2AQUQGB17274Outdoor Fixed Security Light with Wifi module

Globe Electric Company Inc.

Click to zoom

Application Details

Equipment Class: DTS - Digital Transmission System
Date of Grant: Sep 02, 2023
Application Purpose: Original Equipment
Date of Application: Sep 02, 2023
Equipment Note: Outdoor Fixed Security Light with Wifi module
Frequency Range: 2412.00000000 - 2462.00000000
Company: Globe Electric Company Inc.
Country: Canada

Documents & Files

Select a file to view

Document Text

Text extracted from the exhibit documents filed with the FCC. Open a document above to read the original.

Users Manual

OutdoorFixedSecurityLightwithWifi module MODEL:17000274 █INTRODUCTION TheLightincorporatesaPIR(PassiveInfraRed)sensingdevice whichcontinuouslyscansapresetoperatingzoneandimmediately switchesthelightonwhenitdetectsmovementinthatarea.This meansthatwhenevermovementisdetectedwithintherangeofthe sensorthelightwillswitchonautomaticallytoilluminatepathways, steps,patios,porches,orwhateverareayouhaveselectedtolight forreasonsofsafety,convenienceorsecurity. Whilethereismovementwithinrangeoftheunitthelightwillremain on. █WHILETOFITYOURLIGHT Toachievebestresults,wesuggestyouaccountthefollowing points: ■IdeallytheLightshouldbemounted1.8to2.5meters(6to8ft) abovetheareatobescanned ■Toavoiddamagetounit-donotaimthesensortowardsthesun. ■Toavoidnuisancetriggering,thesensorshouldbedirected awayfromheatsourcessuchasbarbecues,Air-conditioners, otheroutsidelighting,movingcarsandfluevents. ■Toavoidnuisancetriggering,keepingawayfromtheareaof strongelectromagneticdisturbance. ■Donotaimtowardsreflectivesurfacessuchassmoothwhite walls,swimmingpools,etc.TheSecuritylightscanning specifications(Max.15metersat240°)mayvaryslightly dependingonthemountingheightandlocation.Thedetection rangeoftheunitmayalsoalterwithtemperaturechange. Beforeselectingaplacetoinstallyourlightyoushouldnotethat movementacrossthescanareaismoreeffectivethan movementdirectlytowardorawayfromthesensor.(refer Figure).Ifmovementismadewalkingdirectlytowardsoraway fromthesensorandnotacross,theapparentdetectionrange willbesubstantiallyreduced. █FITTINGTHEUNIT InstallationbyalicensedelectricianandaccordingtoIECwiring Regulation. Beforecommencinganyelectricalwork,ensuremainssupply cablesareisolatedbyswitchingoffandremovingtherelevant fuse. 1.MountingthemountingsupportontotheJunctionbox 2.Connectthemaincabletotheterminal 3.Mountingthemountingpanelontothemountingsupport 4.Mountingthemainlightontothemountingpanel. 5.Switchthemainpoweron. IMPORTANT: 1.Neverattempttoremovethelenscoverasthiswilldamagethe sensorandrenderallguaranteesinvalid. 2.Beforetouchingthelight,pleaseswitchofffirstandthenletit cool █ UNDERSTANDINGTHECONTROLS(referringto theFigure) ADJUSTINGTHEONTIME:Thelengthoftimethatremains switchedonafteractivationcanbeadjustedbetween TEST,1min,5min,20min. Note: 1.OncethelighthasbeentriggeredbythePIRsensorany subsequentdetectionwillstartthetimedperiodagainfromthe beginning. 