2AQLWYYCBV4CuboAi Smart Baby Monitor 3

MPE Evaluation Report for FCC Report No.: USSC247010001 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 1 of 11 Template: v01.00 MPE Evaluation Report for FCC Applicant Name : Yun yun AI Baby camera Co., Ltd. Applicant Address : 19F.-4, No. 2, Ln. 150, Sec. 5, Xinyi Rd. Xinyi Dist., Taipei City 110049, Taiwan (R.O.C.) Product Name : CuboAi Smart Baby Monitor 3 Brand Name : CuboAi Model Number : Swallow FCC ID : 2AQLWYYCBV4 Report Number : USSC247010001 Compliant Standards : FCC 47 CFR §2.1091 Sample Received Date : Jul. 01, 2024 Report Issued Date : Sep. 11, 2024 The above equipment has been tested by Eurofins E&E Wireless Taiwan Co., Ltd., and found compliance with the requirement of the above standards. The test record, data evaluation & Device Under Test (DUT) configurations represented herein are true and accurate accounts of the measurements of the sample’s characteristics under the conditions specified in this report. Note: 1. The test results are valid only for samples provided by customers and under the test conditions described in this report. 2. This report shall not be reproduced except in full, without the written approval of Eurofins E&E Wireless Taiwan Co., Ltd. 3. The relevant information is provided by customers in this test report. According to the correctness, appropriateness or completeness of the information provided by the customer, if there is any doubt or error in the information which affects the validity of the test results, the laboratory does not take the responsibility. Approved By： Roy Wu / SAR Technical Director MPE Evaluation Report for FCC Report No.: USSC247010001 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 2 of 11 Template: v01.00 Table of Contents Revision History ........................................................................................................................................................................... 3 1. Test Regulations .................................................................................................................................................................... 4 1.1. Reference Standard and Guidance .............................................................................................................................. 4 1.2. RF Exposure Limits ...................................................................................................................................................... 4 2. Information of Testing Laboratory ....................................................................................................................................... 6 3. DUT (Device Under Test) Information .................................................................................................................................. 7 3.1. Device Overview .......................................................................................................................................................... 7 4. Maximum Permissible Exposure (MPE) Assessment ......................................................................................................... 8 4.1. Introduction .................................................................................................................................................................. 8 4.2. Determination of Exemption for Low Power Devices ................................................................................................... 8 4.3. Standalone Maximum Permissible Exposure Evaluation ........................................................................................... 11 MPE Evaluation Report for FCC Report No.: USSC247010001 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 3 of 11 Template: v01.00 Revision History Rev. Issued Date Description Revised by 00 Sep. 11, 2024 Initial Issue Abby Huang MPE Evaluation Report for FCC Report No.: USSC247010001 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 4 of 11 Template: v01.00 1. Test Regulations 1.1. Reference Standard and Guidance The Maximum Permissible Exposure (MPE) evaluation documented in this report were performed in accordance with following FCC published KDB guidance and standard： 47 CFR Part 1.1307 47 CFR Part 1.1310 47 CFR Part 2.1091 KDB Publication 447498 D01 – General RF Exposure Guidance v06 KDB Publication 447498 D04 – Interim General RF Exposure Guidance v01 1.2. RF Exposure Limits According to 47 CFR §1.1310, for operations within the frequency range of 300 kHz and 6 GHz (inclusive), the limits for maximum permissible exposure (MPE), derived from whole-body SAR limits and listed in below table, may be used instead of whole-body SAR limits to evaluate the environmental impact of human exposure to RF radiation as specified in §1.1307(b), except for portable devices as defined in §2.1093 of this chapter as these evaluations shall be performed according to the SAR provisions in §2.1093. At operating frequencies above 6 GHz, the MPE limits listed in below table shall be used in all cases to evaluate the environmental impact of human exposure to RF radiation as specified in §1.1307(b). Limits for Maximum Permissible Exposure (MPE) to Radiofrequency Electromagnetic Fields Frequency Range (MHz) Electric Field Strength (V/m) Magnetic Field Strength (A/m) Power Density (mW/cm2) Averaging Time (minutes) (i) Limits for Occupational / Controlled Exposure 0.3 – 3.0 614 1.63 *(100) ≤ 6 3.0 – 30 1842 / f 4.89 / f *(900 / f2) < 6 30 – 300 61.4 0.163 1.0 < 6 300 – 1500 N/A N/A f / 300 < 6 1500 – 100000 N/A N/A 5 < 6 (ii) Limits for General Population / Uncontrolled Exposure 0.3 – 1.34 614 1.63 *(100) < 30 1.34 – 30 824 / f 2.19 / f *(180 / f2) < 30 30 – 300 27.5 0.073 0.2 < 30 300 – 1500 N/A N/A f / 1500 < 30 1500 – 100000 N/A N/A 1.0 < 30 Notes: 1. f = frequency in MHz. * = Plane-wave equivalent power density. MPE Evaluation Report for FCC Report No.: USSC247010001 Issued Date: Se…

Text truncated - open the document above for the full version.

CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 1 CuboAi Swallow Antenna Check Sheet © 2018 by Alpha Networks Corporation All Right Reserved CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 2 Revision History: Version Date Change Description V01 2024 Jul. New Release CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 3 Contents Antenna Specification............................................................... 4 Test Result........................................................................ 4 Return Loss................................................................. 5 Antenna Gain Table....................................................... 6 Antenna Vendor Information................................................ 6 CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 4 Antenna Specification Test Result: Ant. Antenna Brand Antenna. model Antenna type Antenna Gain (dBi) Frequency Range (MHz) Connector type Cable length (mm) Cable Loss Remark #1 PSA RFFPA401811IMLB401 FPC [email protected] 5.12@5GHz 2400~2500 5150~5850 IPEX 113 X X CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 5 2D Radiation Patterns: CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 6 Antenna Gain Table: Frequency(MHz) (dBi) 2400 2.52 2455 2.84 2500 2.46 Frequency(MHz) (dBi) 5150 5.12 5500 4.69 5750 4.99 5925 4.78 Antenna Vendor information: 蘇州華科電子有限公司 21 5126 中國江蘇省蘇州工業園區長陽街 369 號 No. 369, Changyan Street, Suzhou Industrial Park, Jiangsu Province 215126, China Tel: +86-512-628-36888 Fax: +86-512-628-37888 Email: [email protected] CuboAi Swallow Antenna Check Sheet Date: 2024/7/22 7 Vendor Model Calibrated Date Calibrated Until KEYSIGHT E5071C 2021.12.6 2022.12.6

DFS Test Report Report No.: USRC247010002 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 1 of 21 Template : v01.00 DFS Test Report Applicant ： Yun yun AI Baby camera Co., Ltd. Product Name ： CuboAi Smart Baby Monitor 3 Trade Name ： CuboAi Model Number ： Swallow Applicable Standard ： FCC 47 CFR PART 15 SUBPART E ANSI C63.10:2013 Received Date ： Jul. 01, 2024 Test Period ： Jul. 31, 2024 ~ Aug. 01, 2024 Issued Date ： Sep. 11, 2024 Issued by Eurofins E&E Wireless Taiwan Co., Ltd. No. 140-1, Changan Street, Bade District, Taoyuan City 334025, Taiwan (R.O.C.) Tel：+886-3-2710188 / Fax：+886-3-2710190 Taiwan Accreditation Foundation accreditation number: 1330 Frequency Range: 9 kHz to 325 GHz Bade test site： Test Firm Registration Number: 226252 Test Firm Designation Number: TW0010 Wugu test site： Test Firm Registration Number: 191812 Test Firm Designation Number: TW0034 Note: 1.The test results are valid only for samples provided by customers and under the test conditions described in this report. 2.This report shall not be reproduced except in full, without the written approval of Eurofins E&E Wireless Taiwan Co., Ltd. 3.The relevant information is provided by customers in this test report. According to the correctness, appropriateness or completeness of the information provided by the customer, if there is any doubt or error in the information which affects the validity of the test results, the laboratory does not take the responsibility. DFS Test Report Report No.: USRC247010002 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 2 of 21 Template : v01.00 Revision History Rev. Issued Date Description Revised By 00 Sep. 11, 2024 Initial Issue Rowan Hsieh DFS Test Report Report No.: USRC247010002 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 3 of 21 Template : v01.00 Verification of Compliance Applicant : Yun yun AI Baby camera Co., Ltd. Product Name : CuboAi Smart Baby Monitor 3 Trade Name : CuboAi Model Number : Swallow FCC ID : 2AQLWYYCBV4 Applicable Standard : FCC 47 CFR PART 15 SUBPART E ANSI C63.10:2013 Test Result : Complied Performing Lab. : Eurofins E&E Wireless Taiwan Co., Ltd. No. 140-1, Changan Street, Bade District, Taoyuan City 334025, Taiwan (R.O.C.) Tel：+886-3-2710188 / Fax：+886-3-2710190 Taiwan Accreditation Foundation accreditation number: 1330 Eurofins E&E Wireless Taiwan Co., Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by Eurofins E&E Wireless Taiwan Co., Ltd. based on interpretations and/or observations of test results. