2AQQWFR9380UHF RFID Distributed Antenna System

www.pervasid.com Copyright © February 2022, PervasID Ltd 1 FR 9380 Reader Installation Guide www.pervasid.com Copyright © February 2022, PervasID Ltd 2 Federal Communications Commission (FCC) / IC Canada Compliance Statement This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. However, there is no guarantee that interference will not occur in any given installation. If this equipment does cause interference which can be determined by turning the equipment on and off, the interference may be reduced by: • Increasing the separation between the equipment and the receiver • Reorient or relocating the equipment antenna. Only the recommended antennas listed in Appendix A should be used with this equipment and the output power should be set depending on the cable length in accordance with the PervasID Power tool. (see section on antenna connection) This equipment complies with FCC/IC radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65 and RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment should be installed and operated so that the antennas are kept at least 0.5594 m or more away from a person’s body (excluding extremities: hands, wrists, feet and ankles). ETSI Compliance The FR 9380 Reader (the Reader) is a product and has been certified to IEC 62368-1/EN 62368- 1 and EN 301 489-1/EN 301 489-3. Warning: Please read this manual in its entirety before operating the FR 9380 Reader, as personal injury or equipment damage may result from improper use. Under no circumstances should the Reader enclosure be opened. Caution: An appropriate power supply unit (PSU) that meets the FR 9380 Reader PSU Specification must be used to power the Reader. Any Other PSU could be dangerous and failure to ensure this could make the product unsafe. Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. www.pervasid.com Copyright © February 2022, PervasID Ltd 3 Check List The PervasID FR 9380 system is an 8-port UHF DAS RFID Reader (the Reader), capable of feeding eight antennas and allowing tag information to be uploaded over its Ethernet interface to a server for processing, analysis and display. The real-time information of assets is thereby logged. The Flow Ranger System consists of: 1. A PervasID FR 9380 Reader with internet access 2. A +24 VDC external power supply and AC cord 3. 8x Coaxial cables 4. 8x UHF RFID antennas 5. Brackets 6. Shielded Cat 5 Cable 7. Installation Manual www.pervasid.com Copyright © February 2022, PervasID Ltd 4 Table of Contents Contents List of Acronyms ...................................................................................................................................... 5 1 Introduction ......................................................................................................................................... 6 1.1 FR 9380.......................................................................................................................................... 6 1.2 Requirements for Using FR 9380 .................................................................................................. 6 2 Installing the FR 9380 System .............................................................................................................. 8 2.1 Installing and Connecting the FR 9380 Reader ............................................................................. 9 2.2 Compliance with ETSI Guidelines for Human Exposure to Radio Frequency Electromagnetic Fields ................................................................................................................................................. 12 3 Troubleshooting ................................................................................................................................. 13 References ............................................................................................................................................ 14 Appendix ............................................................................................................................................... 15 www.pervasid.com Copyright © February 2022, PervasID Ltd 5 List of Acronyms CRC Cyclic Redundancy Check DAS Distributed Antennas System EIRP Effective Isotropically Radiated Power EPC Electronic Product Code ERP Effective Radiated Power ETSI European Telecommunications Standards Institute FCC Federal Communications Commission ISO International Organisation for Standardisation RF Radio Frequency RFID Radio Frequency Identification RSSI Received Signal Strength Rx Receiver Tx Transmitter UHF Ultra High Frequency www.pervasid.com Copyright © February 2022, PervasID Ltd 6 1 Introduction This manual provides detailed instructions for installing, connecting, configuring and operating the FR 9380 Reader. The intended audience for this manual is the operator installing and operating the FR 9380 Reader. It is presumed that…

Text truncated - open the document above for the full version.