2.TEST,thelightwillturnonabout5swhetherdayornight 3.1min,5min,20min:Thelightonlyturnonatnight. ADJUSTINGTHEDURATIONSENS:Thesensitivitymeansthe MaximumdistancewhichPIRSensorcanbetriggeredby movementbody. ADJUSTINGTHEBrightnessLEVEL:Thebrightnessofthelight canbeadjustedbetweenhighandlow ADJUSTINGTHEDualBrite:TheDualbrightnessofthelightcan beadjustedbetweenOFF,6h,DusktoDawn. OFF:Nodualbrightness 6h:Thelightwillturnonatlowbrightnessatnight,thenoffafter6 hoursorgoingtoday,inthistime,Whenthesignalissensed,the lightswillturnonhighbrightness. DusktoDawn:Thelightwillturnonatlowbrightnessallthenight,, inthistime,Whenthesignalissensed,thelightswillturnonhigh brightness. RESET:Presstheresetbuttonmorethan5s,thewifiwillRestoreto factorysettings █TECHNICALDETAILS: Voltage:108-132VAC~60Hz Wattage:22WLED Lumen:2200LM Colortemperature:4000K Detectionrange:240ºandMax.15meters Durationtime:TEST,1min,5min,20min Weatherproof:IP44 Protection：ClassII Suitableforindoorandoutdooruse Company：AUROLITEAUTOTECH GUANGDONGLTD Address：No.1Jinsheng1Road,Hualong Town,PanyuDistrict,Guangzhou,China ThisdevicecomplieswithPart15oftheFCCRules.Operationis subjecttothefollowingtwoconditions:(1)thisdevicemaynotcause harmfulinterference,and(2)thisdevicemustacceptany interferencereceived,includinginterferencethatmaycause undesiredoperation. Warning:Changesormodtificationstothisunitnotexpressly approvedbythepartyresponsibleforcompliancecouldvoidthe user’sauthoritytooperatetheequipment. Note:Thisequipmenthasbeentestedandfoundtocomplywiththe limitsforaClassBdigitaldevice,pursuanttopart15oftheFCC Rules.Theselimitsaredesignedtoprovidereasonableprotection againstharmfulinterferenceinaresidentialinstallation.This equipmentgenerates,usesandcanradiateradiofrequencyenergy and,ifnotinstalledandusedinaccordancewiththeinstructions, maycauseharmfulinterferencetoradiocommunications.However, thereisnoguaranteethatinterferencewillnotoccurinaparticular installation.Ifthisequipmentdoescauseharmfulinterferenceto radioortelevisionreception,whichcanbedeterminedbyturningthe equipmentoffandon,theuserisencouragedtotrytocorrectthe interferencebyoneormoreofthefollowingmeasures: -Reorientorrelocatethereceivingantenna. -Increasetheseparationbetweentheequipmentandreceiver. -Connecttheequipmentintoanoutletonacircuitdifferentfromthat towhichthereceiverisconnected. -Consultthedealeroranexperiencedradio/TVtechnicianforhelp. Thisdevicecontainslicence-exempttransmitter(s)/receiver(s)that complywithInnovation,ScienceandEconomicDevelopment Canada’slicence-exemptRSS(s). Operationissubjecttothefollowingtwoconditions: 1.Thisdevicemaynotcauseinterference. 2.Thisdevicemustacceptanyinterference,includinginterference thatmaycauseundesiredoperationofthedevice. FCCResponsiblePartyName:GlobeElectricCompanyInc. Address:150Av.Oneida,Pointe-Claire,QCH9R1A8Canada TelephoneNumber:(514)694-0444 CANICES-005(B)/NMB-005(B) RFwarningforMobiledevice: ThisequipmentcomplieswithFCCradiationexposurelimitsset forthforanuncontrolledenvironment.Thisequipmentshouldbeinst alledandoperatedwithminimumdistance20cmbetweenthe radiator&yourbody. Thisdevicecontainslicence-exempttransmitter(s)/receiver(s)that complywithInnovation,ScienceandEconomicDevelopment Canada’slicence-exemptRSS(s).Operationissubjecttothe followingtwoconditions: (1)Thisdevicemaynotcauseinterference. (2)Thisdevicemustacceptanyinterference,includinginterference thatmaycauseundesiredoperationofthedevice. Cetappareilcontientdesémetteurs/récepteursexemptésde licenceconformesauxRSS(RSS)d'Innovation,Scienceset DéveloppementéconomiqueCanada.Lefonctionnementest soumisauxdeuxconditionssuivantes: (1)Cetappareilnedoitpascauserd'inter…

Text truncated - open the document above for the full version.