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Approved By ： DFS Test Report Report No.: USRC247010002 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 4 of 21 Template : v01.00 TABLE OF CONTENTS 1 General Information ........................................................................................................ 5 1.1. Summary of Test Result ............................................................................................ 5 1.2. Testing Location ........................................................................................................ 6 1.3. Test Site Environment................................................................................................ 6 2 EUT Description............................................................................................................... 7 3 Test Methodology ............................................................................................................ 9 3.1. Mode of Operation ..................................................................................................... 9 3.2. EUT Test Step ........................................................................................................... 9 3.3. Test Instruments ........................................................................................................ 9 4 Dynamic Frequency Selection ..................................................................................... 10 4.1. Limits ....................................................................................................................... 10 4.2. Test and Measurement System ............................................................................... 14 5 Test Results ................................................................................................................... 16 5.1. Radar Waveforms and Traffic .................................................................................. 16 5.2. Channel Loading ..................................................................................................... 17 5.3. Channel Move Time and Channel Closing Transmission Time ................................ 18 5.4. Non-Occupancy Period ........................................................................................... 21 Appendix A. Test Setup Photographs DFS Test Report Report No.: USRC247010002 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 5 of 21 Template : v01.00 1 General Information 1.1. Summary of Test Result Standard Item Result Remark 15.407(h)(2) Channel Availability Check Time N/A --- 15.407(h)(2) Channel Move Time PASS --- 15.407(h)(2) Channel Closing Transmission Time PASS --- 15.407(h)(2) Non-Occupancy Period PASS --- 15.407(h)(2) Non-Associated Test N/A --- 15.407(h)(2) U-NII Detection Bandwidth N/A --- 15.407(h)(2) Statistical Performance check N/A --- Decision Rule ■ Uncertainty is not included. □ Uncertainty is included. Standard Description CFR47, Part 15, Subpart E Unlicensed National Information Infrastructure Devices Canada RSS-247 Issue 3 Digital Transmission Systems (DTSs), Frequency Hopping Systems (FHSs) and Licence-Exempt Local Area Network (LE-LAN) Dev…

Text truncated - open the document above for the full version.