PervasID Flow Ranger 9380 Parameters Descriptions Air Interface Protocol • EPC Class1 Gen2 UHF • ISO 18000-6C Operating Frequency • EU & Middle East: 865.6-867.6 MHz • US & Canada: 902-928 MHz Antennas 8 RF ports connected to 5-8.5 dBic Circular polarised Antenna Cables 1-15m LMR-240 or 1-10m LMR-195 Controller Sensitivity -100dBm User interface RangerDB • Provides basic control of the Reader functions • Presents tag data in local database • Displays tag information Transmit Power 2W EIRP in Europe & Middle East 4W EIRP in US & Canada Network Connectivity 10/100 Base-T Ethernet IP Address Configuration DHCP or fixed IP USB Micro USB Client for accessing Embedded O/S Power Supply 100-240VAC to 24VDC 4A Operating Temperature 0 ºC to +30 ºC Dimensions 25cm x 25cm x 5cm Weight 2 kg www.pervasid.com Copyright © 2022, PervasID Ltd

Registered Office: St John’s Innovation Centre, Cowley Road, Cambridge, CB4 0WS, UK. Registered Company Number: 7559981 VAT Reg No: 136158711 PervasID Ltd St John’s Innovation Centre Cowley Road Cambridge CB4 0WS, UK Tel: 01223 422 383 23 rd August 2022 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Dear Sir or Madam, We, PervasID Ltd, hereby authorize TUV to act as our agent in all matters relating to applications for equipment authorization, including the signing of all documents relating to these matters. This authorization expires on 23 rd August 2023 Sincerely, Company Officer: Dr Sabesan Sithamparanathan Telephone Number: +44 1223 422 383 Email: [email protected]

Registered Office: St John’s Innovation Centre, Cowley Road, Cambridge, CB4 0WS, UK. Registered Company Number: 7559981 VAT Reg No: 136158711 PervasID Ltd St John’s Innovation Centre Cowley Road Cambridge CB4 0WS, UK Tel: 01223 422 383 16 th August 2022 TUV SUD BABT TCB Octagon House, Segensworth Road, Fareham, Hampshire, PO15 5RL Confidentiality Request FCC ID: 2AQQWFR9380 Pursuant to Sections 0.457(d)(1)(ii) and 0.459 of the Commission’s Rules, PervasID hereby requests permanent confidential treatment of information accompanying this application as outlined below: Schematics Bill of Materials/Parts List Block Diagrams Theory of Operation PervasID also hereby requests short-term confidential treatment of information accompanying this application as outlined below for a period of 180 days: Internal Photos External Photos User Manual Test Set-up Photographs The above materials contain trade secrets and proprietary information not customarily released to the public. The public disclosure of these matters might be harmful to the Applicant and provide unjustified benefits to its competitors. The Applicant understands that pursuant to Rule 0.457(d)(1)(ii), disclosure of this Application and all accompanying materials will not be made before the date of the Grant for this Application. Yours sincerely, Company Officer: Dr Sabesan Sithamparanathan Telephone Number: +44 1223 422 383 Email: [email protected]

