2AQKA-AT20914K WiFi Dash Cam

RF Exposure Information This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator and your body.

Shenzhen Fowke Innovation Technology Co., Ltd Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 3, 2024 FCC ID: 2AQKA-AT2091 Ref. #1: Attestation Statements Part 2.911(d)(5)(i) Filing Shenzhen Fowke Innovation Technology Co., Ltd certifies that the equipment for which authorization is sought is not “covered” equipment prohibited from receiving an equipment authorization pursuant to section 2.903 of the FCC rules. Ref. #2: Attestation Statements Part 2.911(d)(5)(ii) Filing Shenzhen Fowke Innovation Technology Co., Ltd certifies that, as of the date of the filing of the application, the applicant is not identified on the Covered List (as a specifically named entity or any of its subsidiaries or affiliates) as an entity producing “covered” equipment. Applicant: Shenzhen Fowke Innovation Technology Co., Ltd Address: 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Contact Person: Shuiping Luo/ Project Director Tel.: +86-13684992953 Email: [email protected] Sincerely, Signature:

ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 1 AntennaApproval Sheet For FD550WProject CustomerFowkeInnovationProject FD550W BandWiFi2.4G ZCPNFD005-CA-93 VersionR:AData2024-7-2 RFME CheckedBy ConfirmedBy CustConfirm ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 2 1.Manufacturer information Company name：Shenzhen Zhongcheng communication products Co., Ltd Address: 5th floor, building C, Huafeng Industrial Zone, Liuxian Road, 71 District, Bao'an, Shenzhen 2. Summary of the DUT FD550W Picture Antenna Picture 3. Electrical Specification: Antenna typesBuilt-in WIFI antenna Frequency2400-2500 MHz Impedance 50 Ω VSWR< 2.0 Peak Gain 2.4GHZ
1.59
dbi Efficiency>35 % Antenna Material FPCB+CoaxialCable Connector Type1.13 MHF-1-Plug ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 3 4. Test Condition 4.1TEST ITEMTESTING INSTRUMENTREMARKS PASSIVE TEST 1.RadiationPattern 2.AntennaGain 3.ReturnLoss 4.S.W.R 1.SatimoSG24(3D) 2.Agilent8960E5515C 3.R&SZVL6 4.2 Antenna installation diagram: 5. RFPerformance 5.1 Passive parameters Freq.(MHz)24002410242024302440245024602470248024902500 Gain (dBi) 0.580.661.11.021.171.590.720.080.721.191.73 5.2 S Parameter Frequency (MHz)240024502480 Return Loss(dB)-20.58-22.74-15.39 VSWR1.631.281.81 ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 4 5.3 Antenna 3D Radiation Pattern (Unit:dbi) ShenzhenZhongchengcommunicationproductsCo.,Ltd Page 5 6. ME Drawing for the antenna

Shenzhen Fowke Innovation Technology Co., Ltd Date：2024-07-03 Product Model Number: AT2091, AT2455 FCC ID：2AQKA-AT2091 To whom it may concern, Re: Product Certification Representative Authorization Letter We authorize QAI Laboratories Ltd. 3980 North Fraser Way, Burnaby B.C. Canada V5J 5K5 to act on our behalf on all matters concerning the above named equipment. This shall include the following: • Testing • Approval applications and procedures We declare that ORGANIZATION. is allowed to forward all information related to the approval project to the applied certification body and to the notification entities and to discuss any issues concerning the approval application. Any and all acts carried out by ORGANIZATION. on our behalf shall have the same effect as acts of our own. By: Contact Listed on FCC Wesbite Title: Project Director Email: [email protected] Telephone: +86-13684992953 On behalf of: Shenzhen Fowke Innovation Technology Co., Ltd

