2AQXM-RJ75Wireless Charging Dock

1 LED Indicator Status Solid green for 3 seconds, then off Connected to power Solid Green Charging mobile device Flashing White Metal objects detected Flashing green Incompatible AC adapter or cable connected ·Using an ultra-thick protective phone case or a case with a magnetic/iron plate is not recommended as it may affect the wireless charging function. ·Do not place any foreign objects between your mobile device and the wireless charger's surface, including metal pads on a car mount, credit cards, door keys, coins, metal, or NFC cards, as it may cause overheating. Important Safety Instructions ·Avoid dropping. ·Do not disassemble. ·Do not expose to liquids. ·This product is suitable for moderate climates only. ·The maximum ambient temperature during use of this product must not exceed 40°C ·Open flame sources, such as candles, must not be placed on this product. ·Only use a dry cloth or brush to clean this product. FCC Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential 2 installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: --Reorient or relocate the receiving antenna. --Increase the separation between the equipment and receiver. --Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. --Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance of 20 cm between the radiator & your body. Specifications Input 12V1.5A Output 5W/10W Size 207 x 147x 123mm Weight 500 g/ 384g

CONFIDENTIALITY REQUEST for Certification Service in USA Federal Communication Commission Equipment Authorization Division, Application Processing Branch 7435 Oakland Mills Road Columbia, MD 21046 Date: 2020/04/28 TO WHOM IT MAY CONCERN Pursuant to Paragraphs §0.457 and 0.459 of the Commission’s Rules (47 C.F.R.) and Section §552(b)(4) of the Freedom of Information Act, we requests confidentiality for the following products: FCC ID Model name 2AQXM-RJ75 RJ75-N090110 For the product stated above, we request that the following information be held confidential; Exhibits Long-Term Confidentiality Short-Term Confidentiality Short-Term Confidentiality Days External Photos Internal Photos Block Diagram Schematics Test Setup Photos User’s Manual Parts List Tune Up Operational Descriptions The long-term confidentiality exhibits contain our trade secrets and proprietary information that could be of benefit to our competitors. The short-term confidentiality on the basis of ensuring that business sensitive information remains confidential until the actual marketing of our new device. If you have any questions, please feel free to contact me at the address shown below. Sincerely, Name: Zhe Chen Company: Shenzhen Ruijing Industrial Co., Ltd. Address: C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Phone: +86-13537475305 Fax: +86-0755-26515068 E-Mail: [email protected]

Shenzhen Ruijing Industrial Co., Ltd. C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Tel: +86-13537475305 Fax: +86-0755-26515068 Federal Communications Commission Authorization and Evaluation Division Equipment Authorization Branch 7435 Oakland Mills Road Columbia, MD 21046 4/28/2020 To whom it may concern: We, Shenzhen Ruijing Industrial Co., Ltd. the undersigned, hereby authorize Eurofins Product Service GmbH to act on our behalf in all matters relating to applications for equipment authorization FCC ID: 2AQXM-RJ75 including the signing of all documents related to these matters. Any and all acts carried out by Eurofins Product Service GmbH on our behalf shall have the same effect as acts of our own. We also hereby certify that no party to this application is subject to a denial of benefits, including FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. 862. Sincerely, Name: Zhe Chen Company: Shenzhen Ruijing Industrial Co., Ltd. Address: C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Phone: +86-13537475305 Fax: +86-0755-26515068 E-Mail: [email protected]

