Pratt & Whitney 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 To: Cetecom, Inc., Re: PTCRB Project Request 59306 Date: 06/29/2017 Exhibit A7: User Manual for the eFAST product WARNING - PROPRIETARY RIGHTS NOTICE This document is the property of Pratt & Whitney Corp. (“P&W”). You may not possess, use, copy or disclose this document or any information in it, for any purpose, including without limitation to design, manufacture, or repair parts, or obtain TCCA, FAA or other government approval to do so, without P&W's express written permission. Neither receipt nor possession of this document alone, from any source, constitutes such permission. Possession, use, copying or disclosure by anyone without P&W's express written permission is not authorized and may result in criminal or civil liability. U.S. Export Classification: EAR ECCN 9E991 PRODUCT DESIGNATION: Manufacturer:Collins Aerospace & Setrix 400 Main Street East Hartford, CT 06118 Marketing Name:eFAST TM (Enhanced, Flight-data, Acquisition, Storage & Transmission) Part # / Rev: FCC ID:2AQWD-HMU200-3G IC_ID:25562-HMU2003G PRODUCT OVERVIEW: The Health Management Unit (HMU) is a multi-function LRU that is capable of recording full-flight data, performing aircraft/engine condition monitoring, generating reports based on recorded data and offloading the data and reports to a remote ground station. The HMU will be integrated with the aircraft’s avionics systems, including the ARINC 664 network, and will be reporting maintenance related data to the Onboard Maintenance System (OMS) and aircraft condition monitoring advisory/info messages to be displayed in the Crew Alerting System. The fundamental function of the HMU is to acquire and record parameters as outlined in the requirements section of this document. Data can be collected from the ARINC 429 and ARINC 664 input ports to be stored in resident non-volatile memory. The user can program reports that will monitor data in real time and trigger at defined conditions to capture data into recordings. The HMU mounts in the forward Avionics Bay. The mounting mechanism is of a tray containing two ARINC 600 style ratchet latches that secure the HMU. The HMU has physical interfaces to the Primary Avionics via ARINC 664 and A429 buses, the electrical system via two DC power buses and a battery bus, the landing gear system via a hardwire discrete, and the Aircraft Network Switch (ANS) via standard Ethernet interface. Pratt & Whitney Page 2 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 Pratt & Whitney Proprietary U.S. Export Classification: EAR ECCN 9E991 External Components / Accessories: 1.Cellular Antenna Laird Technologies, P/N: CAF 94362 Antenna shall be connected to SMA J4 port on front of eFAST by means of a coaxial cable with provided SMA connectors (straight SMA connectors) 2.Wireless LAN Antenna Sensor Systems Inc., P/N: S65-8280-37 Antenna shall be connected to SMA J5 port on front of eFAST by means of a coaxial cable and provided lightning suppressor attachment. Pratt & Whitney Page 3 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 Pratt & Whitney Proprietary U.S. Export Classification: EAR ECCN 9E991 3. Wireless LAN Antenna Cable  Carlisle Interconnect Technologies, P/N: 311501 4. Cellular Antenna Cable Carlisle Interconnect Technologies, P/N: 311501 5. Optional Wireless LAN Lightning Protector Times Microwave Systems, Product Number: LP-WBX-NMP Pratt & Whitney Page 4 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 Pratt & Whitney Proprietary U.S. Export Classification: EAR ECCN 9E991 FCC and ISED Cautionary Statements I. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation Cet appareil est conforme à la partie 15 des règles de la FCC. Son fonctionnement est soumis aux deux conditions suivantes: (1) Cet appareil ne doit pas provoquer d'interférences nuisibles, et (2) cet appareil doit accepter toute interférence reçue, y compris les interférences pouvant entraîner un fonctionnement indésirable. II. Changes or modifications not expressly approved by Pratt & Whitney could void the user’s authority to operate the equipment III. Per RSS GEN 6.8, this radio transmitter (25562-HMU2003G) has been approved by Innovation, Science, and Economic Development Canada to operate with the antenna types listed below, with the maximum permissible gain / associated cable loss as indicated in the filing. Antenna types not included in this list that have a gain greater than the maximum gain indicated for any type listed are strictly prohibited for use with this device. a. Laird Technologies IFMULT-SF00 Multi-band MicroSphere antenna b. Sensor Systems VHF/WLA S65-8280-37 Blade antenna IV. To comply with FCC rule parts 2.1091 / ISED RSS 102 RF exposure requirements for mobile transmitting devices, this device and the antenna(s) used for this transmitter must be installed to provide a separation distance of at least 30 cm (~ 12 inches) from all persons and must not be co-located and/or operating in conjunction with any other antenna or transmitter