Shenzhen Fowke Innovation Technology Co., Ltd Office of Engineering Technology Federal Communications Commission 7435 Oakland Mills Road Columbia, MD 21046 USA Date: July 3, 2024 Subject; Request for Confidentiality FCC ID: 2AQKA-AT2091 To Whom It May Concern, Pursuant to the provisions of the Commission’s rules Title 47 Sections §0.457 and §0.459, we are requesting the Commission to withhold the following attachment(s) as confidential documents from public disclosure indefinitely. These documents contain detailed system and equipment descriptions and are considered as proprietary information in operation of the equipment. The public disclosure of these documents might be harmful to our company and would give competitors an unfair advantage in the market. Schematic Diagram Block Diagram Parts List Operational Description Tune-up Procedure Software Security Requirements for UNII devices In additional to above mentioned documents, in order to comply with the marketing regulations in Title 47 CFR §2.803 and the importation rules in Title 47 CFR §2.1204, while ensuring that business sensitive information remains confidential until the actual marketing of newly authorized devices, we request Short Term Confidentiality of the following attachment(s); External Photos Test Setup Photos Internal Photos User Manual For 45 days, pursuant to Public Notice DA 04-1705. OR For 180 days pursuant to KDB 726920 D01. It is our understanding that all measurement test reports, FCC ID label format and correspondence during the certification review process cannot be granted as confidential documents and this information will be available for public review once the grant of equipment authorization is issued. Sincerely, Signature: Name: Shuiping Luo Title: Project Director

Shenzhen Fowke Innovation Technology Co., Ltd 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Product Similarity Declaration Date: July 3, 2024 FCC ID: 2AQKA-AT2091 Model Number: AT2091,AT2455 To: Federal Communications Commission Authorization and Evaluation Division 7435 Oakland Mills Road Columbia, MD To Whom It May Concern, We, Shenzhen Fowke Innovation Technology Co., Ltd, hereby declare that our product (4K WiFi Dash Cam) Model Number:AT2091,AT2455 board, Schematic, Hardware version, Software version, structure and internal photos are same, only the model number is different due to marketing purposes. Should you have any questions or comments regarding this matter, please have my best attention. Sincerely, (Signed) Name: Shuiping Luo/ Project Director Company: Shenzhen Fowke Innovation Technology Co., Ltd Address:4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Phone: +86-13684992953 Fax: +86-13684992953 E-Mail: [email protected]

Report No.: BTEK240506004AE Page: 1 of 4 Appendix EUT Photos for BTEK240506004AE Report No.: BTEK240506004AE Page: 2 of 4 EUT Constructional Details (EUT Photos) EUT View 1 EUT View 2 EUT View 3 Report No.: BTEK240506004AE Page: 3 of 4 EUT View 4 EUT View 5 EUT View 6 Report No.: BTEK240506004AE Page: 4 of 4 EUT View 7

Report No.: BTEK240506004AE Page: 1 of 4 Appendix EUT Photos for BTEK240506004AE Report No.: BTEK240506004AE Page: 2 of 4 EUT Constructional Details (EUT Photos) EUT View 8 EUT View 9 EUT View 10 Report No.: BTEK240506004AE Page: 3 of 4 EUT View 11 EUT View 12 EUT View 13 Report No.: BTEK240506004AE Page: 4 of 4 EUT View 14 EUT View 15 EUT View 16 Antenna