Antenna

Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong TEST REPORT Report Reference No. ..................... : FCC ID. ............................................ : GTS20200413009-1-1-2 2AQXM-RJ75 Compiled by ( position+printed name+signature) .. : File administrators Jimmy Wang Supervised by ( position+printed name+signature) .. : Test Engineer Aaron Tan Approved by ( position+printed name+signature) .. : Manager Jason Hu Date of issue ..................................... : Apr. 16, 2020 Representative Laboratory Name .: Shenzhen Global Test Service Co., Ltd. Address ............................................ : No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong Applicant’s name ............................ : Shenzhen Ruijing Industrial Co., Ltd. Address ............................................ : C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Test specification ...........................: Standard ........................................... : FCC Rules and Regulations part 2.1091 KDB680106 D01v03 TRF Originator .................................. : Shenzhen Global Test Service Co.,Ltd. Master TRF ....................................... : Dated 2014-12 Shenzhen Global Test Service Co.,Ltd. All rights reserved. This publication may be reproduced in whole or in part for non-commercial purposes as long as the Shenzhen Global Test Service Co.,Ltd. is acknowledged as copyright owner and source of the material. Shenzhen Global Test Service Co.,Ltd. takes no responsibility for and will not assume liability for damages resulting from the reader's interpretation of the reproduced material due to its placement and context. Test item description .....................: Wireless Charging Dock Trade Mark ....................................... : N/A Manufacturer .................................... : Shenzhen Ruijing Industrial Co., Ltd. Model/Type reference....................... : RJ75-N090110 Listed Models .................................. : N/A Modulation Type ............................... : ASK Operation Frequency ........................ : From 110KHz~205KHz Rating ............................................... : 12.0V1.5A Result................................................ : PASS Report No.: GTS20200413009-1-1-2 Page 2 of 11 T E S T R E P O R T Test Report No. : GTS20200413009-1-1-2 Apr. 16, 2020 ____________________________________________________________________________________ Date of issue Equipment under Test : Wireless Charging Dock Model /Type : RJ75-N090110 Listed Models : N/A Applicant : Shenzhen Ruijing Industrial Co., Ltd. Address : C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Manufacturer : Shenzhen Ruijing Industrial Co., Ltd. Address : C1 Building,Hengli Industrial Park, Xiakeng 1st Road No.168,Longgang Street, Longgang District, Shenzhen, Guangdong, China Test Result: PASS The test report merely corresponds to the test sample. It is not permitted to copy extracts of these test result without the written permission of the test laboratory. Report No.: GTS20200413009-1-1-2 Page 3 of 11 Contents 1 S U M M A R Y ............................................................................ 4 1.1 General Remarks 4 1.2 Product Description 4 1.3 Equipment under Test 4 1.4 Modifications 4 2 T E S T E N V I R O N M E N T .............................................................. 5 2.1 Address of the test laboratory 5 2.2 Test Facility 5 2.3 Environmental conditions 5 2.4 Summary of measurement results 6 2.5 Statement of the measurement uncertainty 6 2.6 Equipments Used during the Test 6 3 T E S T C O N D I T I O N S A N D R E S U L T S ............................................. 7 3.1 Applicable Standard 7 3.2 Limit 7 3.3 Test Setup 7 3.4 Measurement Procedure 8 3.5 Test Result of E and H field Strength 8 3.6 Equipment Approval Considerations 9 3.7 Conclusion 10 4 T E S T S E T U P P H O T O S O F T H E E U T ......................................... 11 Report No.: GTS20200413009-1-1-2 Page 4 of 11 1 S U M M A R Y 1.1 General Remarks Date of receipt of test sample : Apr. 06, 2020 Testing commenced on : Apr. 07, 2020 Testing concluded on : Apr. 15, 2020 1.2 Product Description Product Name: Wireless Charging Dock Model/Type reference: RJ75-N090110 Power supply: DC 12V form adapter Adapter information: Model: RJ35F-W120150US Input: 100-240V~, 50/60Hz, 0.6A Output: 12.0V1.5A Wireless Charger Antenna Type Coil Antenna Antenna Gain 0dBi Operation frequency 110KHz~205KHz Modulation Type ASK 1.3 Equipment under Test Power supply system utilised Power supply voltage : ○ 230V / 50 Hz ○ 120V / 60Hz ○ 12 V DC ○ 24 V DC ● Other (specified in blank below) DC 12V from adapter Description of the test mode Operation Frequency each of channel Channel Frequency 1 130KHz Operating Mode The mode is used: Transmitting mode 1.4 Modifications No modifications were implemented to meet testing criteria. Report No.: GTS20200413009-1-1-2 Page 5 of 11 2 T E S T E N V I R O N M E N T 2.1 Address of the test laboratory Shenzhen Global Test Service Co.,Ltd. No.7-101 and 8A-104, Building 7 and 8, DCC Cultural and Creative Garden, No.98, Pingxin North Road, Shangmugu Community, Pinghu Street, Longgang District, Shenzhen, Guangdong The 3m-Semi anechoic test site fulfils CISPR 16-1-4 according to ANSI C63.4:2014 and CISPR 16-1-4:2010 SVSWR requirement for radiated emission above 1GHz. 2.2 Test Facility The test facility is recognized, certified, or accredited by the following organizations: FCC-Registration No.: 165725 Shenzhen Global Test Service Co.,Ltd EMC Laboratory has bee…