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Matthew Russell Senior Engineer (RF) Authorised Signatory 15 September 2022 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. EXECUTIVE SUMMARY The calculation of exposure for this product was found to be compliant at a minimum distance of 31 cm with 47 CFR Part 2.1091: 2020 and Health Canada Safety Code 6 assuming continuous exposure of 6 minutes or more. If alternative antennas are used with greater gains, the distance must be recalculated. Exposure Calculation Report PervasID Limited Model: FR 9380 (8-port FCC) In accordance with FCC 47 CFR Part 2.1091: 2020 and Health Canada Safety Code 6: 2015 Prepared for: PervasID St John’s Innovation Centre Cowley Road Cambridge CB4 OWS UNITED KINGDOM COMMERCIAL-IN-CONFIDENCE FCC ID: 2AQQWFR9380 IC: 24482-FR9380 Document 75954042-03 Issue: 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2022 TÜV SÜD. Document 75954042-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 8 Contents 1 Report Summary ......................................................................................................................... 2 1.1 Report Modification Record ........................................................................................................... 2 1.2 Introduction .................................................................................................................................... 2 1.3 Brief Summary of Results ............................................................................................................. 3 1.4 Product Information ....................................................................................................................... 4 2 Assessment Details .................................................................................................................... 6 2.1 Assessment Method ...................................................................................................................... 6 2.2 Individual Antenna Port Exposure Results .................................................................................... 7 2.3 Far Field Region Boundary Results .............................................................................................. 8 2.4 Uncertainty .................................................................................................................................... 8 Annex A Regional Requirements ............................................................................................................. A.2 Document 75954042-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 8 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 15 September 2022 Table 1 1.2 Introduction Applicant PervasID Manufacturer PervasID Model Number(s) FR 9380 (8-port FCC) Hardware Version(s) V6.4 P0.3 (serial no: 10510422-0074) Software Version(s) Reader software – 3_1_0_EX4; R2000 firmware – 3_1_0_EX3; DB firmware – 1_0_1_EX2, Bootloader 512d8e3 Specification/Issue/Date • FCC 47 CFR Part 2.1091: 2020 Radiofrequency radiation exposure evaluation: mobile devices • ISED Canada: Health Canada Safety Code 6:2015 Order Number Date PO-0519 28 Jan 2022 Related Document(s) • FCC 47 CFR Part 1.1310: 2020 Radiofrequency radiation exposure limits • OET65:97 Evaluating Compliance with FCC Guidelines for Human Exposure to Radiofrequency Electromagnetic Fields • IEEE C95.3:2002 IEEE Recommended Practice for Measurements and Computations of Radio Frequency Electromagnetic Fields with Respect to Human Exposure to Such Fields, 100 kHz–300 GHz • RSS-102 Issue 5 Radio Frequency (RF) Exposure Compliance of Radiocommunication Apparatus (All Frequency Bands) Document 75954042-03 Issue: 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 8 1.3 Brief Summary of Results The wireless device described within this report was compliant with the restrictions related to human exposure to electromagnetic fields for both general public and worker/occupational exposures. The calculations shown in this report were made in accordance with the procedures specified in the applied test specification(s). 1.3.1 Configuration - Single Transmitter Regional Requirement RAT Calculated RF exposure level at minimum compliance boundary of 0.31 m S Power Density (W/m 2 ) E Field (V/m) H Field (A/m) B Field (μT) Result Limit Result Limit Result Limit Result Limit FCC RFiD 2.71 30.09 31.97 N/A 0.0848 N/A 0.1066 N/A CANADA RFiD 2.71 19.39 31.97 85.51 0.0848 0.2268 0.1066 N/A Table 2 – Worker/Occupational Exposure Results The calculations show that the EUT complies with the worker/occupational exposure levels described in the listed specifications in Annex A at the point of investigation, a minimum of 0.31 m. Regional Requirement RAT Calculated RF exposure level at minimum compliance boundary of 0.31 m S Power Density (W/m 2 ) E Field (V/m) H Field (A/m) B Field (μT) Result Limit Result Limit Result Limit Result Limit FCC RFiD 2.71 6.02 31.97 N/A 0.0848 N/A 0.1066 N/A CANADA RFiD 2.71 2.74 31.97 32.15 0.0848 0.0853 0.1066 N/A Table 3 – General Public Exposure Results The calculations show that the EUT complies with the…

Text truncated - open the document above for the full version.