Attestation Statements

GlobeElectricCompanyInc. (date)：2023.8.18 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:AttestationStatementsPart2.911(d)(5)(i)requestfor(2AQUQGB17274) [ GlobeElectricCompanyInc. ](“theapplicant”)certifiesthattheequipmentforwhich authorizationissoughtisnot“covered”equipmentprohibitedfromreceivingan equipmentauthorizationpursuanttosection2.903oftheFCCrules. Sincerely, <Signature> Name：Celine.zhu TitleSeniorprojectmanager CompanyGlobeElectricCompanyInc. GlobeElectricCompanyInc. (date)：2023.8.18 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:AttestationStatementsPart2.911(d)(5)(ii)requestfor(2AQUQGB17274) [GlobeElectricCompanyInc.](“theapplicant”)certifiesthat,asofthedateofthefilingofthe application,theapplicantisnotidentifiedontheCoveredListasanentityproducing “covered”equipment. Sincerely, <Signature> Name ：Celine.zhu TitleSeniorprojectmanager CompanyGlobeElectricCompanyInc.

Attestation Statements

C5266091_X23_Ed.1 1/1 USAGENTLETTEROFATTESTATION USAgent: CompanyName:GlobeElectric ContactName:CelineZhu Address:2264East6thStreetSanBernardino,CA92410UnitedStates TelephoneNo:(514)694-0444 Email: Email:[email protected] FRN:0033436957 TO: OfficeofEngineeringTechnology FederalCommunicationsCommission 7435OaklandMillsRoad Columbia,MD21046 ThisletteristoconfirmthatwehaveacceptedtheresponsibilitytoactasUSagent representativeonbehalfofthe(GlobeElectricCompanyInc.）notedbelowforallfutureFCC certification/registrationsobtainedduringtheperiodofthisagreement,whichendsatthe specifieddatebelow. AsperUSagent,weareawareoftherequirementsinvolvedasoutlinedinFCCEquipment AuthorizationProgramintheirReportandOrderFCC22-84andtheclause§2.911Application requirements. Applicant Companyname:GlobeElectricCompanyInc. USAgent’sName: CelineZh Granteecode: FCCID: Address: Name:CelineZh 2AQUQ 2AQUQGB17274 150 Oneida, Montreal, Quebec, Canada, H9R 1A8 u u Phone:+86-755-25192522 Email:[email protected] TheApplicantacknowledgetheacceptanceofitsobligationtomaintainanagentfor serviceofprocessintheUnitedStatesfornolessthanoneyearaftereitherthe granteehaspermanentlyterminatedallmarketingandimportationoftheapplicable equipmentwithintheU.S.,ortheconclusionofanyCommission-related administrativeorjudicialproceedinginvolvingtheequipment,whicheverislater. Date:2023.8.18 Applicant’s Name: Celine Zhu SignatureSignature

Cover Letter(s)

GlobeElectricCompanyInc. (date)：2023.8.18 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:CONFIDENTIALITYREQUESTFOR(OutdoorFixedSecurityLightwith Wifimodule / 17000274 /ANDFCCID: 2AQUQGB17274 ) ToWhomItMayConcern: Thisletterservesasanofficialrequestforconfidentialityundersections0.457and0.459 ofCFR47.Wehaverequestedthatthe Schematics Blockdiagram Operationdescription requiredtobesubmittedwiththisapplicationbepermanentlywithheldfrompublic review. Thesematerialscontaintradesecretsandproprietaryinformationandarenot customarilyreleasedtothepublic.Thepublicdisclosureofthisinformationmightbe harmfultothecompanyandprovideunjustifiedbenefitstoour Pleasecontactmeifthereisanyinformationyoumayneed. Sincerely, <Signature> Name ：Celine.zhu TitleSeniorprojectmanager CompanyGlobeElectricCompanyInc.

