● SETTING UP THE DISPLAY CONSOLE POWERING UP THE DISPLAY CONSOLE Plug the power adapter into the power jack located in the back of the display console. Insert 3 new AAA alkaline batteries (not included) for backup. Once the display console is turned on, it will automatically enter pairing mode. ● ● PAIRING THE WIRELESS 7-IN-1 SENSOR Once your display console powers on, it should automatically search for and connect to the wireless sensors. If the display console does not connect within the first 5 minutes, ref er to the following section, “RE-PAIRING SENSOR”. You will see the icon of an antenna scrolling in the temperature and humidity (outdoor) section of the display. Once the pairing process completes, the antenna icon will appear solid (not flashing), and the readings for outdoor temperature and humidity, wind speed, wind direction, UV, light intensity, and rainfall will appear in their designated sections of the LCD display. ● ● ● ● RE-PAIRING SENSOR If the connection fails or the display console is reset, then press and hold the 【CHANNEL】button over 2 seconds to enter pairing mode, and the display console will re-register all the sensors that have already been registered to it befor e, (i.e. the display console will not lose the connection of the sensors that you’d paired up befor e.) 17 Model number: Main Features: YT60245 Outdoor temperature/humidity reading, weather index Wind direc�on & speed Indoor temperature/humidity reading Weather forecast Time & date, moon phas e, Weekday Light intensity UV in dex Rain Baro meter WI-FI CONNECTION STATUS When the display console successfully connects to your Wi-Fi router, the Wi-Fi signal will appear on the LCD display. If the Wi-Fi signal is not stable or the display console is trying to connect to the router, the icon will flash. If the icon disappeared, it means the display console is not connected to the Wi-Fi router. TIME SERVER CONNECTION STATUS After the display console has connected to the internet, it will attempt to connect to the internet time server to obtain the UTC time. Once the connection succeeds and the display console’s time has updated. The icon “SYNC” will appear on the LCD. To display the correct time for your specific time zone, you will need to change the time zone in the CLOCK setting mode from 00 to your time zone (eg.GMT+1). If you don’t know your time zone, you can look it up online. Flashing: the display console is attempting to connect to your wireless router Solid: the display console has been connected to your wireless router. In Normal time display, press and hold 【SET】over 2 seconds to enter time setting mode. Pr ess and release 【WIND/+】 and 【BARO/-/ 】 to adjust the values. Hold 【WIND/+】 and 【BARO/-/ 】 over 2 seconds to adjust the values rapidly. Pr ess and release 【SET】to confirm and move to the next item. To exit the setting mode any time, press 【 LIGHT/SNOOZE】button. 14 18 13 13 14 10 10 ● OPERATING INSTRUCTIONS Setting the Clock CLOCK Setting Order 2. NTP On/Off 5. DST On/Off 8. Month 11. Hour 14. Pressure Unit 17 . Rainfall Unit 20. End of setting 3. Language 6. M-D/D-M Date Format 9. Day 12. Minute 15. Relative Pressure Calibration 18. Wind Speed Unit 1. BEEP On/Off 4. Time Zone 7. Year 10. 12/24 Hour Format 13. Temperature Unit 16. Light Intensity Unit 19. Hemisphere 1.) 2.) 3.) 4.) 5.) 6.) 7.) 8.) Pr ess and hold 【SET】button entering the settings. Beep ON flashes. Press 【WIND/+】 or 【BARO/-/ 】 to change between Beep on and Beep off. Press 【SET】to select NTP on/off. When NTP ON flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between NTP on and NTP off. Press 【SET】to select Language. When Language flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between weekday languages. Press 【SET】to select time zone. When Time Zone flashes, press 【WIND/+】 or 【BARO/-/ 】 to set time zone. Pr ess 【SET】to select DST on/off. When DST ON flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between DST on and DST off. Press 【SET】to select date format. When D--M flashes, press 【WIND/+】 or 【BARO/-/ 】 to switch between M-D and D-M date format. Press 【SET】to select year. When year flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the calendar year. Press 【SET】to select month. When month flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the calendar month. Press 【SET】to select day. 1413 10 10 10 10 10 10 10 10 10 14 13 14 13 14 13 14 13 14 13 14 13 14 13 When Day flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the calendar day. Press 【SET】to select 12/24-hour format. When 12 H flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between 12 hour and 24 hour format. Press 【SET】to select hour. When hour flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the hour. Pr ess 【SET】to select minute. When minute flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the minute. Pr ess 【SET】to select temperature unit. When °F flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between °F and °C. Press 【SET】to select pressure unit. When pressure unit flashes, press 【WIND/+】 or 【BARO/-/ 】 to change between hPa, inHg and mmHg. Press 【SET】to select relative pressure calibration. When Relative Pressure flashes, press 【WIND/+】 or 【BARO/-/ 】 to adjust the relative pressure. Press 【SET】to select Light intensity unit. When Light intensity unit flashes, press 【WIND/+】 or 【BARO/-/ 】 to change unit between Klux, fc and w/m 2 . Press 【SET】to select rainfall unit. When Rain unit flashes, press 【WIND/+】 or 【BARO/-/ 】 to change unit between in and mm. Press 【SET】to select windspeed unit. When Windspeed unit flashes, press 【WIND/+】 or 【BARO/-/ 】 to change unit between in and mm. Press 【SET】to select hemisphere. When NTH flashes, press 【WIND/+】 or 【BARO/-/ 】 to change hemisphere between NTH (northern) and STH (southern). Press 【SET】to save and exit the setting. It will return to the normal mode display. 9.) 10.) 11.) 12.) 13.) 14.) 15.) 16.) 17 .) 18.) 19.) 10 10 10 10 10 10 10 10 10 10 10 14 13 14 13 14 13 14 13 14 13 14 13 14 13 14 13 14 13 14 13 14 13 In alarm time display, press 【T…