RF Test Report Report No.: USRC247010003 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 1 of 202 Template : v02.00 RF Test Report Applicant ： Yun yun AI Baby camera Co., Ltd. Product Name ： CuboAi Smart Baby Monitor 3 Trade Name ： CuboAi Model Number ： Swallow Applicable Standard ： FCC 47 CFR PART 15 SUBPART E ANSI C63.10:2013 Received Date ： Jul. 01, 2024 Test Period ： Jul. 30, 2024 ~ Aug. 29, 2024 Issued Date ： Sep. 11, 2024 Issued by Eurofins E&E Wireless Taiwan Co., Ltd. No. 140-1, Changan Street, Bade District, Taoyuan City 334025, Taiwan (R.O.C.) Tel：+886-3-2710188 / Fax：+886-3-2710190 Taiwan Accreditation Foundation accreditation number: 1330 Frequency Range: 9 kHz to 325 GHz Bade test site： Test Firm Registration Number: 226252 Test Firm Designation Number: TW0010 Wugu test site： Test Firm Registration Number: 191812 Test Firm Designation Number: TW0034 Note: 1.The test results are valid only for samples provided by customers and under the test conditions described in this report. 2.This report shall not be reproduced except in full, without the written approval of Eurofins E&E Wireless Taiwan Co., Ltd. 3.The relevant information is provided by customers in this test report. According to the correctness, appropriateness or completeness of the information provided by the customer, if there is any doubt or error in the information which affects the validity of the test results, the laboratory does not take the responsibility. RF Test Report Report No.: USRC247010003 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 2 of 202 Template : v02.00 Revision History Rev. Issued Date Description Revised By 00 Sep. 11, 2024 Initial Issue Rowan Hsieh RF Test Report Report No.: USRC247010003 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 3 of 202 Template : v02.00 Verification of Compliance Applicant : Yun yun AI Baby camera Co., Ltd. Product Name : CuboAi Smart Baby Monitor 3 Trade Name : CuboAi Model Number : Swallow FCC ID : 2AQLWYYCBV4 Applicable Standard : FCC 47 CFR PART 15 SUBPART E ANSI C63.10:2013 Test Result : Complied Performing Lab. : Eurofins E&E Wireless Taiwan Co., Ltd. No. 140-1, Changan Street, Bade District, Taoyuan City 334025, Taiwan (R.O.C.) Tel：+886-3-2710188 / Fax：+886-3-2710190 Taiwan Accreditation Foundation accreditation number: 1330 Eurofins E&E Wireless Taiwan Co., Ltd. tested the above equipment in accordance with the requirements set forth in the above standards. All indications of Pass/Fail in this report are opinions expressed by Eurofins E&E Wireless Taiwan Co., Ltd. based on interpretations and/or observations of test results. The test results show that the equipment tested is capable of demonstrating compliance with the requirements as documented in this report. Approved By ： RF Test Report Report No.: USRC247010003 Issued Date: Sep. 11, 2024 Eurofins E&E Wireless Taiwan Co., Ltd. Page 4 of 202 Template : v02.00 TABLE OF CONTENTS 1 General Information .................................................................................................... 5 1.1. Summary of Test Result ............................................................................................... 5 1.2. Testing Location ........................................................................................................... 6 1.3. Measurement Uncertainty ............................................................................................ 6 1.4. Test Site Environment .................................................................................................. 6 2 EUT Description .......................................................................................................... 7 3 Test Methodology ..................................................................................................... 11 3.1. Mode of Operation ...................................................................................................... 11 3.2. EUT Test Step .............................................................................................................13 3.3. Configuration of Test System Details ..........................................................................14 3.4. Test Instruments .........................................................................................................16 4 Measurement Procedure .......................................................................................... 18 4.1. AC Power Conducted Emission Measurement ...........................................................18 4.2. Transmitter Radiated Emissions Measurement ...........................................................20 4.3. Maximum Conducted Output Power Measurement .....................................................25 4.4. 26 dB RF Bandwidth Measurement ............................................................................26 4.5. 6 dB RF Bandwidth Measurement ..............................................................................27 4.6. Maximum Power Spectral Density Measurement ........................................................28 4.7. Automatically discontinue transmission .......................................................................30 4.8. Antenna Requirement .................................................................................................31 5 Test Results .............................................................................................................. 32 5.1. Conducted Emission ...................................................................................................32 5.2. Radiated Emission Measurement ...............................................................................34 5.3. Conducted Test Results ............................................................................................ 202 Appendix A. Test Data Appendix B. Test Plots Appendix C. Test Setup Photographs RF Test Report Report No.: U…

Text truncated - open the document above for the full version.