Cover Letter(s)

GlobeElectricCompanyInc. (Date):2023.8.18 EurofinsElectricalandElectronicTestingNA,Inc. 914WestPatapscoAvenue Baltimore,MD21230 RE:LETTEROFAGENTAUTHORIZATION ToWhomItMayConcern: We,theundersigned,herebyauthorize Celine.zhu toactonourbehalfinallmattersrelatingto applicationforequipmentauthorization,includingthesigningofalldocumentsrelatingtothese matters. Wealsoherebycertifythatnopartytotheapplicationauthorizedhereunderissubjecttothe denialofbenefits,includingFCCbenefits,pursuanttoSection5301oftheAnti-DrugAbuseAct of1988,21U.S.C.853(a). Thisagreementexpiresoneyearfromthecurrentdate. Sincerely, Sincerely, <Signature> Name ：Celine.zhu TitleSeniorprojectmanager CompanyGlobeElectricCompanyInc.

External Photos

ProductName: OutdoorFixedSecurityLightwithWifi module

Internal Photos

ProductName: OutdoorFixedSecurityLightwithWifi module

RF Exposure Info

SARevaluation ProductName: OutdoorFixedSecurityLightwithWifimodule FCCID: 2AQUQGB17274 TestStandard: KDB447498D04GeneralRFExposure Guidancev01 Accordingto447498D04InterimGeneralRFExposureGuidancev01 StandaloneSARtestexclusionconsiderations UnlessspecificallyrequiredbythepublishedRFexposureKDBprocedures,standalone1-ghead orbodyand10-gextremitySARevaluationforgeneralpopulationexposureconditions,by measurementornumericalsimulation,isnotrequiredwhenthecorrespondingSARExclusion Thresholdcondition,listedbelow,issatisfied. CalculatedResultandLimit(WORSECASEISASBELOW) WIFI Directional antennaGain (Numeric) PeakOutput Power(dBm) PeakOutput Power(mW) Limit(mW/cm²) TestResult 1.37dBi(1.371)18.339 68.218 (802.11g2412) 3060Compiles ERP=18.339+1.37-2.15=57.003mW

Test Report

1 Antenna Specification Manufacture：TUYA Product Name：CB3S Antenna Antenna Type：PCB Test Date：2021.04.16 Tested by：Jianwei Wang Approved by：Licco Antenna Te s t R e p o r t 2 Content 1.General Description ................................................................................. 3 2.Test Configurations .................................................................................. 4 2.1 Test Environment ............................................................................ 4 2.2 Test Equipment ............................................................................... 4 2.3 Test Principle .................................................................................. 4 3.Test Results .............................................................................................. 5 3.1 Gain and Efficiency ........................................................................ 5 3.2 Radiation Pattern ............................................................................. 6 4.Antenna Dimensions ................................................................................ 9 5.EUT Photo ............................................................................................... 9 6.Test Setup Photo .................................................................................... 10 3 1.General Description Manufacturer Hangzhou Tuya Information Technology Co.,Ltd Address Room 701,Building 3,More Center,No.87 GuDun Road, Hangzhou, Zhejiang,China Test Locat ion Room 106, Building 3, Letong Science Park, No. 500, Qiuyi Road, Binjiang District, Hangzhou Product Name CB3S Antenna Product model CB3S Antenna Type PCB Antenna Test Items Gain; Efficiency; Radiation Pattern Test Frequency 2400-2500MHz Test Standard ANSI/IEEE Std 149-1979 4 2.Test Configurations 2.1 Test Environment Temperature ()°C 25 Humidity (%RH) 60 Atmospheric Pressure (kPa) 100.5 2.2 Test Equipment Test System TEM 24 Multi-probe Microwave Chamber Test Instrument Agilent E5071B 2.3 Test Principle 5 3.Test Results 3.1 Gain and Efficiency Frequency (MHz) Peak Gain (dBi) Efficiency (%) 2400 0.46 44.36 2410 0.71 45.71 2420 0.92 45.92 2430 0.91 45.6 2440 0.95 45.6 2450 0.93 45.29 2460 1.27 46.45 2470 1.37 46.88 2480 1.25 47.21 2490 1.24 46.67 2500 1.05 44.87 6 3.2 Radiation Pattern Phi 0 7 Phi 90 8 Theta 90 9 4.Antenna Dimensions 5.EUT Photo 10 6.Test Setup Photo