Pratt & Whitney 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 To: Cetecom, Inc., Re: PTCRB Project Request 59306 Date: 06/29/2017 Exhibit A1: External photos of eFAST product SHORT TERM CONFIDENTIALITY – This notice expires 180 days from grant issue date. WARNING - PROPRIETARY RIGHTS NOTICE This document is the property of Pratt & Whitney Corp. (“P&W”). You may not possess, use, copy or disclose this document or any information in it, for any purpose, including without limitation to design, manufacture, or repair parts, or obtain TCCA, FAA or other government approval to do so, without P&W's express written permission. Neither receipt nor possession of this document alone, from any source, constitutes such permission. Possession, use, copying or disclosure by anyone without P&W's express written permission is not authorized and may result in criminal or civil liability. U.S. Export Classification: EAR ECCN 9E991 Product Designation: Manufacturer:Collins Aerospace & Setrix 400 Main Street East Hartford, CT 06118 Marketing Name:eFAST TM (Enhanced, Flight-data, Acquisition, Storage & Transmission) Part # / Rev: FCC ID:2AQWD-HMU200-3G IC_ID:25562-HMU2003G Pratt & Whitney Page 2 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 PW Proprietary U.S. Export Classification: EAR ECCN 9E991 External Photos: Note: The photos are of current production product prior to PTCRB Registration. The label noted will be changed per the following section. Figure 1: Isometric View of eFAST product on mounting tray (as installed in aircraft) J5 Wi-Fi Antenna J4 Cellular Antenna Memory Card Port USB Port Pratt & Whitney Page 3 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 PW Proprietary U.S. Export Classification: EAR ECCN 9E991 Figure 2: Left Side View Figure 3: Front ViewFigure 4: Rear View Figure 5: SIM Card & Tray Figure 6: Right Side View Connection to Aircraft Pratt & Whitney Page 4 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 PW Proprietary U.S. Export Classification: EAR ECCN 9E991 Figure 7: Bottom of Unit (off tray) Figure 8: Top of Unit

Pratt & Whitney 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 This document does not contain any export regulated technical data. To: Cetecom, Inc., Re: PTCRB Project Request 59306 Date: 12/12/2019 Exhibit A5: Label Product Designation: Manufacturer:Collins Aerospace & Setrix 400 Main Street East Hartford, CT 06118 Marketing Name:eFAST TM (Enhanced, Flight-data, Acquisition, Storage & Transmission) Part # / Rev: FCC ID:2AQWD-HMU200-3G IC_ID:25562-HMU2003G Label: Label will be a permanent sticker applied to the front cover of the eFAST enclosure during the manufacturing process of the box. Label will measure roughly 1” x 5/8” and be positioned under the Memory Cover USB Connector front plate. FCC ID: 2AQWD-HMU200-3G IC ID: 25562-HMU2003G HVIN: HMU200-1 Pratt & Whitney Page 2 of 2 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 This document does not contain any export regulated technical data. F C C I D : 2 A Q W D - H M U 2 0 0 - 3 G I C I D : 2 5 5 6 2 - H M U 2 0 0 3 G H V I N : H M U 2 0 0 - 1

