2AQ4V-J47Smart watch

SMART WATCH USER GUIDE version 1 12345 INSTRUCTION FOR QUICK USE ON/OFF 1.When the bracelet is off, charge it or press and hold for 3 seconds. The bracelet vibrates to turn on; 2. Switch to shutdown interface in start-up state, and have a long press on shutdown interface for. 3. seconds to power off. BAND OPERATION 1. Slide to light up screen or switch display in start-up state; 2. No operation default five-second screen, users can connect to the mobile APP to modify the screen time; 3. The factory default setting of the band (heart rate monitor for 24 hours). Users can turn on or off in the general settings of APP interface. HOW TO INSTALL APP ENGLISH CONNECT WITH DEVICE MAIN INTERFACE MESSAGE BLUETOOTH CALLING You can make or answer calls directly on the watch, and the watch and mobile phone will dial in real time. AI INTELLIGENT VOICE After the watch is successfully linked with the mobile phone, the watch can directly conduct intelligent voice conversations. MAIN FUNCTION INTERFACE Slide up on the main interface to view the information. The bracelet can save 8 pieces information pushed by the APP recently (if there is no message, it will stop at the message interface), Slid right to exit and return to the upper interface. Automatically delete already viewed information, there are all delete options at the bottom, slide down Return to live interface. Main interface: Customized homepage is supported: Smart Watch has 5 main interfaces. On the main interface, press and hold for two seconds. After shaking, you can switch the dial left and right. After connected with the paired APP, the bracelet will synchronize the time, date and week of the phone. Enter "Dial setting" in APP to select homepage of different style. GloryFit MUSIC ALARM CLOCK BREATHING TRAINING RESPIRATION RATE TRAINING STATUS HEART RATE BLOOD OXYGEN BLOOD PRESSURE WEATHER SLEEP Click to enter the sports interface, there are a total of 100+ sports, select a specific sports item, click to start monitoring after three seconds, press the upper corner button or slide to the right to pause, click " " to end. Switch to the status interface to view the current step count, distance, and calorie status. The distance and calories are calculated and displayed according to the current walking steps, the height and weight set by the APP personally. Switch to the heart rate interface to start automatic heart rate measurement. Switch menu re-measure. Switch to the blood pressure interface to start automatic blood pressure measurement, switch the menu to re-measure. Switch to the blood oxygen interface to start automatic measurement of blood oxygen, and switch the menu to re- measure. Switch to the sleep interface, you can check the sleep quality of the previous night! Switch to the weather interface, you can view the weather and temperature conditions. The watch and phone are connected, open the music control, press the play button to play music, pause, previous song, next song. Enter the alarm clock interface, you can add or delete alarm clocks, and you can set up to 8 groups of alarm clocks. Enter the breath test interface, start to measure the breath rate automatically, switch the menu to re-measure. Enter the breathing training function and follow the animation for breathing rhythm training. PHYSIOLOGICAL CYCLE MORE This function will only be enabled when female users are logged in. Go to the APP and click to enter the "biological cycle" - click the device reminder switch, set the personal physiological cycle status, and you can view it on the bracelet side. Stopwatch: Timer: Find a mobile phone: Flashlight: Click to start timing, swipe to the right to exit back to the previous interface when the timing is stopped. Switch to the timer interface, you can choose to set the time or add a custom time. Switch to the search interface, click to find a mobile phone in the connected state, and the mobile phone will send a ringtone to remind you. Click in and out to turn on the flashlight, swipe right to exit and turn it off. 6 PRECAUTIONS · Please prevent your bands from being shocked, or exposed under high temperature or blazing sun for a long time. · Please don't disassemble, repair or change the device. · The device should adopt 5V500MA to charge, it is forbidden to charge with over-voltage power supply. · It should be used within the temperature of 0 degrees - 45 degrees. It is forbidden to throw into fire, avoiding explosion. · Please charge after drying the band with soft cloth, otherwise, it will corrode charging touch points, leading to charge fault. · Please keep away from chemical substance such as gasoline, cleaning solvent, propanol, alcohol or insect repellent. · Please don't use the product in high voltage and high magnetic environment. · In case of sensitive dry skin or too-tight wearing, you may be uncomfortable. · Please don't take a hot bath by wearing it. · Please dry sweat in your wrist timely for its possibility to lead to skin itch or allergy by long-time touch with soap, sweat, allergens or contaminatedingredients. · In case of frequent use, it is suggested to clean weekly. Please wipe with a damp cloth, and remove oil or dust by mild soap. ·Do not open more push without special requirements. SET UP The settings include: 1. Dial and theme, 2. Brightness adjustment, 3. Sound and vibration, 4. Password, 5. Raise your hand to light up the screen, 6. Do not disturb mode, 7. Language settings, 8. QR code, 9. System menu, 10. About. Scan the QR code or enter major application markets to download and install 'GloryFit’. Demands on Device: IOS 9.0 or above; Android 4.4 or above, Bluetooth 5.3 is supported. Open the APP, click "Device" - "Add Device" - "Select Device", click the corresponding model, and follow the prompts to connect. Manually drop APP main page down to synchronize data; the bracelet can save offline date of 7 days. The date is more, the synchronization time will be longer. It will take no more than 2 seconds to sy…

