................................12 4.2TestSetup...................................................................................................................................12 4.3TestProcedure...........................................................................................................................13 4.4TestResult..................................................................................................................................13 5.BANDEDGE ......................................................................................................................... 18 5.1Limits...........................................................................................................................................18 5.2TestProcedure...........................................................................................................................18 5.3TestResult..................................................................................................................................18 6.OCCUPIEDBANDWIDTHMEASUREMENT..................................................................20 6.1TestSetup ................................................................................................................................... 20 6.2TestProcedure ........................................................................................................................... 20 6.3MeasurementEquipmentUsed ..................................................................................…

Text truncated - open the document above for the full version.

Page35of50ReportNo.:UNIA20121711FR-01 10.SPURIOUSRFCONDUCTEDEMISSION 10.1TestLimit 1.Below-20dBofthehighestemissionlevelinoperatingband. 2.Fallintherestrictedbandslistedinsection15.205.Themaximumpermittedaveragefieldstrengthis listedinsection15.209. 3.Forbelow30MHz,For9KHz-150kHz,150K-10MHz,WeusetheRBW1KHz,10KHz,Sothelimitneedto calculatedby“10lg(BW1/BW2)“.forexampleFor9KHz-150kHz,RBW1KHz,TheLimit=thehighest emissionlevel-20-10log(100/1)=thehighestemissionlevel-40. 10.2TestProcedure TheSpuriousRFconductedemissionscomplianceofRFradiatedemissionshouldbemeasuredby followingtheguidanceinANSIC63.10-2013,For9KHz-150kHz,SetRBW=1kHzandVBW=3KHz; For150KHz-10MHz,SetRBW=10kHzandVBW=30KHz:For10MHz-25GHz,SetRBW=100kHzand VBW=300KHzinordertomeasurethepeakfieldstrength,andmwasurefrequenyrangefrom9KHz to25GHz. 10.3TestSetup 10.4TestResult PASS Remark:AllmodesofGFSK,π/4DQPSK,8DPSKweretested,onlytheworstresultofGFSK wasreportedasbelow: GFSK CH:2402MHz Page36of50ReportNo.:UNIA20121711FR-01 30MHz~1GHz 1GHz~25GHz Page37of50ReportNo.:UNIA20121711FR-01 CH:2441MHz 30MHz~1GHz Page38of50ReportNo.:UNIA20121711FR-01 1GHz~25GHz CH:2480MHz Page39of50ReportNo.:UNIA20121711FR-01 30MHz~1GHz 1GHz~25GHz Page40of50ReportNo.:UNIA20121711FR-01 11.NUMBEROFHOPPINGFREQUENCY 11.1TestLimit Frequencyhoppingsystemsinthe2400–2483.5MHzbandshalluseatleast15channels. 11.2TestProcedure Thetransmitteroutputwasconnectedtothespectrumanalyzerthroughanattenuator.Setspectrum analyzerstart2400MHzto2483.5MHzwithRBW=1MHzandVBW=3MHz. 11.3TestSetup 11.4TestResult PASS Modulation NumberofHopping Channel LimitResult GFSK79 ≥15Passπ/4DQPSK79 8DPSK79 GFSK Page41of50ReportNo.:UNIA20121711FR-01 π/4DQPSK 8DPSK Page42of50ReportNo.:UNIA20121711FR-01 12.TIMEOFOCCUPANCY(DWELLTIME) 12.1TestLimit Theaveragetimeofoccupancyonanychannelshallnotbegreaterthan0.4secondswithina pe-riodof0.4secondsmultipliedbythenumberofhoppingchannelsemployed. 