Text truncated - open the document above for the full version.

1/1 US Agent for Service of ProcessLETTER OF ATTESTATION TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 US Agent for Service of Process: Company Name: CLF Import and Export Limited FRN: 0033489683 Contact Name:David Chen Address:1312 17th Street #692,Denver,CO 80202,Unite States Telephone No:(949)254-2565 Email:[email protected] EIN:98-1720547 Applicant: Company name: Fujian Youtong Industries Co., Ltd. Product Description: weather station Grantee code: 2AQBD FCC ID: 2AQBD-60245 FRN: 0027658244 Contact Name:Dongsheng Huang Address:North part of 1st 2nd & 3rd floor Building 1No.18 Majiang Road Mawei Fuzhou Fujian China Telephone No:+86-59188054335 Email:[email protected] [Fujian Youtong Industries Co., Ltd.] certifies that, as of the date of this filing of the application with the TCB, [ CLF Import and Export Limited] is our designated US agent for service of process for the above referenced FCC ID. [Fujian Youtong Industries Co., Ltd.] accepts to maintain an agent for no less than one year after the grantee has terminated all marketing and importation or the conclusion of any commission related proceeding involving equipment. [ CLF Import and Export Limited ] accepts, as of the date of the filing of the application, the obligation of the designated US agent for service of process for the above reference FCC ID. The US Agent for Service of Process is aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. The Applicantis aware of and agrees to comply with the requirements outlined in the FCC Equipment Authorization Program, Report and Order FCC 22-84, and clause § 2.911. Date: 2024/7/25 Applicant’s Name:Dongsheng Huang US Agent’s Name: David Chen Title:General Manager Title: GM Signature Signature 1/1

C5266091_X24_Ed.2 1/1 “Attestation Statements” TO: Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 The Commission adopted rules that prohibit equipment authorization for “covered” telecommunications equipment and video surveillance equipment produced by entities identified on the Commission’s Covered List 1 , which is periodically updated. See the Covered List for more details. This Attestation Statement is to confirm that we follow the Section 2.911(d)(5)(i)-(ii) Applicant Company name: Fujian Youtong Industries Co., Ltd. Applicant’s FRN：0027658244 Product Description: weather station Grantee code: 2AQBD FCC ID: 2AQBD-60245 Contact Name: Dongsheng Huang Address: North part of 1st 2nd & 3rd floor Building 1 No.18 Majiang Road Mawei Fuzhou Fujian China Telephone No: +86-59188054335 Fax No: / Email: [email protected] i. [Fujian Youtong Industries Co., Ltd. ] (“the applicant”) certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. The applicant must sign this certification. ii. [Fujian Youtong Industries Co., Ltd. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] (as a specifically named entity or any of its subsidiaries or affiliates) identified on the Covered List as an entity producing “covered” equipment. The applicant must sign this certification. [Fujian Youtong Industries Co., Ltd. ] (“the applicant”) certifies that, as of the date of the filing of the application, the applicant [is not] identified on the Covered List as an entity producing “covered” equipment . Date: 2024/7/25 Applicant’s Name: Dongsheng Huang Title: General Manager Signature 1 The Commission’s Covered List is published by the Public Safety and Homeland Security Bureau and posted on the Commission’s website. This Covered List, which is periodically updated, identifies particular equipment, produced by particular entities, that constitutes “covered” equipment. https://www.fcc.gov/supplychain/coveredlist

Fujian Youtong Industries Co., Ltd. Product Similarity Declaration Product name: weat her stat ion Model name: YT60245, KYF-WEATHER-001 FCC ID: 2AQBD-60245 We (Fujian Youtong Industries Co., Ltd.) hereby state that all the models are electrical identical including the same software parameter and hardware design (i.e., circuit design, PCB Layout, RF module/circuit, antenna type(s) and antenna location, components on PCB, etc.,), same mechanical structure and design (including product enclosure, materials, etc.,), the only difference is the model name are different. Signature: Name: Dongsheng Huang Title: General Manager Address: North part of 1st 2nd & 3rd floor Building 1 No.18 Majiang Road Mawei Fuzhou Fujian China Date: 2024-7-25