Text truncated - open the document above for the full version.

Shenzhen Yougu Intelligent Technology Co., Ltd. 2024.07.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(i) request for FCC ID: 2AQ4V-J47 [Shenzhen Yougu Intelligent Technology Co., Ltd.] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Sincerely, (Applicant signature) (Applicant printed name) XIONG XIONG Shenzhen Yougu Intelligent Technology Co., Ltd. 2024.07.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 West Patapsco Avenue Baltimore, MD 21230 RE: Attestation Statements Part 2.911(d)(5)(ii) request for FCC ID: 2AQ4V-J47 [Shenzhen Yougu Intelligent Technology Co., Ltd.] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List as an entity producing “covered” equipment. Sincerely, (Applicant signature) (Applicant printed name) XIONG XIONG

Shenzhen Yougu Intelligent Technology Co., Ltd. 2024.07.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: CONFIDENTIALITY REQUEST FOR EUT NAME: Smart watch Trademark: N/A MODEL : J47 FCC ID : 2AQ4V-J47 To Whom It May Concern: This letter serves as an official request for confidentiality under sections 0.457 and 0.459 of CFR 47. We have requested that the - Block Diagram - Schematics - Operational Description required to be submitted with this application be permanently withheld from public review. The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these materials may be harmful to the applicant and provide unjustified benefits to its competitors. Please contact me if there is any information you may need. Sincerely, Client’s signature: Client’s name / title : XIONG XIONG /Manager Contact information / address: Room 24J, Block C, Wanguo Food City, No.9, Pinglang Road,Nanwan Street,Longgang District, Shenzhen, China

Shenzhen Yougu Intelligent Technology Co., Ltd. 2024.07.26 Eurofins Electrical and Electronic Testing NA, Inc. 914 W. Patapsco Avenue Baltimore, MD 21230 USA RE: LETTER OF AGENT AUTHORIZATION To Whom It May Concern: We, the undersigned, hereby authorize Shenzhen BCTC Testing Co., Ltd to act on our behalf in all matters relating to application for equipment authorization, including the signing of all documents relating to these matters. We also hereby certify that no party to the application authorized hereunder is subject to the denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C.853(a). This agreement expires one year from the current date. Sincerely, Client’s signature: Client’s name / title : XIONG XIONG /Manager Contact information / address: Room 24J, Block C, Wanguo Food City, No.9, Pinglang Road,Nanwan Street,Longgang District, Shenzhen, China