Report No.: BTEK240506004AE002 Page: 1 of 5 TEST REPORT Application No.: BTEK240506004AE Applicant: Shenzhen Fowke Innovation Technology Co., Ltd Address of Applicant: 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Manufacturer: Shenzhen Fowke Innovation Technology Co., Ltd Address of Manufacturer: 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Equipment Under Test (EUT): EUT Name: 4K WiFi Dash Cam Test Model.: AT2091 Adding Model(s): AT2455 Trade Mark: Atomi FCC ID: 2AQKA-AT2091 Standard(s) : 47 CFR Part 2 Subpart J Section 2.1091 Date of Receipt: 2024-06-06 Date of Test: 2024-06-07 to 2024-06-24 Date of Issue: 2024-06-25 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Lion Cai/ Approved & Authorized EMC Laboratory Manager Report No.: BTEK240506004AE002 Page: 2 of 5 Revision Record Version Chapter Date Modifier Remark V0 2024-06-25 Original Authorized for issue by Zora Huang /Project Engineer June Li /Reviewer Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Report No.: BTEK240506004AE002 Page: 3 of 5 2 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Contents .................................................................................................................................................... 3 3 General Information .................................................................................................................................. 4 3.1 Details of E.U.T. ................................................................................................................................. 4 3.2 Description of Support Units .............................................................................................................. 4 3.3 Test Location ...................................................................................................................................... 4 3.4 Deviation from Standards ................................................................................................................... 4 3.5 Abnormalities from Standard Conditions ........................................................................................... 4 4 Test Requirement ........................................................................................................................................... 5 4.1Assessment Result..................................................................................................................................... 5 Report No.: BTEK240506004AE002 Page: 4 of 5 General Information 3.1 Details of E.U.T. Power supply: USB 5V/ Battery 3.7V Support Standards: 802.11b, 802.11g, 802.11n-HT20 Frequency Range: 2412-2462MHz for 802.11b/g/n(HT20) Type of Modulation: 802.11b: DSSS; 802.11g/n: OFDM Quantity of Channels 11 for 802.11b/g/n(HT20) Channel Separation: 5MHz Type of Antenna: FPCB Antenna Antenna Gain: 1.59dBi Sample No.: BTEK240506004AE-01 Remark: The information in this section is provided by the applicant or manufacturer, BANTEK is not liable to the accuracy, suitability, reliability or/and integrity of the information. Model No.: AT2091, AT2455 Only the model AT2091 was tested. According to the declaration from the applicant, the electrical circuit design, layout, components used, internal wiring and functions of other models are identical for the above models, with only difference on Model No. 3.2 Description of Support Units Description Manufacturer Model No. Serial No. / / / / 3.3 Test Location All tests were performed at: Shenzhen BANTEK Testing Co., Ltd., A5&A6, Building B1&B2, No.45 Gangtou Road, Bogang Community, Shajing Street, Bao'an District, Shenzhen, Guangdong, China 518103 Tel:0755-2334 4200 Fax: 0755-2334 4200 FCC Registration Number: 264293 Designation Number: CN1356 No tests were sub-contracted. 3.4 Deviation from Standards None 3.5 Abnormalities from Standard Conditions None Report No.: BTEK240506004AE002 Page: 5 of 5 4 Test Requirement According to §1.1307(b)(1) and KDB 447498 D01 General RF Exposure Guidance v06, system operating under the provisions of this section shall be operating in a manner that the public is not exposed to radio frequency energy level in excess limit for maximum permissible exposure. Limits for Maximum Permissible Exposure (MPE) Frequency range (MHz) Electric field strength (V/m) Magnetic field strength (A/m) Power density (mW/cm 2 ) Averaging time (minutes) (A) Limits for Occupational/Controlled Exposures 0.3–3.0 614 1.63 *(100) 6 3.0–30 1842/f 4.89/f *(900/f 2 ) 6 30–300 61.4 0.163 1.0 6 300–1500 f/300 6 1500–100,000 5 6 (B) Limits for General Population/Uncontrolled Exposure 0.3–1.34 614 1.63 *(100) 30 1.34–30 824/f 2.19/f *(180/f 2 ) 30 30–300 27.5 0.073 0.2 30 300–1500 f/1500 30 1500–100,000 1.0 30 f = frequency in MHz Friis transmission formula: Pd = (Pout*G)/(4*pi*r 2 ) Wh ere Pd = power density in mW/cm 2 , Pout = output power to antenna in mW; G = gain of antenna in linear scale, Pi = 3.1416; R = distance between observation point and center of the radiator in cm Pd id the limit of MPE, 1 mW/cm 2 . If we know the maximum gain of the antenna and the total power input to the antenna, through the calculation, we will know the distance r where the MPE limit is reached. 4.1Assessment Result Passed Not Applicable Frequency (MHz) Type Conducted Power (dBm) Maximum Tune- up (dBm) Power Density (mW/cm2) Limit (mW/cm2) Result 2437 2.4G-Wi-Fi 16.30 16.50 0.0158 1.0000 Pass Note: 1.…

Text truncated - open the document above for the full version.