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Andy Lawson Chief Engineer, EMC Authorised Signatory 29 June 2022 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15B and ICES-003. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Matthew Dawkins 29 June 2022 FCC Accreditation 90987 Octagon House, Fareham Test Laboratory ISED Accreditation 12669A Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15B and ICES-003: 2020 and Issue 7: 2020 for the tests detailed in section 1.3. FCC and ISED Test Report PervasID Flow Ranger, Model: FR 9380 (8-port FCC) In accordance with FCC 47 CFR Part 15B and ICES-003 (RFiD) Prepared for: PervasID St John’s Inovation Centre Cowley Road Cambridge CB4 OWS UNITED KINGDOM FCC ID: 2AQQWFR9380 IC: 24482-FR9380 COMMERCIAL-IN-CONFIDENCE Document 75954042-01 Issue 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2022 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75954042-01 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 23 Contents 1 Report Summary .........................................................................................................................2 1.1 Report Modification Record ...........................................................................................................2 1.2 Introduction ....................................................................................................................................2 1.3 Brief Summary of Results .............................................................................................................3 1.4 Declaration of Build Status ............................................................................................................4 1.5 Product Information .......................................................................................................................5 1.6 Deviations from the Standard ........................................................................................................7 1.7 EUT Modification Record ..............................................................................................................7 1.8 Test Location .................................................................................................................................7 2 Test Details ..................................................................................................................................8 2.1 Conducted Disturbance at Mains Terminals .................................................................................8 2.2 Radiated Disturbance ................................................................................................................. 13 3 Incident Reports ....................................................................................................................... 22 4 Measurement Uncertainty ....................................................................................................... 23 Document 75954042-01 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 23 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 29 June 2022 Table 1 1.2 Introduction Applicant PervasID Manufacturer PervasID Model Number(s) FR 9380 (8-port FCC) Serial Number(s) 10510422-0074 Hardware Version(s) V6.4 P0.3 (serial no: 10510422-0074) Software Version(s) Reader software – 3_1_0_EX4; R2000 firmware – 3_1_0_EX3; DB firmware – 1_0_1_EX2, Bootloader 512d8e3 Number of Samples Tested 1 Test Specification/Issue/Date FCC 47 CFR Part 15B and ICES-003: 2020 and Issue 7: 2020 Order Number Date PO-0519 08-December-2021 Date of Receipt of EUT 04-February-2022 Start of Test 23-March-2022 Finish of Test 23-March-2022 Name of Engineer(s) Matthew Dawkins Related Document(s) ANSI C63.4: 2014 Document 75954042-01 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 3 of 23 1.3 Brief Summary of Results A brief summary of the tests carried out in accordance with FCC 47 CFR Part 15B and ICES-003 is shown below. Section Specification Clause Test Description Result Comments/Base Standard Configuration and Mode: AC Powered - Idle 2.1 15.107 and 3.1 Conducted Disturbance at Mains Terminals Pass ANSI C63.4: 2014 2.2 15.109 and 3.2 Radiated Disturbance Pass ANSI C63.4: 2014 Table 2 Document 75954042-01 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 4 of 23 1.4 Declaration of Build Status MAIN EUT MANUFACTURING DESCRIPTION UHF RFID Distributed Antenna System MANUFACTURER PervasID Ltd MO…

Text truncated - open the document above for the full version.