External Photos

Size:10*5mm FCC ID:2AQ4V-J47 Label location

Internal Photos Antenna

RF EXPOSURE EVALUATION METHOD FCC ID:2AQ4V-J47 Applicable standard： In accordance with FCC 47 CFR part 2 (2.1093) this device has been defined as a portable device which is defined as a transmitting device designed to be used so that the radiating structure(s) of the device is/are within 20 centimeters of the body of the user. Portable devices must be evaluated using the specified in FCC 47 CFR part 2 (2.1093) and ANSI/IEEEC95.1-1992. and had been tested in accordance with the measurement methods and procedures specified in IEEE 1528-2003. Per FCC KDB 447498 D01 v06, the 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances s 50 mm are determined by: SAR Test Exclusion Thresholds for 100 MHz – 6 GHz and ≤ 50 mm Approximate SAR Test Exclusion Power Thresholds at Selected Frequencies and Test Separation Distances are illustrated in the following Table. The 1-g and 10-g SAR test exclusion thresholds for 100 MHz to 6 GHz at test separation distances ≤ 50 mm are determined by: [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for 1-g SAR and ≤ 7.5 for 10-g extremity SAR,where f(GHz) is the RF channel transmit frequency in GHz Power and distance are rounded to the nearest mW and mm before calculation The result is rounded to one decimal place for comparison The test exclusions are applicable only when the minimum test separation distance is ≤ 50 mm and for transmission frequencies between 100 MHz and 6 GHz. When the minimum test separation distance is < 5 mm, a distance of 5 mm is applied to determine SAR test exclusion. BLE GFSK 1Mbps 2402 -2.24 30 GFSK 1Mbps 2440 -1.64 30 GFSK 1Mbps 2480 -1.58 30 GFSK 2Mbps 2402 -2.21 30 GFSK 2Mbps 2440 -1.52 30 GFSK 2Mbps 2480 -1.42 30 max possible output power (PK,conducted)：-1±1dBm 0.41dBi logarithmic terms convert to numeric result is nearly 1.1 0dBm=1mW 2402MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.00/5*√2.402=0.31≤3.0 2440MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.00/5*√2.44=0.31≤3.0 2480MHz [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance,mm)] · [√f(GHz)]= 1.00/5*√2.48=0.31≤3.0 Conclusion: 1. [(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] * [√f(GHz)] < 3.0. 2. SAR Test Exclusion Thresholds is 3.0 for separation distance 5mm. Therefore, SAR test is not required.

ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -1- ChangfengElectronicsscienceandtechnologyCo.,Ltd. SampleRecognitionLetter Projectname：QS36 Chang Feng MERFQC Signature LIYANGQIN WEIXINGLIUYANQIN date 2024-06-192024-06-192024-06-19 CUSTOME R MEMDQC Signature date ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -2- DateEditionCondition 2024-06-19AFPCMoldsample 1summary..............................................................................................................1-2 2Machinedescription.............................................................................................2-2 3Debugsettings................................................................................................................................................3 3.1standingwave(VSWR)和Recchoreflection(ReturnLoss)...................................................................... 3.2TRP/TRSmakeuseofAgilent8960(5515C)在ETS5m×4m×4m3DInteriorroomtest。............... 3.3(MatchingCircuitDescription).................................................................................................................. 4EffectiveRadiatedPowerSummation.....................................................................................................4 5assumptiondiagram..................................................................................................5 ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -3- 1Summary Thisreportismainlyusedtodescribethe《ChangfengElectronics》 QS36Sampleantennarecognitionletter. 2Machinedescription QS36networkmodeis2.4G,2.4Gantennaatthebottomofthedevice,PIFA.The antennaisaceramicantenna 3Debugsettings 3.1standingwave(VSWR)andRecchoreflection(ReturnLoss) VSWRIsusingtheAgilentE5062Bconnectedtotheterminalassemblytotest,stateforfree space。 3.2TRP/TRSTestedintheETS5m×4m×3m3DDarkRoomusingAgilent8960 (5513C)。 3.3MatchingCircuitDescriptionMatchhaNOshavechange， ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -4- 4EffectiveRadiatedPowerAndIsotopicSensitivitySummation ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -5- ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -6- ProjectQS36write: WEIX Name:AT907SampleRecognitionLetter Date:2024-06-19 EditionExamineand verify: LI CHANYONG A CONFIDENTIAL ChangfengElectronicsscienceandtechnologyCo.,Ltd. Page -7- 5Structureassemblydiagram