Test Report

Page 1 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. Add:BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict,Shenzhen,GuangdongProvince,China Tel:+86-755-23059481Email:[email protected] TESTREPORT ProductName: OutdoorFixedSecurityLightwithWifi module BrandMark: N/A ModelNo.: 17000274 ReportNumber: BLA-EMC-202308-A2301 FCCID: 2AQUQGB17274 DateofSampleReceipt: 2023/7/21 DateofTest: 2023/7/21to2023/8/17 DateofIssue: 2023/8/17 TestStandard: 47CFRPart15,SubpartC15.247 TestResult:Pass Preparedfor: GLOBEELECTRICCOMPANYINC. 150,ONEIDA,MONTREAL,QUEBEC,CANADA,H9R1A8 Preparedby: BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd. BuildingC,No.107,ShihuanRoad,ShiyanSub-District,BaoanDistrict, Shenzhen,GuangdongProvince,China TEL:+86-755-23059481 Compiledby:Reviewby: Approvedby:Date:2023/8/17 ReportNo.:BLA-EMC-202308-A2301 Page 2 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] REPORTREVISERECORD VersionNo.DateDescription 002023/8/17Original ReportNo.:BLA-EMC-202308-A2301 Page 3 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] TABLEOFCONTENTS 1TESTSUMMARY........................................................................................................................................5 2GENERALINFORMATION.........................................................................................................................6 3GENERALDESCRIPTIONOFE.U.T..........................................................................................................6 4TESTENVIRONMENT................................................................................................................................7 5TESTMODE................................................................................................................................................7 6MEASUREMENTUNCERTAINTY..............................................................................................................7 7DESCRIPTIONOFSUPPORTUNIT..........................................................................................................8 8LABORATORYLOCATION.........................................................................................................................8 9TESTINSTRUMENTSLIST........................................................................................................................9 10ANTENNAREQUIREMENT......................................................................................................................11 10.1CONCLUSION.........................................................................................................................................................11 11RADIATEDSPURIOUSEMISSIONS........................................................................................................12 11.1LIMITS................................................................................................................................................................12 11.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................13 11.3PROCEDURE.......................................................................................................................................................13 11.4TESTDATA...........................................................................................................................................................15 12RADIATEDEMISSIONSWHICHFALLINTHERESTRICTEDBANDS.................................................24 12.1LIMITS................................................................................................................................................................24 12.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................25 12.3PROCEDURE.......................................................................................................................................................25 12.4TESTDATA...........................................................................................................................................................27 13CONDUCTEDSPURIOUSEMISSIONS...................................................................................................44 13.1LIMITS................................................................................................................................................................44 13.