Report No.: BTEK240506004AE001 Page: 1 of 38 Appendix 2.4G_WIFI Test Data for BTEK240506004AE Report No.: BTEK240506004AE001 Page: 2 of 38 Table of Contents 1. -6dB Bandwidth .......................................................................................................................................................... 3 2. 99% Occupied Bandwidth .......................................................................................................................................... 8 3. Duty Cycle ................................................................................................................................................................. 13 4. MAX. Output Power ................................................................................................................................................. 18 5. Power Spectral Density ............................................................................................................................................. 19 6. Bandedge .................................................................................................................................................................. 24 7. Spurious Emission ..................................................................................................................................................... 30 Report No.: BTEK240506004AE001 Page: 3 of 38 1. -6dB Bandwidth Condition Antenna Modulation Frequency (MHz) -6dB BW(MHz) limit(kHz) Result NVNT ANT1 802.11b 2412.00 9.08 500 Pass NVNT ANT1 802.11b 2437.00 9.09 500 Pass NVNT ANT1 802.11b 2462.00 9.09 500 Pass NVNT ANT1 802.11g 2412.00 16.59 500 Pass NVNT ANT1 802.11g 2437.00 16.59 500 Pass NVNT ANT1 802.11g 2462.00 16.59 500 Pass NVNT ANT1 802.11n(HT20) 2412.00 17.82 500 Pass NVNT ANT1 802.11n(HT20) 2437.00 17.80 500 Pass NVNT ANT1 802.11n(HT20) 2462.00 17.80 500 Pass -6dB_Bandwidth_NVNT_ANT1_802_11b_2412 -6dB_Bandwidth_NVNT_ANT1_802_11b_2437 -6dB_Bandwidth_NVNT_ANT1_802_11b_2462 Report No.: BTEK240506004AE001 Page: 4 of 38 -6dB_Bandwidth_NVNT_ANT1_802_11g_2412 -6dB_Bandwidth_NVNT_ANT1_802_11g_2437 Report No.: BTEK240506004AE001 Page: 5 of 38 -6dB_Bandwidth_NVNT_ANT1_802_11g_2462 -6dB_Bandwidth_NVNT_ANT1_802_11n(HT20)_2412 Report No.: BTEK240506004AE001 Page: 6 of 38 -6dB_Bandwidth_NVNT_ANT1_802_11n(HT20)_2437 -6dB_Bandwidth_NVNT_ANT1_802_11n(HT20)_2462 Report No.: BTEK240506004AE001 Page: 7 of 38 Report No.: BTEK240506004AE001 Page: 8 of 38 2. 99% Occupied Bandwidth Condition Antenna Modulation Frequency (MHz) 99%%BW(MHz) NVNT ANT1 802.11b 2412.00 13.560 NVNT ANT1 802.11b 2437.00 13.454 NVNT ANT1 802.11b 2462.00 13.394 NVNT ANT1 802.11g 2412.00 17.395 NVNT ANT1 802.11g 2437.00 17.373 NVNT ANT1 802.11g 2462.00 17.345 NVNT ANT1 802.11n(HT20) 2412.00 18.056 NVNT ANT1 802.11n(HT20) 2437.00 18.012 NVNT ANT1 802.11n(HT20) 2462.00 18.001 99%_Occupied_Bandwidth_NVNT_ANT1_802_11b_2412 99%_Occupied_Bandwidth_NVNT_ANT1_802_11b_2437 99%_Occupied_Bandwidth_NVNT_ANT1_802_11b_2462 