2AQAVHP200HOTEL LOCK

Version 1.0 - 1 - USER GUIDE HP200 / HP200E HOTEL DOOR LOCK Version 1.0 - 2 - Table of Contents 1. Understanding HP200, HP200E Hotel Door Lock ................ 3 1.1 What is HP200, HP200E Hotel Door Lock? ................................................................ 3 1.2 Features by model ....................................................................................................... 3 1.3 Operation cards ........................................................................................................... 5 2. Types of Lock Operating Scenario ....................................... 6 2.1 Guest Card issue ............................................................................................................ 6 2.2 Using RFID card ............................................................................................................. 9 2.3 Using Smartphone .......................................................................................................... 9 2.3.1 Synchronizing guest card to Smartphone .......................................................... 10 2.3.2 Using Mobile Bluetooth (Esmart Sync) .............................................................. 12 3. Lock Operation .................................................................... 16 3.1 Lock Installation ............................................................................................................ 16 3.2 Lock Setting(LIS) card .................................................................................................. 18 Main Item Description ................................................................................................. 18 3.4 Open in Emergency ...................................................................................................... 20 Main Item Description ................................................................................................. 21 3.5 Low Battery warning and battery change .................................................................. 22 4. Specification ........................................................................ 24 5. Indication Instruction .......................................................... 24 ANNEX A Beep & LED Table & Trouble Shooting .................. 24 6 Regulatory Statement ........................................................... 27 Version 1.0 - 3 - 1. Understanding HP200, HP200E Hotel Door Lock 1.1 What is HP200, HP200E Hotel Door Lock? - HP200, HP200E hotel door lock is operated by either 13,56 MHz RF keys or Mobile. - HP200, HP200E can work as both offline (standalone) and online mode. - To set HP200, HP200E as online system, additional peripherals such as Access point, Server and client software are necessary. - This device is used with AP200 (or AP300) by Zigbee communication. (For more information, please refer to the Zigbee Access Point Manual) 1.2 Features by model FEATURES HP200 HP200E Front Design e-Paper display - Yes Touch Key (12 Key) Yes - Support Mortise ANSI(top), ANSI Standard(bottom), Euro #6 ANSI(top), ANSI Standard(bottom), Euro #6 Support deadbolt Yes Yes Panic release Yes Yes Mechanical key override Yes Yes Low battery indicator Yes Yes Version 1.0 - 4 - Power supply 4 x AA (Alkaline battery) 4 x AA (Alkaline battery) Battery Lifetime 18 months for wireless online lock 18 months for wireless online lock 24 months for standalone lock 24 months for standalone lock Block/Unblock card Yes Yes Online Intrusion alarm (over 3 times of unauthorized open trial) Yes Yes Online Ajar alarm Yes Yes Instant Stay Extension Yes Yes Instant Room change Yes Yes Automatic unlock/lock Yes Yes Passage mode Yes Yes Remote audit trail Yes (Online: Unlimited/Offline:2,000 events) Yes (Online: Unlimited/Offline:2,000 events) Remote Maintenance reporting Yes Yes Mobile Key Access Yes Yes Version 1.0 - 5 - 1.3 Operation cards Card Name Description Card type Key card • Security Key value to be loaded to locks at scanning. • Then, the locks will accept only the RFID cards which have the same security key value. Mifare 1KB Setup card • Lock will be programmed with various options at scanning. • Setup card can be set from PTHMS Client Pro Software Staff card • For staffs access card • Set name/title/authority/holiday, etc. Emergency card • All rooms can be opened with an emergency card. Particular attention should be paid to loss Blocking card • A Blocking card is used to block all user groups on a particular door. For example, this card is used to block all groups except Maid by reading the blocking card when Maid cleans the Fitness Club. Clearance card • A card that cancels the registered Guest Card. This card can only be used after the Employee (Maid) Card has been read. Passage Mode card • A card to unlock the door until the specified time for the defined door. Privacy card • It is operated by the Toggle concept in order to display “D.N.D” on the door with the card provided in each room. It can be operated only when Guest Card is registered. In order to delete it, Maid must read Maid Card/Employee Card and then Erase Card/Power-Down Card to cancel it, or it will be automatically cancelled when a new guest card is registered. Audit trail card • A card for collecting usage histories for each lock. (Up to 2000 cases) Combi card (Mifare + Kona COS) Lock info card • A card to read the setting value of each door. Version 1.0 - 6 - 2. Types of Lock Operating Scenario HP200 Hotel Door locks are designed to work for the various operation requirements by simple set up process. Following operation modes can be set by hotel staffs and guests. 2.1 Guest Card issue Guest issue It is a screen for checking in and issuing a guest card for the guests who stay in a general room. Main Item Description Item Description Room No. Room Number you just chose to check-in will be shown. - Room number must be at least 3 digits for floor number and room number. . Ex) Floor1, Room1 “101” Floor10, Room2 “1…