C5266091_X8_Ed.1 1/1 Letter of Authorization Company: Fujian Youtong Industries Co., Ltd. Address: North part of 1st 2nd & 3rd floor Building 1 No.18 Majiang Road Mawei Fuzhou Fujian China Product Name: weather station Model Number: YT60245, KYF-WEATHER-001 FCC Identifier: 2AQBD-60245 We authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, to act on our behalf on all matters concerning the above named equipment. Any individual within LGAI Technological Center S.A. is authorized to act on our behalf and take action on the application. We declare that authorize LGAI Technological Center S.A., Ronda de la Font del Carme, s/n, 08193 Bellaterra, Spain, is allowed to forward all information related to the approval project to the Federal Communication Commission and to discuss any issues concerning the approval application. Any and all acts carried out by LGAI Technological Center S.A. on our behalf shall have the same effect as acts of our own. Name: Dongsheng Huang 2024-7-25 Title: General Manager Signature of applicant:

C5266091_X10_Ed.2 1/1 Fujian Youtong Industries Co., Ltd. Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046w Date: 2024-7-25 Subject: Request for Confidentiality FCC ID: 2AQBD-60245 To Whom It May Concern, Pursuant to the provisions of Sections 0.457 and 0.459 of Commission's rules (47CFR0.457, 0.459), we are requesting the Commission to withhold the following attachment(s) as confidential document from public disclosure. Exhibits Long-Term Confidentiality Short-Term Confidentiality NOTE 2 ID Label/Location No No Attestation Statement No No External Photos No ☐ Block Diagram ☒ ☐ Schematics ☒ ☐ Test Report No No Test Setup Photos No ☐ User’s Manual ☐ NOTE 1 ☐ Internal Photos ☐ NOTE 1 ☐ Parts List / Tune Up ☐ ☐ RF Exposure Info No No Operational Description ☒ ☐ Cover Letter(s) No No SDR Software / Security Info ☐ No NOTE 1: Long-Term Confidentiality may be permitted under special conditions (See II. LONG-TERM CONFIDENTIALITY, Section 3 of KDB 726920, use last in force) NOTE 2: Short-Term Confidentiality can be requested for a maximum of 180 days from the date of the grant. Above mentioned document contains detailed system and equipment description are considered as proprietary information in operation of the equipment. The public disclosure of above documents might be harmful to our company and would give competitor an unfair advantage in the market. In case of short-term Confidentiality, the applicant requests the exhibits selected above are withheld from public view for a period of ______ days from the date of the Grant of Equipment Authorization and prior to marketing. It is our understanding that all measurement test reports, FCC ID label format and correspondent during certification review process cannot be granted as confidential documents and those information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Dongsheng Huang Title: General Manager

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Product Name: weather station Test Model No.: YT60245 EUT Constructional Details Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 3 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 4 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 5 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 6 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 7 of7 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn ------End------

Model No.: YT60235 FCC ID: 2AQBD-60235

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Product Name: weather station Test Model No.: YT60245 EUT Constructional Details： Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 3 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 4 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 5 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn 915MHz Antenna Shenzhen QC Testing Laboratory Co., Ltd. Page 6 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 7 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Shenzhen QC Testing Laboratory Co., Ltd. Page 8 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn WiFi ANTENNA Shenzhen QC Testing Laboratory Co., Ltd. Page 9 of9 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn ------End------

Shenzhen QC Testing Laboratory Co., Ltd. Page 1 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn FCC ID: 2AQBD-60245 RF Exposure Evaluation FCC KDB publication 447498 D01 General RF Exposure Guidance v06: Mobile and Portable Devices RF Exposure Procedures and Equipment Authorization Policies. Limits The criteria listed in the following table shall be used to evaluate the environment impact of human exposure to radio frequency (RF) radiation as specified in 1.1307(b) Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Where Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. Test Procedure Software provided by client enabled the EUT to transmit and receive data at lowest, and highest channel individually. Shenzhen QC Testing Laboratory Co., Ltd. Page 2 of 2 Address: East of 1/F., Building E, Xinghong Science Park, No.111, Shuiku Road, Fenghuanggang, Xixiang Street, Bao'an District, Shenzhen, Guangdong, China Tel: 0755-23008269 Fax: 0755-23726780 www.qctest.com.cn Test Result of RF Exposure Evaluation For 2.4G Wi-Fi Antenna gain=2.21dBi Test Frequency （MHz） Minimum Separation Distance (cm) Output Power (dBm) Target power (dBm) Target power (mW) Antenna Gain (Numeric) Power Density Limit (mW/cm 2 ) Power Density At 20 cm (mW/cm 2 ) Test Results 2412 20.00 16.56 16±1 50.12 1.66 1 0.0166 Pass 2437 20.00 16.64 16±1 50.12 1.66 1 0.0166 Pass 2462 20.00 16.54 16±1 50.12 1.66 1 0.0166 Pass The measurement results comply with the FCC Limit per 47 CFR 2.1091 for the uncontrolled RF Exposure.