Report No.: BTEK240506004AE001 Page: 9 of 38 99%_Occupied_Bandwidth_NVNT_ANT1_802_11g_2412 99%_Occupied_Bandwidth_NVNT_ANT1_802_11g_2437 Report No.: BTEK240506004AE001 Page: 10 of 38 99%_Occupied_Bandwidth_NVNT_ANT1_802_11g_2462 99%_Occupied_Bandwidth_NVNT_ANT1_802_11n(HT20)_2412 Report No.: BTEK240506004AE001 Page: 11 of 38 99%_Occupied_Bandwidth_NVNT_ANT1_802_11n(HT20)_2437 99%_Occupied_Bandwidth_NVNT_ANT1_802_11n(HT20)_2462 Report No.: BTEK240506004AE001 Page: 12 of 38 Report No.: BTEK240506004AE001 Page: 13 of 38 3. Duty Cycle Condition Antenna Modulation Frequency (MHz) Duty cycle(%) Duty factor(dB) NVNT ANT1 802.11b 2412.00 100 0.00 NVNT ANT1 802.11b 2437.00 100 0.00 NVNT ANT1 802.11b 2462.00 100 0.00 NVNT ANT1 802.11g 2412.00 100 0.00 NVNT ANT1 802.11g 2437.00 100 0.00 NVNT ANT1 802.11g 2462.00 100 0.00 NVNT ANT1 802.11n(HT20) 2412.00 100 0.00 NVNT ANT1 802.11n(HT20) 2437.00 100 0.00 NVNT ANT1 802.11n(HT20) 2462.00 100 0.00 Duty_Cycle_NVNT_ANT1_802_11b_2412 Duty_Cycle_NVNT_ANT1_802_11b_2437 Duty_Cycle_NVNT_ANT1_802_11b_2462 Report No.: BTEK240506004AE001 Page: 14 of 38 Duty_Cycle_NVNT_ANT1_802_11g_2412 Duty_Cycle_NVNT_ANT1_802_11g_2437 Report No.: BTEK240506004AE001 Page: 15 of 38 Duty_Cycle_NVNT_ANT1_802_11g_2462 Duty_Cycle_NVNT_ANT1_802_11n(HT20)_2412 Report No.: BTEK240506004AE001 Page: 16 of 38 Duty_Cycle_NVNT_ANT1_802_11n(HT20)_2437 Duty_Cycle_NVNT_ANT1_802_11n(HT20)_2462 Report No.: BTEK240506004AE001 Page: 17 of 38 Report No.: BTEK240506004AE001 Page: 18 of 38 4. MAX. Output Power Condition Antenna Modulation Frequency (MHz) Detector Conducted Power(dBm) limit(dBm) Result NVNT ANT1 802.11b 2412.00 Peak 15.97 30 Pass NVNT ANT1 802.11b 2437.00 Peak 16.30 30 Pass NVNT ANT1 802.11b 2462.00 Peak 16.24 30 Pass NVNT ANT1 802.11g 2412.00 Peak 13.38 30 Pass NVNT ANT1 802.11g 2437.00 Peak 13.55 30 Pass NVNT ANT1 802.11g 2462.00 Peak 13.40 30 Pass NVNT ANT1 802.11n(HT20) 2412.00 Peak 13.40 30 Pass NVNT ANT1 802.11n(HT20) 2437.00 Peak 13.71 30 Pass NVNT ANT1 802.11n(HT20) 2462.00 Peak 13.62 30 Pass Report No.: BTEK240506004AE001 Page: 19 of 38 5. Power Spectral Density Condition Antenna Modulation Frequency (MHz) PSD(dBm/30kHz) RB factor(dB) PSD(dBm/3kHz) limit(dBm/3kHz) Result NVNT ANT1 802.11b 2412.00 -0.27 -10.00 -10.27 8 Pass NVNT ANT1 802.11b 2437.00 -0.83 -10.00 -10.83 8 Pass NVNT ANT1 802.11b 2462.00 -1.10 -10.00 -11.10 8 Pass NVNT ANT1 802.11g 2412.00 -11.52 -10.00 -21.52 8 Pass NVNT ANT1 802.11g 2437.00 -11.17 -10.00 -21.17 8 Pass NVNT ANT1 802.11g 2462.00 -11.32 -10.00 -21.32 8 Pass NVNT ANT1 802.11n(HT20) 2412.00 -11.24 -10.00 -21.24 8 Pass NVNT ANT1 802.11n(HT20) 2437.00 -10.92 -10.00 -20.92 8 Pass NVNT ANT1 802.11n(HT20) 2462.00 -11.02 -10.00 -21.02 8 Pass Power_Spectral_Density_NVNT_ANT1_802_11b_2412 Power_Spectral_Density_NVNT_ANT1_802_11b_2437 Report No.: BTEK240506004AE001 Page: 20 of 38 Power_Spectral_Density_NVNT_ANT1_802_11b_2462 Power_Spectral_Density_NVNT_ANT1_802_11g_2412 Power_Spectral_Density_NVNT_ANT1_80…