Appendix A. Test Data 802.11a518030.000100.0000.0000.010 802.11n HT2051801.39097.8420.0950.735 802.11n HT4051901.05091.4290.3891.042 802.11ac VHT2051802.03096.0590.1750.513 802.11ac VHT4051901.05591.4690.3871.036 802.11ac VHT8052100.56183.4220.7872.137 1/T Minimun VBW (kHz) on+off time (ms) Duty cycle (%) Mode Frequency (MHz) Duty cycle on time (ms) 30.000 1.360 0.960 1.950 0.965 0.468 Duty Factor (dB) RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 1 of 10 ModeChannel Freq. (MHz) Data Rate 802.11a3651806M 802.11a4052006M 802.11a4852406M 802.11a5252606M 802.11a5652806M 802.11a6453206M 802.11a10055006M 802.11a11255606M 802.11a14057006M 802.11a14957456M 802.11a15757856M 802.11a16558256M 802.11n HT203651806.5M 802.11n HT204052006.5M 802.11n HT204852406.5M 802.11n HT205252606.5M 802.11n HT205652806.5M 802.11n HT206453206.5M 802.11n HT2010055006.5M 802.11n HT2011255606.5M 802.11n HT2014057006.5M 802.11n HT2014957456.5M 802.11n HT2015757856.5M 802.11n HT2016558256.5M 802.11n HT4038519013.5M 802.11n HT4046523013.5M 802.11n HT4054527013.5M 802.11n HT4062531013.5M 802.11n HT40102551013.5M 802.11n HT40110555013.5M 802.11n HT40134567013.5M 802.11n HT40151575513.5M 802.11n HT40159579513.5M 5 GHz Band Config RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 2 of 10 ModeChannel Freq. (MHz) Data Rate 802.11ac VHT20365180MCS 0 802.11ac VHT20405200MCS 0 802.11ac VHT20485240MCS 0 802.11ac VHT20525260MCS 0 802.11ac VHT20565280MCS 0 802.11ac VHT20645320MCS 0 802.11ac VHT201005500MCS 0 802.11ac VHT201125560MCS 0 802.11ac VHT201405700MCS 0 802.11ac VHT201495745MCS 0 802.11ac VHT201575785MCS 0 802.11ac VHT201655825MCS 0 802.11ac VHT40385190MCS 0 802.11ac VHT40465230MCS 0 802.11ac VHT40545270MCS 0 802.11ac VHT40625310MCS 0 802.11ac VHT401025510MCS 0 802.11ac VHT401105550MCS 0 802.11ac VHT401345670MCS 0 802.11ac VHT401515755MCS 0 802.11ac VHT401595795MCS 0 802.11ac VHT80425210MCS 0 802.11ac VHT80585290MCS 0 802.11ac VHT801065530MCS 0 802.11ac VHT801225610MCS 0 802.11ac VHT801555775MCS 0 5 GHz Band Config RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 3 of 10 CHAnt-0Ant-1Ant-2Ant-3 3614--- 4021--- 4820--- 5221--- 5621--- 6417--- 10015--- 11221--- 14012--- 14921--- 15721--- 16521--- 3614--- 4021--- 4820--- 5221--- 5621--- 6417--- 10016--- 11221--- 14013--- 14921--- 15721--- 16521--- 3810--- 4620--- 5421--- 6213--- 10212--- 11021--- 13415--- 15121--- 15921--- 3614--- 4021--- 4820--- 5221--- 5621--- 6417--- 10016--- 11221--- 14013--- 14921--- 15721--- 16521--- 3810--- 4620--- 5421--- 6213--- 10212--- 11021--- 13415--- 15121--- 15921--- 428--- 5811--- 10610--- 12217--- 15520--- RF power setting in Test SW Mode Frequency (MHz) Test SW Version 5755 5795 5550 5670 5785 5825 5190 Putty 5230 5270 5310 5510 5700 5745 5180 5700 Putty 5280 5190 5775 5785 5825 5700 5560 5560 5180 5755 5795 5210 Putty 5290 5530 5610 Putty 5230 5270 5310 5510 5550 5670 Putty 5200 5240 5260 Putty 5200 5560 5240 5260 5280 5320 5500 