TÜV SÜD is a trading name of TUV SUD Ltd Registered in Scotland at East Kilbride, Glasgow G75 0QF, United Kingdom Registered number: SC215164 TUV SUD Ltd is a TÜV SÜD Group Company Phone: +44 (0) 1489 558100 Fax: +44 (0) 1489 558101 www.tuvsud.com/en TÜV SÜD Octagon House Concorde Way Fareham Hampshire PO15 5RL United Kingdom TÜV SÜD SIGNATURE NAME JOB TITLE RESPONSIBLE FOR ISSUE DATE Matthew Russell Senior Engineer (RF) Authorised Signatory 15 September 2022 Signatures in this approval box have checked this document in line with the requirements of TÜV SÜD document control rules. ENGINEERING STATEMENT The measurements shown in this report were made in accordance with the procedures described on test pages. All reported testing was carried out on a sample equipment to demonstrate limited compliance with FCC 47 CFR Part 15C, ISED RSS-247 and ISED RSS-GEN. The sample tested was found to comply with the requirements defined in the applied rules. RESPONSIBLE FOR NAME DATE SIGNATURE Testing Graeme Lawler 15 September 2022 Testing Nandhini Mathivanan 15 September 2022 Testing Neil Rousell 15 September 2022 FCC Accreditation 90987 Octagon House, Fareham Test Laboratory ISED Accreditation 12669A Octagon House, Fareham Test Laboratory EXECUTIVE SUMMARY A sample of this product was tested and found to be compliant with FCC 47 CFR Part 15C: 2020, ISED RSS-247: Issue 2 (02- 2017) and ISED RSS-GEN: and Issue 5 (04-2018) + A2 (02-2021) for the tests detailed in section 1.3. FCC and ISED Test Report PervasID Flow Ranger, Model: FR 9380 (8-port FCC) In accordance with FCC 47 CFR Part 15C, ISED RSS-247 and ISED RSS-GEN (RFiD) Prepared for: PervasID St John’s Innovation Centre, Cowley Road Cambridge, CB4 OWS UNITED KINGDOM FCC ID: 2AQQWFR9380 IC: 24482-FR9380 COMMERCIAL-IN-CONFIDENCE Document 75954042-02 Issue 01 DISCLAIMER AND COPYRIGHT This non-binding report has been prepared by TÜV SÜD with all reasonable skill and care. The document is confidential to the potential Client and TÜV SÜD. No part of this document may be reproduced without the prior written approval of TÜV SÜD. © 2022 TÜV SÜD. This report relates only to the actual item/items tested. ACCREDITATION Our UKAS Accreditation does not cover opinions and interpretations and any expressed are outside the scope of our UKAS Accreditation. Results of tests not covered by our UKAS Accreditation Schedule are marked NUA (Not UKAS Accredited). Document 75954042-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 1 of 72 Contents 1 Report Summary ......................................................................................................................... 2 1.1 Report Modification Record ........................................................................................................... 2 1.2 Introduction .................................................................................................................................... 2 1.3 Brief Summary of Results ............................................................................................................. 3 1.4 Application Form ........................................................................................................................... 4 1.5 Product Information ....................................................................................................................... 7 1.6 Deviations from the Standard ........................................................................................................ 7 1.7 EUT Modification Record .............................................................................................................. 7 1.8 Test Location ................................................................................................................................. 8 2 Test Details .................................................................................................................................. 9 2.1 AC Power Line Conducted Emissions .......................................................................................... 9 2.2 Frequency Hopping Systems - Average Time of Occupancy ..................................................... 13 2.3 Frequency Hopping Systems - Channel Separation ................................................................... 17 2.4 Frequency Hopping Systems - Number of Hopping Channels ................................................... 20 2.5 Frequency Hopping Systems - 20 dB Bandwidth ....................................................................... 23 2.6 Maximum Conducted Output Power ........................................................................................... 27 2.7 Conducted Spurious Emissions from the Antenna Port .............................................................. 29 2.8 Spurious Radiated Emissions ..................................................................................................... 45 2.9 Authorised Band Edges .............................................................................................................. 63 3 Photographs .............................................................................................................................. 68 3.1 Test Setup Photographs ............................................................................................................. 68 4 Measurement Uncertainty ........................................................................................................ 72 Document 75954042-02 Issue 01 COMMERCIAL-IN-CONFIDENCE COMMERCIAL-IN-CONFIDENCE Page 2 of 72 1 Report Summary 1.1 Report Modification Record Alterations and additions to this report will be issued to the holders of each copy in the form of a complete document. Issue Description of Change Date of Issue 1 First Issue 15-September-2022 Table 1 1.2 Introduction Applicant PervasID Manufacturer PervasID Model Number(s) FR 9380 (8-port FCC) Serial Number(s) 10510422-0074 Hardware V…

Text truncated - open the document above for the full version.

FCC ID: 2AQQWFR9380 IC: 24482-FR9380 PervasID FR 9380 2022 Not to be reproduced, except in its entirety, Page 1 of 9 without the Permission of TÜV SÜD Reference: 75954042 PHOTOGRAPHS OF TEST SET UP Figure 1 – Conducted Disturbance at Mains Terminals FCC ID: 2AQQWFR9380 IC: 24482-FR9380 PervasID FR 9380 2022 Not to be reproduced, except in its entirety, Page 2 of 9 without the Permission of TÜV SÜD Reference: 75954042 Figure 2 – Radiated Disturbance - 30 MHz to 1 GHz FCC ID: 2AQQWFR9380 IC: 24482-FR9380 PervasID FR 9380 2022 Not to be reproduced, except in its entirety, Page 3 of 9 without the Permission of TÜV SÜD Reference: 75954042 Figure 3 – Radiated Disturbance - 1 GHz to 10 GHz