Pratt & Whitney 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 To: Cetecom, Inc., Re: PTCRB Project Request 59306 Date: 07/06/2017 Exhibit A3: Internal Photos of eFAST product SHORT TERM CONFIDENTIALITY – This notice expires 180 days from grant issue date. WARNING - PROPRIETARY RIGHTS NOTICE This document is the property of Pratt & Whitney Corp. (“P&W”). You may not possess, use, copy or disclose this document or any information in it, for any purpose, including without limitation to design, manufacture, or repair parts, or obtain TCCA, FAA or other government approval to do so, without P&W's express written permission. Neither receipt nor possession of this document alone, from any source, constitutes such permission. Possession, use, copying or disclosure by anyone without P&W's express written permission is not authorized and may result in criminal or civil liability. U.S. Export Classification: EAR ECCN 9E991 Product Designation: Manufacturer:Collins Aerospace & Setrix 400 Main Street East Hartford, CT 06118 Marketing Name:EFAST TM (Enhanced, Flight-data, Acquisition, Storage & Transmission) Part # / Rev: FCC ID:2AQWD-HMU200-3G IC_ID:25562-HMU2003G Pratt & Whitney Page 2 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 PW Proprietary U.S. Export Classification: EAR ECCN 9E991 Internal Circuit Boards: 1.eFAST Certified Processor Boards: Figure 1: eFAST Certified Processor Board Figure3: Backside of eFAST Certified Processor Board eFAST Certified Processor channels A and B are avionics-grade DAL A United Technologies Aerospace System (UTAS) hardware designs. Their primary task is interfacing with the aircraft for collecting and recording data. Each eFAST channel uses a time and space partitioned, real-time operating system (RTOS) allowing multiple processes with different design assurance levels (DAL) to run on the same processor. Pratt & Whitney Page 3 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 Pratt & Whitney Proprietary U.S. Export Classification: EAR ECCN 9E991 2.eFAST Micro-Server Board: Figure 4: eFAST Micro-Server Board Figure 5: Backside of eFAST Micro-Server Board Battery Power Regulator RAM Physical Ethernet Ethernet Switch CPU Flash Compact Flash WiFi Cellular Pratt & Whitney Page 4 of 4 400 Main Street East Hartford, CT 06118 (860) 565-9743 FAX: (860) 755-5845 Pratt & Whitney Proprietary U.S. Export Classification: EAR ECCN 9E991 The MicroServer is a DAL E industrial grade commercial-off-the-shelf (COTS) component that acts as the communications processor board. The MicroServer handles file transfer between: • The eFAST and the outside world via wireless interfaces (Cellular, Wi-Fi,) • The eFAST and the outside world, via a wired Ethernet connection to a user laptop for accessing the GSE Web Interface The MicroServer hosts applications for file processing and management, and hosts the mass storage device. The MicroServer uses a hardware specific version of Linux as its operating system and includes a Java Virtual Machine (JVM), allowing it to host Java-based applications. Isolation between the outside world network connection to the MicroServer and the aircraft systems network connected to eFAST Channel A and eFAST Channel B is provided by Pratt & Whitney proprietary intrusion protection software. The interfaces between the two eFAST channels and the MicroServer are managed by a DAL D process for exposing data received on the A429 interfaces to other eFAST processes.

Radio Frequency Exposure Evaluation Report FOR: Pratt & Whitney, division of UTC Model Number: HMU200-1 Product Description: Collection of aircraft engine and airframe data in flight and wireless transmission of collected data on ground FCC ID: 2AQWD-HMU200-3G IC ID: 25562-HMU2003G Per: CFR Part Part1 (1.1307 &1.1310), Part 2 (2.1091), FCC KDB 447498 D01 General RF Exposure Guidance v06 ISEDC RSS-102 Issue 5 Report number: EMC_PRATT_006_19001_FCC_ISED_MPE-R1 DATE: 2020-08-28 CETECOM Inc. 411 Dixon Landing Road  Milpitas, CA 95035  U.S.A. Phone: + 1 (408) 586 6200  Fax: + 1 (408) 586 6299  E-mail: [email protected]  http://www.cetecom.com Page 2 of 8 CETECOM Inc. is a Delaware Corporation with Corporation number: 2905571 V5.0 2015-10-27 © Copyright by CETECOM 1 Assessment This RF Exposure evaluation report provides evidence for compliance of the below identified device with the RF Exposure limits for mobile devices as defined in FCC CFR Part 1 (1.1307 &1.1310), Part 2 (2.1091) and IC standard RSS-102 issue 5 under worst case conditions (measured or rated RF output power, antenna gain, distance towards human body, multiple transmitter information as presented by the applicant). In addition, maximum antenna gain or minimum distance towards the human body is calculated respectively, where relevant. The device meets the limits as stipulated by the above given FCC and IC rule parts based on available specifications for worst case conditions at 30 cm distance to the body. Company Description Model # Pratt & Whitney, division of UTC Collection