5745 5785 5825 802.11a 802.11n HT20 802.11n HT40 802.11ac VHT20 802.11ac VHT40 5180 5200 5240 5260 5280 5320 5500 802.11ac VHT80 5320 5500 5745 RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 4 of 10 Ant-0Ant-1Ant-2Ant-3Total dBmdBmdBmdBmdBmdBm 3614.51---- 24.00 4018.93---- 24.00 4818.41---- 24.00 5218.83---- 24.00 5618.72---- 24.00 6416.35---- 24.00 10015.11---- 24.00 11218.95---- 24.00 14011.78---- 24.00 14918.88---- 30.00 15718.81---- 30.00 16518.83---- 30.00 3613.82---- 24.00 4018.45---- 24.00 4818.30---- 24.00 5218.36---- 24.00 5618.46---- 24.00 6415.75---- 24.00 10015.27---- 24.00 11218.83---- 24.00 14012.42---- 24.00 14918.71---- 30.00 15718.43---- 30.00 16518.36---- 30.00 3810.08---- 24.00 4618.98---- 24.00 5418.92---- 24.00 6213.01---- 24.00 10212.32---- 24.00 11019.49---- 24.00 13414.76---- 24.00 15119.39---- 30.00 15919.16---- 30.00 5560 5745 5785 802.11n HT40 5190 5230 Maximum Conducted Output Power Measurement Limit ModeCHFrequency (MHz) 802.11a 5180 5280 5320 5500 5200 5240 5260 5270 5310 5825 802.11n HT20 5180 5200 5240 5260 5280 5560 5320 5500 5700 5785 5825 5745 Average power 5510 5550 5670 5700 5755 5795 RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 5 of 10 Ant-0Ant-1Ant-2Ant-3Total dBmdBmdBmdBmdBmdBm 3613.93---- 24.00 4018.72---- 24.00 4818.39---- 24.00 5218.56---- 24.00 5618.63---- 24.00 6415.89---- 24.00 10015.38---- 24.00 11218.97---- 24.00 14012.48---- 24.00 14918.84---- 30.00 15718.69---- 30.00 16518.61---- 30.00 3810.14---- 24.00 4619.05---- 24.00 5419.15---- 24.00 6213.07---- 24.00 10212.42---- 24.00 11019.59---- 24.00 13414.82---- 24.00 15119.51---- 30.00 15919.43---- 30.00 428.14---- 24.00 5811.15---- 24.00 1069.51---- 24.00 12216.07---- 24.00 15518.38---- 30.00 ModeCHFrequency (MHz) Average power Limit 802.11ac VHT20 5700 5745 5180 5200 5240 5500 5560 5320 5260 5280 5785 5825 5270 5755 5795 5775 5610 5670 5510 5550 5310 5190 5230 802.11ac VHT80 5210 5290 5530 802.11ac VHT40 RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd.Page 6 of 10 Ant-0Ant-1Ant-2Ant-3Ant-0Ant-1Ant-2 MHzMHzMHzMHzMHzMHzMHz 36518017.214---21.570-- 40520020.236---33.990-- 48524019.146---33.000-- 52526019.821---33.850-- 56528020.011---33.830-- 64532017.333---21.770-- 100550017.277---21.550-- 112556022.300---35.890-- 140570017.099---21.390-- 36518018.169---21.960-- 40520020.522---34.550-- 48524019.172---32.710-- 52526019.601---33.640-- 56528020.034---34.730-- 64532018.374---22.440-- 100550018.290---21.800-- 112556022.474---42.380-- 140570018.196---21.870-- 38519036.485---40.290-- 46523037.763---68.360-- 54527044.242---82.650-- 62531036.502---40.460-- 102551036.394---40.420-- 110555050.779---87.880-- 134567036.599---43.950-- 42521075.665---81.970-- 58529075.667---81.910-- 106553075.634---82.490-- 122561075.899---93.820-- - - - - - - - - - - - - - - - - - - - - - - - - - - 26 dB & 99 % RF Bandwidth Measurement 26 dB Band…

Text truncated - open the document above for the full version.

RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 1 of 37 Appendix B. Test Plots Duty cycle 802.11a On+off time 802.11n HT20 On+off time RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 2 of 37 802.11n HT40 On+off time 802.11ac VHT20 On+off time RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 3 of 37 802.11ac VHT40 On+off time 802.11ac VHT80 On+off time RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 4 of 37 Maximum Power Spectral Density 802.11a 5180 MHz 5200 MHz 5240 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 5 of 37 802.11a 5260 MHz 5280 MHz 5320 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 6 of 37 802.11a 5500 MHz 5560 MHz 5700 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 7 of 37 802.11a 5745 MHz 5785 MHz 5825 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 8 of 37 802.11ac VHT20_ANT-0 5180 MHz 5200 MHz 5240 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 9 of 37 802.11ac VHT20_ANT-0 5260 MHz 5280 MHz 5320 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 10 of 37 802.11ac VHT20_ANT-0 5500 MHz 5560 MHz 5700 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 11 of 37 802.11ac VHT20_ANT-0 5745 MHz 5785 MHz 5825 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 12 of 37 802.11ac VHT40_ANT-0 5190 MHz 5230 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 13 of 37 802.11ac VHT40_ANT-0 5270 MHz 5310 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 14 of 37 802.11ac VHT40_ANT-0 5510 MHz 5550 MHz 5670 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 15 of 37 802.11ac VHT40_ANT-0 5755 MHz 5795 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 16 of 37 802.11ac VHT80_ANT-0 5210 MHz 5290 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 17 of 37 802.11ac VHT80_ANT-0 5530 MHz 5610 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 18 of 37 802.11ac VHT80_ANT-0 5775 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 19 of 37 26 dB Bandwidth & 99% Occupied Bandwidth 802.11a 5180 MHz 5200 MHz 5240 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 20 of 37 802.11a 5260 MHz 5280 MHz 5320 MHz

RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 21 of 37 802.11a 5500 MHz 5560 MHz 5700 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 22 of 37 802.11ac VHT20_ANT-0 5180 MHz 5200 MHz 5240 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 23 of 37 802.11ac VHT20_ANT-0 5260 MHz 5280 MHz 5320 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 24 of 37 802.11ac VHT20_ANT-0 5500 MHz 5560 MHz 5700 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 25 of 37 802.11ac VHT40_ANT-0 5190 MHz 5230 MHz 5270 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 26 of 37 802.11ac VHT40_ANT-0 5310 MHz 5510 MHz 5550 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 27 of 37 802.11ac VHT40_ANT-0 5670 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 28 of 37 802.11ac VHT80_ANT-0 5210 MHz 5290 MHz 5530 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 29 of 37 802.11ac VHT80_ANT-0 5610 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 30 of 37 6 dB Bandwidth 802.11a 5745 MHz 5785 MHz 5825 MHz RF Test Report Report No.: USRC247010003 Eurofins E&E Wireless Taiwan Co., Ltd. Page 31 of 37 802.11ac VHT20_ANT-0 5745 MHz 5785 MHz 5825 MHz RF Tes…

Text truncated - open the document above for the full version.