12.2TestProcedure Thetransmitteroutputwasconnectedtothespectrumanalyzerthroughanattenuator. Setcenterfrequencyofspectrumanalyzer=operatingfrequencywithRBW=1MHz andVBW=3MHz,Span=0Hz. 12.3TestSetup 12.4TestResult PASS CH:2402MHz TypeModulationCH Pulse time(ms) Dwell Time(ms) Limit(ms)Result Dwell Time GFSK Low2.96315.73400Pass Mid2.98317.87400Pass High2.93312.53400Pass Page43of50ReportNo.:UNIA20121711FR-01 CH:2441MHz CH:2480MHz Page44of50ReportNo.:UNIA20121711FR-01 CH:2402MHz CH:2441MHz TypeModulationCH Pulse time(ms) Dwell Time(ms) Limit(ms)Result Dwell Time π/4DQPSK Low2.95314.67400Pass Mid2.96315.74400Pass High2.96315.74400Pass Page45of50ReportNo.:UNIA20121711FR-01 CH:2480MHz CH:2402MHz TypeModulationCH Pulse time(ms) Dwell Time(ms) Limit(ms)Result Dwell Time 8DPSK Low2.93312.53400Pass Mid2.98317.87400Pass High2.94313.60400Pass Page46of50ReportNo.:UNIA20121711FR-01 CH:2441MHz CH:2480MHz Page47of50ReportNo.:UNIA20121711FR-01 13.PSEUDORANDOMFREQUENCYHPPPINGSEQUENCE For47CFRPart15Csection15.247(a)(1)requirement Frequencyhoppingsystemsshallhavehoppingchannelcarrierfre-quenciesseparatedbyaminimum of25kHzorthe20dBbandwidthofthehop-pingchannel,whicheverisgreater.Al-ternatively,frequency hoppingsystemsoperatinginthe2400–2483.5MHzbandmayhavehoppingchannelcarrier fre-quencies thatareseparatedby25kHzortwo-thirdsofthe20dBbandwidthofthehoppingchannel,whicheveris greater,providedthesystemsoperatewithanoutputpowernogreaterthan125mW.Thesystemshal lhop tochan-nelfrequenciesthatareselectedatthesystemhoppingratefromapseudoran-domlyorderedlist ofhoppingfre-quencies.Eachfrequencymustbeusedequallyontheaveragebyeachtrans-mitter.The systemreceiversshallhaveinputbandwidthsthatmatchthehop-pingchannelbandwidthsoftheir cor-respondingtransmittersandshallshiftfrequenciesinsynchronizationwiththetransmitted signals. TEUTPseudorandomFrequencyHoppingSequenceRequirement Thepseudorandomfrequencyhoppingsequencemaybegeneratedinanice-stageshiftregisterwhose5 th and9thstageoutputsareaddedinamodulo-twoadditionstage.Andtheresultisfedbacktotheinputof thefriststage.Thesequencebeginswiththefristoneof9consecutiveones,forexample:theshiftregister is initializedwithnineones. Numberofshiftregisterstages:9 Lengthofpseudo-randomsequence:29-1=511bits Longestsequenceofzeros:8(non-invertedsignal) Anexplameofpseudorandomfrequencyhoppingsequenceasfollows: Eachfrequencyusedequallyonetheaveragebyeachtransmitter. Thesystemreceiverhaveinputbandwidthsthatmatchthehoppingchannelbandwidthsoftheir correspondingtransmitterandshiftfrequenciesinsynchronizationwiththetransmittedsignals. Page48of50ReportNo.:UNIA20121711FR-01 14.ANTENNAREQUIREMENT StandardApplicable: Forintentionaldevice,accordingtoFCC47CFRSection15.203,anintentionalradiatorshallbe designedtoensurethatnoantennaotherthanthatfurnishedbytheresponsiblepartyshallbeused withthedevice. AntennaConnectedConstruction TheantennausedinthisproductisanPCBAntenna,Thedirectionalgainsofantennausedfor transmittingis0dBi. BTANTENNA: Page49of50ReportNo.:UNIA20121711FR-01 15.PHOTOGRAPHOFTEST RadiatedEmission (Below1G) RadiatedEmission (Above1G) Page50of50ReportNo.:UNIA20121711FR-01 ConductedEmission ***EndofReport***