Text truncated - open the document above for the full version.

Report No.: BTEK240506004AE001 Page: 1 of 24 TEST REPORT Application No.: BTEK240506004AE Applicant: Shenzhen Fowke Innovation Technology Co., Ltd Address of Applicant: 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Manufacturer: Shenzhen Fowke Innovation Technology Co., Ltd Address of Manufacturer: 4F, Building15,Shuangxiang Factory, Shaopai Industry Area, Wulian Community, Longgang Street, Longgang District, Shenzhen, China Equipment Under Test (EUT): EUT Name: 4K WiFi Dash Cam Test Model.: AT2091 Adding Model(s): AT2455 Trade Mark: Atomi FCC ID: 2AQKA-AT2091 Standard(s) : 47 CFR Part 15, Subpart C 15.247 Date of Receipt: 2024-06-06 Date of Test: 2024-06-07 to 2024-06-24 Date of Issue: 2024-06-25 Test Result: Pass* * In the configuration tested, the EUT complied with the standards specified above. Lion Cai/ Approved & Authorized EMC Laboratory Manager Report No.: BTEK240506004AE001 Page: 2 of 24 Revision Record Version Chapter Date Modifier Remark V0 2024-06-25 Original Authorized for issue by Zora Huang /Project Engineer June Li /Reviewer Remarks: The results shown in this test report refer only to the sample(s) tested, this test report cannot be reproduced, except in full, without prior written permission of the company. The report would be invalid without specific stamp of test institute and the signatures of compiler and approver. Report No.: BTEK240506004AE001 Page: 3 of 24 2 Test Summary Radio Spectrum Technical Requirement Standard Item Method Requirement Result Antenna Requirement 47 CFR Part 15, Subpart C 15.247 N/A 47 CFR Part 15, Subpart C 15.203 & 15.247(b)(4) Pass Radio Spectrum Matter Part Item Standard Method Requirement Result 47 CFR Part 15, Subpart C 15.247 Conducted Emissions at AC Power Line (150kHz-30MHz) ANSI C63.10 (2013) Section 6.2 47 CFR Part 15, Subpart C 15.207 N/A* Conducted Peak Output Power ANSI C63.10 (2013) Section 11.9.1.3 47 CFR Part 15, Subpart C 15.247(b)(3) Pass Minimum 6dB Bandwidth ANSI C63.10 (2013) Section 11.8.1 47 CFR Part 15, Subpart C 15.247a(2) Pass Power Spectrum Density ANSI C63.10 (2013) Section 11.10.2 47 CFR Part 15, Subpart C 15.247(e) Pass Conducted Band Edges Measurement ANSI C63.10 (2013) Section 11.13.3.2 47 CFR Part 15, Subpart C 15.247(d) Pass Conducted Spurious Emissions ANSI C63.10 (2013) Section 11.11 47 CFR Part 15, Subpart C 15.247(d) Pass Radiated Emissions which fall in the restricted bands ANSI C63.10 (2013) Section 6.10.5 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Radiated Spurious Emissions ANSI C63.10 (2013) Section 6.4,6.5,6.6 47 CFR Part 15, Subpart C 15.205 & 15.209 Pass Note: E.U.T./EUT means Equipment Under Test. Pass means the test result passed the test standard requirement, please find the detailed decision rule in the report relative section. NA*:Mean’s not application. Report No.: BTEK240506004AE001 Page: 4 of 24 3 Contents Page 1 Cover Page ................................................................................................................................................ 1 2 Test Summary ................................................................................................................................................. 3 3 Contents .......................................................................................................................................................... 4 4 General Information ....................................................................................................................................... 5 4.1 Details of E.U.T. ........................................................................................................................................ 5 4.2 EUT Test Mode and Test Condition .......................................................................................................... 5 4.3 Measurement Uncertainty ......................................................................................................................... 5 4.4 Test Location ............................................................................................................................................. 6 4.5 Deviation from Standards .......................................................................................................................... 6 4.6 Abnormalities from Standard Conditions .................................................................................................. 6 5 Equipment List ................................................................................................................................................ 7 6 Radio Spectrum Technical Requirement ..................................................................................................... 9 6.1 Antenna Requirement ............................................................................................................................... 9 6.1.1 Test Requirement: ............................................................................................................................. 9 6.1.2 Conclusion ......................................................................................................................................... 9 7 Radio Spectrum Matter Test Results .......................................................................................................... 10 7.1 Conducted Emissions at AC Power Line (150kHz-30MHz) .................................................................... 10 7.1.1 Test Setup Diagram ......................................................................................................................... 10 7.1.2 Measurement Procedure and Data ................................................................................................ 10 7.2 Conducted Peak Output Power ............................................................................................................... 11 7.2.…

Text truncated - open the document above for the full version.

Report No.: BTEK240506004AE Page: 1 of 2 Appendix Setup Photos For BTEK240506004AE Report No.: BTEK240506004AE Page: 2 of 2 Radiated Spurious Emissions (Below 1GHz) Radiated Spurious Emissions (Above 1GHz)