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................44 13.3TESTDATA...........................................................................................................................................................45 14CONDUCTEDBANDEDGESMEASUREMENT.....................................................................................46 14.1LIMITS................................................................................................................................................................46 14.2BLOCKDIAGRAMOFTESTSETUP......................................................................................................................46 14.3TESTDATA...........................................................................................................................................................47 ReportNo.:BLA-EMC-202308-A2301 Page 4 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 15MINIMUM6DBBANDWIDTH...................................................................................................................48 15.1LIMITS.......................................................................................................…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202308-A2301 Page 31 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXglowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 32 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXglowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 33 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXghighchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 34 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXghighchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 35 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20lowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 36 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20lowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 37 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20highchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 38 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn20highchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 39 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn40lowchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 40 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn40lowchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 41 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn40highchannel];[Polarity:Horizontal] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 42 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] [TestMode:TXn40highchannel];[Polarity:Vertical] TestResult:Pass ReportNo.:BLA-EMC-202308-A2301 Page 43 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] Remark: 1.FinalLevel=ReceiverReadlevel+Correctfactor 2.Correctfactor=AntennaFactor+CableLoss–PreamplifierFactor 3.Theemissionlevelsofotherfrequenciesareverylowerthanthelimitandnotshowintestreport. ReportNo.:BLA-EMC-202308-A2301 Page 44 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 13CONDUCTEDSPURIOUSEMISSIONS TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.6&Section11.11 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 13.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthehighest levelofthedesiredpower,basedoneitheranRFconductedoraradiated measurement,providedthetransmitterdemonstratescompliancewiththepeak conductedpowerlimits.Ifthetransmittercomplieswiththeconductedpower limitsbasedontheuseofRMSaveragingoveratimeinterval,aspermittedunder paragraph(b)(3)ofthissection,theattenuationrequiredunderthisparagraphshall be30dBinsteadof20dB.Attenuationbelowthegenerallimitsspecifiedin §15.209(a)isnotrequired.Inaddition,radiatedemissionswhichfallinthe restrictedbands,asdefinedin§15.205(a),mustalsocomplywiththeradiated emissionlimitsspecifiedin§15.209(a)(see§15.205(c)). 13.2BLOCKDIAGRAMOFTESTSETUP ReportNo.:BLA-EMC-202308-A2301 Page 45 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 13.3TESTDATA Pass:PleaseReferToAppendix:Appendix1ForDetails ReportNo.:BLA-EMC-202308-A2301 Page 46 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14CONDUCTEDBANDEDGESMEASUREMENT TestStandard47CFRPart15,SubpartC15.247 TestMethodANSIC63.10(2013)Section7.8.8&Section11.13.3.2 TestMode(Pre-Scan)TX TestMode(FinalTest)TX TesterJozu Temperature25°C Humidity60% 14.1LIMITS Limit: Inany100kHzbandwidthoutsidethefrequencybandinwhichthespread spectrumordigitallymodulatedintentionalradiatorisoperating,theradio frequencypowerthatisproducedbytheintentionalradiatorshallbeatleast20dB belowthatinthe100kHzbandwidthwithinthebandthatcontainsthehighest levelofthedesiredpower,basedoneitheranRFconductedoraradiated measurement,providedthetransmitterdemonstratescompliancewiththepeak conductedpowerlimits.Ifthetransmittercomplieswiththeconductedpower limitsbasedontheuseofRMSaveragingoveratimeinterval,aspermittedunder paragraph(b)(3)ofthissection,theattenuationrequiredunderthisparagraphshall be30dBinsteadof20dB.Attenuationbelowthegenerallimitsspecifiedin §15.209(a)isnotrequired.Inaddition,radiatedemissionswhichfallinthe restrictedbands,asdefinedin§15.205(a),mustalsocomplywiththeradiated emissionlimitsspecifiedin§15.209(a)(see§15.205(c)). 14.2BLOCKDIAGRAMOFTESTSETUP ReportNo.:BLA-EMC-202308-A2301 Page 47 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] 14.3TESTDATA Pass:PleaseReferToAppendix:Appendix1ForDetails ReportNo.:BLA-EMC-20…

Text truncated - open the document above for the full version.