of aircraft engine and airframe data in flight and wireless transmission of collected data on ground HMU200-1 Report reviewed by: TCB Evaluator 2020-08-28 Compliance Cindy Li (Lab Manager) Date Section Name Signature Responsible for the Report: 2020-08-28 Compliance Yuchan Lu (Test Engineer) Date Section Name Signature Page 3 of 8 2 Administrative Data 2.1 Identification of the Testing Laboratory Issuing the Test Report Company Name: CETECOM Inc. Department: Compliance Street Address: 411 Dixon Landing Road City/Zip Code Milpitas, CA 95035 Country USA Telephone: +1 (408) 586 6200 Fax: +1 (408) 586 6299 Lab Manager: Cindy Li Responsible Project Leader: Cathy Palacios 2.2 Identification of the Client / Manufacturer Client’s Name: Pratt & Whitney ,division of UTC Street Address: 400 Main Street, MS 168-15 City/Zip Code East Hartford, CT 06118 Country USA 2.3 Identification of the Manufacturer Manufacturer’s Name: Collins Aerospace & Setrix Manufacturers Address: 400 Main Street, MS 168-15 City/Zip Code East Hartford, CT 06118 Country USA Page 4 of 8 3 Equipment under Assessment Model number: HMU200-1 HW Version : 3 SW Version : 1.24 Firmware Version Identification Number (FVIN): 1.24 Hardware Version Identification Number (HVIN): HMU200-1 Product Marketing Name (PMN): eFAST Regulatory Band:  Cellular Module:  GSM 850: 824.2 ~ 848.8 MHz  GSM 1900: 1850.2 ~ 1909.8 MHz  WCDMA/UMTS FDD BAND II: 1852.4 ~ 1907.6 MHz  WCDMA/UMTS FDD BAND V: 826.4 ~ 846.6 MHz  WLAN:  Nominal band: 2400 MHz – 2483.5 MHz;  Center to center: 2412 MHz (ch 1) – 2462 MHz (ch 11), 11 channels Integrated Module Info:  Cellular Module:  Module name: PH8-P  Model number: PH8-P  FCC/IC ID: QIPPH8-P / 7830A-PH8P  WLAN:  Module name: Ti-Wi BLE  FCC/IC ID: TFB-TIWI1-01 / 5969A-TIWI101 Antenna Type:  Cellular:  Antenna maximum gain:  GSM 850: 3.0 dBi  GSM 1900: 3.0 dBi  WCDMA II: 3.0 dBi  WCDMA V: 3.0 dBi  Cable loss 10ft o 1.22 dB at 1000MHz o 1.58 dB at 1600MHz o 1.86 dB at 2400MHz Page 5 of 8  WLAN:  Antenna gain: 3 dBi  Cable loss 10ft: 1.07 dB Maximum Peak Conducted Output Power:  Cellular: From modular grant [Watts]:  GSM 850: 2.588  GSM1900: 1.318  WCDMA Band II: 1.38  WCDMA Band V: 1.122  WLAN: From modular grant [Watts]: 0.093 Power Supply/ Rated Operating Voltage Range: Low 23.8VDC, Nominal 28VDC, High 32.2VDC Operating Temperature Range: Low -30⁰ C, Nominal 25⁰ C, High 70⁰ C Sample Revision: Prototype Unit; Production Unit; Pre-Production Page 6 of 8 4 RF Exposure Limits and FCC and IC Basic Rules For the specific described radio apparatus the following basic limits and rules apply for both, FCC and IC where not indicated differently. 4.1 Power Density Limits acc. to FCC 1.1310(e) / RSS-102 i5, cl. 4: FCC Frequency Range (MHz) Power density (mW/cm 2 ) Averaging time (minutes) 300 – 1500 f (MHz) /1500 30 1500 – 100000 1.0 30 IC 300 – 6000 0.02619 x f (MHz) 0.6834 6 4.2 Routine Environmental Evaluation Categorical Exclusion Limits acc. to FCC 2.109(c) / RSS-102, cl. 2.5 (rounded to 1 decimal point): FCC operating frequency < 1.5GHz: excluded if ERP < 1.5W / 31.8dBm (EIRP: 33.9 dBm); operating frequency > 1.5GHz: excluded if ERP < 3.0W / 34.8dBm (EIRP: 36.9 dBm); IC 300MHz < = operating frequency < 6 GHz: excluded if EIRP < 0.0131 x f (MHz) 0.6834 W 4.3 RF Exposure Estimation (MPE Estimation) Having available the source based average output power and peak antenna gain or the ERP/EIRP of the specified device and for a known minimum distance of its radiating structures from the body of persons according to its use cases (at least 20cm) the power density at that distance can be estimated by the following formula for plane-wave equivalent conditions (far-field conditions), when ground reflection is neglected. 2 4R PG S   where: S = power density (mW/cm 2 or W/m 2 ) P = power input to the antenna (mW or W) G = power gain of the antenna in the direction of interest relative to an isotropic radiator R = distance to the center of radiation of the antenna (cm or m) Page 7 of 8 5 Evaluations 5.1 Analysis of RF Exposure for simultaneous transmission  Evaluations are based on worst case power density limits for Canada.  Calculations are made for 30 cm.  Evaluations are based on ERP/EIRP measured or calculated from known gain and conducted output power.  Cellular can transmit simultaneously with WLAN. Radio freq [MHz] Max Peak Conducted power [W] Conducted Pow…