No.：BCTC/RF-EMC-005 Page: 1 of 57 Edition：B.2 TEST REPORT Shenzhen BCTC Testing Co., Ltd. Report No.: BCTC2407127627E Applicant: Shenzhen Yougu Intelligent Technology Co., Ltd. Product Name: Smart watch Test Model: J47 Tested Date: 2024-07-16 to 2024-07-22 Issued Date: 2024-07-22 Report No.: BCTC2407127627E No.：BCTC/RF-EMC-005 Page: 2 of 57 Edition：B.2 FCC ID:2AQ4V-J47 The test report is effective only with both signature and specialized stamp. This result(s) shown in this report refer only to the sample(s) tested. Without written approval of Shenzhen BCTC Testing Co., Ltd, this report can’t be reproduced except in full. The tested sample(s) and the sample information are provided by the client. Product Name: Smart watch Trademark: N/A Model/Type reference: J47 Prepared For: Shenzhen Yougu Intelligent Technology Co., Ltd. Address: Room 24J, Block C, Wanguo Food City, No.9, Pinglang Road,Nanwan Street, Longgang District, Shenzhen, China Manufacturer: Shenzhen Yougu Intelligent Technology Co., Ltd. Address: Room 24J, Block C, Wanguo Food City, No.9, Pinglang Road,Nanwan Street, Longgang District, Shenzhen, China Prepared By: Shenzhen BCTC Testing Co., Ltd. Address: 1-2/F., Building B, Pengzhou Industrial Park, No.158, Fuyuan 1st Road, Zhancheng, Fuhai Subdistrict, Bao'an District, Shenzhen, Guangdong, China Sample Received Date: 2024-07-16 Sample tested Date: 2024-07-16 to 2024-07-22 Issue Date: 2024-07-22 Report No.: BCTC2407127627E Test Standards: FCC Part15.247 ANSI C63.10-2013 Test Results: PASS Remark: This is Bluetooth BLE radio test report. Tested by: Approved by: Tang Changyu/ Project Handler Zero Zhou/Reviewer Report No.: BCTC2407127627E No.：BCTC/RF-EMC-005 Page: 3 of 57 Edition：B.2 Table Of Content Test Report Declaration Page 1. Version .................................................................................................................. 5 2. Test Summary ....................................................................................................... 6 3. Measurement Uncertainty ..................................................................................... 7 4. Product Information And Test Setup ..................................................................... 8 4.1 Product Information ............................................................................................... 8 4.2 Test Setup Configuration ...................................................................................... 8 4.3 Support Equipment ............................................................................................... 9 4.4 Channel List .......................................................................................................... 9 4.5 Test Mode ............................................................................................................. 9 4.6 Table Of Parameters Of Text Software Setting ................................................... 10 5. Test Facility And Test Instrument Used ............................................................... 11 5.1 Test Facility ......................................................................................................... 11 5.2 Test Instrument Used .......................................................................................... 11 6. Conducted Emissions .......................................................................................... 13 6.1 Block Diagram Of Test Setup .............................................................................. 13 6.2 Limit .................................................................................................................... 13 6.3 Test Procedure ................................................................................................... 13 6.4 EUT Operating Conditions .................................................................................. 13 7. Radiated Emissions ............................................................................................. 16 7.1 Block Diagram Of Test Setup .............................................................................. 16 7.2 Limit .................................................................................................................... 17 7.3 Test Procedure ................................................................................................... 18 7.4 EUT Operating Conditions .................................................................................. 19 7.5 Test Result .......................................................................................................... 19 8. Radiated Band Emission Measurement And Restricted Bands Of Operation ..... 24 8.1 Block Diagram Of Test Setup .............................................................................. 24 8.2 Limit .................................................................................................................... 24 8.3 Test Procedure ................................................................................................... 25 8.4 EUT operating Conditions ................................................................................... 25 8.5 Test Result .......................................................................................................... 26 9. Power Spectral Density Test ............................................................................... 27 9.1 Block Diagram Of Test Setup .............................................................................. 27 9.2 Limit .................................................................................................................... 27 9.3 Test Procedure ................................................................................................... 27 9.4 EUT Operating Conditions .................................................................................. 27 9.5 Test Result .................................................................…

Text truncated - open the document above for the full version.

17. EUT Test Setup Photographs Conducted Measurement Photo Radiated Measurement Photos