Test Report

ReportNo.:BLA-EMC-202308-A2301 Page 61 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] PowerNVNTn202462MHzAnt1 PowerNVNTn402422MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 62 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] PowerNVNTn402437MHzAnt1 PowerNVNTn402452MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 63 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ReportNo.:BLA-EMC-202308-A2301 Page 64 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidth ConditionModeFrequency (MHz) Antenna-6dBBandwidth (MHz) Limit-6dB Bandwidth(MHz) Verdict NVNTb2412Ant112.0140.5Pass NVNTb2437Ant111.5950.5Pass NVNTb2462Ant111.0490.5Pass NVNTg2412Ant116.9490.5Pass NVNTg2437Ant117.1180.5Pass NVNTg2462Ant116.5950.5Pass NVNTn202412Ant116.7650.5Pass NVNTn202437Ant116.9840.5Pass NVNTn202462Ant118.0020.5Pass NVNTn402422Ant134.9990.5Pass NVNTn402437Ant135.2480.5Pass NVNTn402452Ant134.70.5Pass -6dBBandwidthNVNTb2412MHzAnt1 -6dBBandwidthNVNTb2437MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 65 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidthNVNTb2462MHzAnt1 -6dBBandwidthNVNTg2412MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 66 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidthNVNTg2437MHzAnt1 -6dBBandwidthNVNTg2462MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 67 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidthNVNTn202412MHzAnt1 -6dBBandwidthNVNTn202437MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 68 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidthNVNTn202462MHzAnt1 -6dBBandwidthNVNTn402422MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 69 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] -6dBBandwidthNVNTn402437MHzAnt1 -6dBBandwidthNVNTn402452MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 70 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ReportNo.:BLA-EMC-202308-A2301 Page 71 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OccupiedChannelBandwidth ConditionModeFrequency(MHz)Antenna99%OBW(MHz) NVNTb2412Ant115.155 NVNTb2437Ant115.148 NVNTb2462Ant115.123 NVNTg2412Ant117.229 NVNTg2437Ant117.301 NVNTg2462Ant117.336 NVNTn202412Ant118.180 NVNTn202437Ant117.992 NVNTn202462Ant118.035 NVNTn402422Ant136.002 NVNTn402437Ant136.005 NVNTn402452Ant135.967 OBWNVNTb2412MHzAnt1 OBWNVNTb2437MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 72 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OBWNVNTb2462MHzAnt1 OBWNVNTg2412MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 73 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OBWNVNTg2437MHzAnt1 OBWNVNTg2462MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 74 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OBWNVNTn202412MHzAnt1 OBWNVNTn202437MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 75 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OBWNVNTn202462MHzAnt1 OBWNVNTn402422MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 76 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] OBWNVNTn402437MHzAnt1 OBWNVNTn402452MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 77 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] ReportNo.:BLA-EMC-202308-A2301 Page 78 of 118 BlueAsiaofTechnicalServices(Shenzhen)Co.,Ltd.Tel:+86-755-23059481Email:[email protected] MaximumPowerSpectralDensityLevel ConditionModeFrequency(MHz)AntennaMaxPSD(dBm)Limit(dBm)Verdict NVNTb2412Ant1-7.7428Pass NVNTb2437Ant1-8.7188Pass NVNTb2462Ant1-8.2538Pass NVNTg2412Ant1-11.3058Pass NVNTg2437Ant1-10.4778Pass NVNTg2462Ant1-9.6928Pass NVNTn202412Ant1-12.338Pass NVNTn202437Ant1-11.1278Pass NVNTn202462Ant1-12.1328Pass NVNTn402422Ant1-14.9158Pass NVNTn402437Ant1-16.3488Pass NVNTn402452Ant1-16.3868Pass PSDNVNTb2412MHzAnt1 PSDNVNTb2437MHzAnt1 ReportNo.:BLA-EMC-202308-A2301 Page 79 of 118 …

Text truncated - open the document above for the full version.

Contact Information

Applicant

Celine Zhu(Senior Project Manager)

[email protected]+86-755-25192522Fax: 755 8225 7770

Test Firm

BlueAsia of Technical Services (Shenzhen)Blue Zheng

[email protected]+86 755-23059481-815

Technical Specifications

#	Rule Parts	Frequency Range	Power Output
1	15C	2.41 GHz - 2.46 GHz	68.22 mW

Confidentiality

Long Term

Grant Notes

Output power listed is conducted. The device supports 20MHz and 40MHz bandwidths. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter device.
